H-BR 2X COMPACT M 06

PAIR OF HORIZONTAL BRACKET

DESCRIPTION

Pair of horizontal bracket for COMPACT M 06
speaker wall mounting.

FEATURES

• COMPACT M SERIES approved original accessory

• Safe and quick loudspeaker installation

• Steel construction

• Painted with scratch resistant paint, black RAL 9005 and white RAL 9003

DATASHEET

Rev. C Last update: 18/03/2021

TECHNICAL SPECIFICATIONS

Standard compliance

CE marking:

Yes

Physical specifications

Cabinet/Case Material:

Steel

Color:

Black - RAL 9005

Size

Height:

60 mm / 2.36 inches

Width:

382 mm / 15.04 inches

Depth:

282 mm / 11.1 inches

Weight:

3 kg / 6.61 lbs

Shipping informations

Package Height:

70 mm / 2.76 inches

Package Width:

400 mm / 15.75 inches

Package Depth:

210 mm / 8.27 inches

Package Weight:

3.2 kg / 7.05 lbs

PART NUMBER

• 13360470

H-BR 2X COMPACT M 06 W

White - RAL 9003

• 13360461

H-BR 2X COMPACT M 06

Black - RAL 9005

EAN 8024530018825

DATASHEET

RCF products are continually improved. All specifications are therefore subject to change without notice.

VISTA 3D / 3D VIEW

382 [15.0 ]

399.8 [15.7 ]

200 [7.9 ]

60 [2.4 ]

115 [4.5 ]

155 [6.1 ]

180 [7.1 ]

80 [3.2 ]

11 [

.4

]

327 [12.9 ]

25 [ 1.0 ]

32 [ 1.3 ]

334 [ 13.2 ]

R 4.5

[.2

]

HORIZONTAL BRACKET H-BR 2X COMPACT M 06

REV.

A
