S 5020
BASS REFLEX SUBWOOFER
DESCRIPTION
The S 5020 is a vented, high output, compact
subwoofer system where the physically small
size and impact of a dual 10-inch driver is
desired, and works equally well for portable
or install situations. Extending the frequency
response of these systems to below 40Hz this
highly efficient design is capable of providing
output levels normally associated with
considerably larger enclosures.
A system suited to background music
playback in applications ranging from clubs,
bars and cafes, right through to theatres and
AV presentations. The low-frequency
transducers are dual 10” woofer with a 2,5”
voice coil. This new woofer design is the
result of the latest refinements in RCF
experiences in compact active and passive
subwoofer design, resulting in a fast and
controlled reproduction of the bass frequency
range. It is engineered to complement MEDIA
series full-range loudspeakers and is
particularly well-suited in high-quality multimedia applications.
FEATURES
• 2 x 10" high-efficiency 2.5" voice-coil woofer
• 130 dB maximum sound pressure level
• System Power rating 500 Watt RMS
• M20 standard pole mount in top section of cabinet
• Recessed Euroblock Input-Output connectors
• Protective metal grille, polyester fabric coated
• Integrated recessed hand carry points
DATASHEET
TECHNICAL SPECIFICATIONS
Acoustical specifications
Frequency Response (-10dB):
50 Hz ÷ 200 Hz
Max SPL @ 1m:
130 dB
System Sensitivity:
98 dB
Power section
Nominal Impedance (ohm):
4 ohm
Power Handling:
500 W RMS
Peak Power Handling:
2000 W PEAK
Recommended Amplifier:
1000 W
Protections:
Weather
Crossover Frequencies:
Selectable
Transducers
Woofer:
2 x 10'', 2.5'' v.c
Nominal Impedance (ohm):
8 ohm
Input Power Rating:
250 W AES, 500 W PEAK
Sensitivity:
95 dB, 1W @ 1m
Input/Output section
Input connectors:
Euroblock
Standard compliance
CE marking:
Yes
Physical specifications
Cabinet/Case Material:
MDF
Pole mount/Cap:
Yes
Grille:
Steel with robust double mesh polyester
clothing
Size
Height:
340 mm / 13.39 inches
Width:
680 mm / 26.77 inches
Depth:
420 mm / 16.54 inches
Weight:
28.8 kg / 63.49 lbs
Shipping informations
Package Height:
440 mm / 17.32 inches
Package Width:
780 mm / 30.71 inches
Package Depth:
520 mm / 20.47 inches
Package Weight:
31.2 kg / 68.78 lbs
PART NUMBER
• 13041019
S 5020
EAN 8024530011079
DATASHEET
RCF products are continually improved. All specifications are therefore subject to change without notice.
