Redarc G52-BEP User Manual
G52-BEP
EGT & Boost Pressure
(with Optional Oil Pressure Display)*
G52-BEP
52mm Gauge
G52-BEP
30
20
BOOST
PSI
10
0
7
EGT
X100
3
PSI
6
5
4
*Optional Oil Pressure Display requires the purchase of GS-P-150
WARNING & SAFETY INSTRUCTIONS
PSI
EGT
X100
PSI
BOOST
3
5
7
4
6
0
10
20
30
SAVE THESE INSTRUCTIONS - This manual contains IMPORTANT SAFETY INSTRUCTIONS for the G52-BEP
Gauge.
DO NOT OPERATE THE GAUGE UNLESS YOU HAVE READ AND UNDERSTOOD THIS MANUAL AND THE GAUGE IS
INSTALLED AS PER THESE INSTALLATION INSTRUCTIONS. NOT SUITABLE FOR MARINE APPLICATIONS.
1. The G52-BEP Boost & EGT Gauge is designed to provide an accurate indication of boost pressure & exhaust
gas temperature. As accurate as the indication might be, these gauges are not designed to be a substitute for
regular maintenance and inspection by a qualified technician.
2. REDARC recommend that the G52-BEP Boost & EGT Gauge be installed by a qualified technician.
3. Ensure the gauge face is cleaned only using soapy water and a soft cloth.
4. REDARC gauges are not suitable for installation into marine environments.
SPECIFICATIONS
G52-BEP
Input Voltage Range 6 - 16V (For 24V systems use GA-2412V)
Nominal Current Draw 30mA
Gauge Dimensions Ø52mm x 42mm (not incl. studs, Bezel Ø56mm)
Gauge Weight 50g
Warranty 2 Years
Sensor Boost EGT Interface
PRODUCT FUNCTION
The G52-BEP is designed to measure boost pressure (between 0-35psi) and exhaust gas
temperature (between 300°C - 700°C) using the included Boost EGT Interface.
The G52-BEP also features an optional Oil Pressure meter for which a seperate sensor is
required*. The Oil Pressure meter is displayed on the digital readout at the bottom of the
gauge and is capable of measuring up to 150psi.
52mm
42mm
and star washers are
used during installation.
1
4.5mm 20mm
Ensure that ‘P’-Clip
55mm
44mm
36mm
*(GS-P-150)
SAL.FOR.Instruction Manual.G52-BEP - Version 2
Pressure Gauge
120° Sweep
0psi - 35psi
Temp Gauge
120° Sweep
300°C - 700°C
Pressure Gauge Digital
0psi - 35psi
INSTALLATION
Find a suitable location for mounting the Gauge. REDARC offer a range of mounting
solutions - refer to www.redarc.com.au . It is important to ensure that your installation
meets any regulations regarding Field of View and Head Impact requirements.
Wire into vehicle as per the diagram below:
Purple
2:1 View
Primary
Connector
Multiple Gauge
Communications
Link
G52-BEP
Rear View
2:1 View
Secondary
Connector
K
C
O
L
Programming
to Park Light
Positive
Grey
to Dash Light
Negative*
Brown
C
A
C
O
N
S
T
A
R
T
Switch
To Ignition
2A
fuse
Orange
BlackBlack
Yellow
Ground
Connection**
Optional
Relay Output
Yellow
EGT Probe***
Red
Green
Orange
Yellow
Connect Hose
to Manifold****
Boost EGT
Interface
Note: DO NOT MOUNT IN ENGINE BAY
* Connect to a dash light that dims via the vehicle dimmer adjustment to ensure the gauge dims accordingly. If your
illumination circuit in your vehicle varies the positive voltage for dimming you will require a REDARC Enhanced Lighting
Controller (GA-ELC) to get the gauge to dim with your night-time driving lights.
** Ensure that the ground connection makes good contact with the vehicle ground. Poor grounding can cause incorrect
sensor readings. REDARC recommend removing any paint from the surface to ensure a bare metal on metal connection.
It is recommended that any wiring harnesses be covered using conduit or similar.
*** A steel 1/8 inch NPT bung (supplied) can be welded into a suitable location on the exhaust for mounting the EGT
sensor. Make sure the tip of the probe is in the centre of the exhaust pipe when mounted.
**** Connect the manifold pressure sensing hose to a suitable manifold hose using the ‘T’ piece provided. If no suitable
hose exists you may need to attach a suitable fitting into the manifold.
It is recommended that any wiring harnesses be covered using conduit or similar.
2
