Compact Multimeter
with NCV

Instruction
Manual

www.REEDInstruments.com

www.GlobalTestSupply.com

Table of Contents

Introduction ................................................................................................ 3

Product Quality ........................................................................................... 3

Safety ......................................................................................................3-4

Safety Symbols ...................................................................................... 4

Features ...................................................................................................... 4

Included ...................................................................................................... 4

Specications .......................................................................................... 4-6

Instrument Description ............................................................................... 6

Display Description .................................................................................... 7

Operating Instructions ........................................................................... 7-11

DC Voltage Measurement ...................................................................... 7

AC Voltage Measurement ...................................................................... 7

DC Current Measurement ...................................................................... 8

AC Current Measurement ...................................................................... 8

Resistance Measurement ....................................................................... 9

Capacitance Measurement .................................................................... 9

Frequency Measurement ....................................................................... 9

Diode Measurement ............................................................................. 10

Continuity Measurement ...................................................................... 10

Non-Contact AC Voltage Measurements ............................................. 10

Data Hold ............................................................................................. 11

Auto Power Off .................................................................................... 11

Backlight .............................................................................................. 11

Battery Replacement ................................................................................ 11

Applications .............................................................................................. 11

Product Care ............................................................................................ 12

Product Warranty ..................................................................................... 12

Product Disposal and Recycling .............................................................. 12

Product Support ....................................................................................... 13

www.GlobalTestSupply.com

Introduction

Thank you for purchasing your REED R5099 Compact Multimeter with
NCV. Please read the following instructions carefully before using your
instrument. By following the steps outlined in this manual your meter will
provide years of reliable service.

Product Quality

This product has been manufactured in an ISO9001 facility and has been
calibrated during the manufacturing process to meet the stated product
specications. If a certicate of calibration is required please contact the
nearest authorized REED distributor or authorized Service Center. Please
note an additional fee for this service will apply.

Safety

• Never attempt to repair or modify your instrument. Dismantling your
product, other than for the purpose of replacing batteries, may cause
damage that will not be covered under the manufacturer's warranty.

• Servicing should only be provided by an authorized service center.

• Do not use the meter or test leads if they look damaged.

• Do not use the meter around explosive gas, vapor, or in damp or
wet environments.

• Do not switch the function dial while taking a measurement.

• Use the meter only as specied in this manual; otherwise, the protection
provided by the meter may be impaired.

• Use caution when working near voltages above 60V DC or 30V ACrms,
as such voltages pose a shock hazard.

• Use extreme caution when working with high voltages.

• Always discharge lter capacitors in power supplies and disconnect the
power when making resistance, continuity or diode tests.

• Always turn off the power before opening the cover to replace the batteries.

• Never operate the meter unless the battery cover is in place and
fastened securely.

www.GlobalTestSupply.com

continued...

Safety Symbols

Refer to this manual before using the meter.

Dangerous voltages.

Meter is protected throughout by double insulation or
reinforced insulation.

Features

• Measures AC/DC voltage and current, resistance, capacitance,
frequency, diode and continuity

• Built-in non-contact voltage detector and double molded plastic housing

• 4,000-count backlit LCD display

• Low battery indicator and auto shut-off

• CAT III 600V safety rating

Included

• Test Leads

• Batteries

Specifications

AC/DC Voltage

Range: AC: 4, 40, 400, 600V
DC: 400mV, 4, 40, 400, 600V
Accuracy: AC: 4, 40V ±(1.2% rdg. + 5 dgt.)
400, 600V ±(2% rdg.+ 10 dgt.)
DC: 400mV ±(1% rdg.+ 8 dgt.)
4, 40V ±(0.5% rdg.+ 5 dgt.)

400, 600V ±(0.8% rdg.+ 5 dgt.)
Resolution: AC: 0.01, 0.01, 0.1, 1V
DC: 0.1mV, 0.001, 0.01, 0.1, 1V

continued...

www.GlobalTestSupply.com

AC/DC Current

Range: 400µA, 4, 40, 400mA
Accuracy: AC: 400µA, 4, 40, 400mA ±(2% rdg. + 8 dgt.)
DC: 400µA, 4, 40, 400mA ±(1.8% rdg. + 5 dgt.)
Resolution: 0.1µA, 0.001, 0.01, 0.1mA

Resistance

Range: 400Ω, 4, 40, 400kΩ, 4, 40MΩ
Accuracy: 400Ω, 4, 40, 400kΩ: ±(1% rdg. + 5 dgt.)
4MΩ: ±(1.2% rdg. + 10 dgt.)
40MΩ: ±(2% rdg. + 10 dgt.)
Resolution 0.1, 1, 10, 100Ω, 1, 10kΩ

Capacitance

Range: 50, 500nF, 5, 50, 100μF
Accuracy: 50nF: ±(4% rdg.+ 30 dgt.)
500nF: ±(3% rdg. + 15 dgt.)
5, 50, 100μF: ±(4% rdg. + 10 dgt.)
Resolution: 0.01, 0.1, 1, 10, 100nF

Frequency

Range: 9.999Hz to 60kHz
Accuracy: ±(0.1% rdg. + 5 dgt.)
Resolution: 0.001Hz to 0.001Mz

General Specifications

Range Selection: Autoranging
Display: 4,000 count LCD display
Display Hold: Yes
Diode Test: Yes
Continuity Check: Audible signal if resistance ≤10Ω
Non-Contact

Voltage Detector: Yes
Auto Power Off: Yes (after 30 minutes)

www.GlobalTestSupply.com

continued...

Power Supply: 2 x AAA

Low Battery Indicator: Yes

Fuse Protection: Yes

Replaceable Test Leads: No

Overange Indicator: Yes (OL)

Overvoltage Category: CAT III 600V

Product Certications: CE

Operating Temperature: 32 to 104°F (0 to 40°C)

Storage Temperature: 14 to 122°F (-10 to 50°C)

Dimensions: 4.4 x 2.3 x 1.4" (112 x 58 x 35mm)

Weight: 6.3oz (180g)

Instrument Description

1

2

3

4

AUTO

AC

DC

H

Compact Multimeter

SELECT

NCV

nm FVA Mk

HOLD

R5099

Hz %

Ω

6

Hz %

7

8

5

FUSED

MAX 400mA/600V

CAT III 600V

1. NCV LED Indicator

2. LCD Display

3. HOLD/Backlight Button

4. SELECT Button

5. Function Dial

www.GlobalTestSupply.com

9

6. Hz/% Button

7. Test Leads

8. Test Leads Holder

9. Battery Cover

Display Description

6

1

AUTO

nm F VA Mk

Hz %

Ω

2

AC

3

4

1. Auto Range Indicator

2. Low Battery Indicator

3. AC/DC Indicators

DC

H

4. Data Hold Indicator

5. 4000 Count Display

6. Units of measurement

Operating Instructions

DC Voltage Measurement

1. Set the function dial to the position.

2. Press the SELECT button to indicate "DC" on

the LCD display.

3. Measure the voltage by touching the test

probe tips to the load in parallel.

4. Note the measured value.

AC Voltage Measurement

1. Set the function dial to the position.

2. Press the SELECT button to indicate "AC" on

the LCD display.

3. Measure the voltage by touching the test probe

tips to the load in parallel.

4. Note the measured value.

AUTO

AC

DC

H

SELECT

AUTO

AC

DC

H

SELECT

NCV

nmFVA Mk

Compact Multimeter

HOLD

NCV

nmFVA Mk

Compact Multimeter

HOLD

5

R5099

Hz %

Ω

Hz %

R5099

Hz %

Ω

Hz %

continued...

www.GlobalTestSupply.com

DC Current Measurement

Compact Multimeter

NCV

R5099

AUTO

nmFVA Mk

AC

DC

Hz %

Ω

H

SELECT

HOLD

Hz %

1. Set the function dial to the or position.

2. Press the SELECT button to indicate "DC" on

the LCD display.

3. Remove power from the circuit under test, then

open up the circuit at the point where you wish to
measure the current.

4. Touch the black test probe tip to the negative side

of the circuit. Touch the red test probe tip to the
positive side of the circuit.

5. Apply power to the circuit.

6. Note the measured value.

AUTO

AC

DC

H

Compact Multimeter

SELECT

NCV

R5099

nmFVA Mk

Hz %

Ω

HOLD

Hz %

AC Current Measurement

1. Set the function dial to the or position.

2. Press the SELECT button to indicate "AC" on

the LCD display.

3. Remove power from the circuit under test, then

open up the circuit at the point where you wish to
measure the current.

4. Touch the black test probe tip to the negative side

of the circuit. Touch the red test probe tip to the
positive side of the circuit.

5. Apply power to the circuit.

6. Note the measured value.

Resistance Measurement

1. Set the function dial to the position.

2. Press the SELECT button to select resistance

as indicated by on the LCD display.

3. Measure the resistance by touching the test

probe tips to the load in parallel.

4. Note the measured value.

www.GlobalTestSupply.com

AUTO

AC

DC

H

SELECT

AUTO

AC

DC

H

SELECT

NCV

nmFVA Mk

Compact Multimeter

HOLD

NCV

nmFVA Mk

Compact Multimeter

HOLD

R5099

Hz %

Ω

Hz %

R5099

Hz %

Ω

Hz %

continued...

Capacitance Measurement

1. Set the function dial to the position.

2. Press the SELECT button to select capacitance

as indicated by "nF" on the LCD display.

3. Measure the capacitance by touching the test

probe tips to the load in parallel.

4. Note the measured value.

AUTO

AC

DC

H

SELECT

nmFVA Mk

Compact Multimeter

NCV

R5099

Hz %

Ω

HOLD

Hz %

Frequency Measurement

1. Set the function dial to the position.

2. Press the HZ button to select frequency as

indicated by "Hz" on the LCD display.

3. Measure the frequency by touching the test

probe tips to the load.

4. Note the measured value.

Diode Measurement

1. Set the function dial to the position.

2. Press the SELECT button to select diode as

indicated by on the LCD display.

3. Measure the frequency by touching the test

probe tips to the load in parallel.

4. Note the measured value.

Forward voltage will indicate 0.5V to 0.8V. Reverse voltage

will indicate “OL”. Shorted devices will indicate near 0mV

and an open device will indicate “OL” in both polarities.

www.GlobalTestSupply.com

AUTO

AC

DC

H

SELECT

AUTO

AC

DC

H

SELECT

NCV

nmFVA Mk

Compact Multimeter

HOLD

NCV

nmFVA Mk

Compact Multimeter

HOLD

R5099

Hz %

Ω

Hz %

R5099

Hz %

Ω

Hz %

continued...

Continuity Measurement

1. Set the function dial to the position.

2. Press the SELECT button to select continuity

AUTO

AC

DC

H

Compact Multimeter

SELECT

NCV

R5099

nmFVA Mk

Hz %

Ω

HOLD

Hz %

as indicated by on the LCD display.

3. Measure the continuity by touching the

test probe tips to the load in parallel.

4. Note the measured value.

If the measured resistance is >1000Ω, circuit is open. If the

measured resistance ≤10Ω, the audible buzzer will sound.

Non-Contact AC Voltage Measurements

WARNING: Risk of electrocution. Before use, always test the

Voltage Detector on a known live circuit to verify proper operation.

1.

Set the function dial to any position.

2. Place the tip of the meter to the hot

conductor or on the hot side of the
electrical outlet.

3. If AC voltage is present, the detector light

will illuminate.

NOTE: The conductors in electrical cord sets are
often twisted. For best results, rub the meter tip
along the length of the cord to assure placing
the tip in close proximity to the live conductor.
NOTE 2: The detector is designed with high sensitivity. Static
electricity or other sources of energy may randomly trip the sensor. This
is normal operation.

R5099

NCV

Hz %

Compact Multimeter

HOLD

SELECT

www.GlobalTestSupply.com

continued...

Data Hold

1. While taking a measurement, press the HOLD button to freeze the

current reading on the LCD display.

2. While in this mode an "H" symbol will appear.

3. Press the HOLD button again to resume normal operation.

Auto Power Off

To preserve battery life, the meter is programmed to turn itself off after 30
minutes of inactivity. Press any button to delay the auto power off function
and resume normal operation.

Backlight

To turn the backlight on or off, press and hold the BACKLIGHT button for
2 seconds.

Battery Replacement

When the low battery icon
appears on the LCD, the batteries
must be replaced.

1.

Use a small Phillips head screwdriver
to remove the battery cover located
on the back of the meter.

2. Replace the 2 x "AAA" batteries.

3. Secure the battery cover back and

tighten the screw.

Applications

• Testing batteries

• Testing household wiring

• Testing electric motors

• Testing power supplies

www.GlobalTestSupply.com

Product Care

To keep your instrument in good working order we recommend the following:

• Store your product in a clean, dry place.

• Change the battery as needed.

• If your instrument isn't being used for a period of one month or longer
please remove the battery.

• Clean your product and accessories with biodegradable cleaner. Do not
spray the cleaner directly on the instrument. Use on external parts only.

Product Warranty

REED Instruments guarantees this instrument to be free of defects in
material or workmanship for a period of one (1) year from date of shipment.
During the warranty period, REED Instruments will repair or replace, at no
charge, products or parts of a product that proves to be defective because
of improper material or workmanship, under normal use and maintenance.
REED Instruments total liability is limited to repair or replacement of the
product. REED Instruments shall not be liable for damages to goods,
property, or persons due to improper use or through attempts to utilize
the instrument under conditions which exceed the designed capabilities.
In order to begin the warranty service process, please contact us by email
at 1-877-849-2127 or [e-mail] to discuss the claim and
determine the appropriate steps to process the warranty.

Product Disposal and Recycling

Please follow local laws and regulations when disposing or recycling your
instrument. Your product contains electronic components and must be
disposed of separately from standard waste products.

www.GlobalTestSupply.com

Product Support

If you have any questions on your product, please contact your authorized
REED distributor or REED Instruments Customer Service by phone at
1-877-849-2127 or by email at [e-mail].

Please visit www.REEDINSTRUMENTS.com for the most

up-to-date manuals, datasheets, product guides and software.

Product specifications subject to change without notice.
All rights reserved. Any unauthorized copying or reproduction of
this manual is strictly prohibited without prior written permission
from REED Instruments.

www.GlobalTestSupply.com

TEST & MEASURE

WITH CONFIDENCE

CHECK OUT OUR LATEST PRODUCTS!

www.REEDINSTRUMENTS.com

www.GlobalTestSupply.com
