Page 1
C 5215-94
TWO-WAY PASSIVE SPEAKER
DESCRIPTION
C5215-94 The C5215-94 is a full range
extremely versatile controlled narrow
dispersion two-way loudspeaker system for
medium throw applications.
The high-frequency section is a constant
directivity horn loaded to a 2” neodymium
compression driver with a 2.5” diaphragm
assembly for smooth, controlled dispersion.
The 90° x 40° horn design offers higher
sensitivity for longer distance applications.
The low-frequency transducer is a 15” woofer
with a 3” voice coil. The crossover is easily
bypassed for bi-amp via a recessed
changeover switch.
FEATURES
• 90° x 40° CMD (Coverage Matching Design) constant directivity horn
• 2" compression driver with 2,5" diaphragm assembly
• 15" woofer with 3" voice coil
• Dual-function design: built in passive crossover or external bi-amp
• Rotatable Horn System for horizontal cabinet mounting applications
• HF driver AMCDP (Active Mosfet Compression Driver Protection)
• LICC (Low Impedance Compensated Crossover) network
• 14 Suspension points (M10)
• 35 mm standard internal pole mount
DATASHEET
Rev. D
Page 2
TECHNICAL SPECIFICATIONS
Acoustical specifications
Frequency Response (-10dB):
48 Hz ÷ 20000 Hz
Max SPL @ 1m:
133 dB
Horizontal coverage angle:
90°
Vertical coverage angle:
40°
Directivity index Q:
14
System Sensitivity:
100 dB
Power section
Nominal Impedance (ohm):
8 ohm
Power Handling:
500 W RMS
Peak Power Handling:
2000 W PEAK
Recommended Amplifier:
1000 W
Protections:
Dynamic active mosfet
Crossover Frequencies:
1200 Hz
Transducers
Compression Driver:
1.4'', 2.5'' v.c
Nominal Impedance (ohm):
8 ohm
Input Power Rating:
100 W AES, 200 W PEAK
Sensitivity:
111 dB, 1W @ 1m
Woofer:
15'', 3.0'' v.c
Nominal Impedance (ohm):
8 ohm
Input Power Rating:
400 W AES, 800 W PEAK
Sensitivity:
99 dB, 1W @ 1m
Input/Output section
Input connectors:
Speakon® NL4
Output connectors:
Speakon® NL4
Standard compliance
CE marking:
Yes
Physical specifications
Cabinet/Case Material:
Baltic birch plywood
Hardware:
14 x M10, multiplates (top and bottom)
Grille:
Steel with robust double mesh polyester
clothing
Color:
Black
Size
Height:
695 mm / 27.36 inches
Width:
430 mm / 16.93 inches
Depth:
460 mm / 18.11 inches
Weight:
35 kg / 77.16 lbs
Shipping informations
Package Height:
779 mm / 30.67 inches
Package Width:
584 mm / 22.99 inches
Package Depth:
534 mm / 21.02 inches
Package Weight:
39.5 kg / 87.08 lbs
DATASHEET
RCF products are continually improved. All specifications are therefore subject to change without notice.
Page 3
PART NUMBER
• 13000309
C 5215-94
EAN 8024530009274
DATASHEET
RCF products are continually improved. All specifications are therefore subject to change without notice.
Page 4
DATASHEET
Page 5
DATASHEET
110
Response 1W/1m
100
90
dB SPL
80
70
360
330
300
60
20
100 1000 10000
Frequency (Hz)
Beamwidth vs. Frequency
Horizontal Beamwidth (1/3 Octave)
Vertical Beamwidth (1/3 Octave)
270
240
210
180
150
120
Coverage Angle (Deg.)
90
60
30
0
100 1000 10000
Frequency (Hz)
316
Impedance
100
Ohms
10
1
100
10
Total Q
1
100 1000 10000
100 1000 10000
Frequency (Hz)
Directivity Index and Q
Frequency (Hz)
20
18
16
14
Directivity index Di, dB
12
10
8
6
4
2
0
5
Normalized Horizontal off-axis Response
0
-5
-10
-15
Attenuation in dB
-20
-25
-30
100 1000 10000
5
Horizontal ±10 degrees
Horizontal ±20 degrees
Horizontal ±30 degrees
Horizontal ±40 degrees
Horizontal ±50 degrees
Horizontal ±60 degrees
Frequency (Hz)
Normalized Vertical off-axis Response. Below the box
0
-5
-10
-15
Attenuation in dB
-20
-25
-30
100 1000 10000
Vertical -10 degrees
Vertical -20 degrees
Vertical -30 degrees
Vertical -40 degrees
Vertical -50 degrees
Vertical -60 degrees
Frequency (Hz)
5
Normalized Vertical off-axis Response. Above the box
0
-5
-10
-15
Attenuation in dB
-20
-25
-30
100 1000 10000
Vertical +10 degrees
Vertical +20 degrees
Vertical +30 degrees
Vertical +40 degrees
Vertical +50 degrees
Vertical +60 degrees
Frequency (Hz)
C5215 90°x40°
Page 6
DATASHEET
Horizontal 1/3 Octave Polars
300°
270°
240°
Horizontal 1/3 Octave Polars
300°
270°
240°
330°
330°
210°
210°
180°
180°
0°
30°
60°
-36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
120°
150°
0°
30°
60°
-36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
120°
150°
160
125
100
90°
630
500
400
90°
Horizontal 1/3 Octave Polars
300°
270°
240°
Horizontal 1/3 Octave Polars
300°
270°
240°
210°
330°
330°
210°
180°
0°
180°
315
30°
60°
-36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
120°
150°
0°
30°
60°
-36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
120°
150°
250
200
90°
1250
1000
800
90°
Horizontal 1/3 Octave Polars
300°
270°
240°
Horizontal 1/3 Octave Polars
300°
270°
240°
330°
210°
330°
210°
180°
180°
0°
30°
60°
-36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
120°
150°
0°
30°
60°
-36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
120°
150°
2500
2000
1600
90°
10000
8000
6300
90°
Horizontal 1/3 Octave Polars
300°
270°
240°
300°
270°
240°
330°
210°
330°
210°
180°
180°
0°
0°
30°
60°
-36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
120°
150°
Horizontal One Octave Polars
30°
60°
-36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
120°
150°
5000
4000
3150
90°
90°
C5215 90°x40°
Page 7
DATASHEET
Vertical 1/3 Octave Polars
150°
180°
210°
Vertical 1/3 Octave Polars
150°
180°
210°
120°
240°
120°
240°
270°
270°
90°
60°
30°
-36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
330°
300°
90°
60°
30°
-36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
330°
300°
160
125
100
0°
630
500
400
0°
Vertical 1/3 Octave Polars
150°
180°
210°
Vertical 1/3 Octave Polars
150°
180°
210°
240°
120°
120°
240°
270°
270°
90°
60°
30°
-36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
330°
300°
90°
60°
30°
-36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
330°
300°
315
250
200
0°
1250
1000
800
0°
Vertical 1/3 Octave Polars
150°
180°
210°
Vertical 1/3 Octave Polars
150°
180°
210°
120°
240°
120°
240°
270°
270°
90°
60°
30°
-36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
330°
300°
90°
60°
30°
-36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
330°
300°
2500
2000
1600
0°
10000
8000
6300
0°
Vertical 1/3 Octave Polars
150°
180°
210°
150°
180°
210°
120°
240°
120°
240°
270°
270°
90°
90°
60°
30°
-36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
330°
300°
Vertical One Octave Polars
60°
30°
-36-36 -30-30 -24-24 -18-18 -12-12 -6-6 00
330°
300°
5000
4000
3150
0°
0°
C5215 90°x40°
