Page 1
TABLE
Assembly Instructions
MAX TOP LOAD: 80 lbs.
Page 2
TABLE
Please review all parts and hardware before disposing of any packaging.
Call Customer Service if missing hardware. Do not return to store/retailer.
Using a screw that is too long will cause damage. Before beginning assembly,
separate each type of screw. Carefully study the screw diagrams below. You may
receive extra hardware with your unit.
Parts List
A
TABLE
#2
Side Plate
(A)
Quantity of 1
Quantity of 8
#1
Quantity of 1
Table top
#3
Side Plate
(B) Quantity of 4
Quantity of 1
Allen Head Bolt
(C)
Quantity of 8
Flat Washer
“L” Connecting Strip
(D) Quantity of 1
Wrench
Page 3
TABLE
Assembly Instructions
Step 1
- Spread clean blanket or towel onto work surface
to prevent scratch damage to parts.
- Locate all parts in cartons. Be sure to check
packing materials carefully. Check against parts
list to insure all necessary parts and hardware
available for assembly.
- Place 1pc “L” connecting strip（B）to one of the
holes on the side plate, then insert the bolt（A）
through the flat washer（C）and the “L” connecting
strip（B）and use wrench（D）to tighten. Also place
1pc “L” connecting strip（B）to the other hole
against the side plate, then insert the bolt（A）
through the flat washer（C）and the “L” connecting
Step 2
Step 3
strip（B）to use wrench（D）to tighten.
- Let side plate #2 and side plate #3 cross place.
Please refer to left photo.
- Place table top on a clean blanket or towel, the
face is down.
-
Insert bolt (A) thru the flat washer（C）and “L”
connecting strip (B) on the side plate into screw
hole on the back of table top. Insert 4pcs bolt（A）
into 4 screw holes separately. Also use wrench
（D）to tighten.
Page 4
Parts Replacement Form
Step 4
- Finally, please turn over the table.
Customer Information
Name
Address
City/State/Zip Code
Phone Number
Please indicate where you purchased this item: Store/Website/Catalog
Please indicate color/size/style number:
Style No Parts Letter Parts Description Quantity Needed
Please immediately examine this product carefully. Any request for missing parts or damage replacement
must be received within 90 days of your receipt of the product. Replacement, if available, will be honored within
this time frame. Parts will not be available for items arriving fully assembled. We do not recommend modifying
product(s) and we are not responsible for any damages due to product modification(s).
If damages or missing
parts are not reported within 90 days of your receipt, we are under no obligation to provide parts or replacement
merchandise.
Please contact the retailer that you purchased from for returns.
