Electric Fireplace
Electric Fireplace
Instruction Manual
Instruction Manual
Electric Fireplace Packing List
Electric Fireplace Packing List
1
1
1
1
1
Electric Fireplace
Remote Control
Battery
Instruction Manual
Fastener Package
Page 2
QUICK REFERENCE GUIDE
I. Prior to installation, please ensure:
1. The rated voltage of your heater fits the output voltage of your outlet;
2. The light bulbs in your heater are in good condition. To check this, please follow the
instructions for replacing the light bulbs on section MAINTENANCE.
II. The heater on your electric fireplace may emit a slight, harmless odor when first used. This odor is
a normal condition caused by the initial heating of internal heater parts and will not occur again.
III. If your heater does not emit heat, please ensure the Heater Switch is on. For further information,
please consult section Operation of the Practical User's Guide.
NOTE
Procedures and techniques that are considered important enough to emphasize.
CAUTION
Procedures, which if not carefully followed, will result in damage to the equipment.
WARNING
Procedures, which if not carefully followed, will expose the user to the risk of serious injury, illness or
death.
Page 3
IMPORTANT INSTRUCTIONS
WARNING
You should read and always follow the important instructions below to reduce the risk of fire, electric
shock, and injury to persons.
1. Read all instructions before using this heater.
2. This heater is hot when in use. To avoid burns, do not let bare skin touch hot surfaces, such as
surfaces near the heater outlet or light bulbs. The grill directly in front of the heater outlet becomes
hot during heater operation. If provided, use handles when moving this heater. Keep combustible
materials such as clothes, pillows, furniture, bedding, papers and curtains at least 3 feet from the
front of this appliance.
3. CAUTION: Whenever the heater is left operating and unattended, extreme caution is necessary if
children or invalids are nearby.
4. Do not install the heater directly on carpet or a similar surface, which may restrict air circulation
beneath the unit.
5. Always unplug heater when not in use.
6. To disconnect heater, turn controls to off then remove plug from outlet.
7. Do not use outdoors.
8. This heater is not intended for use in wet locations such as bathrooms, laundry areas and similar
indoor locations. Never locate heater where it may fall into a bathtub or other water container.
9. Do not operate any heater with a damaged cord or plug, or if the heater has malfunctioned, or if the
heater has been dropped or damaged in any manner. Discard heater, or Return heater to
authorized service for examination, adjustment or repair.
10. Do not run cord under carpeting. Do not cover cord with throw rugs and runners. Arrange cord away
from traffic areas and where it will not be tripped over. Do not route cord under furniture or
appliances
11. Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may cause
an electric shock, fire, or may damage the heater.
12. To prevent a possible fire, do not block heater outlet or any ventilation or exhaust in any manner. Do
not use on soft surfaces, like a bed, where openings may become blocked.
Front view upper view
360mm
Air inlet
175mm
Air outlet
250mm
50mmm
Page 4
13. All electrical heaters have hot and arcing or sparking parts inside. Do not use it in areas where
gasoline, paint, or flammable liquids are used or stored or where the unit will be exposed to
flammable vapours.
14. Do not modify this heater. Use it only as described in this manual. Any other use not recommended
by the manufacturer may cause fire, electric shock or injury to persons.
15. Always plug heaters directly into a wall outlet/receptacle. Never use with an extension cord or
relocatable power tap (outlet/power strip).
16. Do not burn wood or other materials in this heater.
17. Do not strike heater glass.
18. Always use a certified electrician should new circuits or outlets be required.
19. Always use properly grounded, fused and polarized outlets.
20. Always use ground fault protection where required by electrical code.
21. Always disconnect power before performing any cleaning, maintenance or relocation of the heater.
22. When transporting or storing the heater and cord, keep in a dry place and free from excessive
vibration.
23. The heater must not be located immediately below a socket-outlet.
24. This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
25. Children should be supervised to ensure that they do not play with the appliance.
26. Heater is for household use only.
Page 5
GROUNDING INSTRUCTIONS
This heater is for use on 120 volts. The cord has a plug as shown at A in Figure. An adapter as shown at C
is available for connecting three-blade grounding-type plugs to two-slot receptacles. The green grounding lug
extending from the adapter must be connected to a permanent ground such as a properly grounded outlet
box. The adapter should not be used if a three-slot grounded receptacle is available.
Figure
Page 6
INSTALLATION
This section provides step-by-step instructions for installation of your heater.
WARNING
The outlet must be 15A/120V.
CAUTION
Do not remove the four rubber feet at the bottom of the heater or install the heater directly on soft
surfaces, which may restrict air circulation. Otherwise, it may cause a risk of fire or damage.
1. Select a suitable location, which is not susceptible to moisture, safe, dust free, away from high traffic and
away from things may catch fire or block openings such as drapes, furniture, etc.
NOTE
This heater is household use only.
It is a good idea to place your heater near an existing outlet for ease of electrical hook up.
2. Place the heater in the desired location to see how it will look in the room.
3. The size of IN2400 is: 24” W x 18 ½” H x 7 ¾” D
The size of IN2600 is: 26” W x 23” H x 7 ¾” D
The size of IN3000 is: 30” W x 25 ½” H x 7 ¾” D
4. If there is no 15A/120V outlet near the desired location, install a new one.
WARNING
Do not attempt to wire you own new outlets or circuits. To reduce the risk of fire, electric shock or
injury to persons, always use a licensed electrician.
5. Make sure the heater is switched off (refer to operation instruction section).
6. Plug the heater into a 15A/120V outlet. Wiring the cord along the corner of wall.
Plug must be accessible after installation.
Page 7
OPERATION
This section will explain the function of each convenient control.
This section will explain the function of each convenient control.
NOTE
The heater may emit a slight, harmless odor when first used. This odor is a normal condition caused
The heater may emit a slight, harmless odor when first used. This odor is a normal condition caused
The heater may emit a slight, harmless odor when first used. This odor is a normal condition caused
by initial heating of internal heater parts and will not occur agai
by initial heating of internal heater parts and will not occur again.
Control Panel Operation
Control Panel Operation
A. Buttons and Indicators
There are four buttons on the remote control
with the same label perform the same function, the back of it is manual switch near the
with the same label perform the same function, the back of it is manual switch near the po
There are four indicators on the control panel:
There are four indicators on the control panel:
The red window on the control panel of
The red window on the control panel of heater is the eye of receiver, please do not cover
buttons on the remote control, and four on the control panel of the heater
<ON/OFF> button is power switch of the heater;
<ON/OFF> button is power switch of the heater;
<DIMMER> button is used to adjust the brightness of simulated flame and logs;
<DIMMER> button is used to adjust the brightness of simulated flame and logs;
<LOW> button turns the fireplace insert on and switches it to low
<LOW> button turns the fireplace insert on and switches it to low-power status.
is already working at low
<HIGH> button turns the fireplace insert on and switches it to high
<HIGH> button turns the fireplace insert on and switches it to high-power status.
already working at high-power status, to push this button will turn the fireplac
is the power indicator, it lights up when the
is the power indicator, it lights up when the heater is working, and turned out when the
turned off;
indicates the status of the simulated flame and logs.
indicates the status of the simulated flame and logs.
indicates the heater is w
indicates the heater is working in low-power status;
indicates the heater is working in high
indicates the heater is working in high-power status.
ng at low-power status, to push this button will turn the fireplace off.
power status, to push this button will turn the fireplace off.
power status, to push this button will turn the fireplac
power status, to push this button will turn the fireplace off;
is working, and turned out when the heater is
power status. If the fireplace insert
heater, each pair of buttons
power status. If the fireplace is
do not cover.
power cord:
Page 8
B. Operation
On the first use of remote control, install the battery first: open the battery box by sliding its cover along
the arrow, install one (1) coin cell battery according to the marks in the box, and slide the cover to its
original position. If no battery installed or the battery is not working, the remote control will be unusable.
To use the remote control effectively, point it to the electric fireplace and keep a distance of 1-5 meters.
There are four buttons marked the same as buttons on the remote control, each pair of them perform the
same function, choose as you favour.
1. On/Off Switch. Press on/off switch to turn fire on. The indicator lamp will brighten up in the
control panel. Press the <ON/OFF> button again; the fireplace insert will be powered off.
2. Flame Effect Dimmer. Adjust the brightness of simulated flame and logs. When the fireplace insert
is powered on, flame is turned on automatically. Press <DIMMER> button to adjust the brightness,
the lamp will be flashing. During the dimming cycle the fire will slowly dim then brighten allowing
user to choose suitable level. Press a second time to stop cycle when the desired brightness level is
obtained.
3. Heater Low Heat (750 W). Press <LOW> button once to switch the fireplace insert to low-power
status. The indicator lamp will brighten up. Press again the <LOW> button to turn it off.
4. Heater High Heat (1500 W). Press <HIGH> button once to switch the fireplace insert to high-power
status. The indicator lamp will brighten up. Press again the <HIGH> button will turn it off.
NOTE: Before the heater emits heat or after it stops producing heat, the hot air outlet may output air
for 10 seconds. This is designed to protect the circuit.
5. Switch off the heater when you leave it for a long time.
6. Remove the lithium battery from the appliance before it is scrapped.
7. The lithium battery needs to be disposed of safely.
8. Roll up the power cord in the supports when the fireplace is not in use. If you select to store your
heater fully assembled, be sure to cover it, to protect it from accumulating dust.
9. Temperature Limiting control will automatically turn the unit off if it reaches a certain temperature.
Unplug the unit. When the temperature falls, the thermostat will be restored. Connect the plug to
power and heater will work.
Page 9
MAINTENANCE
WARNING
Disconnect power before attempting any maintenance or cleaning to reduce the risk of fire, electric
shock to persons or damage.
Light Bulb Replacement
Light bulbs need to be replaced when you notice a dark section of the flame or when the clarity and detail of
the log exterior disappears. There are two bulbs under the log set for IN2400 and IN2600. Four bulbs for
IN3000.
WARNING
Allow at least 5 minutes for light bulbs to cool off before touching bulbs to avoid burning of skin.
Except the light bulb replacement, any other servicing should be performed by an authorized service
representative.
I. Bulb Requirements
Light bulbs are 40 W att, 120 volts Candelabra with an E-12 small socket base.
CAUTION
Do not exceed 40 watts per bulb
II. Operation
1. Open the light bulb area:
The light bulb area is at the back of electric fireplace, see “E”. There are 6 screws on it. Loosen
the screw and then you can open it.
2. Examine the bulbs to determine which bulbs require replacement.
3. Remove old bulb and replace a new one. Hold the socket while unscrewing or screwing bulbs.
4. Replace the cover of light bulbs.
5. Done.
Page 10
Correct Disposal of this product
This marking indicates that this product should not be disposed with
other household wastes. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, recycle it responsibly
to promote the sustainable reuse of material resources. To return your
used device, please use the return and collection systems or contact the
retailer where the product was purchased. They can take this product for
environmental safe recycling.
