DP 5EN
UNIDIRECTIONAL SOUND PROJECTOR
DESCRIPTION
DP 5EN is a weatherproof sound projector
suitable for all those installations where high
intelligibility for alarm messages broadcasting
and great sound reproduction quality are
required. Thanks to its IP65 protection grade,
it can be installed both indoor and outdoor.
Moreover, a modern and endearing design
makes it the perfect product for
environments where projectors are intended
also as architectural elements and contribute
to improve global aesthetics.
FEATURES
• 5" fullrange transducer.
• Power selectable (100 V): 20 W – 10 W – 5 W – 2.5 W.
• 88 dB sensitivity.
• Colour white RAL 9016.
• Flameproof ABS body, steel grille.
• In/out ceramic terminal block.
• Thermal fuse protection.
• Protection grade IP65.
DATASHEET
Rev. M
TECHNICAL SPECIFICATIONS
Acoustical specifications
Frequency Response (-10dB):
80 Hz ÷ 20000 Hz
Max SPL @ 1m:
101 dB
Max SPL @ 4m:
89 dB
Coverage angle:
210°
System Sensitivity:
88 dB
System Sensitivity 1W @ 4m:
76 dB
Power section
Power Handling:
20 W RMS
Peak Power Handling:
80 W PEAK
Recommended Amplifier:
40 W
Protections:
Thermal fuse
Transducers
Fullrange:
5.0''
Input/Output section
Input connectors:
Ceramic screw terminals
Output connectors:
Ceramic screw terminals
Constant Voltage Transformer:
100 V
Power selection 1 (100 V):
20 W - 500 ohm
Power selection 2 (100 V):
10 W - 1000 ohm
Power selection 3 (100 V):
5 W - 2000 ohm
Power selection 4 (100 V):
2.5 W - 4000 ohm
Standard compliance
IP protection grade:
IP 65
EN54-24 certified:
Yes
CE marking:
Yes
CPR number:
0068-CPR-058/2014
Physical specifications
Cabinet/Case Material:
ABS
Hardware:
Wall mount metal plate
Grille:
Steel
Color:
White - RAL 9016
Size
Height:
183 mm / 7.2 inches
Width:
176 mm / 6.93 inches
Depth:
261 mm / 10.28 inches
Weight:
2.61 kg / 5.75 lbs
Shipping informations
Package Height:
230 mm / 9.06 inches
Package Width:
400 mm / 15.75 inches
Package Depth:
380 mm / 14.96 inches
Package Weight:
3.54 kg / 7.8 lbs
DATASHEET
RCF products are continually improved. All specifications are therefore subject to change without notice.
PART NUMBER
• 13133076
DP 5EN
White - RAL 9016
EAN 8024530011123
DATASHEET
RCF products are continually improved. All specifications are therefore subject to change without notice.
DRAWINGS
176 mm
183 mm
334 mm
261 mm73 mm
147 mm
DATASHEET
SCHEMATICS
CERAMIC
SCREW TERMINAL
100 V
+
0
IN
WHITE (2.5 W)
YELLOW (5 W)
BLUE (10 W)
RED (20 W)
BLACK (COM)
4Ω
8Ω 8Ω
+
–
–
+
DATASHEET
100 1000 10000
Frequency (Hz)
60
70
80
90
100
110
dB SPL
20
Response
DP 5EN
100 1000 10000
Frequency (Hz)
1
10
100
Total Q
0
2
4
6
8
10
12
14
16
18
20
Directivity index Di, dB
Directivity Index and Q
100 1000 10000
Frequency (Hz)
0
30
60
90
120
150
180
210
240
270
300
330
360
Coverage Angle (Deg.)
Horizontal Beamwidth (1/3 Octave)
Vertical Beamwidth (1/3 Octave)
Beamwidth vs. Frequency
100 1000 10000
Frequency (Hz)
-30
-25
-20
-15
-10
-5
0
5
Attenuation in dB
Horizontal ±10 degrees
Horizontal ±20 degrees
Horizontal ±30 degrees
Horizontal ±40 degrees
Horizontal ±50 degrees
Horizontal ±60 degrees
Normalized Horizontal o-axis Response
DATASHEET
-48-48 -42-42 -36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
300°
330°
270°
240°
210°
180°
150°
120°
90°
60°
30°
0°
1250
1000
800
Horizontal 1/3 Octave Polars
-48-48 -42-42 -36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
300°
330°
270°
240°
210°
180°
150°
120°
90°
60°
30°
0°
315
250
200
Horizontal 1/3 Octave Polars
-48-48 -42-42 -36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
300°
330°
270°
240°
210°
180°
150°
120°
90°
60°
30°
0°
2500
2000
1600
Horizontal 1/3 Octave Polars
-48-48 -42-42 -36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
300°
330°
270°
240°
210°
180°
150°
120°
90°
60°
30°
0°
630
500
400
Horizontal 1/3 Octave Polars
-48-48 -42-42 -36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
300°
330°
270°
240°
210°
180°
150°
120°
90°
60°
30°
0°
5000
4000
3150
Horizontal 1/3 Octave Polars
-48-48 -42-42 -36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
300°
330°
270°
240°
210°
180°
150°
120°
90°
60°
30°
0°
10000
8000
6300
Horizontal 1/3 Octave Polars
HORIZONTAL 1/3 POLAR PLOT
DATASHEET
ACCESSORIES
CV210 CABLE SPEAKER 100V SEZ 2X1MMQ EVAC
PART NUMBER
14380030
EAN:
8024530012168
CV215 CABLE SPEAKER 100V SEZ 2X1.5MMQ EVAC
PART NUMBER
14380031
EAN:
8024530012175
CV225 CABLE SPEAKER 100V SEZ 2X2.5MMQ EVAC
PART NUMBER
14380032
EAN:
8024530012182
DATASHEET
NOTES
NO CAUTION is NECESSARY in case of ALERTED PERSON for AUDIO voltages up to 120V, when warning symbols are present near the connection
terminals. In the case of AUDIO voltages up to 71V, it is not even necessary to put warning symbols.
No need of linking to earth metal parts of speakers equipped with transformers and connected to 70.7 V / 100 V outputs of power amplifiers that do
not have any reference to earth (ref. EN 62368-1 item 4.3.2.2 ), unless specific local requirements.
