Label Picture Description QTY
A Chair Backrest 1
B Left Wing 1
Caution : You must read this before you proceed
RECLINING CHAIR
Page 1 of 8
C Right Wing 1
D
Chair Base With
Footrest
1
Before
Beginning
Assembly:
Page 2 of 8
Step 1
Step 2
Overview
This Reclining Chair has multiple parts and may require up to 30 minutes to assemble. To give
you an overview of the Reclining Chair parts, the above picture is to help you put the various
parts into perspective. Please read through the instructions below to familiarise yourself with the
parts and steps before assembly.
Take out the two non-woven bags with the Left Wing(B) and Right Wing(C) inside from the
bottom of the armrest.
Then take out the Wings from non-woven bags.
C
B
Non-woven bag
Non-woven bag
A
D
Page 3 of 8
Step 3
Step 4
Remove the Chair Backrest(A) from the Chair Base with Footrest(D).
Position the Chair Backrest(A) on it's right side.
Align the mounting brackets of the Left Wing(B) with those on the left side of Chair Backrest(A).
Then slide Left Wing(B) forward by hand to make sure it locks into the position as shown in the
picture.
Repeat the same process to attach Right Wing(C) to the right side of Chair Backrest(A).
With assistance from an adult partner, hold up the fully assembled Chair Backrest(A) with Wings,
and stand behind the Chair Base with Footrest(D).
Insert the small metal arms on the sides of the Chair Backrest(A) into the prefabricated slide lock
gadget on the Chair Base with Footrest(D) as shown above.
Firmly but gently, push the Chair Backrest(A) downwards until it is fully slotted and locked into
position.
A
B
C
A
BCD
Page 4 of 8
Step 5
Step 6
Smooth down the fabric flap on the Chair Backrest(A).
Run your hands down both sides of the flap, from top to bottom, allowing the velcro tape to
adhere to the flap under the seat of the chair.
Your Reclining Chair is ready for use.
This Reclining Chair can only be used on a flat, level surfaces.
Page 5 of 8
To recline backrest:
Warning
Keep hands and feet clear of the footrest mechanism and any gaps.
Do not allow children to play on the chair.
Always leave the chair in an upright and closed position after use.
Do not sit on the arms of the recliner.
Do not stand up on the recliner.
Only the occupant should operate the chair.
User Instructions
Sit into the seat.
Open the trigger on the outside of right armrest.
Use your body weight and push backwards into the backrest, until you reach your desired,
reclined position.
Reclining Chair
Please read the Instruction Manual below carefully before use.
This is a Reclining Chair. At anytime in a reclined seat position or in the upright position. You may
enjoy the rocking motion by using your body weight in a back-front rocking motion, and also the
swivel motion.
Supervise children, when in use of this Recliner.
Page 6 of 8
To Disassemble:
Open the flap on the Chair Backrest(A).
Use a screwdriver (Don't use fingers) to press the metal ear on the preattached Metal Bracket
outward;
At the same time pull the Chair Backrest(A) upward while your adult partner steadies the Chair
Base(D).
Repeat the same step for another side.
Then the Chair Backrest(A) can be taken out.
To get out of chair - move Seatback into upright position
Tilt your body weight slightly forward and upwards.
The seat back will come up to an upright position.
Use your feet to push the footrest back. You can stand up when the footrest and the machanism
click.
Where necessary, use your arms to help lift - push yourself out of the seat.
Page 7 of 8
Page 8 of 8
