HDL 12-AS
ACTIVE FLYABLE HISUBWOOFERGH POWER
DESCRIPTION
The HDL 12-AS is the companion subwoofer
for HDL 6-A. Housing a 12” woofer, the HDL 12
-AS, is a very compact active sub enclosure
and features a 1400 W powerful digital
amplifier. It is the ideal complement to create
flown HDL 6-A clusters with outstanding
performance. It features a built-in digital
stereo crossover (DSP) with adjustable
crossover frequency to connect the HDL 6-A
line array module or a satellite. The integrated
mechanics are both fast and reliable. The
heavy-duty front grille is power coated. A
special transparent-to-sound foam backing
inside helps the further protection of the
transducers from dust.
FEATURES
• 1400 Watt Peak power - 700 Watt RMS
• 131 dB max SPL
• 40 Hz - 120 Hz frequency response
• 1 x 12" Woofer
• Stereo crossover
• Switchable crossover frequencies
• Designed to compliment the HDL 6-A speaker system
• Polarity reverse switch
DATASHEET
Rev. E
TECHNICAL SPECIFICATIONS
Acoustical specifications
Frequency Response:
40 Hz ÷ 120 Hz
Transducers
Woofer:
12'', 3.0'' v.c
Input/Output section
Input signal:
bal/unbal
Input connectors:
XLR
Output connectors:
XLR
Input sensitivity:
-2 dBu/+4 dBu
Processor section
Hi-Pass Frequencies:
40Hz
Low-Pass Frequencies:
80Hz, 110Hz
Protections:
Thermal, RMS
Limiter:
Soft Limiter
Controls:
Volume, EQ, Phase, Xover
Power section
Total Power:
1400 W Peak, 700 W RMS
Low frequencies:
1400 W Peak, 700 W RMS
Cooling:
Convection
Connections:
Powercon IN/OUT
Standard compliance
CE marking:
Yes
Physical specifications
Cabinet/Case Material:
Baltic birch plywood
Hardware:
Array fittings, pole
Handles:
2 side
Grille:
Steel
Color:
Black
Size
Height:
379 mm / 14.92 inches
Width:
470 mm / 18.5 inches
Depth:
508 mm / 20 inches
Weight:
25 kg / 55.12 lbs
Shipping informations
Package Height:
435 mm / 17.13 inches
Package Width:
560 mm / 22.05 inches
Package Depth:
520 mm / 20.47 inches
Package Weight:
28 kg / 61.73 lbs
DATASHEET
RCF products are continually improved. All specifications are therefore subject to change without notice.
PART NUMBER
• 13000533
HDL12-AS W
115V
EAN 8024530015244
• 13000532
HDL12-AS W
220-240V
EAN 8024530015022
• 13000510
HDL12-AS
115V
EAN 8024530014728
• 13000505
HDL12-AS
220-240V
EAN 8024530014650
DATASHEET
RCF products are continually improved. All specifications are therefore subject to change without notice.
VISTA 3D / 3D VIEW
508
20.00[ ]
350
13.78[ ]
4
.16[ ]
469
18.46[ ]
217.5
8.56[ ]
33
1.30[ ]
478.5
18.84[ ]
229.5
9[ ]
228
8.98[ ]
45.5
2[ ]
121
5[ ]
SUBWOOFER HDL12-AS 230 V
REV.
A
M20
DATASHEET
DATASHEET
Response -20dBu/1m Preset 80Hz
120
110
100
dB SPL
90
80
Frequency (Hz)
100 1000 10000
20
70
HDL12-AS
DATASHEET
100
80
63
90°
0°
30°
60°
120°
150°
-24-24 -21-21 -18-18 -15-15 -12-12 -9-9 -6-6 -3-3 00
180°
330°
Horizontal 1/3 Octave Polars
300°
210°
240°
270°
DATASHEET
200
160
125
90°
0°
30°
60°
120°
150°
-24-24 -21-21 -18-18 -15-15 -12-12 -9-9 -6-6 -3-3 00
180°
330°
Horizontal 1/3 Octave Polars
300°
210°
240°
270°
DATASHEET
100
80
63
0°
90°
60°
30°
330°
300°
-24-24 -21-21 -18-18 -15-15 -12-12 -9-9 -6-6 -3-3 00
270°
Vertical 1/3 Octave P olars
120°
150°
240°
210°
180°
DATASHEET
200
160
125
0°
90°
60°
30°
330°
300°
-24-24 -21-21 -18-18 -15-15 -12-12 -9-9 -6-6 -3-3 00
270°
Vertical 1/3 Octave P olars
120°
150°
240°
210°
180°
ACCESSORIES
AC 2X AZIMUT PLATE
PART NUMBER
13360351
EAN:
8024530013516
AC PMA - POLE MOUNT
PART NUMBER
13360034
EAN:
8024530007713
AC PM-M20
PART NUMBER
13360067
EAN:
8024530014599
AC PMX POLE MOUNT M20
PART NUMBER
13360232
EAN:
8024530010058
AC POWER CABLE 6X TTL55
PART NUMBER
13360138
EAN:
AC TRUSS CLAMP HDL6
PART NUMBER
13360371
EAN:
8024530014360
AC TT PMA - POLE MOUNT TT+
PART NUMBER
13360068
EAN:
8024530005825
AC XLR-3M3F XLR CONN. 3MALE3FEMALEXCABLE
PART NUMBER
13360102
EAN:
8024530006402
CABLES KIT CBL LK 25 MULTIPIN 10M
PART NUMBER
12399023
EAN:
8024530013837
DATASHEET
CABLES KIT CBL LK 25 MULTIPIN 20M
PART NUMBER
12399022
EAN:
8024530013820
CABLES KIT CBL LKS 19 ARRAY FANOUT
PART NUMBER
12399024
EAN:
8024530013905
CABLES KIT CBL LKS 19 BREAKOUT
PART NUMBER
12399026
EAN:
8024530013929
CABLES KIT CBL LKS 19 POWER 10M
PART NUMBER
12399027
EAN:
8024530013936
CABLES KIT CBL LKS 19 SUB FANOUT
PART NUMBER
12399025
EAN:
8024530013912
CABLES KIT CBL POWER BOX 6X
PART NUMBER
13360145
EAN:
8024530015534
CABLES KIT CBL POWERCON LINK 0.7M
PART NUMBER
12399031
EAN:
8024530013738
CABLES KIT CBL POWERCON LINK 1.5M
PART NUMBER
12399030
EAN:
8024530013721
CABLES KIT CBL POWERCON LINK 10M
PART NUMBER
12399028
EAN:
8024530013707
CABLES KIT CBL POWERCON LINK 5M
PART NUMBER
12399029
EAN:
8024530013714
DATASHEET
CABLES KIT LK 25-2 FANOUT
PART NUMBER
12399021
EAN:
8024530013813
FLYBAR HDL6-A
PART NUMBER
13360360
EAN:
8024530014209
FLYBAR PICKUP HDL6
PART NUMBER
13360372
EAN:
8024530014353
HOIST SPACING CHAIN TTL55
PART NUMBER
13360129
EAN:
LINKBAR HDL12 TO HDL6
PART NUMBER
13360375
EAN:
8024530014414
LKS 19-20 POWER CABLE
PART NUMBER
13360146
EAN:
8024530013943
SPARE PINS FRONT 4X HDL20- HDL18
PART NUMBER
13360219
EAN:
8024530015763
DATASHEET
