Redhat NETWORK PROXY SERVER 4.0 User Manual

RHN Proxy Server 4.0

Installation Guide

RHN Proxy Server 4.0: Installation Guide

Red Hat, Inc.

1801 Varsity Drive Raleigh NC 27606-2072 USA Phone: +1 919 754 3700 Phone: 888 733 4281 Fax: +1 919 754 3701 PO Box 13588 Research Triangle Park NC 27709 USA

RHNproxy(EN)-4.0-RHI (2005-04-20T13:40) Copyright © 2005 by Red Hat, Inc. This material may be distributedonly subject to the terms and conditions set forth in the Open PublicationLicense, V1.0 or later (the latest version is presently available at http://www.opencontent.org/openpub/). Distribution of substantively modiﬁed versions of this document is prohibitedwithout the explicit permission of the copyright holder. Distribution of the work or derivative of the work in any standard (paper) book form for commercial purposes is prohibited unless prior permission is obtained from the copyrightholder.

Red Hat and the Red Hat "Shadow Man" logo are registered trademarks of Red Hat, Inc. in the United States and other countries. All other trademarks referencedherein are the property of their respective owners. The GPG ﬁngerprint of the security@redhat.comkey is: CA 20 86 86 2B D6 9D FC 65 F6 EC C4 21 91 80 CD DB 42 A6 0E

1. Introduction.................................................................................................................... 1

1.1. Red Hat Network ..............................................................................................1

1.2. RHN Proxy Server ............................................................................................1

1.3. Terms to Understand .........................................................................................2

1.4. How it Works ....................................................................................................3

2. Requirements..................................................................................................................7

2.1. Software Requirements .....................................................................................7

2.2. Hardware Requirements....................................................................................8

2.3. Disk Space Requirements .................................................................................8

2.4. Additional Requirements ..................................................................................9

3. Example Topologies .....................................................................................................11

3.1. Single Proxy Topology ...................................................................................11

3.2. Multiple Proxy Horizontally Tiered Topology ...............................................12

3.3. Multiple Proxy Vertically Tiered Topology ....................................................12

3.4. Proxies with RHN Satellite Server .................................................................13

4. Installation ....................................................................................................................15

4.1. Base Install......................................................................................................15

4.2. RHN Proxy Server Installation Process ..........................................................15

5. RHN Package Manager ...............................................................................................27

5.1. Creating a Private Channel .............................................................................27

5.2. Uploading Packages ........................................................................................27

5.3. Command Line Options ..................................................................................29

6. Troubleshooting............................................................................................................31

6.1. Managing the Proxy Service ...........................................................................31

6.2. Log Files .........................................................................................................31

6.3. Questions and Answers...................................................................................32

6.4. General Problems ............................................................................................33

6.5. Host Not Found/Could Not Determine FQDN ...............................................33

6.6. Connection Errors ...........................................................................................34

6.7. Caching Issues ................................................................................................34

6.8. Proxy Debugging by Red Hat .........................................................................35

A. Sample RHN Proxy Server Conﬁguration File ........................................................37

Index..................................................................................................................................39

Chapter 1. Introduction

1.1. Red Hat Network

Red Hat Network (RHN) is the environment for system-level support and management of Red Hat systems and networks of systems. Red Hat Network brings together the tools, services, and information repositories needed to maximize the reliability, security, and performance of their systems. To use RHN, system administrators register the software and hardware proﬁles, known as System Proﬁles, of their client systems with Red Hat Network. When a client system requests package updates, only the applicable packages for the client are returned (based upon the software proﬁle stored on the RHN Servers).

Advantages of using Red Hat Network include:

• Scalability — with Red Hat Network, a single system administrator can set up and main-

tain hundreds or thousands of Red Hat systems more easily, accurately, and quickly than they could maintain a single system without Red Hat Network.

• Standard Protocols — standard protocols are used to maintain security and increase

capability. For example, XML-RPC gives Red Hat Network the ability to do much more than merely download ﬁles.

• Security — all communication between registered systems and Red Hat Network takes

place over secure Internet connections.

• View Errata Alerts — easily view Errata Alerts for all your client systems through one

website.

• Scheduled Actions — use the website to schedule actions, including Errata Updates,

package installs, and software proﬁle updates.

• Simpliﬁcation — maintaining Red Hat systems becomes a simple, automated process.

1.2. RHN Proxy Server

An RHN Proxy Server is a service deployed within a corporate network with advanced Red Hat Network functionality, such as a package-caching mechanism for reduced bandwidth usage and customizable channels enabling custom package deployment.

This service allows a business or corporation to cache RPM Updates on an internal, centrally located RHN Proxy Server and have the client systems download the updates from

2 Chapter 1. Introduction

that server instead of from one of the RHN Servers1over the Internet. The clients’ System Proﬁles and user information are stored on the secure, central RHN Servers, which also serve the RHN website (rhn.redhat.com). The Proxy acts as a go-between for client systems and Red Hat Network (or an RHN Satellite Server). Only the package ﬁles are stored on the RHN Proxy Server. Every transaction is authenticated, and the Red Hat Update Agent checks the GPG signature of each package retrieved from the local RHN Proxy Server.

In addition to storing ofﬁcial Red Hat packages, the RHN Proxy Server can be conﬁgured to deliver an organization’s own custom packages from private RHN channels, using the RHN Package Manager. For instance, an organization could develop its own software, package it in an RPM, sign it with its own GPG signature, and have the local RHN Proxy Server update all the individual systems in the network with the latest versions of the custom software.

Advantages of using RHN Proxy Server include:

• Scalability — there can be multiple local RHN Proxy Servers within one organization.

• Security — an end-to-end secure connection is maintained: from the client systems, to

the local RHN Proxy Server, to the Red Hat Network servers.

• Saves time — packages are delivered signiﬁcantly faster over a local area network than

the Internet.

• Saves bandwidth — packages are downloaded from the RHN File servers only once (per

local Proxy Server’s caching mechanism) instead of downloading each package to each client system.

• Saves disk space on individual systems — one large disk array is required instead of

extra disk space on all the client systems.

• Customized updates — create a truly automated package delivery system for custom

software packages, as well as ofﬁcial Red Hat packages required for the client systems. Custom private RHN channels allow an organization to automate delivery of in-house packages.

• Customized conﬁguration — restrict or grant updates to speciﬁc architectures and OS

versions.

• Only one Internet connection required — the client systems connect only through the

HTTP-enabled Proxy Server and therefore do not need a connection to the external network (Internet), but only require access to the Local Area Network to which the RHN Proxy Server is connected. Only the RHN Proxy Server needs an Internet connection to contact the RHN Servers, unless the RHN Proxy Server is using a RHN Satellite Server, in which case only the RHN Satellite Server requires an Internet connection.

1. Throughout this document, replace RHN Server with RHN Satellite Server if the RHN Proxy

Server connects to a RHN Satellite Server instead.

Chapter 1. Introduction 3

1.3. Terms to Understand

Before understanding RHN Proxy Server, it is important to become familiar with the following Red Hat Network terms:

•

Channel — A channel is a list of software packages. There are two types of channels: base channels and child channels. A base channel consists of a list of packages based on a speciﬁc architecture and Red Hat release. A child channel is a channel associated with a base channel but contains extra packages.

•

Organization Administrator — Organization Administrator is a user role with the highest level of control over an organization’s Red Hat Network account. Members with this role can add other users, other systems, and system groups to the organization, as well as remove them. A Red Hat Network organization must have at least one Organization Administrator.

•

Channel Administrator — A Channel Administrator is a user role with full access to channel management capabilities. Users with this role are capable of creating channels and assigning packages to channels. This role can be assigned by an Organization Administrator through the Users tab of the RHN website.

•

Red Hat Update Agent — The Red Hat Update Agent is the Red Hat Network client application (up2date) that allows users to retrieve and install new or updated packages for the client system on which the application is run.

•

Traceback — A traceback is a detailed description of "what went wrong" that is useful for troubleshooting the RHN Proxy Server. Tracebacks are automatically generated when a critical error occurs and are mailed to the individual(s) designated in the RHN Proxy Server’s conﬁguration ﬁle.

For more detailed explanations of these terms and others, refer to the Red Hat Network Reference Guide available at http://www.redhat.com/docs/.

1.4. How it Works

The Red Hat Update Agent on the client systems does not directly contact a Red Hat Network Server. Instead, the client (or clients) connects to an RHN Proxy Server that connects to the Red Hat Network Servers or to a RHN Satellite Server. Thus, the client systems do not need direct access to the Internet. They need access only to the RHN Proxy Server.

4 Chapter 1. Introduction

Important

Red Hat strongly recommends that clients connected to RHN Proxy Server be running the latest update of Red Hat Enter prise Linux to ensure proper connectivity.

By default, a client is authenticated directly by Red Hat Network Servers. Using an RHN Proxy Server, authentication works similarly except that the RHN Proxy Server provides route information as well. After a successful authentication, the Red Hat Network Server informs the RHN Proxy Server that it is permitted to execute a speciﬁc action for the client. The RHN Proxy Server downloads all of the updated packages (if they are not already present in its cache) and delivers them to the client system.

Requests from the Red Hat Update Agent on the client systems are still authenticated on the server side, but package delivery is signiﬁcantly faster since the packages are cached in the HTTP Proxy Caching Server or the RHN Proxy Server (for local packages); the RHN Proxy Server and client system are connected via the LAN and are limited only by the speed of the local network.

Authentication is done in the following order:

1. The client performs a login action at the beginning of a client session. This login is passed through one or more RHN Proxy Servers until it reaches a Red Hat Network Server.

2. The Red Hat Network Server attempts to authenticate the client. If authentication is successful, the server then passes back a session token via the chain of RHN Proxy Servers. This token, which has a signature and expiration, contains user information, including subscribe-to channels, username, etc.

3. Each RHN Proxy Server caches this token on its local ﬁle system in

/var/cache/rhn/. Caching reduces some of the overhead of authenticating with

Red Hat Network Servers and greatly improves the performance of Red Hat Network.

4. This session token is passed back to the client machine and is used in subsequent actions on Red Hat Network.

From the client’s point of view, there is no difference between an RHN Proxy Server and a Red Hat Network Server. From the Red Hat Network Server’s point of view, an RHN Proxy Server is a special type of RHN client. Clients are thus not affected by the route a request takes to reach a Red Hat Network Server. All the logic is implemented in the RHN Proxy Servers and Red Hat Network Servers.

Optionally the RHN Package Manager can be installed and conﬁgured to serve custom packages written speciﬁcally for the organization. These are not ofﬁcial Red Hat packages. After creating a private RHN channel, the custom RPM packages are associated with the private channel by uploading the package headers to the RHN Servers. Only the headers are uploaded, not the actual package ﬁles. The headers are required because they

Chapter 1. Introduction 5

contain crucial RPM information, such as software dependencies, that allows RHN to automate package installation. The actual custom RPM packages are stored on the RHN Proxy Server and sent to the client systems from inside the organization’s local area network.

Conﬁguring a computer network to use RHN Proxy Servers is straightforward. The Red Hat Network applications on the client systems must be conﬁgured to connect to the RHN Proxy Server instead of the Red Hat Network Servers. Refer to the RHN Client Conﬁgu- ration Guide for details. On the proxy side, one has to specify the next proxy in the chain (which will eventually end with a Red Hat Network Server). If the RHN Package Manager is used, the client systems must be subscribed to the private RHN channel.

6 Chapter 1. Introduction

Chapter 2. Requirements

These requirements must be met before installation. To install RHN Proxy Server version

3.6 or later from RHN Satellite Server, the Satellite itself must be version 3.6 or later.

2.1. Software Requirements

To perform an installation, the following software-related components must be available:

• Base operating system — RHN Proxy Server is supported with Red Hat Enterprise

Linux AS 3 Update 5 or later, or Red Hat Enterprise Linux AS 4 only. The operating system can be installed from disc, local ISO image, kickstart, or any of the methods supported by Red Hat.

Important

If you plan to obtain Monitoring-level service, you must install your RHN Proxy Server on Red Hat Enterprise Linux AS 3 Update 5 or Red Hat Enterprise Linux AS 4. These are the only supported base operating systems for Proxies serving Monitoring-entitled systems.

Each version of Red Hat Enterprise Linux AS requires a certain package set to support RHN Proxy Server. Anything more can cause errors during installation. Therefore, Red Hat recommends obtaining the desired package set in the following ways:

Note

For kickstarting either Red Hat Enterprise Linux AS 4 or Red Hat Enterprise Linux AS 3 Update 5, specify the following package group: @ Base

For installing Red Hat Enterprise Linux AS 4 or Red Hat Enterprise Linux AS 3 Update 5 via CD or ISO image, select the following package group: Minimal

Warning

Security-enhanced Linux (SELinux) must be disabled in Red Hat Enterprise Linux AS 4 prior to installation of RHN Proxy Server. To do this during CD or ISO image installation, select Disabled when presented with options for SELinux support. To do this

8 Chapter 2. Requirements

for kickstart installation, include the command selinux --disabled or wait for the install to complete, edit the /etc/selinux/config ﬁle to read SELINUX=disabled and reboot the system.

• An available RHN Proxy Server entitlement within your Red Hat Network account.

• An available Provisioning entitlement within your Red Hat Network account (which

should come packaged with your RHN Proxy Server entitlement).

• Access to the Red Hat Network Tools channel for the installed version of Red Hat En-

terprise Linux AS.

• All rhncfg* packages installed on the Proxy (from the RHN Tools channel).

• Either the rhns-certs-tools package installed on the Proxy (from the RHN Tools

channel) or the secure sockets layer (SSL) CA certiﬁcate password used to generate the parent server certiﬁcate (such as on an RHN Satellite Server).

• Conﬁguration of the system to accept remote commands and conﬁguration management

through Red Hat Network. Refer to Section 4.2 RHN Proxy Server Installation Process for instructions.

2.2. Hardware Requirements

The following hardware conﬁguration is required for the RHN Proxy Server:

• Pentium III processor, 1.26GHz, 512K cache or equivalent

• 512 MB of memory

• 3 GB storage for base install of Red Hat Enterprise Linux AS

• 6 GB storage per distribution/channel

The load on the Apache HTTP Server is directly related to the frequency with which client systems connect to the Proxy, so if you reduce the default interval of four hours (or 240 minutes) as set in the /etc/sysconfig/rhn/rhnsd conﬁguration ﬁle of the client systems, you will increase the load on this component signiﬁcantly.

2.3. Disk Space Requirements

The caching mechanism used by RHN Proxy Server is the Squid HTTPproxy, which saves signiﬁcant bandwidth for the clients. It should have a reasonable amount of space available. The cached packages are stored in /var/spool/squid. The required free space allotment is 6 GB storage per distribution/channel.

If the RHN Proxy Server is conﬁgured to distribute custom, or local packages, make sure that the /var mount point on the system storing local packages has sufﬁcient disk space

Chapter 2. Requirements 9

to hold all of the custom packages, which are stored in /var/spool/rhn-proxy. The required disk space for local packages depends on the number of custom packages served.

2.4. Additional Requirements

The following additional requirements must be met before the RHN Proxy Server installation can be considered complete:

• Full Access

Client systems need full network access to the RHN Proxy Server services and ports.

• Firewall Rules

The RHN Proxy Server solution can be ﬁrewalled from the Internet, but it must be able to issue outbound connections to the Internet on ports 80 and 443. In addition, if the Proxy will be connected to an RHN Satellite Server that will be conﬁgured to push actions to client systems and the Proxy, you must allow inbound connections on port 5222.

• Synchronized System Times

There is great time sensitivity when connecting to a Web server running SSL (Secure Sockets Layer); it is imperative the time settings on the clients and server are reasonably close together so the SSL certiﬁcate does not expire before or during use. It is recommended Network Time Protocol (NTP) be used to synchronize the clocks.

• Fully Qualiﬁed Domain Name (FQDN)

The system upon which the RHN Proxy Server will be installed must resolve its own FQDN properly.

• A Red Hat Network Account

Customers who will be connecting to the central Red Hat Network Servers to receive incremental updates will need an account with Red Hat Network. This account should be set up at the time of purchase with the sales representative.

• Backups of Login Information

It is imperative customers keep track of all primary login information. For RHN Proxy Server, this includes usernames and passwords for the Organization Administrator account and SSL certiﬁcate generation. Red Hat strongly recommends this information be copied onto two separate ﬂoppy disks, printed out on paper, and stored in a ﬁreproof safe.

• Distribution Locations

Since the Proxy forwards virtually all local HTTP requests to the central RHN Servers, you must take care to put ﬁles destined for distribution (such as in a kickstart installation tree) in the non-forwarding location on the Proxy: /var/www/html/pub/. Files placed

10 Chapter 2. Requirements

in this directory can be downloaded directly from the Proxy. This can be especially useful for distributing GPG keys or establishing installation trees for kickstarts.

In addition, Red Hat recommends the system running the code not be publicly available. No users but the system administrators should have shell access to these machines. All unnecessary services should be disabled. You can use ntsysv or chkconfig to disable services.

Finally, you should have the following technical documents in hand for use in roughly this order:

1. The RHN Proxy Server Installation Guide — This guide, which you are now reading, provides the essential steps necessary to get an RHN Proxy Server up and running.

2. The RHN Client Conﬁguration Guide — This guide explains how to conﬁgure the systems to be served by an RHN Proxy Server or RHN Satellite Server. (This will also likely require referencing The RHN Reference Guide, which contains steps for registering and updating systems.)

3. The RHN Channel Management Guide — This guide identiﬁes in great detail the recommended methods for building custom packages, creating custom channels, and managing private Errata.

4. The RHN Reference Guide — This guide describes how to create RHN accounts, register and update systems, and use the RHN website to its utmost potential. This guide will probably come in handy throughout the installation and conﬁguration process.

Chapter 3. Example Topologies

The RHN Proxy Server can be conﬁgured in multiple ways. Select one method depending on the following factors:

1. The total number of client systems to be served by the

2. The maximum number of clients expected to connect concurrently to the RHN Proxy Server.

3. The number of custom packages and channels to be served by the RHN Proxy Server.

4. The number of RHN Proxy Servers being used in the customer environment.

The rest of this chapter describes possible conﬁgurations and explains their beneﬁts.

3.1. Single Proxy Topology

The simplest conﬁguration is to use a single RHN Proxy Server to serve your entire network. This conﬁguration is adequate to service a small group of clients and a network that would beneﬁt from caching Red Hat RPMs and storing custom packages on a local server.

The disadvantage of using one RHN Proxy Server is that performance will be compromised as the number of clients requesting packages grows.

Figure 3-1. Single Proxy Topology

12 Chapter 3. Example Topologies

3.2. Multiple Proxy Horizontally Tiered Topology

For larger networks, a more distributed method may be needed, such as having multiple RHN Proxy Servers all connecting to Red Hat Network individually. This horizontally tiered conﬁguration balances the load of client requests while enabling each Proxy to simultaneously synchronize with RHN.

A disadvantage of this horizontal structure is that custom packages loaded to an individual Proxy must be distributed to its sibling servers. This situation can be addressed in one of two ways:

• Either, the rsync ﬁle transfer program can be used to synchronize packages between the

Proxies, or

• a Network File System (NFS) share can be established between the Proxies and the

custom channel repository.

Either of these solutions will allow any client of any RHN Proxy Servers to have all custom packages delivered to them.

Figure 3-2. Multiple Proxy Horizontally Tiered Topology

3.3. Multiple Proxy Vertically Tiered Topology

An alternative method for multiple RHN Proxy Servers is to establish a primary Proxy that the others connect to for RPMs from Red Hat Network and custom packages created locally. In essence, the secondary Proxies act as clients of the primary. This alleviates the

Chapter 3. Example Topologies 13

need to establish synchronization between the RHN Proxy Servers as they use the up2date functionality inherent with the product.

Like the horizontally tiered conﬁguration, this vertical method allows any client of any RHN Proxy Servers to have all custom packages delivered to them. The Proxy merely looks in its repository to see if it can ﬁnd the package on its ﬁlesystem. If not, it then makes the attempt from the next level up.

This vertically tiered conﬁguration ensures the secondary Proxies depend upon the primary for updates from RHN, as well as for custom packages. Also, custom channels and packages must be placed on the primary Proxy only, to ensure distribution to the child Proxies. Finally, the conﬁguration ﬁles of the secondary Proxies must point to the primary, instead of directly at Red Hat Network.

Figure 3-3. Multiple Proxy Vertically Tiered Topology

3.4. Proxies with RHN Satellite Server

In addition to the methods described in detail within this chapter, customers also have the option of using RHN Proxy Server in conjunction with RHN Satellite Server. This works similarly to the vertically tiered Proxy conﬁguration but increases capacity signiﬁcantly, as Satellites can serve a much greater number of client systems.

For a thorough description of this combination, refer to the Example Topologies chapter of the RHN Satellite Server Installation Guide. Linking the two products’ SSL certiﬁcates is

14 Chapter 3. Example Topologies

described in the RHN Client Conﬁguration Guide. To ﬁnd out how channels and packages are shared between them, refer to the RHN Channel Management Guide.

Chapter 4. Installation

This chapter describes the initial installation of the RHN Proxy Server. It presumes the prerequisites listed in Chapter 2 Requirements have been met. However, if you are upgrading to a newer version of RHN Proxy Server, contact your Red Hat representative for assistance.

4.1. Base Install

The RHN Proxy Server is designed to run on the Red Hat Enterprise Linux AS operating system. Therefore, the ﬁrst phase is to install the base operating system, either from disc, ISO image, or kickstart. During and after operating system installation, make sure you:

• Allocate plenty of space to the partition that will be used to store packages, according

to the hardware requirements set forth earlier. The default location for cached Red Hat packages is /var/spool/squid, while custom packages are located in

/var/spool/rhn-proxy.

• Install the packages required by RHN Proxy Server and only those packages. You must

install only the base packages as others will cause the RHN Proxy Server installation to fail Refer to Section 2.1 Software Requirements for the method to obtain the correct

package group needed for each version of Red Hat Enterprise Linux AS.

Important

• Enable Network Time Protocol (NTP) on the Proxy and select the appropriate time zone.

All client systems should already be running the ntpd daemon and be set to the correct time zone.

• Disable the ipchains and iptables services after installation.

4.2. RHN Proxy Server Installation Process

The following instructions describe the RHN Proxy Server installation process:

16 Chapter 4. Installation

1. Register the newly installed Red Hat Enterprise Linux AS system with Red Hat Network (either the central RHN Servers or your RHN Satellite Server) using the organizational account containing the RHN Proxy Server entitlement with the command:

up2date --register.

2. Grant the system a Provisioning entitlement by visiting the RHN Website (or the fully qualiﬁed domain name of the Satellite serving the Proxy), logging in as the Organization Administrator, navigating to the Systems ⇒ System Entitlements page, checking the box of system on which the RHN Proxy Server is to be installed and clicking the Add Provisioning button.

3. Ensure the system is subscribed to the Red Hat Network Tools channel for its base operating system by clicking the name of the system and navigating to the System ⇒ System Details ⇒ Channels ⇒ Software subtab. If the Red Hat Network Tools channel is not selected, please select it and subscribe the system to this channel by clicking on the Change Subscriptions button.

4. Install all the rhncfg packages by navigating to the System ⇒ System Details ⇒

Packages ⇒ Install subtab and searching for rhncfg using the Filter by Package Name text search box. In the resulting list, select all the packages and install them.

5. If you will be enabling secure sockets layer (SSL) encryption on the Proxy and connecting to the central RHN Servers, install the rhns-certs-tools package from the same Red Hat Network Tools channel and use the RHN SSL Maintenance Tool to generate the tar ﬁle required later. Refer to the SSL Certiﬁcates chapter of the RHN Client Conﬁguration Guide for instructions.

If you will be enabling SSL encryption on the Proxy and connecting to an RHN Satellite Server or another RHN Proxy Server with SSL, you will also need the CA certiﬁcate password used for the parent system.

6. Log into the system through a terminal as root and run the rhn_check command to immediately initiate the scheduled package installation.

7. Once the packages have been installed, as conﬁrmed through the System Details ⇒ Events tab, prepare the system to accept remote commands and conﬁguration management with the following command:

/usr/bin/rhn-actions-control --enable-all

8. Within the RHN website, navigate to the System Details ⇒ Proxy subtab.

Warning

Please note the RHN Proxy Server installation may replace the squid.conf and

httpd.conf conﬁguration ﬁles on the system to ease upgrades later. If you have

edited these ﬁles and want to preserve them, they are rotated in place and can be retrieved after installation.

Chapter 4. Installation 17

Figure 4-1. System Details ⇒ Proxy

9. In the System Details ⇒ Proxy subtab, the pulldown menu should indicate your ability to activate the system as an RHN Proxy Server. Ensure the version is properly selected and click the Activate Proxy button. The Welcome page of the installation appears.

18 Chapter 4. Installation

Figure 4-2. Welcome

10. In the Welcome page, you will ﬁnd notiﬁcation of any requirements not met by the system. When the system is ready, a continue link appears. Click it to go to the

Terms & Conditions page.

Chapter 4. Installation 19

Figure 4-3. Terms & Conditions

11. In the Terms & Conditions page, click the terms and conditions link to view the licensing agreement of the RHN Proxy Server. When satisﬁed, click the I agree link. The Enable Monitoring page appears next.

20 Chapter 4. Installation

Figure 4-4. Enable Monitoring

12. In the Enable Monitoring page, you must decide whether the Proxy will be used to monitor systems served by it. For this to take place, the RHN Proxy Server must meet the requirements identiﬁed in Chapter 2 Requirements and be connected to an RHN Satellite Server (or another Proxy connected to a Satellite). To enable monitoring on the Proxy, select the checkbox and click continue. The Conﬁgure RHN Proxy

Server page appears.

Chapter 4. Installation 21

Figure 4-5. Conﬁgure RHN Proxy Server

13. In the Conﬁgure RHN Proxy Server page, provide or conﬁrm the entries for all required ﬁelds. The Administrator Email Address will receive all mail generated by the Proxy, including sometimes large quantities of error-related tracebacks. To stem this ﬂow, consider establishing mail ﬁlters that capture messages with a subject of "RHN TRACEBACK from hostname". To list more than one administrator, enter a comma-separated list of email addresses.

The RHN Proxy Hostname is the fully qualiﬁed domain name (FQDN) of the RHN Proxy Server. The RHN Parent Server is the domain name of the server serving the Proxy, either the central RHN Servers, another RHN Proxy Server or an RHN Satellite Server. To connect to the central RHN Servers, include the value xmlrpc.rhn.redhat.com. To connect to a Satellite or another Proxy, enter the parent system’s FQDN.

22 Chapter 4. Installation

If the RHN Proxy Server will connect through an HTTP proxy, conﬁgure it using the associated ﬁelds. Note that references to protocol, such as http:// or https:// should not be included in the HTTP Proxy Server ﬁeld. Insert only the hostname and port in the form hostname:port, such as my.corporate.gateway.example.com:3128.

Tip

The installation process affects only the Proxy conﬁguration ﬁle:

/etc/rhn/rhn.conf. The Red Hat Update Agent (up2date) conﬁguration ﬁle, /etc/sysconfig/rhn/up2date, must be updated manually to receive its updates

from another server, such as an RHN Satellite Server.

Finally, you must decide whether to enable SSL using the checkbox at the bottom. Red Hat strongly recommends you employ this level of encryption for all trafﬁc to and from the RHN Proxy Server. To select it, however, you must be connecting to the central RHN Servers (which have SSL enabled by default) or to an RHN Satellite Server or RHN Proxy Server that has SSL enabled. Connection to the central RHN Servers requires upload of the certiﬁcate tar ﬁle mentioned earlier. Connection to a Satellite or another Proxy through SSL requires the CA certiﬁcate password used in enabling SSL on the parent system.

If you will not enable SSL during installation, leave this box unchecked and refer to the SSL Certiﬁcates chapter of the RHN Client Conﬁguration Guide to learn how to obtain this level of security post install. When ﬁnished, click continue. If you enabled SSL and are connecting to a Satellite or another Proxy, the Conﬁgure SSL page appears. If you enabled SSL and are connecting to the central RHN servers, the Upload SSL page appears. If you did not enable SSL but did enable Monitoring, skip to the description of the Conﬁgure Monitoring page. If you did not enable SSL or Monitoring, skip to the description of the Install Progress page.

Chapter 4. Installation 23

Figure 4-6. Conﬁgure SSL

14. In the Conﬁgure SSL page applicable only to a Proxy connecting to an RHN Satellite Server or another RHN Proxy Server with SSL enabled, provide the information

needed to generate the server certiﬁcate. The most important item is the CA certiﬁcate password, which must match the password used while enabling SSL on the parent server. The remaining ﬁelds may match the parent server’s values but can differ depending on the role of the RHN Proxy Server, for instance reﬂecting a different geographic location. Similarly, the email address can be the same one provided earlier for the Proxy administrator but can be directed to a particular certiﬁcate administrator. Certiﬁcate expiration is conﬁgurable. As always, ensure the values provided here exist in the backups of information described in Chapter 2 Requirements. Once ﬁnished, click continue.

24 Chapter 4. Installation

Figure 4-7. Upload SSL

In the Upload SSL page applicable only to a Proxy connecting to the central RHN Servers, locate the tar ﬁle created using the RHN

SSL Maintenance Tool using the Browse button. It will be named

rhn-org-httpd-ssl-archive-MACHINENAME-VERSION .tar with the

machine name reﬂecting the Proxy’s hostname. Once located, click continue.

Note

Since you must be root to generate the SSL key, the resulting SSL tar ﬁle will be located in /root/ssl-build/HOSTNAME/. This ﬁle will not be visible to a non-root user, therefore you must copy the ﬁle to a location visible to the user running the browser.

Chapter 4. Installation 25

Figure 4-8. Conﬁgure Monitoring

15. In the Conﬁgure Monitoring page, provide or conﬁrm the hostname and IP address of the parent server connected to by the RHN Proxy Server. This must be either an RHN Satellite Server or another Proxy which is in turn connected to a Satellite. You cannot achieve Monitoring through the central RHN Servers. When ﬁnished, click

continue. The Install Progress page appears.

Figure 4-9. Install Progress

26 Chapter 4. Installation

16. In the Install Progress page, you may monitor the steps of the installation as they take place. Click the link to any step to go to its Action Details page. When a step has been undertaken, its status goes from Queued to Picked Up and then ﬁnally to Completed. Like the earlier package installs, you can immediately trigger these steps by running the rhn_check command in a terminal on the system as root. When ﬁnished, the Install Progress page will display the message The installation

is complete. You may now begin registering systems to be served by the RHN

Proxy Server. Refer to the RHN Client Conﬁguration Guide.

Chapter 5. RHN Package Manager

The RHN Package Manager is a command line tool that allows an organization to serve local packages associated with a private RHN channel through the RHN Proxy Server. If you want the RHN Proxy Server to update only ofﬁcial Red Hat packages, you do not need to install the RHN Package Manager.

To use the RHN Package Manager, install the rhns-proxy-package-manager package and its dependencies.

Only the header information for packages is uploaded to the RHN Servers. The headers are required so that RHN can resolve package dependencies for the client systems. The actual package ﬁles (*.rpm) are stored on the RHN Proxy Server.

The RHN Package Manager uses the same settings as the Proxy, deﬁned in the

/etc/rhn/rhn.conf conﬁguration ﬁle.

5.1. Creating a Private Channel

Before local packages can be provided through the RHN Proxy Server, a private channel is needed to store them. Perform the following steps to create a private channel:

1. Log in to the RHN Web interface at https://rhn.redhat.com.

2. Click Channels on the top navigation bar. If the Manage Channels option is not

present in the left navigation bar, ensure this user has channel editing permissions set. Do this through the Users category accessible through the top navigation bar.

3. In the left navigation bar, click Manage Software Channels and then the create new channel button at the top-right corner of the page.

4. Select a parent channel and base channel architecture, then enter a name, label, summary, and description for the new private channel. The channel label must: be at least six characters long, begin with a letter, and contain only lowercase letters, digits, dashes (-), and periods(.). Also enter the URL of the channel’s GPG key. Although this ﬁeld isn’t required, it is recommended to enhance security. For instructions on generating GPG keys, refer to the RHN Channel Management Guide.

5. Click Create Channel.

28 Chapter 5. RHN Package Manager

5.2. Uploading Packages

Note

You must be an Organization Administrator to upload packages to private RHN channels. The script will prompt you for your RHN username and password.

After creating the private channel, upload the package headers for your binary and source RPMs to the RHN Server and copy the packages to the RHN Proxy Broker Server. To upload the package headers for the binary RPMs, at the command line:

rhn_package_manager -c "label_of_private_chann el" pkg-list

pkg-list is the list of packages to be uploaded. Alternatively, use the -d option to specify

the local directory that contains the packages to add to the channel. Ensure the directory contains only the packages to be included and no other ﬁles. RHN Package Manager can also read the list of packages from standard input (using --stdin).

To upload the package headers for the source RPMs:

rhn_package_manager -c "label_of_private_chann el" --source pkg-list

If you have more than one channel speciﬁed (using -c or --channel), the uploaded package headers will be linked to all the channels listed.

Note

If a channel name is not speciﬁed, the packages are not added to any channel. The packages can then be added to a channel using the Red Hat Network Web interface. The interface can also be used to modify existing private channels.

After uploading the packages, you can immediately check the RHN Web interface to verify their presence. Click Channels in the top navigation bar, Manage Software Channels in the left navigation bar, and then the name of the custom channel. Then click the Packages subtab. Each RPM should be listed.

You can also check to see if the local directory is in sync with the RHN Server’s image of the channels at the command line:

rhn_package_manager -s -c "label_of_private_channel"

Chapter 5. RHN Package Manager 29

This -s option will list all the missing packages (packages uploaded to the RHN Server not present in the local directory). You must be an Organization Administrator to use this command. The script will prompt you for your RHN username and password. Refer to Table 5-1 for additional command line options.

If you are using the RHN Package Manager to update local packages, you must go to the RHN website to subscribe the system to the private channel.

5.3. Command Line Options

A summary of all the command line options for RHN Package Manager

rhn_package_manager:

Option Description

-v, --verbose Increase verbosity.

-dDIR, --dir=DIR Process packages from directory DIR.

-cCHANNEL,

--channel=CHANNEL

-nNUMBER, --count=NUMBER Process this number of headers per call — the

-l, --list List each package name, version number, release

-s, --sync Check if local directory is in sync with the server.

-p, --printconf Print the current conﬁguration and exit.

-XPATTERN ,

--exclude=PATTERN

--newest Push only the packages that are newer than

--stdin Read the package names from stdin.

--nosig Push unsigned packages. By default the RHN

--username=USERNAME Specify your RHN username. If you do not provide

Manage this channel — may be present multiple times.

default is 32.

number, and architecture in the speciﬁed channel(s).

Exclude ﬁles matching this glob expression — can be present multiple times.

packages already pushed to the server for the speciﬁed channel.

Package Manager attempts to push only signed packages.

one with this option, you will be prompted for it.

30 Chapter 5. RHN Package Manager

Option Description

--password=PASSWORD Specify your RHN password. If you do not provide

one with this option, you will be prompted for it.

--source Upload source package headers.

--dontcopy In the post-upload step, do not copy the packages to

their ﬁnal location in the package tree.

--test Only print the packages to be pushed.

--no-ssl Not recommended — Turn off SSL.

-?, --usage Brieﬂy describe the options.

--copyonly Copies the ﬁle listed in the argument into the

speciﬁed channel. Useful when a channel on the proxy is missing a package and you don’t want to reimport all of the packages in the channel. E.g.,

rhn_package_manager -cCHANNEL

--copyonly /PATH/TO/MISSING/FILE

-h, --help Display the help screen with a list of options.

Table 5-1. rhn_package_manager options

Tip

These command line options are also described in the rhn_package_manager man page:

man rhn_package_manager.

Chapter 6. Troubleshooting

This chapter provides tips for determining the cause of and resolving the most common errors associated with RHN Proxy Server. If you need additional help, contact Red Hat Network support at https://rhn.redhat.com/help/contact.pxt. Log in using your Satelliteentitled account to see your full list of options.

6.1. Managing the Proxy Service

Since the RHN Proxy Server consists of a multitude of individual components, Red Hat provides a master service, rhn-proxy, that allows you to stop, start, or retrieve status from the various services in the appropriate order. This helper service accepts all of the typical commands:

service rhn-proxy start service rhn-proxy stop service rhn-proxy restart service rhn-proxy status

Use the rhn-proxy service to shut down and bring up the entire RHN Satellite Server and retrieve status messages from all of its services at once.

6.2. Log Files

Virtually every troubleshooting step should start with a look at the associated log ﬁle or ﬁles. These ﬁles provide invaluable information about the activity that has taken place on the device or within the application and can be used to monitor performance and ensure proper conﬁguration. See Table 6-1 for the paths to all relevant log ﬁles:

Component Log File Location

Apache HTTP Server /var/log/httpd/ directory

Squid /var/log/squid/ directory

RHN Proxy Broker Server /var/log/rhn/rhn_proxy_broker.log

RHN SSL Redirect Server /var/log/rhn/rhn_proxy_redirect.log

32 Chapter 6. Troubleshooting

Component Log File Location

Red Hat Update Agent /var/log/up2date

Table 6-1. Log Files

6.3. Questions and Answers

This section contains the answers to the most frequently asked questions regarding installing and conﬁguring an RHN Proxy Server solution.

1. After conﬁguring the RHN Package Manager how can I determine if the local packages were successfully added to the private RHN channel?

Use the command rhn_package_manager -l -c "name_of_private_channel" to list the private channel packages known to the RHN Servers. Or visit the RHN Web interface.

After subscribing a registered system to the private channel, you can also execute the command up2date -l --showall on the registered system and look for the packages from the private RHN channel.

2. How can I determine whether the clients are connecting to the Squid server?

The /var/log/squid/access.log ﬁle logs all connections to the Squid server.

3. The Red Hat Update Agent on the client systems will not connect through the RHN Proxy Server. How can I resolve this error?

Make sure the latest version of the Red Hat Update Agent is installed on the client systems. The latest version contains features necessary to connect through an RHN Proxy Server. The latest version can be obtained through the Red Hat Network or from http://www.redhat.com/support/errata/. Also, be advised that since the RHN Proxy Server acts as a caching mechanism for RHN, the httpProxy setting in /etc/sysconfig/rhn/up2date on client systems is redundant and probably unnecessary.

The RHN Proxy Server is an extension of Apache. See Table 6-1 for its log ﬁle location.

4. My RHN Proxy Server conﬁguration does not work. Where do I begin troubleshooting it?

Make sure /etc/sysconfig/rhn/systemid is owned by root.apache with the permissions 0640.

Read the log ﬁles. A list is available at Table 6-1.

Chapter 6. Troubleshooting 33

6.4. General Problems

To begin troubleshooting general problems, examine the log ﬁle or ﬁles related to the component exhibiting failures. A useful exercise is to tail all log ﬁles and then run up2date

--list. You should then examine all new log entries for potential clues.

A common issue is full disk space. An almost sure sign of this is the appearance of halted writing in the log ﬁles. If logging stopped during a write, such as mid-word, you likely have ﬁlled disks. To conﬁrm this, run this command and check the percentages in the Use% column:

df -h

In addition to log ﬁles, you can obtain valuable information by retrieving the status of your various components. This can be done for the Apache HTTP Server and Squid.

To obtain the status of the Apache HTTP Server, run the command:

service httpd status

To obtain the status of Squid, run the command:

service squid status

If the administrator isn’t getting email from the RHN Proxy Server, conﬁrm the correct email addresses have been set for traceback_mail in /etc/rhn/rhn.conf.

6.5. Host Not Found/Could Not Determine FQDN

Because RHN conﬁguration ﬁles rely exclusively on fully qualiﬁed domain names (FQDN), it is imperative key applications are able to resolve the name of the RHN Proxy Server into an IP address. Red Hat Update Agent, Red Hat Network Registration Client, and the Apache HTTP Server are particularly prone to this problem with the RHN applications issuing errors of "host not found" and the Web server stating "Could not determine the server’s fully qualiﬁed domain name" upon failing to start.

This problem typically originates from the /etc/hosts ﬁle. You may conﬁrm this by examining /etc/nsswitch.conf, which deﬁnes the methods and the order by which domain names are resolved. Usually, the /etc/hosts ﬁle is checked ﬁrst, followed by Network Information Service (NIS) if used, followed by DNS. One of these has to succeed for the Apache HTTP Server to start and the RHN client applications to work.

To resolve this problem, identify the contents of the /etc/hosts ﬁle. It may look like this:

34 Chapter 6. Troubleshooting

127.0.0.1 this_machine.example.com this_machine localhost.localdomain \ localhost

First, in a text editor, remove the offending machine information, like so:

127.0.0.1 localhost.localdomain.com localhost

Then, save the ﬁle and attempt to re-run the RHN client applications or the Apache HTTP Server. If they still fail, explicitly identify the IP address of the Proxy in the ﬁle, such as:

127.0.0.1 localhost.localdomain.com localhost

123.45.67.8 this_machine.example.com this_machine

Replace the value here with the actual IP address of the Proxy. This should resolve the problem. Keep in mind, if the speciﬁc IP address is stipulated, the ﬁle will need to be updated when the machine obtains a new address.

6.6. Connection Errors

If your are experiencing problems that you believe to be related to failed connections, follow these measures:

• Conﬁrm the correct package:

rhn-org-httpd-ssl-key-pair-MACHINE_NA ME-VER-REL.noarch.rpm

is installed on the RHN Proxy Server and the corresponding

rhn-org-trusted-ssl-cert-*.noarch.rpm or raw CA SSL public (client)

certiﬁcate is installed on all client systems.

• Verify the client systems are conﬁgured to use the appropriate certiﬁcate.

• If using one or more RHN Proxy Servers, ensure each Proxy’s SSL certiﬁcate is prepared

correctly. If using the RHN Proxy Server in conjunction with an RHN Satellite Server the Proxy should have both its own server SSL key-pair and CA SSL public (client) certiﬁcate installed, since it will serve in both capacities. Refer to the SSL Certiﬁcates chapter of the RHN Client Conﬁguration Guide for speciﬁc instructions.

• If the RHN Proxy Server is connecting through an HTTP Proxy, make sure the URL

listed is valid. For instance, the HTTP Proxy URL ﬁeld should not contain references to protocols, such as http:// or https://. Only the hostname and port should be included in the form hostname:port, such as corporate_gateway.example.com:8080.

• Make sure client systems are not using ﬁrewalls of their own blocking required ports, as

identiﬁed in Section 2.4 Additional Requirements.

Chapter 6. Troubleshooting 35

6.7. Caching Issues

If package delivery fails or an object appears to be corrupt, and it isn’t related to connection errors, you should consider clearing the caches. The RHN Proxy Server has two caches you should be concerned with: one for Squid and the other for authentication.

The Squid cache is located in /var/spool/squid/. To clear it, stop the Apache HTTP Server and Squid, delete the contents of that directory, and restart both services. Issue these commands in this order:

service httpd stop service squid stop rm -fv /var/spool/squid/* service squid start service httpd start

You may accomplish the same task more quickly by just clearing the directory and restarting squid, but you will likely receive a number of RHN traceback messages.

The internal caching mechanism used for authentication by the Proxy may also need its cache cleared. To do this, issue the following command:

rm -fv /var/cache/rhn/*

Although the RHN Authentication Daemon was deprecated with the release of RHN Proxy Server 3.2.2 and replaced with the aforementioned internal authentication caching mechanism, the daemon may still be running on your Proxy. To turn it off, issue the following individual commands in this order:

chkconfig --level 2345 rhn_auth_cache off service rhn_auth_cache stop

To clear its cache, issue:

rm /var/up2date/rhn_auth_cache

If you must retain the RHN Authentication Daemon, which Red Hat recommends against and does not support, note that its performance can suffer from verbose logging. For this reason, its logging (to /var/log/rhn/rhn_auth_cache.log) is turned off by default. If you do run the daemon and desire logging, turn it back on by adding the following line to the Proxy’s /etc/rhn/rhn.conf ﬁle:

auth_cache.debug = 2

36 Chapter 6. Troubleshooting

6.8. Proxy Debugging by Red Hat

If you’ve exhausted these troubleshooting steps or want to defer them to Red Hat Network professionals, Red Hat recommends you take advantage of the strong support that comes with RHN Proxy Server. The most efﬁcient way to do this is to aggregate your Proxy’s conﬁguration parameters, log ﬁles, and database information and send this package directly to Red Hat.

RHN provides a command line tool explicitly for this purpose: The RHN Proxy Diag- nostic Info Gatherer, commonly known by its command rhn-proxy-debug. To use this tool, simply issue that command as root. You will see the pieces of information collected and the single tarball created, like so:

[root@rhel-4 root]# rhn-proxy-debug Collecting and packaging relevant diagnostic information. Warning: this may take some time...

* copying configuration information * copying logs * querying RPM database (versioning of RHN Proxy, etc.) * get diskspace available * timestamping * creating tarball (may take some time): /tmp/rhn-proxy-debug.tar.b z2 * removing temporary debug tree

Debug dump created, stored in /tmp/rhn-proxy-debug.tar.bz2 Deliver the generated tarball to your RHN contact or support channel.

Once ﬁnished, email the new ﬁle from the /tmp/ directory to your Red Hat representative for immediate diagnosis.

Appendix A.

Sample RHN Proxy Server Conﬁguration File

The /etc/rhn/rhn.conf conﬁguration ﬁle for the RHN Proxy Server provides a means for you to establish key settings. Be warned, however, that errors inserted into this ﬁle may cause Proxy failures. Make conﬁguration changes with caution.

If you are also using an RHN Satellite Server, you should be particularly concerned with the following parameters: traceback_mail and proxy.rhn_parent. Review the sample and its comments (beginning with a hash mark #), for additional details.

Note

You may add the use_ssl setting to rhn.conf for testing pur poses only. Set its value to 0 to turn off SSL between the Proxy and the upstream server temporarily. Note that this greatly compromises security. Return the setting to its default value of 1 to re-enable SSL, or simply remove the line from the conﬁguration ﬁle.

# Automatically generated RHN Management Proxy Server configuration file. # --------------------------------------------------------------------- ----

# SSL CA certificate location proxy.ca_chain = /usr/share/rhn/RHNS-CA-CERT

# Corporate HTTP proxy, format: corp_gateway.example.com:8080 proxy.http_proxy =

# Password for that corporate HTTP proxy proxy.http_proxy_password =

# Username for that corporate HTTP proxy proxy.http_proxy_username =

# Location of locally built, custom packages proxy.pkg_dir = /var/spool/rhn-proxy

# Hostname of RHN Server or RHN Satellite proxy.rhn_parent = rhn.redhat.com

# Destination of all tracebacks, etc. traceback_mail = user0@domain.com, user1@domain.com

38 Appendix A. Sample RHN Proxy Server Conﬁguration File

Index

additional requirements, 9

advantages, 2

authentication, 4

authentication caching

clearing, 35

caching issues, 35

channel, 3

creating a private channel, 27

channel administrator, 3

client conﬁguration

subscribe to private channel, 29

connection errors, 34

installation

base, 15 of RHN Proxy Server, 15

log ﬁles, 31

organization administrator, 3

private channel, 27

questions and answers, 32

disk space requirements, 8

general problems, 33

hardware requirements, 8

host now found error

could not determine FQDN, 33

how it works, 3

HTTP Proxy Caching Server

disk space requirements, 8

Red Hat Network

introduction, 1 Red Hat Update Agent, 3, 3 requirements, 7

additional, 9

disk space, 8

hardware, 8

software, 7 RHN Authentication Daemon, disabling

rhn_auth_cache, stopping, 35 RHN Package Manager, 4, 27

channels, specifying, 28

command line options, 29

conﬁguration ﬁle, 27

conﬁguring, 27

create private channel, 27

installing, 27

upload package headers, 28

verify local package list, 28

rhn-proxy

service, 31

rhn.conf

sample ﬁle, 37

rhn_package_manager, 28

(see RHN Package Manager)

satellite-debug, 36 software requirements, 7 squid caching, 35

terms to understand, 3 topologies, 11

multiple proxies horizontally tiered, 12 multiple proxies vertically tiered, 12 proxies with RHN Satellite Server, 13

single proxy, 11 traceback, 3 troubleshooting, 31

Redhat NETWORK PROXY SERVER 4.0 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

Chapter 1.

Introduction

1.1. Red Hat Network

1.2. RHN Proxy Server

1.3. Terms to Understand

1.4. How it Works

Chapter 2.

Requirements

2.1. Software Requirements

2.2. Hardware Requirements

2.3. Disk Space Requirements

2.4. Additional Requirements

Chapter 3.

Example Topologies

3.1. Single Proxy Topology

3.2. Multiple Proxy Horizontally Tiered Topology

3.3. Multiple Proxy Vertically Tiered Topology

3.4. Proxies with RHN Satellite Server

Chapter 4.

Installation

4.1. Base Install

4.2. RHN Proxy Server Installation Process

Chapter 5.

RHN Package Manager

5.1. Creating a Private Channel

5.2. Uploading Packages

5.3. Command Line Options

Chapter 6.

Troubleshooting

6.1. Managing the Proxy Service

6.2. Log Files

6.3. Questions and Answers

6.4. General Problems

6.5. Host Not Found/Could Not Determine FQDN

6.6. Connection Errors

6.7. Caching Issues

6.8. Proxy Debugging by Red Hat

Appendix A.

Index
