200701KE (B1-B3)
REVISION 1 : 01/09/2012
EASTERN KING SIZE BED
ASSEMBLY INSTRUCTIONS
COASTER FINE FURNITURE
www.coastercompany.com
PAGE 1 OF 4
REVISION 0 : 01/05/2009
Page 2
ITEM : ASSEMBLY INSTRUCTIONS
G
BED RAIL
2PCS
200701KE (B2)
200701KE (B1)
www.coastercompany.com
200701KE (B1-B3)
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior start of assembly.
3. Please follow attached instruction in the same sequence as numbered to assure fast & easy assembly.
Warning!
1. Don't attempt to repair or modify parts that are broken or defective. Please contact the store
immediately.
2. This product is for home use only and not intended for commercial establishment.
PARTS IDENTIFICATION
B1 (BOX 1) B3 (BOX 3)
A
B
C
B2 (BOX 2)
D
HEADBOARD
LEFT HEADBOARD LEG
RIGHT HEADBOARD LEG
FOOTBOARD
1PC
1PC
1PC
1PC
E
F
G
HB
D
BED SLAT
BED SLAT SUPPORT
WITH LEVELER
*FROM BOX 1
HEADBOARD
COMPLETE
*FROM BOX 2
FOOTBOARD
5PCS
10PCS
1PC
1PC
Z - B1 (BOX 1)
1
2
HARDWARE IDENTIFICATION
Z - B3 (BOX 3)
BOLT 6PCS
ALLEN WRENCH 1PC
PAGE 2 OF 4
3
SCREW 10PCS
Page 3
ITEM : 200701KE (B1-B3)
*
*BACK VIEW
*
*BACK VIEW
(B1) - BOX 1
STEP 1 STEP 2
Place headboard panel upside down on soft surface,
place the headboard leg on the correct position
Align and fasten headboard leg to headboard panel using
bolt and tighten with Allen wrench.
ASSEMBLY INSTRUCTIONS
I
F PURCHASE HEADBOARD ONLY, SKIP BELOW STEPS
(B1-B3) - BOX 1 to BOX 3
STEP 3
A
lign and hook the bed rails to headboard and footboard.
PAGE 3 OF 4
ww.coastercompany.com
w
Page 4
200701KE (B1-B3)ITEM :
STEP 4
Screw in the bed slat support to bed slat.
ASSEMBLY INSTRUCTIONS
STEP 5 STEP 6
Align and fasten bed slats to bed rails using screw and
tighten with screw driver (Not included).
Complete
PAGE 4 OF 4
