USER MANUAL

BLUETOOTH OUTDOOR SPEAKER

Model No.: OS01BT

Read the operating instructions carefully before the initial start-up and keep the

instructions for future reference.

The device must be fully charged before first use.

2

SAFTY INSTRUCTIONS

The exclamation mark in the triangle draws the user's attention
to important operating and maintenance instructions (service) in
this manual that must be followed.

The lightning symbol in the triangle indicates to the user
"dangerous voltages" on some components inside the device.

To avoid the risk of electric shock, do not open the housing
under any circumstances. There are no user-serviceable parts
inside. Repairs may only be carried out by an authorized
specialist workshop.

This device is designed for DC 5V mains voltage. After
charging, disconnect the USB cable from the micro USB
socket.

Do not expose the device to moisture or rain.

Set up the device so that an undisturbed fresh air supply is
always ensured. Never place the device on carpets or near
curtains and do not install it on bookshelves.

Do not expose the device to direct sunlight
Heat sources.

READ ALL INSTRUCTIONS BEFORE USE
Always use basic safety precautions when using this
Bluetooth speaker system with a microphone, especially
when there are children around.

3

SAFETY INSTRUCTIONS

1) Read these operating instructions carefully before using the device for the first

time.

2) Keep these operating instructions in a safe place for future reference.

3) The device must not be exposed to dripping or splashing water and no objects

filled with liquids, such as vases, should be placed on the device. Use only in
dry regions.

4) Do not place open flames such as candles on the device and keep the device
away from open flames.

5) Children should be supervised to ensure that they do not play with the device.

6) Make sure that the device for charging the integrated battery is connected to a

DC 5V power supply. If higher voltage is used, the device may malfunction.

7) Only use accessories and spare parts that are approved by the manufacturer.

8) Install the device according to the manufacturer's instructions.

9) Only install the device in sufficiently ventilated surroundings. Place the device

on a flat and stable surface.

10) Do not expose to temperatures above 35 ° C. At the installation site make sure
that 30 cm to the rear and the top of the device and 5 cm from each side are
observed.

11) Dispose of used batteries / rechargeable batteries in an environmentally
friendly manner.

12) Always make sure that the device is pulled out of the socket before transport or
cleaning. Only clean it with a dry cloth.

13) Disconnect the device from the mains during a thunderstorm or when the
device is not used for a long period of time.

14) This device has no user-serviceable parts. Do not try to repair this device
yourself. Only qualified service personnel may carry out maintenance. In the
event of a defect, complain about the device to your dealer.

15) Never leave the device unattended and take care that nothing is pushed
through holes, slots or any other openings in the device housing. This can
result in a fatal electric shock.

16) Do not place the device near TV sets, loudspeakers and other objects that
generate strong magnetic fields.

4

DESCRIPTION OF THE CONTROL ELEMENTS

Front view

1. Control panel

2. Handle

3. Phone stand

4. Speaker (lights up blue to the beat of the music)
