ART 710-A MK4
ACTIVE TWO-WAY SPEAKER
DESCRIPTION
ART 710-A MK4 is a unique product in its
category. The compression driver with
custom designed dome and high power voice
coil offers unique vocal clarity and sound
projection. The 10” woofer offers an
extremely linear response and a precise, deep
low frequency control. The transducers are
produced using the most advanced assembly
technologies. The amplifier delivers 1400
watts and is controlled by a DSP that takes
care of crossover, equalisation, phase control,
soft limiting and speaker protections.
FEATURES
• 129 dB Max SPL
• 1400 WATT 2-way peak power
• Innovative DSP Processing
• 1" Compression Driver, 1.75" v.c.
• 10" Woofer
• 90°x70°, wide dispersion constant directivity horn
• FiRPHASE Technology
DATASHEET
Rev. K
TECHNICAL SPECIFICATIONS
Acoustical specifications
Frequency Response:
50 Hz ÷ 20000 Hz
Max SPL @ 1m:
129 dB
Horizontal coverage angle:
90°
Vertical coverage angle:
70°
Transducers
Compression Driver:
1 x 1.0'', 1.75'' v.c
Woofer:
10'', 2.5'' v.c
Input/Output section
Input signal:
bal/unbal
Input connectors:
XLR, Jack
Output connectors:
XLR
Input sensitivity:
-2 dBu/+4 dBu
Mic. Input Sensitivity:
-32 dBu
Processor section
Crossover Frequencies:
1600 Hz
Protections:
Thermal, RMS
Limiter:
Soft Limiter
Controls:
Volume, Boost, Mic/Line
Power section
Total Power:
1400 W Peak, 700 W RMS
High frequencies:
400 W Peak, 200 W RMS
Low frequencies:
1000 W Peak, 500 W RMS
Cooling:
Convection
Connections:
VDE
Standard compliance
CE marking:
Yes
Physical specifications
Cabinet/Case Material:
PP Composite
Hardware:
2 x M10
Handles:
1 Top
Grille:
Steel
Color:
Black
Size
Height:
548 mm / 21.57 inches
Width:
340 mm / 13.39 inches
Depth:
305 mm / 12.01 inches
Weight:
14.2 kg / 31.31 lbs
Shipping informations
Package Height:
585 mm / 23.03 inches
Package Width:
425 mm / 16.73 inches
Package Depth:
405 mm / 15.94 inches
Package Weight:
16.8 kg / 37.04 lbs
DATASHEET
RCF products are continually improved. All specifications are therefore subject to change without notice.
PART NUMBER
• 13000521
ART 710-A MK4
115V
EAN 8024530014988
• 13000520
ART 710-A MK4
220-240V
EAN 8024530014858
DATASHEET
RCF products are continually improved. All specifications are therefore subject to change without notice.
