Reef Octopus Space Saving Bio pellets Reactor：：BR 1000SS
Instrucon：
Reef Octopus Space Saving Bio-pellets Reactor uses the design that Subvert the tradional, making it works on
a crazy effect. It just uses a pump that has only 1000L per hour water flow driving as much as 1500ml
Bio-pellets. It is enrely due to its boom direct injecon water flow style.
To prevent pellets get into the pump, our engineer
invented a Umbrella-shaped device, it only has 1.5mm gap,
matched with the bowl-shaped boom, make bio-pellets
been totally srred but can’t get into the reactor’s boom.
The cover of it is an easy removable design, could turn the
outlet at four direcons. There also have a Sieve plate
screwed on the cover to prevent pellets flowed out of the
chamber.
Installaon：
1. There should have 4 lile packages in the box, the main
chamber, the outlet part , the pump and water inlet valve.
2. Fix the outlet onto the cover.
3. Open the pump box, install the pump directly into the
boom. As the picture shows
4. Added enough medias to the chamber.
5. Connect the pump to power.
How to Adding Medias.
1.Make sure the Umbrella-shaped devices is already
Installed
on the boom before you added media, it will
prevent the medias get into the pump.
2. Loose the screws that fixed the cover, remove the
cover, added medias in.
3. Be sure the O-ring is in the O-ring groove on the top
of the chamber. Put the cover on and ghten the screws
Safety：
1. Please use the pump under marked voltage;
2. Don’t added medias which diam is less than 2mm;
3. Never take maintains of the devices when it is running.
4. Keep enough water level, prevent the pump working without water.
njeco
n
r
ellets
dth
ethethe
in
inlet valve.
y
y
,
i
ll
e
;
Reef Octopus Space Saving Bio pellets Reactor：：BR 2000SS
Instrucon：
Reef Octopus Space Saving Bio-pellets Reactor uses the design that Subvert the tradional, making it works on
a crazy effect. It just uses a pump that has only 2000L per hour water flow driving as much as 2000ml
Bio-pellets. It is enrely due to its boom direct injecon water flow style.
To prevent pellets get into the pump, our engineer
invented a Umbrella-shaped device, it only has 1.5mm gap,
matched with the bowl-shaped boom, make bio-pellets
been totally srred but can’t get into the reactor’s
boom.
The cover of it is an easy removable design, could turn the
outlet at two direcons. There also have a Sieve plate
screwed on the cover to prevent pellets flowed out of the
chamber.
Installaon：
1. There should have 4 lile packages in the box, the main
chamber, the outlet part, the pump and water inlet valve.
2. Fix the outlet onto the cover.
3. Open the pump box, install the pump directly into the
boom. As the picture shows
4. Added enough medias to the chamber.
5. Connect the pump to power.
How to Adding Medias.
1.Make sure the Umbrella-shaped devices is already
Installed
on the boom before you added media, it will
prevent the medias get into the pump.
2. Loose the screws that fixed the cover, remove the cover,
added medias in.
3. Be sure the O-ring is in the O-ring groove on the top of
the chamber. Put the cover on and ghten the screws
Safety：
1. Please use the pump under marked voltage;
2. Don’t added medias which diam is less than 2mm;
3. Never take maintains of the devices when it is running.
4. Keep enough water level, prevent the pump working without water.
i
njeconw
a
engineer
s
5
m
ioellets
t
he
t
he
ethe
x,t
h
e
er inlet valve.
t
h
e
ea
ia,
i
ll
t
he
v
t
he
t
e
;
ss
running.
orking without
ater.
Reef Octopus Space Saving Bio pellets Reactor：：BR 3000SS
Instrucon：
Reef Octopus Space Saving Bio-pellets Reactor uses the design that Subvert the tradional, making it works on
a crazy effect. It just uses a pump that has only 3000L per hour water flow driving as much as 2500ml
Bio-pellets. It is enrely due to its boom direct injecon water flow style.
To prevent pellets get into the pump, our engineer
invented a Umbrella-shaped device, it only has 1.5mm
gap, matched with the bowl-shaped boom, make
bio-pellets been totally srred but can’t get into the
reactor’s boom.
The cover of it is an easy removable design, could turn
the outlet at four direcons. There also have a Sieve
plate screwed on the cover to prevent pellets flowed
out of the chamber.
Installaon：
1. There should have 4 lile packages in the box, the
main chamber, the outlet part and water inlet valve.
2. Fix the outlet onto the cover.
3. Open the pump box, install the pump directly into the
boom. As the picture shows
4. Added enough medias to the chamber.
5. Connect the pump to power.
How to Adding Medias.
1.Make sure the Umbrella-shaped devices is already
Installed
on the boom before you added media, it will
prevent the medias get into the pump.
2. Loose the screws that fixed the cover, remove the
cover, added medias in.
3. Be sure the O-ring is in the O-ring groove on the top
of the chamber. Put the cover on and ghten the screws
Safety：
1. Please use the pump under marked voltage;
2. Don’t added medias which diam is less than 2mm;
3. Never take maintains of the devices when it is running.
4. Keep enough water level, prevent the pump working without water.
onw
a
t
he
r
n
e
e
t
he
i
ll
WARRANTY：：
Reef Octopus skimmers have the 1 year warranty on craftsmanship, one year on the water pump from
the date of the retail purchase by the original end-user.
We are responsible for the products as long as it’s been installed and used properly. Consumable
spare parts are not applicable to the warranty.
Reef Octopus cannot be held liable for damages to personal property due to misuse or improper care
and maintenance of the skimmer.
Reef Octopus warranty does not, under any circumstance; cover the replacement or cost of any
electronic device or personal property.
Descripon of it’s special Components：
Sieve plate Umbrella-shaped device at the boom
Been fixed by a screw Keep the screws at the right posion
HONYA CO., LTD
Add:#68 Jiao Yu Bei Lu, Bai Shi Tang Cun, Long Gang Ping Di Zhen, Shenzhen, China
www.reefoctopus.com
