MR 44T
2 WAY REFLEX SPEAKERS 60 W WITH TRANSFORMER
DESCRIPTION
Careful acoustic design and the use of
advanced materials contribute to the
exceptional music fidelity and speech
intelligibility exhibited by the RCF Monitor
44T (black) and Monitor 44/WT (white) twoway speaker systems.
The carbon fiber diaphragm remains
extremely rigid at high power levels,
producing a more linear response and lower
distortion. The cone is fitted with a durable
foam surround and treated to resist moisture.
The high-frequency section features a
constant directivity horn with a built-in
mechanical phase equalizer. The horn is
driven by a Ferrofluid® cooled, 0.5" mylar
dome tweeter. The system is nominally
crossed over at 4 kHz by a 12 dB/octave
network, which uses markedly lower (than
conventional) inductance values in series with
the woofer. This design reduces sound delays
associated with high inductance values and
provides excellent low fre-quency transient
response. The high-pass section is corrected
for optimum perfor-mance of the CD horn
and is protected with a circuit based on a lowvalue/low-mass filament resistor that
smoothly limits the power sent to the tweeter
FEATURES
• Ideal for high quality paging and music reproduction
• Low impedance (4O - 60W) or 100V operating mode
• Transducers LF 5" - HF 0.5" constant directivity tweeter
• Built-in low inductance passive crossover with high frequency dynamic protection, bass refl ex Built-in
low inductance passive crossover with high frequency dynamic protection, bass refl ex @65Hz
• Body in self-extinguishing plastic
• Includes hinged support for installation
DATASHEET
TECHNICAL SPECIFICATIONS
Acoustical specifications
Frequency Response (-10dB):
60 Hz ÷ 23000 Hz
Max SPL @ 1m:
108 dB
Coverage angle:
110°
System Sensitivity:
87 dB
Power section
Nominal Impedance (ohm):
4 ohm
Power Handling:
60 W RMS
Peak Power Handling:
240 W PEAK
Recommended Amplifier:
120 W
Crossover Frequencies:
4000 Hz
Transducers
Dome Tweeter:
0.5''
Woofer:
5.0''
Input/Output section
Input connectors:
Push Type Terminals
Output connectors:
Push Type Terminals
Constant Voltage Transformer:
70/100 V
Power selection 1 (100 V):
40 W - 250 ohm
Power selection 2 (100 V):
30 W - 333 ohm
Power selection 3 (100 V):
20 W - 500 ohm
Power selection 4 (100 V):
10 W - 1000 ohm
Power selection 5 (100 V):
5 W - 2000 ohm
Standard compliance
CE marking:
Yes
Physical specifications
Cabinet/Case Material:
Plastic
Hardware:
Wall mount bracket
Grille:
Steel
Color:
White - RAL 9003
Size
Height:
270 mm / 10.63 inches
Width:
187 mm / 7.36 inches
Depth:
172 mm / 6.77 inches
Weight:
3.73 kg / 8.22 lbs
Shipping informations
Package Height:
380 mm / 14.96 inches
Package Width:
260 mm / 10.24 inches
Package Depth:
260 mm / 10.24 inches
Package Weight:
4.54 kg / 10.01 lbs
PART NUMBER
• 13100015
MR 44T W
White - RAL 9003
EAN 8024530014285
• 13100014
MR 44T
Black - RAL 9005
EAN 8024530014261
DATASHEET
RCF products are continually improved. All specifications are therefore subject to change without notice.
