AM 1064
MIXER AMPLIFIER
DESCRIPTION
AM 1064 is a 60W mixer-amplifier having 3
audio inputs.
Audio input 1 has Phantom power supply and
get the priority over the other audio inputs
through an external command or
automatically thanks to the ‘VOX’ circuit. Dual
RCA connectors can be used to link stereo
(unbalanced) sound sources (e.g. CD – MP3
players, tuners, etc.). The amplifier output is
available either for low impedance
loudspeakers (min. 4 O) or 100 – 70 V
constant voltage line (for loudspeakers
having 100 – 70 V transformers).
FEATURES
• 60W 3-inputs Mixer-Amplifie
• 3 XLR input
• VOX facility and Phantom power supply on input 1
• Audio input 3 also with dual RCA connector
• Aux input on dual RCA connector
• DUCKING Control to adjust the Aux in level
• Audio output (with RCA connector) that sends the same signal routed to the internal amplifier
• Audio input (with RCA connector) to connect an external device directly to the internal power
amplifier
• Amplifier output to loudspeakers, available as 100 / 70 V constant voltage line and Low impedance
(min. 4 O)
DATASHEET
TECHNICAL SPECIFICATIONS
Amplifier specifications
Number of channels:
1
Power output per channel (@ 4 ohm):
60 W RMS
Power output (@ 100 V):
60 W RMS
Frequency Response (-3dB):
60 Hz ÷ 15 kHz
Distortion (THD+N) @ 1 kHz nominal
power:
<1.5 %
Input section
Total number of inputs:
5
Balanced:
3
Unbalanced:
5
Mono:
4
Stereo:
2
Line inputs:
2
Line connectors:
RCA
Mic+Line inputs:
3
Mic+Line connectors:
RCA, XLR
Mic+Line Phantom:
18 V DC
VOX:
Yes
General Purpose Inputs (GPI):
1
Output section
Signal output number:
1
Signal output connectors:
RCA
Power output connectors:
Euroblock
Processing
Tone controls:
Yes
Controls
Configuration:
Front panel
Priority:
Yes
Protections
Cooling:
Convection
Short circuit:
Yes
Thermal:
Yes
DC:
Yes
Fuses:
Yes
Power requirement
Operating voltage:
220-240/115 V~ 50/60Hz
Voltage selection:
External
DC power:
Yes
DC power value:
24 V
Power consumption:
170 W
Standard compliance
CE marking:
Yes
DATASHEET
RCF products are continually improved. All specifications are therefore subject to change without notice.
Physical specifications
Cabinet/Case Material:
Metal
Color:
Black
Rack mounting:
19", 2U
Size
Height:
88 mm / 3.46 inches
Width:
431 mm / 16.97 inches
Depth:
385 mm / 15.16 inches
Weight:
5.6 kg / 12.35 lbs
Shipping informations
Package Height:
165 mm / 6.5 inches
Package Width:
500 mm / 19.69 inches
Package Depth:
380 mm / 14.96 inches
Package Weight:
6.72 kg / 14.82 lbs
PART NUMBER
• 12135081
AM 1064
EAN 8024530007621
DATASHEET
RCF products are continually improved. All specifications are therefore subject to change without notice.
431 mm
88 mm
385 mm
Front panel
DRAWINGS
PANELS
Rear panel
