Reflecta x10-Scan User Manual

N E W S

reflecta gmbh

Technical details are subject to ch

ange without prior notice

reflecta

x10-Scan

With the reflecta x10-Scan slides and negatives can be
digitized in no time.

The 14-megapixel CMOS sensor ensures the highest
image quality and enables short scan times of less than
two seconds.

The scanner comes with an 8.9 cm large LCD monitor
and thus allows a comfortable viewing and selecting of
the scanned images.

The images are saved as JPEG files directly on an SD
card. A TV-Cable (included) also allows playback on
televisions.

This makes the reflecta x10-Scan as a stand-alone device

completely independent of computers and software.

Product Information

•

Image Sensor:

1/2.33" - 14 Mega-Pixel CMOS-Sensor

• Scanned Resolution:

4416 x 2944 Pixel

• Display:
3,5“ (8,9 cm) LCD

• Brightness and Color Correction:

automatic/manual via button

• Film Type:

Negative, Positives, B/W as strip (35mm) or
slide (5x5cm); optional 110/126

• External Memory:

SD/SDHC-Memory cards up to 32 GB

• Power Supply:

Power Adapter 5V /1A

• Interface for Data Transfer

USB 2.0

• Compatibility:

The JPEG-Format is compatible to all digital
Playback formats

Delivery Content

- Scanner

- Power Supply

- TV-Out Cable

- Film Holder for Negatives strips up to 6

exposures

- Slide Holder for 3 framed slides up to 3.2mm

thick

- Cleaning Brush

- CD with Manuals

Art.-No.: 64500
EAN Code: 4005039645006

Merkurstraße 8

D-72184 Eutingen / Germany

Phone: [phone]

Fax: [phone]

e-mail:

[e-mail]

http: www.reflecta.de
