RCA TruFlat 24F610TD User Manual
TV/DVD
User's Guide
Changing Entertainment. Again.
This symbol indicates "dangerous voltage" inside the
product that presents a risk of electric shock or
personal injury.
WARNING
To reduce the risk of fire or electric shock, do
not expose this product to rain or moisture.
The apparatus shall not be exposed to
dripping or splashing and that no objects
filled with liquids, such as vases, shall be
placed on the apparatus.
Caution: To reduce the risk of electric shock, do not remove cover (or back). No user serviceable
parts inside. Refer servicing to qualified service personnel.
This symbol indicates important
instructions accompanying the
product.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
Refer to the identification/rating label located on the
back panel of your product for its proper operating
voltage.
FCC Regulations state that unauthorized changes or
modifications to this equipment may void the user’s
authority to operate it.
Caution: Using video games or any external accessory
with fixed images for extended periods of time can
cause them to be permanently imprinted on the
picture tube (or projection TV picture tubes). ALSO,
some network/program logos, phone numbers, etc.
may cause similar damage. This damage is not covered
by your warranty.
Cable TV Installer: This reminder is provided to call your
attention to Article 820-40 of the National Electrical
Code (Section 54 of the Canadian Electrical Code, Part
1) which provides guidelines for proper grounding and,
in particular, specifies that the cable ground shall be
connected to the grounding system of the building as
close to the point of cable entry as practical.
Important Information
Product Registration
Please fill out the product registration card
(packed separately) and return it immediately.
For U.S. customers: Your RCA Consumer
Electronics product may also be registered at
www.rca.com/productregistration. Registering
this product allows us to contact you if needed.
This symbol indicates that this product incorporates double
insulation between hazardous mains voltage and user
accessible parts. When servicing use only identical
replacement parts.
CAUTION
THIS PRODUCT UTILIZES A LASER. USE OF
CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE. DO NOT
OPEN COVERS AND DO NOT REPAIR YOURSELF.
REFER SERVICING TO QUALIFIED PERSONNEL.
Notes:
This DVD player is designed and manufactured to respond to the Region Management Information. If the Region
number of a DVD disc does not correspond to the Region number of this DVD player, this DVD player cannot play
the disc. The Region number for this DVD player is Region No 1.
This device is protected by U.S. patent numbers 4,631,603 and 4,577,216 and 4,819,098 and other intellectual
property rights. The use of Macrovision’s copy protection technology in the device must be authorized by
Macrovision and is intended for home and other limited pay-per-view uses only, unless otherwise authorized in
writing by Macrovision. Reverse engineering or disassembly is prohibited.
CLASS 1
LASER
PRODUCT
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here
and record the serial and model numbers. These numbers are located on the product.
Model No. ____________________ Serial No. __________________ Purchase Date: ______________
Dealer/Address/Phone: _________________________________________________________________
Table of Contents
1
Chapter 1: Connections & Setup
Things to Consider Before You Connect ......... 3
Protect Against Power Surges .................................. 3
Protect Components from Overheating ................ 3
Position Cables Properly to Avoid Audio
Interference ............................................................... 3
Important Stand and Base Safety Information ... 3
Use Indirect Light ........................................................ 3
Types of Discs Your TV/DVD will Play ..................... 3
Cables Needed to Connect Components to Your
TV/DVD ........................................................................ 3
TV/DVD + VCR ................................................... 4
Explanation of Jacks ......................................... 5
The Front of Your TV/DVD................................ 6
Front Panel Buttons .................................................... 6
Plug in the TV/DVD ........................................... 7
Put batteries in the remote ............................. 7
How to Use the Remote Control to Complete
the Initial Setup ................................................ 7
Turn on the TV................................................... 7
Complete the Initial Setup ............................... 7
Complete Auto Channel Search .............................. 8
Set the DVD Menu Language ........................... 8
Setting Other Options ...................................... 8
Chapter 2: Using the Remote Control
Button Descriptions .......................................... 9
Using the INPUT Button .......................................... 10
Programming the Remote to Operate Other
Components ..................................................... 10
Find Out If You Need to Program the Remote . 10
Programming the Remote ....................................... 11
How to Use the Remote After You’ve
Programmed It ....................................................... 12
Remote Control Codes ....................................12
Chapter 3: Playing Discs
Regional Coding .............................................. 14
Using Different Menus ................................... 14
Loading and Playing Discs .............................. 14
To Load and Play a Disc .......................................... 14
Using a Disc Menu .......................................... 15
Disc Playback Features Using the Remote .... 15
Using the On-Screen Info Display ................. 16
DVD Disc Info Display .............................................. 16
Time Display ............................................................... 16
Selecting a Title ......................................................... 16
Selecting a Chapter .................................................. 17
Selecting Subtitles ................................................... 17
Changing the Audio Language ............................. 17
Using the Repeat Feature ....................................... 18
Changing the Camera Angle ................................. 19
Playing Other Discs .........................................19
Audio CD Info Display ............................................. 19
mp3 Info Display ....................................................... 19
Video CD Info Display .............................................. 19
Using the Time Display ............................................ 20
Selecting a Specific Track....................................... 20
Selecting a Specific Index (Available only on
Video CDs) ............................................................... 20
Selecting a Play Mode (Available only on Audio
CDs and mp3s) ....................................................... 20
Using the Program Play Feature ........................... 21
Editing a Playlist ....................................................... 22
Using the Repeat Feature ....................................... 22
Changing the Audio Channel Output (Available
only on Video CDs) ................................................ 22
Using IntroScan (Available only on Audio CDs and
mp3s) ........................................................................ 22
Using PlayBack Control (Available only on Video
CDs) ........................................................................... 22
Viewing JPEG files........................................... 23
Chapter 4: Using the TV’s Features
Channel Banner ............................................... 24
Why You Should Use the Auto Tuning
Feature ............................................................. 24
How to Set Up the Auto Tuning Feature............ 24
Parental Controls and V-Chip ........................ 25
2
Table of Contents
How V-Chip Works ................................................... 26
USA V-Chip Rating System .................................... 26
Canadian English V-Chip Rating System ........... 27
Canadian French V-Chip Rating System ............ 28
USA V-Chip TV Rating Limit .................................. 28
Blocking Specific Content Themes ...................... 30
Viewing Specific Content Themes........................ 30
Blocking Canadian V-Chip Ratings ...................... 31
V-Chip Movie Rating Limit .................................... 31
V-Chip Exempt Program Block ............................. 31
KidPass ......................................................................... 32
V-Chip Active ............................................................. 32
Front Panel Lock........................................................ 32
Change Password ...................................................... 32
Chapter 5: Using the DVD Menu
The DVD’s Menu System ................................. 33
The Play/Resume Play Option......................... 33
The Play Mode Menu ...................................... 33
Selecting a Play Mode ............................................. 33
How to Create a Program ....................................... 33
Editing a Program ..................................................... 34
AutoPlay ...................................................................... 35
IntroScan ..................................................................... 35
The Lock Menu ................................................ 35
Locking Your DVD ..................................................... 36
Unlocking Your DVD................................................. 36
Changing Your Password ........................................ 36
Setting the Ratings Limits ..................................... 37
Unrated Titles ............................................................. 38
System Test................................................................. 38
The Display Menu ............................................ 39
TV Image ...................................................................... 39
On-Screen Displays .................................................. 40
The Sound Menu ............................................. 40
Sound Logic ................................................................ 40
Digital Output ............................................................ 41
The Languages Menu ...................................... 42
Changing the Player Menus, Disc Menus, Audio or
Subtitles Language Preferences ........................ 42
Chapter 6: Using the TV’s Menu System
Sound Menu .................................................... 43
Picture Menu ................................................... 43
Setup Menu ..................................................... 44
Parental Control Menu ................................... 45
Time Menu ....................................................... 45
Chapter 7: Other Information
Troubleshooting ...............................................46
Care and Cleaning ........................................... 50
Limited Warranty ............................................ 51
Accessory Information .................................... 54
Chapter 1 3
Graphics contained within this publication are for representation only.
Chapter 1: Connections & Setup
Things to Consider Before You Connect
Protect Against Power Surges
• Connect all components before you plug any of their power cords into the wall outlet.
•Turn off the TV/DVD and/or component before you connect or disconnect any cables.
• Make sure all antennas and cables are properly grounded. Refer to the Important Safety Instructions
packed separately.
Protect Components from Overheating
• Don’t block ventilation holes on any of the components. Arrange the components so that air can
circulate freely.
• Don’t stack components.
• If you place components in a stand, make sure you allow adequate ventilation.
• If you connect an audio receiver or amplifier, place it on the top shelf so the heated air from it won’t
flow around other components.
Position Cables Properly to Avoid Audio Interference
• Insert each cable firmly into the designated jack.
• If you place components above the TV/DVD, route all cables down the side of the back of the TV/DVD
instead of straight down the middle of the TV/DVD.
• If your antenna uses 300-ohm twin lead cables, do not coil the cables. Also, keep the twin lead
cables away from audio/video cables.
Important Stand and Base Safety Information
Choose the location for your TV/DVD carefully. Place the TV/DVD on a stand or base that is of adequate
size and strength to prevent the TV/DVD from being accidentally tipped over, pushed off, or pulled off.
This could cause personal injury and/or damage the TV/DVD. Refer to the Important Safety Instructions
packed separately.
Use Indirect Light
Don’t place the TV/DVD where sunlight or room lighting will be directed toward the screen. Use soft or
indirect lighting.
Types of Discs Your TV/DVD will Play
• DVD discs - DVD discs contain high quality picture and sound content.
• Audio discs - Audio CDs contain musical or sound content only. This player is also capable of playing
CDs that contain JPEG files.
• Video CD discs – Like DVD video discs, Video CDs contain picture and sound content. The difference is
the amount of information that can be stored on the disc, and the quality of the video.
• mp3 discs – A disc that contains audio files (for example, a CD-R with downloaded mp3 files).
Cables Needed to Connect Components to Your TV/DVD
The pictures below show the cables needed for the connections represented in this book.
Audio/Video cables
S-Video cableCoaxial cable
4 Chapter 1
Graphics contained within this publication are for representation only.
Connections & Setup
TV/DVD + VCR
1. Connect your TV/DVD to your VCR.
A. Connect the audio (white and red) cables to the VIDEO 1 R and L/MONO AUDIO jacks on the back
of the TV/DVD and to the Audio Output jacks on the VCR.
B. If your VCR has an S-Video jack, connect an S-Video cable to the S-Video jack on the VCR and to
the S-VIDEO IN jack on the back of the TV. If your VCR doesn’t have an S-Video jack, go to C.
-OR-
C. Connect a video cable (yellow) to the Video Output Jack on the VCR and to the VIDEO 1 VIDEO
jack on the back of the TV/DVD.
D. Connect a coaxial cable to the TV ANT jack on your TV/DVD and to the Output Jack on your VCR
(sometimes labeled OUT TO TV).
Note: If your VCR has A/V output jacks, you can connect your TV to your VCR using audio/video cables for
better quality.
2. Make sure cable or antenna is connected to your VCR.
Connect the coaxial cable from your cable outlet or antenna to the antenna input on the VCR.
Go to page 7
TV (back panel)
DIGITAL
R
L/MONO
AUDIO
VIDEO
TV ANT
VCR
S-VIDEO
LR VIDEO
OUT
IN FROM ANT
OUT TO TV
CH3
CH4
From Cable
or Antenna
S-VIDEO IN
R
AUDIO
VIDEO
R
L
VIDEO 1
MONITOR
OUT
L/MONO
VIDEO 2
VIDEO
AUDIO
OUT
1A
1D
2
1B
1C
Chapter 1 5
Graphics contained within this publication are for representation only.
Connections & Setup
Explanation of Jacks
This section describes the jacks you can use to make connections. There are several
ways to connect components to your TV/DVD.
TV ANT Lets you connect a coaxial cable to receive the signal from the antenna,
cable, cable box, or if using the example on page 4, a VCR.
VIDEO 1
VIDEO, AUDIO R and L/MONO Lets you connect a
component such as a VCR.
• R (RIGHT) AUDIO Provides right audio connection. The
right audio connector is usually red.
• L/MONO AUDIO Provides left audio connection. The
left audio connector is usually white.
• VIDEO Provides composite video connection. The video
connector is usually yellow.
• S-VIDEO IN Provides better picture quality than the
video jacks because the color part of the signal is
separated from the black and white part of the picture.
When using S-VIDEO IN, make sure to connect left and
right audio cables to the L/MONO and R AUDIO Input
jacks.
VIDEO 2
VIDEO, AUDIO R and L/MONO Lets you connect a second
component, such as a VCR. Their description is the same as
VIDEO 1.
R
L/MONO
AUDIO
VIDEO
S-VIDEO IN
VIDEO 1
R
L
MONITOR
OUT
VIDEO
R
AUDIO
VIDEO
L/MONO
VIDEO 2
DIGITAL
AUDIO
OUT
DIGITAL AUDIO OUT Lets you connect a digital receiver for
improved sound quality. Go to page 41 for more information
on digital audio.
MONITOR OUT Lets you connect an amplifier or audio
receiver for improved sound quality or an external video
monitor. Connect to a component such as a DVD recorder for
recording capability.
6 Chapter 1
Graphics contained within this publication are for representation only.
Connections & Setup
The Front of Your TV/DVD
The TV/DVD has front input jacks for your convenience: one
set of audio/video inputs and a headphone jack. These jacks
are towards the front of the TV/DVD on the side. To access
the component you connected to the front of the TV/DVD,
press the INPUT button on your remote until FRNT appears
on the screen. The jacks are ideal for connecting a video
game console or a camcorder.
Note: When connecting a component that only has one audio jack,
such as some camcorders, use the TV/DVD’s AUDIO L/MONO jack to
hear the audio.
H-PHONE Allows you to connect headphones to listen to
the sound coming from the TV/DVD.
L/MONO and R AUDIO Receives audio from another
component such as a VCR, camcorder, or video game console.
VIDEO Receives video from another component such as a
VCR, camcorder, or video game console.
Front Panel Buttons
If you cannot locate your remote, you can use the front
panel buttons of your TV/DVD to operate many of the
TV/DVD’s features.
PLAY/PAUSE Begins disc play. If in play mode, pauses disc.
STOP Stops disc play.
OPEN/CLOSE Press to open and close the disc tray.
MENU/OK Brings up the Main menu. In the menu system, it
selects highlighted items.
CH v Scans down through the current channel list. In the
menu system, acts like the down arrow button on the remote
control and adjusts menu controls.
CH Scans up through the channel list. In the menu
system, acts like the up arrow button on the remote control
and adjusts menu controls.
VOL < Decreases the volume. In the menu system, acts like
the left arrow button on the remote control and adjusts
menu controls.
VOL > Increases the volume. In the menu system, acts like
the right arrow button on the remote control and adjusts
menu controls.
POWER Turns the TV/DVD on and off.
MENU/OK
VOL
CH
CH
VOL
POWER
L
AUDIO
VIDEOH-PHONE R
v
Chapter 1 7
Graphics contained within this publication are for representation only.
Connections & Setup
Plug in the TV/DVD
Plug the end of the power cord into a grounded wall outlet. Insert the plug
completely into the outlet.
Put batteries in the remote
• Remove the battery compartment cover from the back of the remote by
pushing down on and sliding off the cover.
• Insert 2 fresh “AAA” batteries. Make sure the polarities (+ and -) are aligned
correctly.
• Replace the cover.
How to Use the Remote Control to Complete
the Initial Setup
The technical term is “Navigation”– how you move through
the on-screen menus. The method is the same throughout
the menu screens: highlight your choice and select it.
To highlight a menu item, press the arrow buttons on the
remote to highlight one of the items listed on the screen. Use
the up or down arrow button to move up or down. Use the
right or left arrow button to move right or left.
To select the item that you’ve highlighted, press OK.
Note: Highlighted means that the menu item stands out from other
menu items on the list (appears darker, brighter, or a different color).
Turn on the TV
Press TV on the remote, or press POWER on the TV/DVD’s
front panel.
Note: Pressing the TV button not only turns on the TV, but puts the
remote into TV mode. “TV mode” means that the buttons on the
remote control operate the TV’s functions.
Complete the Initial Setup
The menu system in your TV allows the TV’s features to work
properly. The first time you turn on your TV, the SETUP screen
appears with Language highlighted. The default language is
English. To choose another language, press the right arrow
button on the remote.
DVD
ON OFF
VCR TV
VOL
MUTE GO BACK
CH
CLEAR
MENU
PRESETS
SKIP
OKOK
DISC MENU
Arrows
Go Back
Auto Ch. Search
Closed Caption
Auto Tuning
Language
SETUP
. . .
. . .
. . .
English . . .
OK
button
8 Chapter 1
Graphics contained within this publication are for representation only.
Connections & Setup
Complete Auto Channel Search
This part of the setup allows the TV to search for all channels
viewable through your antenna or cable TV system. This is
sometimes called auto programming.
1. Highlight Auto Ch. Search and press OK.
2. The Signal Type option is set to Cable. To change the
option to Antenna, press the right arrow button and then
press OK.
3. Press the down arrow button to highlight Start. Press OK
to begin the auto channel search.
Once the search is complete, you can begin watching TV. For
information on customizing your channels or menu options,
go to Chapter 6.
Set the DVD Menu Language
The first time you are in DVD mode, the Automatic Language
Selection Screen appears.
By default, the DVD’s on-screen displays are shown in
English. If you want the on-screen menus to appear in
English, press OK on the remote.
To change the language:
1. Press the down arrow button on the remote until the
appropriate language is highlighted.
2. Press OK on the remote.
This screen sets all language preferences for on-screen
displays to the same language. You can use the DVD’s menu
system to set individual language preferences (see Chapter 5).
Setting Other Options
The DVD’s menu system contains many options which can
enhance your disc viewing and listening experience. These
options include:
•ratings limits
• language preferences
• audio preferences
• display options
For more information on DVD menu options, see Chapter 5.
Go Back
Signal Type
Start
Channel
AUTO CHANNEL SEARCH
Cable. . .
This is the Automatic Language Selection
Screen. English is the default language,
and appears highlighted when the screen
comes up.
Chapter 2 9
Graphics contained within this publication are for representation only.
Chapter 2: Using the Remote Control
Button Descriptions
Arrows Used to highlight different items in the TV menu and to adjust the menu
controls.
Indicator Indicates the programming mode when programming the remote to
control components. Lights when you press a valid button on the remote. Flickers
when a button is pressed and the batteries are low.
(0-9) Number Buttons Enter channel numbers and time settings directly
through the remote control.
To enter a one-digit channel, enter a zero first. To enter a two-digit channel, press
the two digits and expect a few seconds delay. This is if you want to enter a third
digit.
AGAIN In DVD mode, goes back approximately 10 seconds to see and hear missed
content.
CC In TV mode, toggles closed captioning on and off. In DVD mode, displays the
Info Display with the Subtitle icon highlighted.
ANTENNA In VCR mode, functions as a TV/VCR button.
CH + or CH - In TV mode, scans up or down through the current channel list.
Press once to change the channel up or down; press and hold to continue
changing channels. In DVD mode, highlights the Chapter Info Display icon.
CLEAR Removes any menu or display from the screen and returns you to normal
viewing.
DISC MENU In DVD mode, press while playing a DVD or Video disc and the disc’s
menu system will appear.
DVD Puts the remote in DVD mode.
FORWARD In DVD mode, advances the disc forward.
GO BACK In TV mode, returns you to the previous channel. In DVD mode, returns
you to previous screen.
GUIDE If you’re operating another component that has a guide, this button
accesses the on-screen Guide.
INFO In TV mode, brings up the channel banner. In DVD mode, displays the Info
Display.
INPUT Toggles through the available input sources (VID1/SVID1, VID2, FRNT, and
current channel).
MENU Brings up the TV’s Main menu.
MUTE Reduces the TV’s volume to its minimum level. Press again to restore the
volume.
OK When in the menu system, selects highlighted items.
ON•OFF When in TV mode, turns the TV/DVD on and off. If in another mode
(VCR) and programmed, will turn the component on and off.
OPEN•CLOSE Opens the disc tray if it is closed; closes the disc tray if it is open.
PAUSE In DVD mode, press PAUSE when the disc is playing to pause playback.
PLAY In DVD mode, plays the disc.
DVD
ON OFF
VCR TV
VOL
MUTE GO BACK
CH
CLEAR
MENU
PRESETS
CC
GUIDE
INFO
SKIP
123
4
56
7
89
0
INPUT
ANTENNA
REVERSE
PLAY
FORWARD
RECORD
STOP
PAUSE
AGAIN
ZOOM
OPEN CLOSE
SPEED
SEARCH
OKOK
DISC MENU
Indicator
10 Chapter 2
Graphics contained within this publication are for representation only.
Using the Remote Control
PRESETS In TV mode, picture options are reset to original factory settings.
RECORD In VCR mode, press to program your VCR to record a program.
REVERSE In DVD mode, press REVERSE to go backwards on a disc.
SEARCH In VCR mode, accesses Index Search feature.
SKIP Press once before changing channels and the TV will wait 30 seconds before
returning to the original channel. Press repeatedly to add more time. In DVD mode,
displays the Info Display with the Angle icon highlighted.
SPEED In VCR mode, selects a recording speed.
STOP In DVD mode, stops playing the disc and displays the DVD’s menu system.
TV Turns on the TV and puts the remote in TV mode. Also displays current status.
VCR Puts the remote in VCR mode and, if auto tuning is enabled, will turn on the TV
and tune to the correct video input channel.
VOL – or VOL + Decreases or increases the TV’s volume.
ZOOM In DVD mode, zooms in on the picture.
Using the INPUT Button
Use the INPUT button to scroll through the available video input channels and view
components you have connected to the TV/DVD.
1. Make sure the component you want to view is turned ON.
2. Press INPUT to tune to an available video input source and view the component.
3. To return to the previous channel, continue pressing INPUT.
Programming the Remote to Operate Other
Components
The universal remote can be programmed to operate most
brands of remote controllable components. The remote is
already programmed to operate most RCA, GE, and Proscan
components.
Notes: The TV and DVD buttons can’t be programmed on this remote.
The remote may not be compatible with all brands and models of
components. It also may not operate all functions of the remote that
came with your component.
Find Out If You Need to Program the Remote
To determine whether the universal remote needs to be
programmed for your component, turn the component ON.
For example, to program the remote for a VCR, turn on the
VCR. Point the remote at the VCR, and press the VCR button.
Then press ON•OFF or CH + (channel up) or CH – (channel
down) to see if the VCR responds to the remote commands. If
the component does not respond, the remote needs to be
programmed.
DVD
ON OFF
VCR TV
VOL
MUTE GO BACK
CH
CLEAR
MENU
PRESETS
CC
GUIDE
INFO
SKIP
123
4
56
7
89
0
INPUT
ANTENNA
REVERSE
PLAY
FORWARD
RECORD
STOP
PAUSE
AGAIN
ZOOM
OPEN CLOSE
SPEED
SEARCH
OKOK
DISC MENU
VCR button
ON•OFF
button
REVERSE
and PLAY
buttons
STOP
button
You’ll use these buttons when
programming the remote.
CLEAR
button
Chapter 2 11
Graphics contained within this publication are for representation only.
Using the Remote Control
Programming the Remote
There are two ways to program the remote control:
• automatic code search
• direct entry
Using Automatic Code Search
The following instructions can be used to program the remote to operate each of your
components. If you want to stop the automatic code search without programming any of
your components, press CLEAR until the indicator on the remote turns off.
1. Turn on the component you want to operate.
2. Press and hold the component button you want to program. While holding the
component button, press and hold ON•OFF until the indicator on the remote turns on,
then release both buttons.
3. Point the remote at the component. Press and release PLAY (the indicator light on the
remote flashes).
The remote is searching for the correct code to program. When the indicator stops
flashing (after about 5 seconds), press PLAY again to tell the remote to search the next
set of codes.
Continue pressing PLAY until the component turns off or the indicator light on the
remote turns off. If the indicator light turns off, then all the codes for that particular
component have been tested once. If the component does not turn off, then the
remote can’t be programmed to operate that component.
Note: Each time you press PLAY, the remote sends about 10 sets of codes. Therefore, you might have
to press the PLAY button up to 20 times.
If the component you want to operate does turn off:
1. Press and release REVERSE, then wait 2 seconds. Repeat this step until the device turns
back ON.
2. To finish, press and hold STOP until the indicator on the remote turns off.
Using Direct Entry
1. Turn on the component to be programmed.
2. Look up the brand and code number(s) for the component on the code list in this
section.
3. Press and hold the component button you want to program on the remote.
4. Enter the code from the remote control code list on the following pages. If the
indicator flashes, you have either entered an invalid code or the button isn’t
programmable.
5. Release the component button.
6. Point the remote at the component. Press ON•OFF to see if the component responds to
the command. If it doesn’t, try pressing the component button and then ON•OFF again.
• If you get no response, repeat these steps using the next code listed for your brand,
until the component responds to the remote commands.
• If you try all the codes for your component brand and none work, try the automatic
code search method. If automatic code search doesn’t find the code, the remote is not
compatible with your component.
12 Chapter 2
Graphics contained within this publication are for representation only.
Using the Remote Control
How to Use the Remote After You’ve Programmed It
Because this universal remote can operate several different components it uses
operational modes triggered by the component buttons. For example, if you want
the remote to operate the TV, you would press the TV button to put the remote
into TV mode before you could operate the TV.
1. Press the appropriate component button (DVD, TV, VCR) to set the remote to
operate the component.
2. Press ON•OFF to turn the component ON or OFF.
3. Use the remote buttons that apply to that component.
Note: If you keep pressing buttons and nothing happens, the remote is probably in the wrong
mode. You must press the component button that matches the component you want to
operate (i.e., if you want to operate the VCR, press VCR on the remote control to put the remote
in VCR mode.)
VCR Codes
Programmable for VCR button.
Admiral ...................................................................................... 2132
Adventura .................................................................................. 2026
Aiko ............................................................................................ 2027
Aiwa ........................................................................................... 2026
Akai ................... 2003, 2004, 2005, 2007, 2008, 2111, 2112, 2113
American High .......................................................................... 2021
Asha ........................................................................................... 2013
Audio Dynamics ............................................................ 2009, 2010
Audiovox ................................................................................... 2014
Bell & Howell .............................................................................2011
Beaumark ................................................................................... 2013
Broksonic ........................................................................ 2012, 2025
Calix ........................................................................................... 2014
Candle ....................................................... 2013, 2014, 2015, 2016,
............................................................................... 2017, 2018, 2019
Canon .................................................................... 2021, 2022, 2114
Capehart ........................................................................... 2020, 2110
Carver ......................................................................................... 2062
CCE .................................................................................. 2027, 2061
Citizen ............................................................................ 2013, 2014,
............................................... 2015, 2016, 2017, 2018, 2019, 2027
Colortyme .................................................................................. 2009
Colt ............................................................................................. 2061
Craig ........................................................... 2013, 2014, 2023, 2061
Curtis-Mathes ..................................................... 2000, 2009, 2013,
..................................... 2016, 2018, 2021, 2022, 2024, 2115, 2131
Cybernex ................................................................................... 2013
Daewoo ............ 2015, 2017, 2019, 2025, 2026, 2027, 2028, 2110
Daytron ....................................................................................... 2110
DBX ................................................................................. 2009, 2010
Dimensia ......................................................................... 2000, 2131
Dynatech .................................................................................... 2026
Electrohome ................................................................... 2014, 2029
Electrophonic ............................................................................ 2014
Emerson ...............................2012, 2014, 2015, 2021, 2024, 2025,
..........2026, 2029, 2030, 2031, 2032, 2033, 2034,2035, 2036,
..........2037, 2038, 2039, 2040, 2041, 2042,2044, 2045, 2046,
............................................2047, 2065, 2113, 2116, 2117, 2130
Fisher ...............2011, 2023, 2048, 2049, 2050, 2051, 2052, 2118
Fuji ................................................................................... 2021, 2119
Funai .......................................................................................... 2026
Garrard .................................................................................. 2026
GE .................................................................... 2000, 2001, 2013,
........................................... 2021, 2022, 2053, 2115, 2120, 2131
Goldstar ................................................ 2009, 2014, 2018, 2054
Gradiente .............................................................................. 2026
Harley Davidson .................................................................. 2026
Harman Kardon ................................................................... 2009
Harwood ............................................................................... 2061
Headquarter ........................................................................... 2011
Hitachi ...................................................................... 2055, 2056,
...................................................... 2057, 2107, 2111, 2120, 2122
Hi-Q ....................................................................................... 2023
Instant Replay ...................................................................... 2021
JCL ......................................................................................... 2021
JC Penney ............................................. 2009, 2010, 2011, 2013,
................................................... 2014, 2021, 2022, 2055, 2056,
..................................................... 2058, 2059, 2060, 2107, 2118
Jensen ............................................................... 2055, 2056, 2111
JVC ..................................... 2009, 2010, 2011, 2018, 2111, 2123
Kenwood ................. 2009, 2010, 2011, 2016, 2018, 2111, 2123
KLH ........................................................................................ 2061
Kodak .......................................................................... 2014, 2021
Lloyd ..................................................................................... 2026
Logik ..................................................................................... 2061
LXI ......................................................................................... 2014
Magnavox ...................................................... 2021, 2022, 2062,
..................................................... 2063, 2104, 2105, 2108, 2124
Magnin .................................................................................. 2013
Marantz ....... 2009, 2010, 2011, 2016, 2018, 2021, 2062, 2064
Marta ..................................................................................... 2014
Masushita ............................................................................. 2021
Mei ........................................................................................ 2021
Memorex ..... 2011, 2013, 2014, 2021, 2023, 2026, 2104, 2132
MGA ................................................................. 2029, 2065, 2113
MGN Technology ................................................................. 2013
Midland ................................................................................. 2053
Minolta ............................................................ 2055, 2056, 2107
Mitsubishi ........... 2029, 2055, 2056, 2065, 2066, 2067, 2068,
.......... 2069, 2070, 2071, 2072, 2073, 2074, 2106, 2113, 2123
Montgomery Ward .................................................... 2075, 2132
Motorola ..................................................................... 2021, 2132
Remote Control Codes
Chapter 2 13
Graphics contained within this publication are for representation only.
Using the Remote Control
VCR Codes continued
MTC ............................................................................. 2013, 2126
Multitech .................................... 2013, 2016, 2026, 2053, 2061
NEC ............................................... 2009, 2010, 2011,2016, 2018,
............................................ 2064, 2076, 2078, 2079, 2111, 2123
Nikko ...................................................................................... 2014
Noblex .................................................................................... 2013
Olympus ................................................................................. 2021
Optimus ....................................................................... 2014, 2132
Optonica ................................................................................ 2096
Panasonic ......................... 2021, 2022, 2109, 2125, 2126, 2127
Pentax ..........................................2016, 2055, 2056, 2107, 2120
Pentex Research.................................................................... 2018
Philco ..................................................... 2021, 2022, 2062, 2063
Philips .................................................... 2021, 2062, 2096, 2124
Pilot ........................................................................................ 2014
Pioneer ........................................ 2010, 2055, 2080, 2081, 2123
Portland .................................................. 2016, 2017, 2019, 2110
Proscan ............................................................. 2000, 2001, 2131
Protec ..................................................................................... 2061
Pulsar ..................................................................................... 2104
Quarter ....................................................................................2011
Quartz .....................................................................................2011
Quasar ............................................................... 2021, 2022, 2125
RCA ...................... 2000, 2001, 2003, 2013, 2021, 2055, 2056,
.................. 2082, 2083, 2084, 2085, 2086, 2087, 2088, 2089,
....................... 2090, 2091, 2107, 2115, 2120, 2125, 2131, 2133
Radioshack/Realistic ............................ 2011, 2013, 2014, 2021,
.................... 2022, 2023, 2026, 2029, 2049, 2050, 2096, 2132
Radix ...................................................................................... 2014
Randex ................................................................................... 2014
Ricoh ...................................................................................... 2128
Runco ..................................................................................... 2104
Samsung ........................... 2005, 2013, 2015, 2033, 2053, 2112
Sanky ........................................................................... 2104, 2132
Sansui ..................................................... 2010, 2092, 2111, 2123
Sanyo ................................................................ 2011, 2013, 2023
Scott ............ 2012, 2015, 2025, 2032, 2038, 2065, 2093, 2116
Sears ............................................ 2011, 2014, 2021, 2023, 2048,
............................... 2049, 2050, 2051, 2055, 2056, 2107, 2118
Sharp ..................... 2017, 2029, 2094, 2095, 2096, 2097, 2132
Shintom ................................................. 2004, 2056, 2061, 2098
Shogun ................................................................................... 2013
Signature ............................................................................... 2132
Singer ................................................................ 2021, 2061, 2128
Sony ....................................................... 2004, 2098, 2099, 2119
STS ............................................................................... 2021, 2107
Sylvania ................ 2021, 2022, 2026, 2062, 2063, 2065, 2124
Symphonic ............................................................................ 2026
Tandy ......................................................................................2011
Tashiko ................................................................................... 2014
Tatung ..................................................................................... 2111
TEAC ................................................................. 2026, 2085, 2111
Technics ....................................................................... 2021, 2109
Teknika ........................................ 2014, 2021, 2026, 2100, 2129
TMK .................................................................. 2013, 2024, 2047
Toshiba ................... 2015, 2049, 2051, 2055, 2065, 2093, 2116
Totevsion .................................................................... 2013, 2014
Unitech ................................................................................... 2013
Vector Research .................................... 2009, 2010, 2015, 2016
Victor ..................................................................................... 2010
Video Concepts ........................... 2009, 2010, 2015, 2016, 2113
Videosonic ............................................................................. 2013
Wards ........................................................ 2013, 2014, 2015, 2021,
........................................... 2023, 2026, 2029, 2055, 2056, 2061,
.................................... 2096, 2101, 2102, 2103, 2107, 2116, 2132
XR-1000 .............................................................. 2021, 2026, 2061
Yamaha ............................................. 2009, 2010, 2011, 2018, 2111
Zenith ............................................... 2004, 2098, 2104, 2119, 2128
14 Chapter 3
Graphics contained within this publication are for representation only.
Chapter 3: Playing Discs
Regional Coding
Both the TV/DVD unit and the discs are coded by region. These regional codes must match in order for
the disc to play. If the codes don’t match, the disc won’t play. This unit’s code is region 1.
Using Different Menus
Each disc is programmed with different features. There are three separate menu paths that you can use
to access features:
• The Disc menu – The disc menu is part of each disc and is separate from the DVD’s menu system. The
contents of each disc menu vary according to how the disc was authored and what features are
included. The disc menu is turned on and off (while the disc is playing) with the DISC MENU button
on the remote.
• The DVD’s Info Display – The Info Display appears as icons across the top of the screen when a disc
is playing. It can only be accessed while you are playing a disc. It’s turned on and off with the INFO
button on the remote.
• The DVD’s menu system – The DVD’s menu system is accessed only when a disc isn’t playing. It
appears automatically when the STOP button is pressed.
A feature will only work if the disc was programmed with that feature. If a menu item is “grayed out” it
means that item isn’t available.
Loading and Playing Discs
Your TV/DVD unit plays DVD discs, Video CD discs, Audio CD discs, mp3 discs, CD-R discs, and CDs with
JPEG files. Before you load a disc, make sure that it is compatible with the player. The following discs
CANNOT be used with this player:
• Laserdiscs, CD-I, CD-ROM (computer-only discs), CD-RW, DVD-ROM, Discs recorded using other
broadcast standards (i.e. PAL or SECAM)
To Load and Play a Disc
To put the TV/DVD in DVD mode and play a disc, press the DVD button on the
remote control.
1. Press the OPEN•CLOSE button on the front of the TV/DVD. The disc tray opens.
2. Place a disc gently into the tray with the disc’s label facing up (double-sided
discs have content on both sides, so you can place either side up).
3. Press the OPEN•CLOSE or PLAY button. The disc tray closes.
The TV/DVD reads the disc’s table of contents, and then one of three things
happens depending on how the disc was programmed:
• The disc starts playing.
• The disc menu appears on the screen. One of the options will start disc
play. Highlight that option and press OK on the remote.
• The DVD’s main menu appears on the screen. Highlight the Play option and
press OK on the remote.
The unit remembers the five most recent discs (DVD or Video CD only) played and
begins playback at the approximate point which the disc was last stopped. To
resume normal playback, press the DISC MENU button and choose PLAY from the
Disc main menu.
C
a
n
'
t
C
a
t
c
h
U
p
C
a
n
'
t
C
a
t
c
h
U
p
C
a
n
'
t
C
a
t
c
h
U
p
(
W
i
d
e
s
c
r
e
e
n
V
e
r
s
i
o
n
)
This is an example of
a one-sided disc.
This is an example of
a 2-sided disc. The
title is in the center.
Chapter 3 15
Graphics contained within this publication are for representation only.
Playing Discs
Using a Disc Menu
A disc is capable of having an on-screen menu that is separate from the DVD’s menu
system and on-screen Info Display. The disc menu might only contain a list of the titles
and chapters, or it may allow you to change features such as language and playback
settings.
The content and operation of disc menus vary from disc to disc.
Disc Playback Features Using the Remote
You can use the remote control to activate disc playback features.
Playback features aren’t usually available during the opening credits of a movie. If a
playback feature isn’t available, the invalid symbol
appears on the screen when you
press that button.
Fast Motion Playback (Picture Scan)
To scan quickly through the disc when you’re playing it, use the Picture Scan feature.
1. Press the REVERSE or FORWARD button on the remote when you’re playing a disc.
2. Press the button again to scan at a faster speed. Each time you press the button,
the scanning speed increases.
3. Press the PLAY button at any time to resume normal playback.
Note: You won’t hear the sound (audio) on DVD discs when you’re using the picture scan feature.
Freeze Frame and Frame Advance
1. Press PAUSE when a disc is playing to freeze the picture.
2. Each time you press the PAUSE button, the picture advances one frame.
3. Press PLAY to resume normal playback.
Slow Motion Playback (in Freeze Frame Mode)
While the disc is in freeze frame mode, you can use slow motion playback.
1. While the disc is playing, press PAUSE on the remote.
2. Press the REVERSE or the FORWARD button.
3. Press the button again to increase the slow motion playback speed.
4. Press PLAY to resume normal playback.
Chapter Advance
While a disc is playing, press CH + or CH – button to highlight the Chapter icon and go
forward or backward a chapter or track. Press CH + or CH – again to continue to go
forward or backward a chapter or track at a time by.
Scene Again™
When you’re watching or listening to a DVD disc, press the AGAIN button on the
remote to go back approximately 10 seconds to see and hear missed content. Subtitles
will automatically be displayed until the end of the replayed scene (to select the
subtitle options, go to page 17). This feature only works if the disc is encoded with
navigation control.
16 Chapter 3
Graphics contained within this publication are for representation only.
Playing Discs
Using the On-Screen Info Display
The on-screen Info Display contains many playback features. To see the Info
Display, press the INFO button on the remote while a disc is playing. The Info
Display appears across the top of the screen. Each feature is illustrated with an
icon. Use the left/right arrow buttons on the remote to move through the different
icons in the Info Display.
When an icon is highlighted, use the up/down arrow buttons on the remote to
scroll through the choices displayed in the text box under the icons.
Remember, you can only access the Info Display when you’re playing a disc. Also,
the Info Display features are only available if the disc was created with that
particular feature (i.e., if you select the Subtitle icon, you won’t be able to change
the subtitle language unless the author of the disc created the disc with subtitles).
The invalid symbol
appears on the screen when you press a button that doesn’t
have any function. If one of the icons is “grayed out,” that Info Display feature
isn’t available for the disc you’re playing. To make the Info Display disappear from
the screen, press INFO on the remote.
DVD Disc Info Display
Time Display
This feature displays the audio/video time. For DVD discs, the time displayed refers
to the current title time. For Audio CDs, it refers to the current track time.
For DVD video discs, the Time Display also acts as a Time Search feature. This lets
you go to a particular scene in a movie by entering the time that scene is played.
To use Time Search, press INFO on the remote to bring up the Info Display.
Highlight the Time Display and enter the elapsed time of the scene you wish to go
to. For example, enter 01:12:00 to go to the scene that plays at 1 hour and twelve
minutes into the movie.
Title
Repeat
Audio
Time Display
Angle
Subtitles
Chapter
Selecting a Title
Some discs contain more than one title. Each title is divided into chapters. To select
a title:
1. While the disc is playing, press INFO on the remote to bring up the Info Display.
2. If the Title icon on the Info Display isn’t highlighted, use the left/right arrow
buttons to highlight it.
3. Use the number button(s) on the remote to enter the title number or press the
up/down arrow buttons to go to the next/previous title.
4. Press OK on the remote when the title you want to play appears in the text
window.
Note: Some discs only have one title.
Chapter 3 17
Graphics contained within this publication are for representation only.
Playing Discs
Selecting a Chapter
Because DVD discs use digital technology, a title can be divided into individual
chapters (similar to tracks on a CD). You can skip to a specific chapter by using the
Chapter feature in the Info Display.
1. While a disc is playing, press INFO on the remote to bring up the Info Display.
2. Press the left/right arrow buttons to highlight the Chapter icon.
3. Use the number buttons on the remote to enter the number of the chapter you
want to play or press the up/down arrow buttons to go to the next/previous
title.
Notes: The Chapter feature won’t work if the disc isn’t formatted with separate chapters.
By pressing CH + or CH – on the remote you can automatically highlight the Chapter icon and
advance to the next chapter or preceding chapter.
Selecting Subtitles
By default, subtitles are off. To turn subtitles on and change the Subtitle language
while you’re watching a DVD disc:
1. While a disc is playing, press CC on the remote.
2. If subtitles are off, press OK to turn them on.
3. Use the up/down arrow buttons to scroll through the subtitle languages that
are available on the disc. If subtitles aren’t available, the text in the text box
will read Subtitles: Not Available. If subtitles are available, the language
currently showing in the text box is the active selection. The subtitles will be
shown in that language.
4. To make the Info Display disappear, press the INFO button on the remote.
Notes: Changing the subtitle language with the Info Display will only affect the disc currently
being played. When the disc is removed or the unit is turned off, the subtitle language will
revert to the language setting specified through the DVD’s main menu.
The subtitle language can also be changed through the DVD’s main menu.
Changing the Audio Language
If the disc was created with different language tracks (recorded in different
languages), you can use the Info Display to temporarily change the DVD’s Audio
Language setting.
1. While a disc is playing, press INFO on the remote to bring up the Info Display.
2. Press the left/right arrow buttons to highlight the Audio Language icon. The
current audio language appears in the text box below the row of icons.
3. Press the up/down arrow buttons to scroll through the audio languages that
are available on the disc until the audio language you want to use appears in
the text box. Audio will be played in that language.
4. To make the Info Display disappear, press the INFO button on the remote.
Notes: The language feature only works if the disc was created with multiple audio tracks.
When you choose an audio language from the Info Display, you only override the audio
language setting in the DVD’s main menu temporarily.
The audio language can also be changed through the DVD’s main menu.
18 Chapter 3
Graphics contained within this publication are for representation only.
Playing Discs
Using the Repeat Feature
The default mode for the Repeat feature is Off. There are four Repeat options:
• Disc – repeats the disc that is playing
• Title – repeats the title that is playing
• Chapter – repeats the chapter that is playing
• A•B – Set the beginning (point A) and the end (point B) to make this part of
the movie play repeatedly.
To Use Repeat:
1. While a disc is playing, press INFO on the remote to bring up the Info Display.
2. Highlight the Repeat icon. The text in the text box below the icons will read
Repeat Mode: Off.
3. Press the up/down arrow buttons to scroll through the Repeat options until the
Repeat option you want is displayed in the text box.
4. The selected repeat option will loop repeatedly until you turn Repeat off.
Repeat is turned off by completing steps 1 through 3 above, and selecting the
Off option.
A•B Repeat
A•B Repeat lets you define a specific segment on the disc that you want to repeat.
For example, you might like to watch the dogfight in the movie Top Gun. To watch
this scene over and over:
1. Find the spot on the disc that is a few seconds before the beginning of the
scene you want to repeat (this gives you time to access the Info Display and
the Repeat feature).
2. Press INFO on the remote and select the Repeat icon from the Info Display.
3. Press the up/down arrow buttons until the A•B Repeat option is shown in the
text box underneath the icons. The text box reads Repeat Mode: A-B Press OK
to Set A Point.
4. At the beginning of the scene you want to repeat, press OK to set the A point.
5. When you get to the part of the disc that you want to be the end of the
repeated segment (the B point), press OK. The segment will repeat until you
turn Repeat off.
6. To make the Info Display disappear from the screen, press the INFO button on
the remote.
How to Cancel Repeat
There are three ways to cancel Repeat:
•Press STOP twice.
• Go to the Repeat icon in the Info Display and select Off.
• Eject the disc.
