Page 1
Style that revolves around you.
•
CEILING FAN OWNER’S MANUAL
•
• ILLUSION •
8/06
WARNING: Read and follow these instructions carefully and be mindful of all warnings shown throughout.
Page 2
GENERAL INSTALLATION & OPERATION INSTRUCTIONS
IMPORTANT SAFEGUARDS:
1. To ensure the success of the installation, be sure to read the instructions and review the diagrams thoroughly
before beginning.
2. To avoid possible electric shock, be sure electricity is turned off at the main power box before wiring. All
electrical connections must be made in accordance with local codes, ordinances and/or the National Electric Code.
If you are unfamiliar with the methods of installing electrical wiring and products, secure the services of a qualified
and licensed electrician as well as someone who can check the strength of the supportive ceiling members and make
the proper installation(s) and connections.
3. Make sure that your installation site will not allow rotating fan blades to come in contact with any object. Blades
should be at least 7 feet from floor when fan is operating.
4. If possible, mount ceiling fan on a ceiling joist - the joist must be able to support the motion and weight of the
moving fan. If the fan will be mounted on a ceiling outlet box, an approved box UL listed as “
support” is required. The box and its supporting members must be able to support the moving weight of the fan
(at least 35lbs.). The box must not be able to twist or work loose. Installation on a concrete ceiling should be
performed by qualified personnel.
suitable for fan
5. Blades should be attached after
until ready to be installed to protect its finish. If you are installing more than one ceiling fan, make sure that you
do not mix fan blade sets, as each blade is part of a weighted set.
6. After making electrical connections, spliced conductors should be tur
outlet box. The wires should be spread apart with the common conductor and the grounding conductor on one
side of the outlet box, and the “HOT” wires on the other side.
7. Electrical diagrams are for reference only. Light kits that are not packed with the fan must be UL listed and should
be installed per the light kit’
After fan is completely installed, check to make sur
8.
and/or causing damage or injury.
The fan can be made to work immediately after installation – the bearings ar
9.
that, under normal conditions, further lubrication should not be necessary for the life of the fan.
10. The fan should be turned off and allowed to stop rotating before reversing fan direction.
motor housing is hung and in place. Fan motor housing should be kept in the carton
efully up into
s installation instr
ned upward and pushed car
uctions.
e that all connections are secure to prevent fan from falling
e adequately charged with grease so
1
Page 3
IMPORTANT SAFETY PRECAUTIONS
Thank you for choosing a Regency Ceiling Fan. You have chosen the best!
Your new ceiling fan has been designed to provide many years of service and enjoyment.
Warnings:
• Disconnect power by removing fuse or turning off circuit breaker before installing the fan and/or optional
lighting. Support directly from building structure.
• To reduce the risk of fire, electric shock, or personal injury, mount to outlet box marked “
support
of lighting fixtures are not acceptable for fan support and may need to be replaced. Consult a qualified electrician if
in doubt.
• To reduce the risk of fire, electrical shock, or personal injury, only use this fan with an appropriate speed control
device designed for use with ceiling fans, if you choose a wall control.
LIGHT DIMMER. Do not use this fan with any transformer type fan speed control device
• To reduce the risk of personal injury, do not bend the blade arms when installing them, balancing the blades or
cleaning the fan. Do not insert any objects(s) between rotating fan blades.
” and use mounting screws provided with the outlet box. Most outlet boxes commonly used for the support
DO NOT USE A SIMPLE INCANDESCENT
acceptable for fan
.
NOTE: The important precautions, safeguards and instructions appearing in this manual are not meant to cover
all possible conditions and situations that may occur. It must be understood that common sense, caution and
efulness ar
car
installing, caring for, and operating the unit.
e factors which cannot be built into this product. These factors must be supplied by the person(s)
TOOLS AND MATERIALS REQUIRED
• Phillips screwdriver
• Blade screwdriver
ench or pliers
r
• W
• Wire cutter
• Stepladder
• Wiring supplies as required by
electrical code
2
Page 4
UNPACKING YOUR FAN
LIGHT
FAN/OFF
HIMEDL
OW
FOR/REV
1. Unpack your fan and check the contents. Do not discard the carton. If warranty replacement or repair is ever necessary,
the fan should be returned in original packing. Remove all parts and hardware. Do not lay motor housing on its side,
or the decorative housing may shift, be bent or damaged.
2. Examine all parts. You should have the following:
7
1
2
3
4
5
13
14
15
8
12
6
9
10
11
16
17
18
1. Hanging bracket
2. Ceiling canopy
3. Downrod/ball assembly
Decorative scr
4.
ollwork bracket
5. Rubber washer for scrollwork bracket
6. Decorative scrollwork
7. Collar cover
8. Fan housing with motor
ound motor
suppor
Save scr
ts ar
ews.)
(Remove rubber shipping
, if included on your fan.
9. Glass shade
10. Bottom cap
11. Finial
Fan blades (8)
12.
13. Bracket hardware (wood screws, washers, wire nuts)
14. Blade arm to blade screws, w/washers (16)
15. Downrod pin and cotter pin
16. Light bulbs (2)
17.
18.
Remote contr
Remote contr
ol w/holster
eceiver
ol r
3
Page 5
PREPARATION
Ceiling Fan
Outlet Box
Hanger
Bracket
Outlet Box
Screw
Flat Washer
Spring Washer
Washer Nut
Parts identification on
assembled fan
Blade
Motor
Housing
ecorative
D
crollwork
S
upport
S
Glass
Shade
Downrod
Canopy
Decorative
Scrollwork
Collar
Cover
Blade
Arm
Cap and
Finial
PREPARATION:
Verify you have all par
ts befor
from packing. To avoid damage to finish, assemble motor on soft padded surface or use the original foam inset in motor
box.
Do not lay motor housing on its side as this could result in shifting of motor in decorative enclosure.
e beginning the installation. Check foam insert closely for missing parts. Remove motor
Caution: To avoid possible electrical shock, be sure
electricity is turned off at the main power box before wiring.
All wiring must be in accordance with National and Local
Electrical Codes and the ceiling fan must be grounded as a
pr
1. Locate ceiling joist where fan is to be mounted, being
2. If not already present, mount a UL listed outlet box marked
INSTALLING THE MOUNTING BRACKET
ecaution against possible electric shock.
sure location agrees with the requirements in the mini-
mum clearance section of this guide. Wood joist must be
sound and of adequate size to support 35 lbs. (See Page
1, Items 3 and 4).
“suitable for fan support” following the instructions
provided with the outlet box. The outlet box must be
able to suppor
t a minimum of 35 pounds.
3. Attach hanger bracket to outlet box using scr
ovided with the outlet box.
ews pr
4
Page 6
INSTALLING THE FAN
Ground
Wire
Hook-up
Wires
Ball
Collar Cover
Jam Screws
Mounting Collar
Downrod
Pin
Cotter
Pin
Top of
Fan Body
Canopy
Downrod
(3)
Decorative
Scrollwork
Bracket
Rubber
Washer
Decorative
Scrollwork
ATTACH DOWNROD AND DECORATIVE SCROLLWORK:
1. Carefully support fan body (motor) in its styrofoam packing with the mounting collar (where the wires come out)
facing upward.
2. Remove ball from downrod by loosening set screw in the side of the ball. Slide ball down and remove ball pin;
remove ball.
3. Feed the wires from top of fan through end of downrod you have chosen and set end of downrod into mounting
collar so the hole in the downrod lines up with the hole in the side of the mounting collar.
4. Insert downrod pin through holes in mounting collar and downrod; slip cotter pin through small hole in end of
downrod pin to hold downrod in place.
5. Tighten jam screws against downrod using a large flat blade screwdriver to ensure a tight fit against downrod.
Tighten nuts against mounting collar.
NOTE: Fan has 6 feet of hook-up wire in case
you are using a long extension downrod. Wires
can be cut so only 8 inches or so extend beyond
the top of the downrod to make the electrical
connections easier and safer.
6. Feed wires thr
ough collar cover and slide
collar cover down the downrod to top of fan.
Attach decorative scr
7.
scr
ews pr
ovided. Insert rubber washer into
ollwork to bracket with
bracket opening from bottom and snap into
place.
8. Feed wires through decorative scrollwork
bracket. Scr
.
body
ollwork will r
9. Feed wires through canopy and slide canopy
over downr
It will be attached to ceiling later
10. Feed wires through ball and slide ball over
downr
downr
od to lay on top of collar cover
od, past hole in the top end of the
od. Inser
t ball pin (removed in step
2), slide ball up, and tighten set screw to
secure ball in place.
est on top of fan
.
.
5
Page 7
INSTALLING THE FAN
Ball
Ball slot
Hanger
bracket tab
Receiver
Antenna
B
L
U
E
B
L
U
E
W
H
I
T
E
W
H
I
T
E
B
L
A
C
K
B
L
A
C
K
G
R
E
E
N
G
R
O
U
N
D
B
L
A
C
K
H
O
T
C
A
R
R
IE
R
(
B
L
A
C
K
)
W
H
I
T
E
C
O
M
M
O
N
(
W
H
I
T
E
)
HANG THE FAN
WARNING: To avoid damaging the blade arms and blades, do not
nstall them onto fan until fan is fastened to ceiling.
i
1. Lift ball/downrod/fan into hanger bracket opening. NOTE: The
tab opposite hanger bracket opening should fit in slot on ball.
2. Make wire connections, (refer below to “Electrical Connections”).
3. Slide canopy up and fasten to hanger bracket with 2 screws provided.
ELECTRICAL CONNECTIONS
Three wires ar
e connected to the fan (plus the gr
ound wire).
Black - the “hot” power to run fan.
White - the “common” power to run fan and light,
also refer
red to as “AC neutral”.
Blue - the “hot” power for upper light.
Green - ground wire.
Five wires are connected to the remote control receiver. Three
will connect to the thr
color to color) and the r
ee wires coming out of the fan (matching
emaining black wire and white wire will
connect to the building AC circuit.
BE SURE ELECTRICITY IS TURNED OFF AT THE MAIN
POWER BOX BEFORE WIRING.
Connect five power wir
Connect green ground wire to building ground wire circuit.
es as shown, using wire nuts provided.
Extend antenna wire inside canopy, but do not attach to any
s electrical ceiling box is contr
olled by a wall switch, the wall switch must r
ned back ON to allow use of r
emote contr
emain ON for
ol.
other wire.
NOTE: If power to the fan’
the radio remote control to operate. Turning the wall switch OFF will turn off all fan/light functions and resets the
receiver back to default mode. The wall switch will need to be tur
* Restore power by replacing fuse or resetting circuit breaker ONLY AFTER ALL INSTALLATION AND ELECTRICAL
WORK IS COMPLETED AND DOUBLE-CHECKED.
6
Page 8
REMOTE CONTROL
1
234
1 2 3 4
ON
Code
Switches
TRANSMITTER
ON ECE
Code
Switches
RECEIVER
1 2 3 4
ON
1
2
3
4
ON DIP
Antenna
Hanger
bracket
Ball
Receiver
GENERAL INFORMATION
Multiple code choices are included with your fan’s remote control in case:
• you have more than one remote control fan and want them to respond only to their own remote control
• you have other radio controlled devices in your home that may interfere with the fan remote control (i.e. garage
door opener)
• you experience radio interference on a chosen frequency (code setting)
SET-UP AND OPERATING INSTRUCTIONS
Setting the code:
This unit has 16 different code combinations. To set the code, perform these steps:
1. Setting the code on the TRANSMITTER [Fig. 1]:
a. Remove battery cover.
Slide code switches to your choice of ON or OFF position. Use a small scr
b.
each switch firmly up or down.
c. Install 9v battery (not included).
d. Replace battery cover on transmitter
.
2. Setting the code on the RECEIVER [Fig. 2]:
a. Locate the code switches on the bottom of the remote receiver.
Slide code switches to the SAME POSITIONS as set on your transmitter
b.
ewdriver or ball point pen to slide
.
After codes are set, install the receiver
in the space above the ball in the
hanger bracket [Fig. 3]. Be careful not
to pinch any of the receiver’s wires.
Fig. 1
Fig. 2
Fig. 3
7
Page 9
BLADE ATTACHMENT
Blade Arm (already attached to fan motor)
Install gasket between
blade arm and blade
(optional)
Blade
Screw
Fiber
Washer
BLADE ATTACHMENT:
1. Place fiber washer on screw. Insert this assembly through the blade and start the screw into the blade arm. Repeat
this procedure without tightening the screw until all 2 screws have been started into the blade arm.
2. Tighten each screw.
3 Fasten blade assembly to motor with provided screws and metal lockwashers. Repeat procedure for remaining
blades. Make sure screws are TIGHT! Loose motor screws can contribute to unnecessary hum during operation.
NOTE: Cordless power screwdrivers are NOT recommended, as they tend to strip the heads of the screws and usually will
not fully compress the lock washers on the motor screws. Use a large flat blade screwdriver for final tightening to fully compress the washers. This will help ensure proper alignment of the blades and noise-free, wobble-free running.
NOTE: Design of parts shown above may look slightly different for your specific model of fan.
8
Page 10
Bottom glass
Finial
Cap
Candelabra base bulb (x2)
(40w maximum)
Light socket (x2)
Threaded rod
COMPLETING THE INSTALLATION
1. Install 2 candelabra base bulbs (E12, 40 watt maximum) into sockets on light kit fitter. Be careful wires do not lay against
bulbs.
2. Lift bottom glass up to fitter so that fitter’s threaded rod passes through hole in bottom glass. Place cap and finial
over end of threaded rod and screw finial securely by hand to hold glass in place.
CONGRATULATIONS! Your fan is now ready to enjoy!
9
Page 11
OPERATION
Forward/Reverse Direction:
Forward is a counterclockwise rotation of the blades
when viewed from beneath the fan. This will create a
downward breeze that can be felt below the fan. This
is the normal direction for the fan to run when the
weather is warm.
Reverse (clockwise) will draw air up through the blades
and towards the ceiling, down the walls, and into the
living space during the cooler months.
WARM MONTHS
Forward (counterclockwise)
COOL MONTHS
Reverse (clockwise)
TROUBLESHOOTING - IN CASE OF DIFFICULTY
IMPORTANT: To prevent damage or cause injury, be sure that fan is switched to off and blades have stopped moving
completely before attempting to change direction of rotation.
1. If fan will not start: Check main and branch circuit breakers and/or fuses. Check line wire connections to fan and switch
housing wiring. Make sure forward/reverse switch is set to one or the other position, not stuck in between.
2. If fan is noisy: Check and make sure that all screws in motor housing are snug (but not over tight). Check that the screws
securing blade brackets to the motor are tight. Check that wire connectors in switch housing are not rattling against each
other or the interior wall of the switch housing. Check that all glassware is finger tight and that bulb(s) are well held in the
sockets, if a light kit is used. Check that the canopy is firmly attached to hanging bracket and not vibrating against ceiling.
If fan wobbles: Check that all blades are firmly screwed into blade arms. Check that all blade arms are firmly secured to the
3.
motor. Make sure that the light kit (if present) is firmly attached to switch housing and that all glassware and shades are fastened properly. Wobble can also result from even the smallest deviations in distance from blade tip to blade tip - if measurements from blade tip to blade tip are not equal, loosen screws connecting blade to bracket one at a time and adjust blade(s)
so that distances are equal. Interchanging adjacent blades may redistribute mass and result in smoother operation. Blade arms
can be bent slightly to restore same pitch to all blades if a blade is different than the other blades when viewed edge on.
10
Page 12
CARE AND CLEANING
Periodic cleaning of your new ceiling fan is about the only maintenance that is needed. Only use a soft brush or lint free
cloth to avoid scratching the finish. DO NOT use water when cleaning your ceiling fan. It could damage the motor or the
wood blades and/or create the possibility of electrical shock.
Periodically it may be necessary to re-tighten blade to blade arm screws or blade arm to motor screws to prevent
clicking or humming sound during operation. This is especially true in climates with broad temperature and
humidity ranges and in fans with painted or high gloss blades.
When dusting the blades, you must support the blade to prevent bending – no pressure should be applied to the blades.
THANK YOU FOR PURCHASING A REGENCY CEILING FAN.
Write to us at:
Regency Ceiling Fans
P.O. Box 730
Fenton, MO 63026
For additional troubleshooting tips,
visit us on the Web at: www.regencyfan.com
8/06 Regency Ceiling Fans
Loading...
