RCF AYRA-SIX-PRO Data Sheet

AYRA PRO6

PROFESSIONAL ACTIVE TWO-WAY STUDIO MONITORS

DESCRIPTION

AYRA PRO6 studio monitor works perfectly
in any listening environment, whether large or
small production facilities, with absolute
clarity. It delivers accurate monitoring and
provides the engineer or producer with a
neutral tool to analyze recordings and
optimize the mix; for this reason, we call it
PRO.
Featuring a dedicated powerful internal DSP
that optimizes frequency response and
dynamics together with the exclusive RCF
FiRPHASE processing and selected
components, the AYRA PRO is the first Studio
Monitor in its class to boast an outstanding 0°
phase response.

FEATURES

• 45 – 20 kHz Frequency Response

• 0° Phase Response

• 80W + 40W Class-D Amplifiers

• 6.5” Composite Fiberglass Woofer

• 1” ferrofluid cooled Soft Dome tweeter

• RCF Precision Waveguide

• DSP Processing with FiRPHASE

• Low distortion frontal Vented Ports

DATASHEET

TECHNICAL SPECIFICATIONS

Acoustical specifications

Frequency Response:

45 Hz ÷ 20000 Hz

Max SPL @ 1m:

109 dB

Horizontal coverage angle:

110°

Vertical coverage angle:

70°

Transducers

Dome Tweeter:

1.0'' neo, 1.0'' v.c

Woofer:

6.5'', 1.2'' v.c

Input/Output section

Input signal:

bal/unbal

Input connectors:

XLR, Jack, RCA

Input sensitivity:

-2 dBu/+4 dBu

Processor section

Crossover Frequencies:

2000Hz

Limiter:

Soft Limiter

Controls:

HF Adjust -1dB,0,+1dB
LF Adjust -2dB,0,+2dB

Power section

Total Power:

240 W Peak, 120 W RMS

High frequencies:

80 W Peak, 40 W RMS

Low frequencies:

160 W Peak, 80 W RMS

Connections:

XLR, Jack, RCA

Standard compliance

CE marking:

Yes

Physical specifications

Cabinet/Case Material:

MDF

Color:

Black - RAL 9005

Size

Height:

340 mm / 13.39 inches

Width:

210 mm / 8.27 inches

Depth:

290 mm / 11.42 inches

Weight:

5.5 kg / 12.13 lbs

Shipping informations

Package Height:

440 mm / 17.32 inches

Package Width:

368 mm / 14.49 inches

Package Depth:

286 mm / 11.26 inches

Package Weight:

6.2 kg / 13.67 lbs

DATASHEET

RCF products are continually improved. All specifications are therefore subject to change without notice.
