Red-M Blade
Bluetooth Clip-on for Palm Vx
User Guide
980-959-03
2
Red-M Blade - Bluetooth Clip-on for Palm Vx Getting Started Guide
Table of contents
Introduction..............................................................................5
About the Red-M Blade ................................................................5
Getting started ...........................................................................6
Red-M Blade overview...............................................................7
Bluetooth services .......................................................................7
Additions to Palm Vx menus .........................................................7
Managing Bluetooth devices ..........................................................8
Palm network service settings .......................................................9
Installing the Red-M Blade software .......................................11
Before you begin .......................................................................11
To install the Red-M Blade software .............................................11
Additional software on the Red-M Blade CD .................................. 11
Attaching the Red-M Blade ......................................................12
Detaching the Red-M Blade .....................................................13
Configuring a connection to the Internet via a mobile phone ..14
Before you begin .......................................................................14
To configure your Palm Vx to connect to a mobile phone ................ 19
Configuring a Bluetooth-enabled LAN connection....................21
Before you begin .......................................................................21
To configure your Palm Vx to connect to LAN Access infrastructure ..21
Configuring Bluetooth Ho tSync operations..............................23
Configuring a HotSync operation with a computer ..........................23
Configuring a HotSync operation via a Bluetooth-enabled LAN ......... 25
Configuring a remote HotSync operation via a mobile phone ...........27
Technical support and contact information..............................30
Regulatory information ...........................................................31
Europe (EEA) ............................................................................ 31
North America .......................................................................... 31
Power supply information ...........................................................32
Red-M User License and Limited Warranty Agreement ............35
3
4
Red-M Blade - Bluetooth Clip-on for Palm Vx User Guide
Introduction
About the Red-M Blade
The Red-M Blade is a simple and innovative accessory that adds
a new level of flexibility to your Palm
TM
Vx handheld. Whether
you are in the office or on t he road you can enjoy hass le-free,
wireless connection to personal, corporate and public data.
TM
With a Red-M Blade and a Bluetooth
enabled mobile phone,
you can access the Internet, and send and receive email. The
connection is cable- free and there is no longer any need to
carefully line up your P alm Vx handheld with your mobil e phone
or PC to achieve a line-of-sight, infrared connection.
You can perform a wireless HotSync
®
operation to your laptop
via your Red-M Blade instead of the usual Palm cradle. When
away from the office, you can perform a remote HotSync
operation via your mobile phone. The Red-M Blade also enables
you to interact with other Bluetooth-enabled Palm Vx handhelds.
If your office has Bluetooth infrastructure installed, you can use
your Palm Vx with the Red-M Blade attached in meeting rooms
and other Bluetooth enabled areas to maintain connection to the
corporate intranet o r Internet, to send and receive emai ls, and to
update your calendar.
5
Getting started
To use your Red-M Blade, do the foll owing:
1. Install the software
For instructions on ho w to install Red-M Blade so ftware on
your Palm Vx, see Installing the Red-M Blade software on
page 11.
2. Attach the Red-M Blade
For instructions on how to attach the Red-M Blade, see
Attaching the Red-M Blade on page 12.
3. Configure your Palm Vx for Bluetooth services
Configure the software to connect with any or all of the
following Bluetooth-enab le d devices:
• a mobile phone for access to the Internet or to perform
remote HotSync operations with your computer via your
corporate network (where you have a remote access
dial-up facility). For instructions, see Configuring a
connection to the Internet vi a a mobile phone on page
14 and Configuring a remote HotSync operation via a
mobile phone on page 27.
• a laptop computer or PC to perform HotSync o perations.
For instructions, see Configuring a HotSync operation
with a computer on page 23.
• an Access Point on your local area network (LAN) for
connection to LAN intranet and Internet services and to
perform HotSync operations with a designated comp uter.
For instructions, see Configuring a Bluetooth-enabled
LAN connection on page 21 and Configuring a HotSync
operation via a Bluetooth-enabled LAN on page 25.
• another Bluetooth enabled Palm Vx handheld for playing
games. There are games and associated documentation
included on the Red-M CD.
6
Red-M Blade - Bluetooth Clip-on for Palm Vx User Guide
Red-M Blade overview
This section lists the Bluetooth services provided by the Red-M
Blade. It describes the additional options and menu items that
you will find on your Palm Vx handheld following installati on of
the Red-M Blade software. It also explains how to use device
categories and the information used when you con nect to the
Internet.
Bluetooth services
To enable the Red-M Blade to connect to a number of different
types of devices, Red-M software supports three Bluetooth
services:
• LAN Access
Use this service to connect to Bluetooth network
infrastructure.
• Dial-up Networking
Use this service to connect to a Bluetooth-enabled mobile
phone.
•Serial
Use this service to perform a HotSync op erat ion with a
computer or to connect to another Palm Vx handheld to play
games.
Additions to Palm Vx menus
When you have completed the software installation, you will find
some additional items on your Palm Vx handheld System, Prefs
menus.
•the option Bluetooth has been added to the
pick list in the upper-right corner of the
System, Prefs screen. From the Bluetooth
preferences screen you can set the default
device categories for each Bluetooth service
which enables you to automate your
Bluetooth conne c ti ons (see Managing
Bluetooth devic es below).
7
• four Blueto ot h co nnec t ion c onf ig ur at io n s (Bt
LAN Access, Bt Dial-up, Bt Serial and Bt
Serial Host) have been added to the
Available Configurations list on the System,
Prefs, Connections screen. Choose
Connections from the pick list described
above to access this screen.
• a new network service called Bt LAN Access
on the System, Prefs, Network screen
(choose Network from the pick list) . This is
the service that is use d to connect to a
Bluetooth-en abled local area ne twork.
Managing Bluetooth devices
Before your Red-M Blade can connect to any other Bluetooth
device it must first discover other Bluetooth devices within
range.
You can discover all Bluetooth-enabled devices within range of
your Red-M Blade by performing a ‘device discovery’. Once
discovered, you can move devices into categories such as
Phones, Computers and Access Points, for easy management and
automated con nection to each Bluetooth serv ic e.
Using categories
Each Bluetooth service (Dial-up, LAN access and Serial) has a
default device category assigned to it. Whenever a Bluetooth
connection is requested, your Palm Vx handheld will
automatically connect to a device in the Bluetooth service’s
default category. F or example, if you place your mobile phone
into the Phones category, you can specify that each time you
make a Bluetooth Dial-up networking connection, your Palm Vx
handheld shou ld connect to a device in the Phones category.
Similarly, if you put a Red-M Access Point into the Access Points
category, you can specify that each time your Palm Vx handheld
makes a LAN Access connection, it should connect to a device
from the Access Points category.
8
Red-M Blade - Bluetooth Clip-on for Palm Vx User Guide
If a category contains multiple devices, the Red-M Blade will
connect to the first avai lable device. This is use ful if, for ex ample,
there are several LAN Access Points in your office to which you
can connect.
File devices into categories using Bluetooth
preferences screen 2.
When you have installed the Re d- M Blade
software, the Phones, Access Points and
Computers categories will already be available
for you to use. You can add, delete and merge
categories as required using the Edit categories
option from the pick list on this screen.
Set the default device category for each Bluetooth service by using Bluetooth preferences
screen 1. You can also set the default device category to Prompt. If you do this, when the Palm
Vx handheld needs to make a Bluetooth connection, you will be asked whi c h ca te gory and/or
device to which you want to connect.
Palm network service settings
When an application (for example, a WAP browser) on the Palm
Vx handheld wants to use the network, the netw ork s ervice that
will be used to make the connection will be the service that is
displayed on the System, Prefs, Network screen.
Each network service has a Connection setting, which determines
the physical network connection used. Connections are managed
through the System, Prefs, Connection screen.
Red-M Blade software adds a network service setting called Bt
LAN Access, with Connection set to Bt LAN Access. This is the
network service that is used when you c onnect to Blu etooth LAN
Access Points.
If you are connecting to an intranet or the Internet via a
Bluetooth-enabled mobile phone, you must add a new network
service and set Connection to Bt Dial-up. For more information,
see Configuring a co nnection to the Inter net via a mobile phone
on page 14.
When a network se r vice using Bt LAN Access or Bt Dial-up
connection is used, the device used to make the conne c tion will
9
be one that is stored in the default device category for LAN
Access or Dial-up respectively.
Your System, Prefs settings determine which Bluetooth - enabled
device and which network service will be used to make the
connection. The diagram below illustrates how the information on
the Bluetooth and Network screens from System, Prefs settings
is used when internet connection is made.
Figure 1: Use of Network and Bluetooth preferences when making an Internet
10
connection
Red-M Blade - Bluetooth Clip-on for Palm Vx User Guide
Installing the Red-M Blade software
Before you begin
Before you begin, you will need:
• a Palm Vx handheld running Palm OS® 3.5.x or later. To find
out which version of the Palm OS
Applications icon then the menu icon , an d from th e App
menu choose Info, then tap Version. Upgrades for earlier
Palm OS versions are available from the P alm web site at
www.palm.com. Red-M Blade software is not compatible with
Palm V models.
• a PC running Microsoft Windows 95, 98, NT4, ME or 2000
Professiona l with a CD-ROM drive (for software insta llation).
Your PC must have P alm Vx Desktop software installed and
have the Palm cradle connected.
• a Red-M CD (supplied).
you are runnin g, tap the
To install the Red-M Blade software
1. Insert the Red-M CD into your PC; the Red-M Blade install menu is displayed.
2. Click on Install Software for Red-M Blade. If more than one
Palm Vx user is installed on your PC, you will also need to
specify which user you wish to receive the files.
3. Click OK to exit the install menu.
4. Install the Red-M Blade software on your Palm Vx by
mounting the Palm Vx in its cra dle (without t he Red-M Bla de
attached) and performing a HotSync operation.
5. When the HotS yn c op er atio n co mpl etes , y ou w ill b e asked to reset your Palm Vx handheld. Do so.
Additional software on the Red-M Blade CD
Some additional Palm Vx applications have been included on the
Red-M Blade CD which you may wish to install on your Palm Vx
handheld to en ha nce your Blue tooth function ality and ease of
connection. Adobe Acrobat Reader is also included, which is a PC
application required to read the do cumentation that is on the CD .
To install any or all of these applications, select ‘Other Software’
on the Red-M Blade install menu, select your application and
then follow the on-screen instructions. Documentation for these
applications is included on the CD.
11
Attaching th e Red-M B la de
Before attaching the Red-M Blade, note down its Bluetooth
address, which is pr inted on its front. Depending on your
Bluetooth security settings, this may be required to identify the
Red-M Blad e when connect ing to Bluetoot h services.
The Red-M Blade has a 10-pin connector at the bottom, which is
identical to the one on your Palm handheld serial cradle. T o
attach the Red-M Blade, simply slide your Pa lm handheld onto
the Red-M Blade's connector as you wo uld for mounting in its
serial cradle. Once connected, push the Palm handheld back
towards the Blade until you hear a ‘click’.
Figure 2: Attaching the Red-M Blade
Note: With the Red-M Blade attached, you can perform a
Bluetooth HotSync operation but not the usual serial HotSync
operation using the cradle. If you need to perform a serial
HotSync operation with the cradle attached, simply detach the
Blade from your Palm handheld. The Palm handheld will recharge
its batteries as normal when placed in the serial cradle with the
Red-M Blade attached.
12
Red-M Blade - Bluetooth Clip-on for Palm Vx User Guide
Detaching the Red-M Blade
To detach the Red-M Blade, turn the unit over so that it is face
down, and push the latch at the back to the left to unclip the
Palm Vx handheld. Pull the Palm Vx handheld up and away from
the Red-M Blade.
Figure 3: Pushing the latch on the back of the Red-M Blade
Figure 4: Detaching the Red-M Blade
13
Configuring a connection to the Internet via a mobile phone
Before you begin
Before you begin, you will need:
• a Palm Vx handheld with a Red-M Blade attached (see
page 12) and Red-M software installed (see page 11).
• a Bluetooth-enabled mobile phone:
• if you have a Nokia 6210, see To configure your Pal m Vx
to connect to a Nok ia 6210 with bluetooth battery on
page 14.
• if you have and Ericsson T39m or R520m, see To
configure your Palm Vx to connect to an Ericsson T39m
or R520m on page 16.
• if you hav e any other Bluetooth-ena bled mobile phone,
see To configure your Palm Vx to connect to a mobile
phone on page 19.
• the Bluetooth address and passkey of your mobile phone.
This information may be print ed on the mobile phone’s
battery label, but the location varies with manufacturer. On
some mobile phones you choose your own passkey. Refer to
your mobile phone manual for more information.
• an ISP account user name, password and phone number.
To configure your Palm Vx to connect to a Nokia 6210 with bluetooth battery
Configuring your Pal m Vx handheld
1. On your Palm Vx handheld, perform a device
discovery:
i. Go to System, Prefs and select Bluetooth
from the pick list.
ii. Tap 2 ( ) to go to Screen 2 (shown);
ensure that the pick list selection is set to
All or Unfiled, and then tap Discover.
iii. The Red-M Blade w ill then find all
Bluetooth-enabled devices in range.
iv . Tap Stop to hal t the discovery proc es s.
14
Red-M Blade - Bluetooth Clip-on for Palm Vx User Guide
2. Look for the Bluetooth address or name of
your mobile phone in the list of discovered
devices. Tap on this address or name to go
to the Device Information dialog (shown).
3. In the Device Info rmat io n di a l og, tap
-Not set- and enter the pas s key of your
mobile phone. Tap OK to close th e Bluetooth
Passkey dialog.
4. Tap Update. The Red-M Blade will retrie ve
the device name an d s er vice profiles
available; a tick should now be displayed
beside Dial-up Networking.
5. Tap OK to exit the Device Information dialog
and return to the list of discovered devices.
6. Move your mobile phone into the Phones
category:
i. Tap the checkbox to the left of the name
of your mobile phone.
ii. Tap Move; in the Move Selected Devices
dialog, select Phones from the drop-down
menu. Tap OK to accept the change and
close the dialog.
7. Tap 1 to go to Screen 1; ensure that the
Dial-up category is set to Phones.
8. Set up your ISP details: i. From the pick list in the top right-hand
corner, select Network, then tap the Menu
icon and tap New.
ii. Give the Service a name - ‘Freeserve’ for
example - and under User Name input the
name required by your ISP.
iii. Tap -Prompt- to enter the ISP password;
if you leave the password setting as
-Prompt- you will be asked to input the
password each time you connect.
iv . Set Connection as Bt Dial-up using the
drop-down list.
v. Enter the ISP phone nu mber in Phone.
15
Testing the connection
To test the connection, ta p Connect in the Network, Prefs screen.
Using the Internet
Now that the ISP and phone set up is complet e, when yo u use an
application that requires an Internet connection, the Red-M Blade
will automatic a ll y co ntact the mobile phone which will dial your
ISP and give you an Internet connection.
Note: If you subsequently change the network service selected
on the System, Prefs, Network screen (for example, if you
change to Bluetooth Bt LAN Access service that uses a LAN
Access Point on a corporate Bluetooth network), when you want
to connect to your mobile phone, you must reset the current
network service to the Bluetooth Dial-up service that you added
in the above procedure.
To end the Bluetooth session
To end the Bluetooth session and thereby terminat e the mobile
phone call, do one of the following:
• switch off the Palm Vx.
•use the Disconnect option (if one exists) in whichever
application you are using.
•go to System, Prefs, Network and tap the Disconnect button.
To configure your Palm Vx to connect to an Ericsson T39m or R520m
Connecting your Palm Vx handheld to your mobile phone
1. On your mobile phone, select Menu, Extras,
Bluetooth and Discoverable.
2. On your Palm Vx handheld, perform a device
discovery:
i. Go to System, Prefs and select Bluetooth
from the pick list.
ii. Tap 2 ( ) to go to Screen 2 (shown);
ensure that the pick list selection is set to
All or Unfiled, and then tap Discover.
iii. The Red-M Blade w ill then find all
Bluetooth-enabled devices in range.
iv . Tap Stop to hal t the discovery proc es s.
16
Red-M Blade - Bluetooth Clip-on for Palm Vx User Guide
3. Look for the Bluetooth address or name of
your mobile phone in the list of discovered
devices. Tap on this address or name to go
to the Device Information dialog (shown).
4. In the Device Info rmat io n di a l og, tap
-Not set- and enter a passkey for your
mobile phone (a four figure numb er, for
example). Tap OK to close the Bluetooth
Passkey dialog.
5. On your mobile phone, select Menu, Extras,
Bluetooth. Select Paired devices, Add device,
and Phone accepts.
6. On the Palm Vx handheld, ensure yo ur
mobile phone is highlighted in the list of
discovered devices. From the Preferences
pick list, tap Connect. Your mobile phone will
display the prompt: Add to paired devices?.
7. On your mobile phone select Yes. Your
mobile phone will now prompt you for the
passkey that you entered on the Palm Vx
handheld earlier in this procedure.
8. On your mobile phone, enter the passkey
and select Yes. If pairing is successful, you
can now edit the name of your Palm Vx on
your mobile phone. Your mobile phone adds
your paired devices to the Paired List.
9. On your Palm Vx handheld, move your
mobile phone in to the Phones category:
i. Tap the checkbox to the left of the name
of your mobile phone.
ii. Tap Move; in the Move Selected Devices
dialog, select Phones from the drop-down
menu. Tap OK to accept the change and
close the dialog.
10. Tap 1 to go to Screen 1; ensure that the
Dial-up category is set to Phones.
17
11. Set up your ISP details: i. From the pick list in the top right-hand
corner, select Network, then tap the Menu
icon and tap New.
ii. Give the Service a name - ‘Freeserve’ for
example - and under User Name input the
name required by your ISP.
iii. Tap -Prompt- to enter the ISP password;
if you leave the password setting as
-Prompt- you will be asked to input the
password each time you connect.
iv . Set Connection as Bt Dial-up using the
drop-down list.
v. Enter the ISP phone nu mber in Phone.
Testing the connection
To test the connection, tap Connect in the Network, Prefs screen
Using the Internet
Now that the ISP and phone set up is complet e, when yo u use an
application that requires an Internet connection, the Red-M Blade
will automatic a ll y co ntact the mobile phone which will dial your
ISP and give you an Internet connection.
Note: If you subsequently change the network service selected
on the System, Prefs, Network screen (for example, if you
change to Bluetooth Bt LAN Access service that uses a LAN
Access Point on a corporate Bluetooth network), when you want
to connect to your mobile phone, you must reset the current
network service to the Bluetooth Dial-up service that you added
in the above procedure.
To end the Bluetooth session
To end the Bluetooth session and thereby terminat e the mobile
phone call, do one of the following:
• switch off the Palm Vx.
•use the Disconnect option (if one exists) in whichever
application you are using.
•go to System, Prefs, Network and tap the Disconnect button.
18
Red-M Blade - Bluetooth Clip-on for Palm Vx User Guide
To configure your Palm Vx to connect to a mobile phone
Note: Depending on the manufacturer, you may need to
configure your mob ile phone to be Blueto ot h- enabled. Refer to
the documentation that accompanied it for more information.
1. On your Palm Vx handheld, perform a device
discovery:
i. Go to System, Prefs and select Bluetooth
from the pick list.
ii. Tap 2 ( ) to go to Screen 2 (shown);
ensure that the pick list selection is set to
All or Unfiled, and then tap Discover.
iii. The Red-M Blade w ill then find all
Bluetooth-enabled devices in range.
iv . Tap Stop to hal t the discovery proc es s.
2. Look for the Bluetooth address or name of
your mobile phone in the list of discovered
devices. Tap on this address or name to go
to the Device Information dialog (shown).
3. In the Device Info rmat io n di a l og, tap
-Not set- and enter the pas s key of your
mobile phone. Tap OK to close th e Bluetooth
Passkey dialog.
4. Tap Update. The Red-M Blade will retrie ve
the device name an d s er vice profiles
available; a tick should now be displayed
beside Dial-up Networking.
5. Tap OK to exit the Device Information dialog
and return to the list of discovered devices.
6. Move your mobile phone into the Phones
category:
i. Tap the checkbox to the left of the name
of your mobile phone.
ii. Tap Move; in the Move Selected Devices
dialog, select Phones from the drop-down
menu. Tap OK to accept the change and
close the dialog.
7. Tap 1 to go to Screen 1; ensure that the
Dial-up category is set to Phones.
19
8. Set up your ISP details: i. Select Network, then tap the Menu icon
and tap New.
ii. Give the Service a name - ‘Freeserve’ for
example - and under User Name input the
name required by your ISP.
iii. Tap -Prompt- to enter the ISP password;
if you leave the password setting as
-Prompt- you will be asked to input the
password each time you connect.
iv . Set Connection as Bt Dial-up using the
drop-down list.
v. Enter the ISP phone nu mber in Phone.
Testing the connection
To test the connection, ta p Connect in the Network, Prefs screen.
Using the Internet
Now that the ISP and phone set up is complet e, when yo u use an
application that requires an Internet connection, the Red-M Blade
will automatic a ll y co ntact the mobile phone which will dial your
ISP and give you an Internet connection.
Note: If you subsequently change the network service selected
on the System, Prefs, Network screen (for example, if you
change to Bluetooth Bt LAN Access service that uses a LAN
Access Point on a corporate Bluetooth network), when you want
to connect to your mobile phone, you must reset the current
network service to the Bluetooth Dial-up service that you added
in the above procedure.
To end the Bluetooth session
To end the Bluetooth session and thereby terminat e the mobile
phone call, do one of the following:
• switch off the Palm Vx.
•use the Disconnect option (if one exists) in whichever
application you are using.
•go to System, Prefs, Network and tap the Disconnect button.
20
Red-M Blade - Bluetooth Clip-on for Palm Vx User Guide
Configuring a Bluetooth-enabled LAN connection
Before you begin
Before you begin, you will need:
• a Palm Vx handheld with a Red-M Blade attached (see
page 12) and Red-M software installed (see page 11).
• configured Bluetooth infrastructure (for example, a Red-M
3000AS access server running software version 1.3 or later
with Access Points connected).
• the name or Bluetooth address of the Access Point or Access
Server to which you want to connect a nd the Blue t ooth
passkey if one is u sed. F or t h is i nforma tio n , ask y o ur syst em
administrator.
To configure your Palm Vx to connect to LAN Access infrastructure
1. On your Palm Vx handheld, perform a device
discovery:
i. Go to System, Prefs and select Bluetooth
from the pick list.
ii. Tap 2 ( ) to go to Screen 2 (shown),
ensure that the pick list selection is set to
All or Unfiled, and then tap Discover.
iii. The Red-M Blade w ill then find all
Bluetooth-enabled devices in range.
iv . Tap Stop to hal t the discovery proc es s.
2. In the list of discovered devices, look for the
name or Bluetooth address of each of the
Access Points to which you want to connect.
Access Points and Access Servers will be
categorized as LANs in this list. (Access
Servers are treated as Access Points in this
procedure.)
21
3. If your system administrator has given you a
Bluetooth passkey:
i. Tap the Access Point’s name to go to the
Device Information sc r ee n ( shown)
ii. Tap -Not set- and enter the passkey. Tap
OK to exit the Bluetooth Passkey dialog.
4. Move your Access Point into the Access
Points category:
i. Tap the checkbox to the left of the name
of your Access Point.
ii. Tap Move; in the Move Selected Devices
dialog, select Access Points from the
drop-down menu.
iii. Tap OK to accept the change and close
the dialog.
5. Tap 1. Ensure the LAN Access default
category is set to Access Points.
6. Set the Service type to Bt LAN Access: i. Select Network from the top right-hand
menu.
ii. Set the Service type to Bt LAN Access
using the drop-down list that appears on
this screen.
iii. The Connection selection should also be
Bt LAN Access.
Now that the Access Point set up is complete, when you use an
application that needs a network connection, the Red-M Blade
will automatically make a Bluetooth connection to an available
Access Point in the Access Points category and giv e you access to
the network.
Note: If you subsequently change the network service selected
when you go to System, Prefs, Network (for example, if you
change to a Bluetooth dial-up service that uses a mobile phone),
when you want to connect to an Access Point, you must reset the
current network service to Bt LAN Access.
22
Red-M Blade - Bluetooth Clip-on for Palm Vx User Guide
Configuring Bluetooth HotSync operations
You can perform a Bluetooth HotSync operation with your
computer using your Red-M Blade in three different ways:
• from your R ed-M Blade directly to a Blue tooth-enab led laptop
or PC.
• from your Red-M Blade via an Access Point on a Bluetoothenabled LAN to a designated computer.
• from your Red-M Blade via a mobile phone connection to a
remote access server on your LAN.
Note: to perform a serial HotSync operation using the Palm
cradle, you must first detach the Red-M Blade from your Palm
Vx.
Configuring a HotSync operation with a computer
Before you begin
Before you begin, you will need:
• a Palm Vx handheld with a Red-M Blade attached (see
page 8) and Red-M software installed (see page 6).
• a computer with Palm Vx Desktop software and a Bluetooth
PCMCIA card or Bluetooth USB device installed.
• the Bluetooth address of the Bluetooth PCMCIA card or
Bluetooth USB device. You can find this address by using the
Bluetooth clien t soft wa r e on your c om p ut er.
To configure a HotSync operation with a computer
1. On your Palm Vx handheld, perform a device
discovery:
i. Go to System, Prefs and select Bluetooth
from the pick list.
ii. Tap 2 ( ) to go to Screen 2 (shown),
ensure that the pick list selection is set to
All or Unfiled, and then tap Discover.
iii. The Red-M Blade w ill then find all
Bluetooth-enabled devices in range.
iv . Tap Stop to hal t the discovery proc es s.
23
2. Look for the Bluetooth address or name of
your computer on the discovered devices
list.
3. If you are using Bluetooth authentication: i. Tap the computer’s address or name to
go to the Device Information dialog.
ii. Enter the pas s key here by tapping -Not
set-.
iii. Tap Update; tap OK to exit the Device
Information dialog.
4. Move your computer into the Computers
category:
i. Tap the checkbox to the left of the name
of your computer.
ii. Tap Move; in the Move Selected Devices
dialog, select Computers from the dropdown menu.
iii. Tap OK to accept the change and close
the dialog.
5. Tap 1. Ensure that the Serial Port default
category should be set to Computers.
6. Tap the Applications icon then the
HotSync icon .
7. Your HotSync settings should specify a local
HotSync operation:
i. Tap Local to select the Local ta b.
ii. Tap the Menu icon and select
LANSync Prefs.
iii. Tap Local HotSync and OK.
8. On the HotSync screen, select Bt Serial from
the pick list beneath the HotSync button.
9. Tap the HotSync button. The HotSync
operation will begin.
Now that you have configured your Palm Vx handheld to perform
a Hotsync operation with a Bluetooth-enabled computer, the next
time you want to perform a HotSync ope rati on you only have to
tap the HotSync button.
24
Red-M Blade - Bluetooth Clip-on for Palm Vx User Guide
Note: If you are using a PC with a Bluetooth USB device, ensure
that the HotSync Manager on your PC is configured to use same
serial port as your Bluetooth USB device. To check this, rightclick the HotSync Manager on your PC, select Setup and then the
Local tab.
Configuring a HotSync operation via a Bluetooth-enabled LAN
You can perform a HotSync operation from your Palm Vx
handheld (with Red-M Blade attached) via an Access Point on a
Bluetooth-enabled local area network (LAN) . The PC that your
Palm Vx will perform the operation with is specified as part of the
configuration process.
Before you begin
Before you begin, you will need:
• a Palm Vx handheld with a Red-M Blade attached (see
page 12) and Red-M software installed (see page 11).
• a computer with Palm Vx Desktop software installed and the
name and IP address of this computer, which should be
configured to allow networ k HotSync operations.
• configured Bluetooth infrastructure (for example, a Red-M
3000AS access server running software version 1.3 or later
with Access Points connected).
• to have completed the procedure to connect to LAN Access
infrastructure on pa ge 21.
To configure a HotSync operation via a Bluetooth-enabled
LAN
1. Go to System, HotSync. Tap Modem on the
HotSync screen to select the Modem tab.
2. Tap the Menu icon , select Modem Sync
Prefs, then choose Network and tap OK.
25
3. Tap the Menu icon , select LANSync Prefs
then choose LANSync and tap OK.
4. Tap the Menu icon , select Connection
Setup, ensure Bt LAN Access is selected in
the list and tap Done.
5. Select Bt LAN Access as the serv ic e , using
the pick list beneath the HotSync icon. The
HotSync screen should now l ook lik e th e one
shown.
6. Tap the Menu icon , select Primary PC
Setup and enter your HotSync PC’s name in
the Primary PC Name field.
• to view this information, rig ht-click the
HotSync Manager on your PC, select
Setup and the Network tab and then click
TCP/IP Settings.
7. Enter your HotSync PC’s IP address in the
Primary PC Address field.
• to view this information, rig ht-click the
HotSync Manager on your PC, select
Setup and the Network tab and then click
TCP/IP Settings.
8. Tap the HotSync button. The HotSync
operation will begin.
Now that you have configured your Palm Vx handheld to perform
a Hotsync operation via a Bluetooth-enabled LAN, the next time
you want to perform a HotS ync operatio n you only have to tap
the HotSync button.
26
Red-M Blade - Bluetooth Clip-on for Palm Vx User Guide
Note: If your computer has more than one IP address, you will
need to ensure that the HotSync Manager is using the correct
address. To check this, right-click the HotSync Manager on your
PC, select Setup and the Network tab and then click TCP/IP
Settings; the IP address displayed here should be the same as
the IP address you have entered into the Primary PC Setup on
your Palm handheld.
Configuring a remote HotSync operation via a mobile phone
You can perform a HotSync operation from your Palm Vx
handheld (with Red-M Bla de attached) to a co m puter connected
to your company network, via a Bluetooth connection to your
mobile phone. This option will only be available if your company
network supports dial-up remote access.
Before you begin
Before you begin, you will need:
• a Palm Vx handheld with a Red-M Blade attached (see
page 12) and Red-M software installed (see page 11).
• a computer with Palm Vx Desktop software installed.
• a dial-up account on your company network.
• a Bluetooth-enabled mobile phone.
• the Bluetooth address and passkey of your mobile phone.
Sometimes these are printed on the battery label. You will
need these before you can make a Bluetooth connection.
27
To configure a HotSync operation with a mobile phone
1. Follow the ins t r uc t ions to connect to your
mobile phone on page 14 up to and includ ing
step 7.
2. Set up your company dial-up details: i. Go to System, Prefs and from t he pick list
on the upper-right corn er of the screen,
select Network
ii. Tap the Menu icon and tap New.
iii. G ive the Service a name; this name will
be used to select this service from the
Network, Services pick list.
iv. Select Bt Dial-up as the connection type
using the Connection drop-down menu.
v . Enter the telephone number of your
company’s dial-up service and your
username and password.
vi. Tap OK.
3. Tap the Applications icon then the
HotSync icon .
4. Tap Modem on the HotSync dialog to select
the Modem tab.
5. Tap the Menu icon and select Modem
Sync Prefs. Select Network and tap OK.
6. Tap the Menu icon and select LANSync
Prefs. Select LANSync and tap OK.
28
Red-M Blade - Bluetooth Clip-on for Palm Vx User Guide
7. Ensure that your corporate remote-access
dial-up service is the selected service (this is
displayed below the HotSync icon). If you
need to change the service selection:
i. Tap the current service selection.
ii. On the Prefs, Network screen, tap Service
and select your corporate remote-access
dial-up service.
iii. Tap Done.
8. Tap the Menu icon , select Primary PC
Setup and enter your HotSync PC’s name in
the Primary PC Name field.
• to view this information, rig ht-click the
HotSync Manager on your PC, select
Setup and the Network tab and then click
TCP/IP Settings.
9. Enter your HotSync PC’s IP address in the
Primary PC Address field.
• to view this information, rig ht-click the
HotSync Manager on your PC, select
Setup and the Network tab and then click
TCP/IP Settings.
10. Tap the HotSync button. The HotSync
operation will begin.
Now that you have configured your Palm Vx handheld to perform
a Hotsync operation via your mobile phone, the next time you
want to perform a HotSync operation in this way you only have
to tap the HotSync button.
29
Technical support and contact information
For Red-M Blade support information, visit the R ed-M website at
www.red-m.com/blade
30
Red-M Blade - Bluetooth Clip- on for Palm Vx User Guide
Regulatory information
The following regulatory statements apply to the Red-M Blade - Bluetooth
Clip-on for Palm Vx.
Europe (EEA)
This product is designed to connect to "Bluetooth" compatible radio
interfaces using th e 2.4 GH z fre q u en cy ba nd in all E EA Me m be r S ta te s
with the excepti on of Fr ance where t he use of the fo llowing frequencie s is
restricted:
2.4000 - 2.4460 GHz Use Excluded - Military Band
2.4540 - 2.4835 GHz Limited to indoor video applications
[Member States of the EEA are: Austria, Belgium, Denmark, Finland,
France, Germany, Greece, Iceland, Ireland, Italy, Luxembourg,
Liechtenstein, Neth erlands, Norway, Portugal, Spain, Sweden,
Switzerla nd, United Kingdom.]
North America
This equipment complies with part 15 of the FCC rul es. Any changes or
modifications not expressly approved by the manufacturer could void the
user’s authority to operate the equipment.
Operation is subject to th e foll ow in g tw o co n di tio n s : (1) this de vic e may
not cause interference, and (2) this devi ce must accep t any inter ferenc e,
including interference that may cause undesired operati on of the device.
This device has been designed to operate with an antenna having a
maximum g ain of 0 dB. Antenna having a hi gher gain is strictly
prohibited per re gulations of Industr y Ca na d a . Th e requ ir ed an te n na
impedance is 50 ohms.
To reduce potential rad io in t er fe re nc e to othe r u s er s , th e a nte n na typ e
and its gain should be so chosen that the equivalent isotropically radiated
power (EIRP) is not more than that required for successful
communication.
To prevent radio interference to the licensed service, this device is
intended to be operate d in do or s a nd away from windows to provide
maximum shielding. Equipment (or its transmit antenna) that is installed
outdoors is subjec t to lice n s ing .
IMPORTANT NOTE: To com ply with FC C RF ex po s u re co mp liance
requirements , the foll owing antenna installation and devic e opera tin g
configurations must b e sa tisf ied- The devi ce and i ts ant enn a must n ot be
co-located or operating in conjunction with any other antenna or
transmitter.
31
Power supply information
English
CAUTION: Only use this pro duct with a power source that meets the
"Limited Power Source" requirements of IEC 60950 or equivalent safety
standards. Use the power supply provided (if applicable) or cont act RedM for a list of suitable po we r sources.
Dansk
ADVARSEL: Dette produkt må kun anvendes samme n med strømkilder,
der opfylder kravene vedrø rende "Limited P ower Source" i IEC 60950
eller tilsvarende sikkerhedsstandarder. Anvend den medfø lgend e
strømforsyning (hvis muligt), eller kontakt Red-M og få en liste over
godkendte strømkilder.
Français
ATTENTION: n'utilisez ce produit qu'avec une source d'énergie conforme
à la norme IEC 60950 en matière de « source d' énergie limitée », ou
autre norme de sécurité équivalente. Utilisez l'alimentation en courant
fournie (si applicable) ou bien contactez Red-M pour obtenir une liste des
sources d'énergie adéquates.
Español
PRECAUCIÓN: Emplee este producto únicamente con una fuente de
alimentación que cumpla la norma de seguridad IEC 60950 de
alimentación lim itada, o equivalente . Uti lic e la fue nte de alimentación
suministrada, si es el caso, o consulte a Red-M para obtener una lista de
fuentes de alimentación apropiadas.
Português
Advertência: Utilize este produto apenas com uma fon te de energia que
respeite os requisitos definidos em "Fontes de Energia Limitadas" da
norma IEC 60950 ou dos padrõe s de seg u rança equivalent es. U tili ze a
fonte de alimentação fornecida (se aplicável) ou contacte Re d-M par a
obter uma lista de fontes adequadas.
Suomi
MUISTUTUS: Käytä tätä tuo te tta vain sel lais en virtalähteen yhteydess ä,
joka täyttää standardin 60950 "rajoitetun virtalähteen" tai muiden
vastaavien standar dien asettamat tur vallis uusvaatimukset. Kä yt ä
toimitettua virtalähdettä (jos asianmukaista) tai ota yhteys RedM:ään
sopivien virtalähteiden luettelon saamiseksi.
Flemish
OPGELET: gebruik dit product enkel met een voedingsbron die voldoet
aan de "Minimum voedingsbron"-vereisten van IEC 60950 of
evenwaardige veiligheidsvoorschriften. Gebruik bijhorende voedingsbron
(indien deze geschikt is) of neem contact op met RED-M voor een lijst
van geschikte voedingsbronnen.
32
Red-M Blade - Bluetooth Clip- on for Palm Vx User Guide
Nederlands
WAARSCHUWING: Gebruik dit product alleen met een voedingsbron die
voldoet aan de "Minimum voedingsbron"-vereisten van IEC 60950 of
evenwaardige veiligheidsvoorschriften. Gebruik de bijbehorende
voedingsbron (indien van toepassing) of neem contact op met Red-M
voor een lijst van geschikte voedingsbronnen.
Deutsch
WARNUNG: Verwenden Sie dieses Produkt nur mit einer Stromquelle, die
die Anforder un g en be z üg lic h "b egrenzter Stro m qu e ll en" gemäß IEC
60950 oder entsprechender Sicherheitsnormen erfüllt. Verwenden Sie
das im Lieferumfan g enthalt ene Netzt eil (sof ern zutref fend), oder for dern
Sie bei Red-M eine List e de r ge e igneten Stromq ue lle n an .
Svensk
FÖRSIKTIGT! Denna produkt får bara användas med en effektkälla som
uppfyller kraven för "Begränsad effektkälla" i IEC 60950 eller
motsvaran de säkerhetsnormer. Använd medföljande effekt källa (i
förekommande fall) eller begär en lista över lämpliga effektkällor från
Red-M.
Íslenska
VARÚÐ: Notið þessa vöru eingöngu með aflgjafa sem stenst kröfur í
kaflanum um "aflgjafa með takmarkað afl" í IEC 60950 (ÍST EN 60950)
eða sambærilegra öryggisstaðla. Notið aflgjafann sem fylgir (ef
viðeigandi) eða fáið lista yfir nothæfa aflgjafa hjá umboðsaðila vörunnar.
Norsk
FORSIKTIG: Dette produktet skal bare brukes med en strømkilde som
tilfredsstiller kravene til "Begrenset strømkilde" i IEC 60950 eller
tilsvarende sikkerhetsstandard. Bruk den medfølgende strømforsyningen
(hvis en slik finnes) eller kontakt Red-M for å få en oversikt over
passende str øm k ilder.
λληνικά
ΠΡΟΣΟΧΗ: Χρησιµοποιήστε αυτό το προϊόν µόνο µε πηγή
ενέργειας που είναι σύµφωνη µε την οδηγία του IΕC 60950 περί
«Περιορισµένης Πηγής Ενέργειας» ή αντίστοιχων προδιαγραφών
ασφαλείας. Χρησιµοποιήστε την πηγή ενέργειας που παρέχεται
(αν είναι κατάλληλη) ή επικοινωνήστε µε την Red-M για να σας
προµηθεύσει µε κατάλογο συµβατών πηγών ενέργειας
Italiano
ATTENZIONE: Utilizzare que sto pr odotto solo con sorgenti di
alimentazione ch e s oddisfano i requis iti di sicurezz a IEC 60950 o
equivalenti. Utilizzare l'alimentatore fornito (ove applicabile) o contattare
Red-M per ottenere un elenco delle sorgenti di alimentazione adeguate.
33
34
Red-M Blade - Bluetooth Clip- on for Palm Vx User Guide
Red-M User License and Limited Warranty Agreement
IMPORTANT: THIS IS A LEGAL AGREEMENT BETWEEN YOU AND RED-M.
BY INSTALLING, COPYING OR OTHERWISE USING THE SOFTWARE
PRODUCT (AS DEFINED BELOW), YOU AGREE TO BE BOUND BY THE
TERMS OF THE "RED-M USER LICENSE AND LIMITED WARRANTY
AGREEMENT " BELOW. IF YOU DO NOT AGREE TO THE TERMS OF THIS
AGREEMENT, RED-M ARE UNWILLING TO LICENSE THE SOFTWARE
PRODUCT TO YOU. IN SUCH EVENT, YOU MAY NOT USE OR COPY THE
SOFTWARE PRODUCT, AND YOU SHOULD PROMPTLY RETURN THE
UNUSED PRODUCT EITHER TO RED-M OR AN AUTHORIZED RESELLER
FOR A REFUND.
THE "SOFTWARE PRODUCT" INCLUDES COMPUTER HARDWARE AND
SOFTWARE, EMBEDDED FIRMWARE, THE ASSOCIATED MEDIA, ANY
PRINTED MATERIALS, AND ANY "ONLINE" OR ELECTRONIC
DOCUMENTATION.
RED-M User License and Limited Warranty Agreement
This Red-M User License and Limited Warranty Agreement, as modified
by the "Additional License Provisions" set forth below or in the
documentation accompanying this product (collectively, the
"Agreement
in this package (if any) (the "Hardware
use the Red-M software described below (the "Software
terms and conditions below. You agree that all other hardware
subsequently supplied to you by Red-M or Red-M's authorized agents,
distributors or resellers will be subject to the terms, conditions, limited
warranties and remedies of this Agreement, unless you are bound by
terms of a different Red-M agreement distributed with such hardware.
Red-M License
The Software li cen sed by t his Ag reemen t in cludes all th e softw are on an y
distribution media supplied to you within this package (and includes any
software accompanying, pre-programmed or pre-loaded within any
Hardware supplied). You agree that all other software and upgrades,
enhancements or imp rovem ents to any of the Software subs e que ntl y
supplied to you by Red-M or Red-M's authorized agents, di stributors or
resellers on any distribution media or via any form of electronic
distribution will be subject to the terms, conditions, limited warranties
and remedies of th i s Ag re e ment, unless you a re bou n d by terms of a
different Red -M license distribute d with such software, upgrades,
enhancements or improvements. The Software is owned by Red-M or its
licensors and is protected by United States and other country copyright
laws and by international treaty provisions.
Red-M or its licensors retain ownership of the Software and no rights are
granted to you other than a license to use the Software on the terms
expressly set forth in this Agreement. This Agreement imposes certain
restrictions on your use of the Softwa re .
"), grants you the right to use the Red-M hardware en closed
") and a non-exclusive license to
"), under the
35
Subject to any limitation in the Additional License Provisions, if
any, you may:
• use only one copy of the Software on any accompanying Hardware;
• use the Software in only machine-readable form
• make copies of the Software for back-up purposes, but you may not
use the back-up copies other than as a replacement for the original
copy. You must include all copyr ight and other notices included on
the Software on any copies you make;
• make copies of the documentation, the written materials or electronic user information accompanying the Software and/or the Hardware (if any) supplied by Red-M, but only for use within the
organization to which you belong, and only for the purposes of
installing and using the Software and the Hardware. You must
include all copyright and other notices included on the materials on
any copies you make.
Except as otherwise permitted pursuant to this Agreement, you
may not:
• make any copies of any of the Software other than for back-up purposes as permitte d above ;
• sublicense , rent, lo an or lease the Software or document atio n to
another, except where you are leasing Red-M Hardware with which
or for which the Sof tware w as suppli ed (if any ) to an end us er, and in
such circumstances, you agre e on behalf of the en d user to b e bound
by all of the terms of this Agreement;
• decompile, disassemble, reverse engineer, or modify in any way , any
of the Hardware, Softwa r e or othe r Red-M Pro duc ts , e xce pt to the
extent that this restriction is expressly prohibited by applicable law;
• transfer or assign your rights to use the Software except upon a
transfer of any associated Red-M hardware
• transfer or assign your rights to use the Software except upon a
transfer of any associated Red-M hardware with which or for which
the Software was supplied (if any), and in such circumstances, you
agree on behalf of th e end user to be bound by al l of the terms of
this Agreement;
• use the Software in a life-support or safety system or in any other
application in whi ch th e failure of the Software or Har dwa re co u ld
create a situation where personal in jury or death may oc cur, without
the prior approval of Red-M, and in any event, you s h all ta ke full
responsibility for any such use.
• us e the So ftwar e fo r a ny purp os e othe r tha n as pe r mi tte d in this
Agreement.
You acknowledge and agree that:
• if you upgrade any older Red-M products ("Upgraded Products
") with
any of the Software, then you agree tha t this Ag re em e nt wi ll the re after apply to such Upgraded Products.
• if you obtain any other Red-M software and are not bound by a written Red-M user license agreement, then you agree that you are
using such software in accordance with the applicable terms of this
Agreement;
36
Red-M Blade - Bluetooth Clip- on for Palm Vx User Guide
• Red-M or its licensors retain ownership of the Software and no rights
are granted to you other than a licen se to us e the So ftwar e on the
terms expressly set forth in this Agreement; the underlying design of
all Red-M hardware and the structure, sequen ce, organization and
source code of a ll Red-M software are valuab le t rade se c re ts o f RedM or its licensors;
• the export of the Software and Hardware may be restricted by th e
export control laws of the United States of America and other countries. You agree to comply wit h al l suc h a pp lic a bl e e xport control
laws;
• without limiting the rights that the licensors or suppliers of Red-M
otherwise have to protect their intellectual property rights, each of
such licensors or suppl ie rs are thi rd part y be nefi ciar ie s of thi s Agreement for their respective products and may have the right to enforce
such terms against you;
• by using the Hardware and / or Sof t w are y ou h er eby gi v e exp lic it co nsent for Red-M to process your personal data ("Personal Data") for
administrative, billing, marketing and support purposes, to include
the transfer of P erso nal Data i nside and o utsid e of the Euro pean Economic Area (including, but not limited to, the USA). You agree that
Red-M may collect Personal Data from , or through your use of, the
Hardware and/or Software supplied to you by Red-M and from information that you or your reseller supplies directly to Red-M. Red-M
acknowledges your rights in relation to Personal Data and will have
in place appropriate technical and organizational security measures
so as to ensure a level of security that is appropriate to the nature of
the data that is being processed. You may obtain further information
on your rights in relation to Personal Data by contacting Red-M's
Data Protection Compliance Officer at Wexham Springs, Framewood
Road, Wexham, Slough, SL3 6PJ, UK.
• the So ftwa r e m ay cont a in or be de rived from portions of c ode an d
documentation provided by a third party under license to Red- M.
Red-M has assumed resp onsi b ili ty f or the se le ctio n of suc h code and
documentation and its use in producing and licensing the Software.
ALL SUCH THIRD PARTIES DISCLAIMS ALL WARRANTIES WITH
RESPECT TO THE USE OF SUCH CODE OR DOCUMENTATION IN THE
SOFTWARE, INCLUDING (WITHOUT LIMITATION) ANY WARRANTIES
OF SATISFACTORY QUALITY OR FITNESS FOR A PARTICULAR PURPOSE.
The limitation of liabilities described in this Agreement also applies to any
third-party supplier of code and documentation supplied to you. Red-M
and its third-party supplier limitations of liabilities are not cumulative.
Such third-party supplier is an intended beneficiary of this section. The
Red-M 100 0 AP pr oduct con tains s oftw are l ice nsed from P recis e Soft war e
Technologies In c. ©Copyright 2000 Prec is e So ftware Technologies Inc.
The Red-M 3000 AS product contain s software licensed from Extended
Systems Inc. © Copyrig ht 2000 Ex tended S ystems Inc. Co pyrigh t © 2000
General Software Inc. All rights reserved. The Software may contain
portions of code or other works which are licensed to Red-M under, and
are subject to, the GNU GENERAL PUBLIC LICENSE, which is reproduced
37
in the user ref ere nce gu id e di st rib ute d w it h t he H ard wa re. I n a ccord an ce
with the GNU GENERAL PUBLIC LICENSE and subject to receiving a
request and payment for the costs of performing such source
distribution, Red-M shall provide any third party, who so requests, with a
machine readable copy of the source code of the works on a medium
customarily use d for software interch an ge : th is off e r sha l l re ma i n valid
for a period of three years from the first customer release of a version of
the works. Copyright © 19 89, 1991 Free Software Foundation, Inc. 67 5
Mass Ave, Cambridge, MA 02139, USA. The Red-M 3000AS product
contains software licensed from PHP, freely available from http://
www.php.net/. The PHP License, version 2.2. Copyright © 1999, 2000
The PHP Group. All rights re s erved. Copyright © 1997 Eric Young
(eay@mincom.oz.au) All rights reserved. The Red-M 3000AS product
contains Qpopper software which, excluding the portions owned by the
Regents of the University of California, is Copyright 1993-2000
QUALCOMM Incorporated and code from the software program Popper,
which is © Copyright 1989-1991 The Regents of the University of
California, All Rights Reserve d. Co py rig ht (c ) 199 0 , 199 3, 19 94, 1 995 ,
1996, 1997, 1998 Sleepycat Software. All rights reserved. Copyright (c)
1990, 1993, 1994, 1995 The Regents of the University of California. All
rights reserved. Copyright (c) 1995, 1996 The President and Fellows of
Harvard University. All rights reserved. Contains security software from
RSA Data Security, Inc Copyright © 1998 and 1990 RSA Data Security
Inc. All rights reserved.
• the license granted hereby is effective until terminated. You may terminate this Agreement as to any Software at any time by destroying
such Software, the related med ia, and all related ba ck -up copi es and
documentation. Upon any violation of any of the prov is ions of this
Agreement, your right to use the Software and Hardware (if any) will
automatically terminate and you will be obligated to return to Red-M
or destroy all of such Software and to cease to use all of such Hardware;
• this Agreement will be governed by the laws of England and Wales,
other than its provisions concerning the applicability of laws of other
jurisdictions;
• this Agreement is the complete and exclusive statement of you r
agreement with Red-M with respect to the subject matter hereof and
supersedes all prior agreements or communications, written or oral.
If any provision of this Agreement is held to be invalid or unenforceable by a court of competent jurisdiction, the remaining provisions of
this Agreement shall remain in full force and effect.
38
Red-M Blade - Bluetooth Clip- on for Palm Vx User Guide
U.S. Department of Defense & U.S. Civilian Agencies
If the comput er soft ware pr ograms or docume ntati on prov ided und er thi s
license agreem e n t are to be u tili ze d in contracts with or on be ha l f of th e
United States of America, its agencies, or its instrumentaliti es (the
"Government"), th e y s ha ll be co n side red and treated as "co m me r ci a l
computer software", as that term is de fine d in the De pa r tm ent of
Defense Federal Acquisition Regulati on Su pplement ("DFARS") Subpart
227.72. If the Governme n t is the lic e nse e , it sh a ll h ave on ly the rig h ts
specified in this license and shall have no greater rights than any other
licensee of the commercial computer software or commercial software
documentation.
Red-M Limited Warranty
Red-M warrants that under normal use and conditions the products listed
below will for the appropriate duration after the date of original purchase
from Red-M listed below (each a "Warranty Period") be free from defects
in materials and workmanship as follows:
Product Warranty
Red-M Blade - Bluetooth Clip -on fo r Palm Vx 1 year
Red-M 3000AS 1 year
Red-M 1000AP 1 year
Software Media (if any) 90 days
THE SOFTWARE (OTHER THAN SOFTWARE MEDIA, IF ANY) IS PROVIDED
"AS IS" WITHOUT ANY WARRANTY.
If you believe that you have discovered any covered defect during the
applicable Warranty Period, please contact your local authorized reseller
or distributor or, if they are unable to help you or you obtained the
product directly from Red-M, please contact your local Red-M office
directly. If Red-M, or the authorized reseller or distributor, instructs you
to return the product please return any Hardware together with the
accompanying Software media (including all copies of the Software) (or
just the Software media if no Hardware was supplied) freight prepaid to
either the authori zed res el le r or di st ribu to r fr om which i t wa s pur ch ased ,
or to Red-M, as instructed. Please note you may also be asked to provide
written documenta tion of yo ur purchase.
CUSTOMER REMEDIES:
Red-M's and its licenso rs ' , suppliers', res ell er s '
and distributors' entire liability to you, and your exclusive remedy will be,
at Red-M's option: (i) re pair or replacement of the Software media or
Hardware that does not m eet the Red-M Warranty, or (ii) return of the
price paid. All media and Hardware which is replaced will become the
property of Red-M. Replacem e nt pro du c ts may be n ew or re con d iti on e d.
Red-M will have no responsibility, warranty or other obligations
whatsoever as a result of: (a) th e use of the Hardware, Software media
and/or Software in a manner inconsistent with the accompanying
manuals and this Agree m ent, or (b) any modifications mad e to th e
Hardware or Software, or (c) failure of the Hardware, Software media or
Software as a result of accident, abuse or misapplication, or (d) use of
Hardware and Software with products not read ily commercially availa bl e
on the date of the original pur cha se . Red-M a nd its au thor ized
distributors or resellers are not re sponsible for any software, firmwa re,
information or data contained in, or stored on, any returned items.
39
NO OTHER WARRANTIES:
THE WARRANTIES SET FORTH ABOVE ARE
EXCLUSIVE AND IN LIEU OF ALL OTHER WARRANTIES. RED-M MAKES NO
OTHER WARRANTIES, EXPRESS OR IMPLIED, AND RED-M EXPRESSLY
DISCLAIMS ALL OTHER WARRANTIES, INCLUDING BUT NOT LIMITED TO
IMPLIED WARRANTIES OF SATISFACTO RY QUALITY, MERCHANTABILITY
AND FITNESS FOR A PAR TICULAR PURPOSE AND ACCURACY AND ANY
WARRANTY OF NONINFRINGEMENT OF INTELLECTUAL PROPERTY
RIGHTS. MOREOVER, THE PROVISIONS SET FORTH ABOVE STATE REDM'S ENTIRE RESPONSIBILITY AND YOUR SOLE AND EXCLUSIVE REMEDY
WITH RESPECT TO ANY BREACH OF ANY WARRANTY.
THIS WARRANTY DOES NOT AFFECT ANY STA TUTORY RIGHTS THAT YOU
MAY HAVE IF YOU ARE A CONSUMER
LIMITATION ON LIABILITY; NO LIABILITY FOR CONSEQUENTIAL
DAMAGES: UNDER NO CIRCUMSTANCE AND UNDER NO THEORY OF
LIABILITY WILL RED-M OR ITS LICENSORS, SUPPLIERS, RESELLERS OR
DISTRIBUTORS BE LIABLE FOR COSTS OF PROCUREMENT OF
SUBSTITUTE PRODUCTS OR SERVICES, LOST PROFITS, LOST SAVINGS,
LOSS OF INFORMATION OR DATA, OR ANY OTHER SPECIAL, INDIRECT,
CONSEQUENTIAL OR INCIDENTAL DAMAGES, ARISING IN ANY WAY OUT
OF THIS AGREEMENT OR THE SALE, LICENSE OR USE OF, OR INABILITY
TO USE, ANY RED-M PRODUCT (HARDWARE OR SOFT WARE) OR
SERVICE, EVEN IF RED-M HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES, AND NOTWITHSTANDING ANY FAILURE OF ESSENTIAL
PURPOSE OF ANY LIMITED WARRANTY.
The warranties, limitations and remedies contained herein allocate risk of
Software, Hardware and media breach of warranty or other liability and
Red-M's prices reflect the allocation of such risk. Cert ain jurisdictions
restrict the ability to (a) exclude implied warranties, (b) limit or exclude
incidental or conse quential damages , or (c) lim it lia bi lity im po s ed un de r
product liability laws. T o the extent any such restrictions apply to you and
may not be waived, the foregoing limitations and exclusions may not
apply to you. If, notwithstand ing the a bove clau se s, Red-M is sub jec t to
any liability in connection with the Software or Hardware, whether arising
from negligence, b reach of contr act or ot herwise, R ed-M' s liabil ity wi ll not
exceed the sum paid by you to Red-M for the Hardware and/or Software
that did not comply with the Red-M Limited Warranty. This limitation does
not apply in the case of personal injury or death if and to the extent
prohibited by app lic ab le law.
Trademarks Red-M, and the Red-M logo are trademarks, and in some
jurisdictions may be registered trademarks, of Red-M (Communications)
Ltd. Bluetooth is a trademark owned by Bluetooth SIG Inc USA and used
by Red-M under license.
Other trademarks appearing in this document are the property of their
respective owners.
Additional Provisions: None
©Copyright 2001 Red-M. All Rights Reserved.
40
Loading...
