TTS 36-A
ACTIVE HIGH POWER SUBWOOFER
DESCRIPTION
The TTS36-A is a high power, high output
active subwoofer system that sets a new
standard in the touring sound reinforcement.
The new 18” neodymium design represents
the result of many years dedicated in
pioneering new solutions for the transducers
technology. The integration of the 4000
Watt, 2 channels digital amplification and the
advanced digital processing set a new
standard for distortion, noise and thermal
efficiency.
FEATURES
• 4000 watt (2 x 2000 Watt digital amplifiers)
• 2 x 18" high power neodymium woofers, 4.5" v. c.
• 96 Khz, 32 bit DSP processing
• Remote monitoring and control
• Time delay alignment
• Bass reflex design, Cardioid preset for groups
• Tour grade cabinet
• RDNet on board
• Maximum output per size on market
DATASHEET
Rev. C
TECHNICAL SPECIFICATIONS
Acoustical specifications
Frequency Response:
35 Hz ÷ 120 Hz
Max SPL @ 1m:
143 dB
Transducers
Woofer:
2 x 18'' neo, 4.5'' v.c
Input/Output section
Input signal:
bal/unbal
Input connectors:
XLR, RDNet Ethercon
Output connectors:
XLR, RDNet Ethercon
Input sensitivity:
-2 dBu/+10 dBu
Processor section
Hi-Pass Frequencies:
30-45 Hz
Low-Pass Frequencies:
60-90 Hz
Protections:
Thermal, Excurs., RMS
Limiter:
Soft Limiter
Controls:
DSP Controlled
RDNet:
Yes
Power section
Total Power:
8000 W Peak, 4000 W RMS
Low frequencies:
8000 W Peak, 4000 W RMS
Cooling:
Convection/Forced
Connections:
Powercon IN/OUT
Standard compliance
CE marking:
Yes
Physical specifications
Cabinet/Case Material:
Baltic birch plywood
Hardware:
4 wheels, Steel bars x fork-lift
Handles:
6 side
Grille:
Steel
Color:
Black
Size
Height:
525 mm / 20.67 inches
Width:
1170 mm / 46.06 inches
Depth:
850 mm / 33.46 inches
Weight:
100 kg / 220.46 lbs
Shipping informations
Package Height:
1151 mm / 45.31 inches
Package Width:
1194 mm / 47.01 inches
Package Depth:
794 mm / 31.26 inches
Package Weight:
154 kg / 339.51 lbs
DATASHEET
RCF products are continually improved. All specifications are therefore subject to change without notice.
PART NUMBER
• 13000272
TTS 36-A
90-240V
EAN 8024530009090
DATASHEET
RCF products are continually improved. All specifications are therefore subject to change without notice.
DATASHEET
Horizontal 1/3 Octave Polars
300°
270°
240°
330°
210°
180°
130
Response -20dBu/2m Preset 30Hz-90Hz
120
110
dB SPL
100
90
80
20
0°
30°
-24-24 -21-21 -18-18 -15-15 -12-12 -9-9 -6-6 -3-3 00
150°
100 1000 10000
60°
90°
120°
100
80
63
Frequency (Hz)
Horizontal 1/3 Octave Polars
270°
300°
240°
210°
330°
0°
180°
200
30°
60°
-24-24 -21-21 -18-18 -15-15 -12-12 -9-9 -6-6 -3-3 00
120°
150°
160
125
90°
Vertical 1/3 Octave Polars
150°
180°
210°
300°
270°
240°
120°
240°
210°
330°
270°
180°
90°
0°
60°
30°
-24-24 -21-21 -18-18 -15-15 -12-12 -9-9 -6-6 -3-3 00
330°
300°
Horizontal One Octave Polars
30°
60°
-24-24 -21-21 -18-18 -15-15 -12-12 -9-9 -6-6 -3-3 00
120°
150°
100
80
63
0°
90°
Vertical 1/3 Octave Polars
150°
180°
210°
150°
180°
210°
240°
120°
120°
240°
270°
270°
90°
90°
60°
30°
-24-24 -21-21 -18-18 -15-15 -12-12 -9-9 -6-6 -3-3 00
330°
300°
Vertical One Octave Polars
60°
30°
-24-24 -21-21 -18-18 -15-15 -12-12 -9-9 -6-6 -3-3 00
330°
300°
200
160
125
0°
0°
TTS36-A
ACCESSORIES
AC POWER CABLE 6X TTL55
PART NUMBER
13360138
EAN:
AC RAIN COVER TTS56-A
PART NUMBER
13360137
EAN:
AC XLR-3M3F XLR CONN. 3MALE3FEMALEXCABLE
PART NUMBER
13360102
EAN:
8024530006402
CABLES KIT CBL ETHERCON 0.7M
PART NUMBER
12399016
EAN:
8024530013844
CABLES KIT CBL ETHERCON 3M
PART NUMBER
12399035
EAN:
8024530013868
CABLES KIT CBL ETHERCON 5M
PART NUMBER
12399018
EAN:
8024530013875
CABLES KIT CBL ETHERCON TO XLR F 0.2M
PART NUMBER
12399019
EAN:
8024530013882
CABLES KIT CBL ETHERCON TO XLR M 0.2M
PART NUMBER
12399020
EAN:
8024530013899
CABLES KIT CBL LK 25 MULTIPIN 10M
PART NUMBER
12399023
EAN:
8024530013837
DATASHEET
CABLES KIT CBL LK 25 MULTIPIN 20M
PART NUMBER
12399022
EAN:
8024530013820
CABLES KIT CBL LKS 19 ARRAY FANOUT
PART NUMBER
12399024
EAN:
8024530013905
CABLES KIT CBL LKS 19 BREAKOUT
PART NUMBER
12399026
EAN:
8024530013929
CABLES KIT CBL LKS 19 POWER 10M
PART NUMBER
12399027
EAN:
8024530013936
CABLES KIT CBL LKS 19 SUB FANOUT
PART NUMBER
12399025
EAN:
8024530013912
CABLES KIT CBL LKS 25-2 FANOUT
PART NUMBER
12399021
EAN:
8024530013813
CABLES KIT CBL POWER BOX 6X
PART NUMBER
13360145
EAN:
8024530015534
CABLES KIT CBL POWERCON LINK 1.5M
PART NUMBER
12399030
EAN:
8024530013721
CABLES KIT CBL POWERCON LINK 10M
PART NUMBER
12399028
EAN:
8024530013707
CABLES KIT CBL POWERCON LINK 5M
PART NUMBER
12399029
EAN:
8024530013714
DATASHEET
LKS 19-20 POWER CABLE
PART NUMBER
13360146
EAN:
8024530013943
PRO SWIVEL WHEELS KIT
PART NUMBER
13360238
EAN:
DATASHEET
