RCF UP-2161 Data Sheet
UP 2161
POWER AMPLIFIER
DESCRIPTION
UP 2161 is a 160 W power amplifier designed
for the transmission of announcements and
musical programmes. The amplifier is
equipped with a (mic / line) Main Input on
either removable connector or XLR or RJ 45
and an Auxiliary Input for music sources (e.g.
CD players, tuners, etc.). The amplifier output
is available either for low impedance
loudspeakers or 100 – 70 V constant voltage
line. The amplifier is Class D with switching
power supply; the overall weight is extremely
reduced plus it offers a wide audio bandwidth
quality.
FEATURES
• Full digital technology Power Amplifier 160 W RMS
• Main input on either removable connector or XLR or RJ 45
• Main Input can have priority over the Aux Input
• Main Input has a presence control command
• Main Input has a high-pass filter useful for improving speech intelligibility
• Aux Input for music sources on RCA type connector
• Aux input with volume and tone controls
• 100 V - 70 V and 4 Ohm outputs
• Front panel LEDs indicate the device state (ON, PROT), the priority activation (PRIOR) and the
signal/peak level (SIG/PK)
DATASHEET
TECHNICAL SPECIFICATIONS
Amplifier specifications
Number of channels:
1
Power output per channel (@ 4 ohm):
160 W RMS
Power output (@ 100 V):
160 W RMS
Frequency Response (-3dB):
50 Hz ÷ 14 kHz
Distortion (THD+N) @ 1 kHz nominal
power:
<0.3 %
Input section
Total number of inputs:
3
Balanced:
3
Unbalanced:
2
Mono:
3
Line inputs:
1
Line connectors:
RCA
Mic+Line inputs:
1
Mic+Line connectors:
Euroblock, XLR
Mic+Line Phantom:
32 V DC
VOX:
Yes
Paging inputs:
1
Paging connectors:
RJ45
Paging command:
Contact
General Purpose Inputs (GPI):
1
Output section
Power output connectors:
Euroblock
Processing
Tone controls:
Yes
High-pass filter:
150 Hz
Controls
Configuration:
DIP switch, Front panel
Priority:
Yes
Protections
Cooling:
Convection
Short circuit:
Yes
Thermal:
Yes
DC:
Yes
Fuses:
Yes
Power requirement
Operating voltage:
220-240/115 V~ 50/60Hz
Voltage selection:
Internal
Power consumption:
350 W
Standard compliance
CE marking:
Yes
DATASHEET
RCF products are continually improved. All specifications are therefore subject to change without notice.
