Page 1
RM-310 WIRELESS
WIRELESS OPTICAL
MOUSE
USER’S MANUAL
Page 2
Technical support: www.real-el.com
1
ENG
User’s Manual
RM-310 WIRELESS
2
2
2
3
3
6
6
Congratulations on purchasing the ТМ REAL-EL PC mouse!
Please read the following instructions carefully before connecting, operating or adjusting this product. Besides, please keep this Manual in a safe
place for future reference.
COPYRIGHT
© 2015. ENEL GROUP OU. This Manual and information contained in it are
copyrighted. All rights reserved. All trademarks are the property of their legal
holders.
NOTICE OF RESPONSIBILITY RESTRICTION
Despite the exerted efforts to make this Manual more exact, some discrepancies may occur. The information in this Manual is given on “as is”
terms. The author and the publisher do not bear any liability to a person or
an organization for loss or damage which has arisen from the information
contained in this Manual.
CONTENTS
1. SPECIAL FEATURES ..................................................
2. PACKAGE CONTENTS ................................................
3. SYSTEM REQUIREMENTS ..........................................
4. DESCRIPTION .........................................................
5. INSTALLATION .........................................................
6. TROUBLESHOOTING ................................
.................
7. TECHNICAL SPECIFICATIONS ...........................
...........
Page 3
ENG
Technical support: www.real-el.com
2
Wireless Optical Mouse
RM-310 WIRELESS
1. FEATURES
• Power saving wireless technology
• Stylish ergonomic design
• Effective on most surfaces
• High speed operation
• 2.4 GHz USB nano receiver included (range of actionup to 10 m)
• Dpi resolution switch
• USB interface
• Battery long service life (1 year)
• Installation drivers for Windows XP/Vista/7/8 are not required
• Convenient for laptop operation
2. PACKAGE CONTENTS
• Optical mouse – 1 рс
• 2.4 GHz USB nano receiver – 1 рс
•
1.5V DC AAA batteries – 2 рсs
• User’s Мanual – 1 рс
• Warranty card – 1 рс
3. SYSTEM REQUIREMENTS
• Windows XP/Vista/7/8.
• Free USB port.
Page 4
Technical support: www.real-el.com
ENG
3
User’s Manual
RM-310 WIRELESS
Fig. 3. Nano receiver
Fig. 2. Bottom view
4. DESCRIPTION
Scroll wheel
Dpi resolution switch
On/off power switch
Optical sensor
Battery compartment
Nano receiver
USB connector
Fig. 1. Top view
5. PREPARATION TO OPERATION
• Open the cover of the mouse battery compartment
, insert 2 AAA 1.5V
DC
batteries into the battery compartment observing the polarity and close
the cover of the battery compartment (see Fig. 4).
• Сonnect the included nano receiver to a free PC USB port (Fig. 5).
• Then switch on the mouse using the switch and press any button or
rotate the scroll wheel to activate the mouse. If the mouse has been connected correctly, it will be switched on automatically.
Page 5
ААА 1.5V DC
batteries
Fig. 4. Battery installation
Fig. 5. Receiver connection
Battery
compartment
Improper installation of the
batteries can result in failure
of the mouse!
Battery compartment cover
Technical support: www.real-el.com
ENG
4
Wireless Optical Mouse
RM-310 WIRELESS
Page 6
•
After finishing your work, you can pull out the receiver from the PC USB
port and insert it into the mouse (Fig. 6).
When using the receiver again,
pull it out from the mouse (Fig. 7) and connect it to the PC USB port again.
• Do not place the receiver into a confined metal space (table drawer, box,
safe), as a metal screen does not transmit radio signals.
• If the batteries are discharged, the mouse works in jerks. It means that the
batteries should be replaced with new ones, as it is shown in Fig. 4.
Fig. 6. Fitting the receiver
into the mouse case
Fig. 7. Extraction of the receiver
from the mouse case
Technical support: www.real-el.com
ENG
5
User’s Manual
RM-310 WIRELESS
This device meets the highest standards of energy conservation.
Use the switch
on the bottom of the mouse to switch it on/off –
it will help you extend the mouse battery life.
Important
Page 7
Technical support: www.real-el.com
6
Wireless Optical Mouse
ENG
RM-310 WIRELESS
Notes:
• Technical specifications given in this table are supplemental information and cannot give occasion to claims.
• Technical specifications and package contents are subject to change
without notice due to improvement of TM REAL-EL production.
7.
TECHNICAL SPECIFICATIONS
Parameter
OS compatibility
Type of mouse
Resolution, dpi
Quantity of buttons
Interface
Battery type
Dimensions, mm
Weight, g
6. TROUBLESHOOTING
Solution
1. Make sure that the nano receiver has been
inserted into the USB port and its distance to
the mouse is less than 10 m.
2. Check whether the batteries have been
installed correctly.
3. Check if the batteries have run down, replace
the batteries with new ones if necessary.
4. Address nearest authorized service center.
Problem
The mouse does not
work.
Value
Windows XP/Vista/7/8
wireless 2.4 GHz
800/1200/1600
3 + 1 (scroll wheel)
USB
2 × ААА 1.5V DC
100 × 58 × 35
85
Page 8
Model: RM-310 Wireless
Manufacturer: ENEL GROUP OU, Joe tn 5-39, Tallinn, Harjumaa 10151, Estonia.
Made in China.
® Registered Trademark of ENEL GROUP OU. Estonia.
