RDI Technology CA670QN Users Manual

PORTABLE DIGITAL

FCC ID: SJ8-M370M

FCC ID: SJ8-CA670QN

WIRELESS MONITORING SYSTEM

INSTRUCTION MANUAL

CAMERA: CA670QN

MONITOR:M370M

Welcome!

Thank you for purchasing the wireless video monitor. Before you start, make sure you have the contents

listed below.

Contents

The system comes with the following components:

• Camera X1

• Video Monitor X1

• Charging cradle for video monitor X1

• Driver CD X1

• Power adapter for camera X1

• Power adapter for video monitor X1

• Mini USB cable X1

• User’s manual X1

• Hardware kit X1

Camera Video Monitor with Charging Cradle Driver CD

Power Adaptor for Camera* Power Adaptor for Video Monitor* Mini USB Cable

* The shape of power adaptor may not be exactly as shown

Check your package to confirm that you have received the complete system, including all components

shown above.

1

Features

• Digital wireless technology provides excellent image quality and clarity

• Interference free, secure and private signal

②

①

• Up to 450ft wireless transmission range

• Listen in with exceptional sound clarity

• Two-way audio communication

• Safety warning feature notifies you when out of range

• System expandable up to 4 cameras

• Micro SD card recording

• Timer Function

• USB output for monitoring on PC

①

Maximum open space transmission range. The actual range is dependent upon building

materials and other obstructions in path of wireless signal.

②

Additional cameras sold separately.

Camera Features

• Night vision allows for low light viewing up to 15 feet / 4.5 meters

• Two-way controlled night light

• Built-in microphone and speaker

• Camera can be battery operated for true portable wireless operation

• Two-way controlled lullabies

• Adjustable sensitivity for audio alarm

• Weatherproof for outdoor use

③

IR illumination range of 15ft./4.5m under ideal conditions. Objects at or beyond this range

may be partially or completely obscured, depending on the camera application.

Receiver Features

• 3.5” color LCD monitor/receiver with superior image quality

• Rechargeable lithium polymer battery for true portability

• Convenient receiver cradle included

• Audio level indicator and alarm

③

• Temperature display on LCD screen

2

Overview

Video Monitor Overview

3

Using the joystick to navigate menus

The joystick allows you to navigate through the video monitor menus.

4

Camera Overview

1). Lens: Camera lens.

2). Microphone: Built-in microphone underneath camera body.

3). PIR Sensor: Passive IR motion sensor for more accurate motion recording.

4). Speaker: Speaker for two-way audio.

5). Night Vision IR: Night vision IR LEDs used for viewing in complete darkness.

6). Pair: Pairing button. For more details, see “Appendix C: Adding Cameras” on page 33.

7). Antenna: Wireless antenna.

8). Power Cable: Connect the included power adapter to the cable extending from the camera.
Note: This camera includes an Auto Mechanical IR Cut Filter. When the camera changes between

day/night lighting, an audible clicking noise may be heard coming from the camera. This clicking is

normal, and indicates that the camera filter is working.

5

OSD Overview

The video monitor displays the following icons during normal use. The table below summarizes the video

monitor icons, and what they mean.

6

7
