RCF SUB-9006AS Specifications

SUB 9006-AS

ACTIVE HIGH POWER SUBWOOFER

DESCRIPTION

The SUB 9006-AS is one of the most powerful 2x18” subwoofers in the
field of live sound. Featuring two high-power hyper-vented 18” neodymium
woofers with 4.0” inside-outside voice coils, this cabinet delivers a serious
amount of low frequencies. Powered by a 7200 W digital amplifier, the SUB
9006-AS can perform in the most demanding situations. The housing of the
SUB 9006-AS matches the RCF D-Line HDL50-A and HDL10-A array systems,
enabling to build stacked systems in a perfect combination.

MAIN APPLICATIONS

• Live sound

• Rental

• Portable PA

• Clubs

• Ballrooms

• Live theatre

• House of worship

• Club sound, DJs

ACOUSTICAL SPECIFICATIONS

Frequency response: 30 Hz - 400 Hz
Max SPL: 142 dB
Horizontal coverage angle: ­Vertical coverage angle: ­Compression driver: ­Midrange: ­Woofer: 2 x 18” neo, 4.0” v.c.

INPUT SECTION

Input signal (Impedance): bal/unbal
Input/Output connector: XRL, RDNet Ethercon
Input sensitivity: +4 dBu

PROCESSOR SECTION

Protections: Thermal - RMS
Limiter: fast limiter

Controls:

Gain, EQ, Preset, Phase switch, Output Delay
Settings

MAIN FEATURES

• 7200 Watt Peak power - 3600 Watt RMS

• 142 dB max SPL

• 30 Hz - 400 Hz frequency response

• 2 x 18” Woofer

• DSP controlled Input section with selectable presets

• RDNet remote control

• Delay control

• Baltic birch cabinet

AMPLIFIER

Power supply: 7200 W PEAK
High frequencies: ­Mid frequencies: ­Low frequencies: 7200 W PEAK
Cooling: Convection/Forced

Connection: Powercon in/out

PHYSICAL

Height: 558 mm (22”)
Width: 1188 mm (46.8”)
Depth: 785 mm (30.90”)
Weight: 86 kg (189.59 lbs)
Cabinet: baltic birch plywood
Hardware: 2 x M20
Handles: 8 side
Pole mount cap yes
Colour: Black

180°

180°

SUB 9006-AS

120

110

100

dB SPL

SUB9006-AS

Horizontal 1/3 Octave Polars

330°

300°

90

80

70

20

Response -20dBu/1m

Frequency (Hz)

0°

30°

100
80
63

60°

Horizontal 1/3 Octave Polars

330°

300°

0°

000010001001

200
160

30°

125

60°

270°

240°

210°

Vertical 1/3 Octave Polars

120°

150°

180°

210°

270°

240°

210°

Vertical 1/3 Octave Polars

120°

150°

180°

210°

120°

330°

90°

200
160
125

30°

0°

-24-24 -21-21 -18-18 -15-15 -12-12 -9-9 -6-6 -3-3 00

150°

90°

60°

-24-24 -21-21 -18-18 -15-15 -12-12 -9-9 -6-6 -3-3 00

120°

330°

90°

100
80
63

30°

0°

-24-24 -21-21 -18-18 -15-15 -12-12 -9-9 -6-6 -3-3 00

150°

90°

60°

-24-24 -21-21 -18-18 -15-15 -12-12 -9-9 -6-6 -3-3 00

240°

270°

300°

240°

300°

270°
