Red Barrel Studio W004927632 Assembly Instructions

Label Picture Description QTY (pc)

A Backrest 1

B

Chair Base With

Footrest

1

Assembly Instructions

Caution : You must read this before you proceed

Push Back Chair

Parts List

Page 1 of 9

C Front Leg 2

D Hind Leg 2

Label Picture Description QTY (pc)



Gasket 7

Hardwares List

Assembly Preparation

Before Beginning
Assembly:

Page 2 of 9

Step 1
Step 2

Assembly Steps

Parts Introduction

This product has multiple parts and may require up to some 30 minutes to
assemble. To give you an overview of the product parts, the above picture
is to help you put the various parts into perspective. Please read through
the instructions below to familiarise yourself with the parts and steps
before assembly.

Take out the Backrest(A) from the Chair Base with Footrest(B).

Front Facing

Backrest(A)

Front Legs(C)

Chair Base

With
Footrest(B)

C

D

1

Hind Legs(D)

A

B

A

Page 3 of 9

Step 3

Step 4

Place the Chair Base with Footrest(B) facedown on a clean,non-marring surface.
Open the non-woven bag and take out the Front Legs(C)，Hind Legs(D) and

Gasket(）.

Install the Front Leg(C) and Hind Leg (D) at the bottom of the Chair by
placing one Gasket() on the threaded stem.
Then insert threaded stem into the mounting postion at the corner of the
Chair.
Tighten by turning the Leg clockwise.Do not over tighten.
Repeat the same process to install the remaining two Legs.
Take care of the shape of the Legs and ensure they in the correct
postions.
Note: The use of Gaskets are OPTIONALand are especially useful to help
alleviate slight wobbleness. Some Legs may need more than one gasket
whilst some Legs may not need any.

C

D

A

Velcro

B

C

DBVelcro

C

D

A

Page 4 of 9

Step 5
Step 6

With assistance from your adult partner, hold up the Chair Backrest(A)
while standing behind the Chair.
Insert the small metal arms on the sides of the Chair Backrest(A)into the
prefabricated slide lock gadget on the Chair Base with Footrest(B)as
shown above.
Firmly but gently, push the Chair Backrest(A)downwards until the Chair
Backrest(A) is fully slotted and locked into position.

Smooth down the fabric flap on the Chair Backrest(A).
Run your hands down both sides of the flap,from top to bottom,allowing
the velcro tape to adhere to the flap under the seat of the Chair.

Velcro

Test for stability

Page 5 of 9

Step 7

Disassembly Note:open the flap on the Chair Backrest(A),use a
screwdriver(Don not use fingers) pressing outward on the metal ear on the
preattached Metal Bracket on one side of the Chair Base(B),with
assistance of you adult partner to keep the Chair Base(B) in place,pull out
the Chair Backrest(A) upward at the same time,repeat the same step for
another side.Then the Chair Backrest(A) can be taken out.

Make sure all parts are connected and securely locked into position.
Position Chair right side up and test for stability.
Your Chair is ready for use.
Caution: This Chair can only be used on a flat, level surface.

A

B

C

D

Velcro

Velcro

Page 6 of 9

Do not allow children to play on the chair.
Always leave the chair in an upright and closed position after use.
Keep hands and feet clear of the footrest mechanism and any gaps.
Just push it by your feet.
Don't sit any armrest of chair.

To get into a open position-To push the Chair Backrest

Sit into the seat.
The Chair Backrest will fall down and footrest will open when push the
Chair Backrest by your back.So do must put your feet on footrest well
when you push down the Chair Backrest.Open the trigger on the outside of
right armrest.
Use your body weight and push backwards into the seat into a fully
reclined position.

User Instructions.

Push Back Chair

Please read the Instruction Manual below carefully before use.

Supervise children,when in use of this Push Back Chair.

to get out of chair-move Seatback into Upright Position

Page 7 of 9

Tilt your body weight slightly forward and upwards.
The seat back will come up to an upright position.
Use your feet to push the footrest down.
The Chair will automatically lock when it is in the fully upright position.
Where necessary,use your arms help lift/push yourself out of the seat

Page 8 of 9

Page 9 of 9
