RCA MPA0001 User Manual

Model: MPA0001
Register online NOW to be automatically entered into a drawing for a chance to
win a FREE MultiStream HD.
Registered users receive immediate sup­port and automatic email notification of any software updates. See full details at www.radiosophy.com/register.
User’s Guide
En Español http://www.radiosophy.com/formas_espanolas
Protect Your Investment with the Radiosophy Extended Protection Plan.
Visit www.radiosophy.com/store
or call 877-443-7234.
Customer Service:
www.radiosophy.com/help
1. Pass plug through speaker base and then attach to receiver.
NOTE: Also thread any other cables through the speaker base at this time.
Quick Setup
1
2
3
2. Plug into wall.
3. Rock the receiver into the speaker base dock.
4. Push the 'ON/OFF' button.
1
MultiStream HD User's Guide www.radiosophy.com
TIP: Keep your sales receipt here.
We're sure you'll enjoy your MultiStream HD for years to come. To get the most from it, please take a few minutes to read through this manual and learn about all the special features this radio offers.
For your records:
Should you need to contact Customer Service, please have this information ready.
Serial Number (on the bottom of the receiver)
Purchase Date
Specifications subject to change without notice.
Copyright 2006 Radiosophy, LLC -- All Rights Reserved. Radiosophy, the Radiosophy logo, MultiStream, the MultiStream HD logo, Broadcast Partner Program, the Broadcast Partner Program logo, HomeStation, and the HomeStation logo are trademarks of Radiosophy, LLC. HD Radio is a trademark and the HD Radio logo is a registered trade­mark of iBiquity Digital Corporation.
Congratulations on your purchase!
Updating Your MultiStream HD
As HD technology evolves, improvements to the software that con­trols your radio (firmware) may become available. The MultiStream HD can be connected to a computer with an Internet connection to download updates. When an update occurs, all registered users will be notified and provided with instructions. Important: to be sure you are notified, register now at www.radiosophy.com/register.
Selecting a Location:
• Place the base on a table or other flat surface.
• Put the unit on a non-metal surface (metal interferes with AM reception).
• Don't put the unit on a heat-sensitive surface. Like all electrical equipment it generates some heat.
• Do not get the radio or speaker base wet.
• When using the receiver separately from the base, be sure to place it where it will not be easily bumped or dropped.
Important Safety Instructions are on page 11.
All safety and operating instructions should be read before the radio is operated.
2
www.radiosophy.com MultiStream HD User's Guide
MultiStream HD at a Glance . . . . . . . . . . . . . . . . . . . .page 3
Control Button (diagram) . . . . . . . . . . . . . . . . . . . .page 3
The LCD Display . . . . . . . . . . . . . . . . . . . . . . . . . .page 3
Setting Clock Time . . . . . . . . . . . . . . . . . . . . . . . .page 3
Setting sound and brightness preferences . . . . . . .page 3
HD Radio Indicators (diagram) . . . . . . . . . . . . . . . . .page 4
Multiple streams mean more channels . . . . . . . . . .page 4
Tuning and Seeking (diagram) . . . . . . . . . . . . . . . . . .page 5
Presetting your favorites . . . . . . . . . . . . . . . . . . . .page 5
Cycling through streams . . . . . . . . . . . . . . . . . . . .page 5
Setting alarm time . . . . . . . . . . . . . . . . . . . . . . . . .page 5
Using the Alarm (diagram) . . . . . . . . . . . . . . . . . . . . .page 6
Snooze, Alarm Off, Sleep . . . . . . . . . . . . . . . . . . . .page 6
Transportable
Connecting to audio equipment . . . . . . . . . . . . . . .page 7
Connecting to vehicles . . . . . . . . . . . . . . . . . . . . . .page 7
Cable connections (diagram) . . . . . . . . . . . . . . . . .page 8
Using External Antennas
Using an external antenna . . . . . . . . . . . . . . . . . . .page 9
About signal coverage area and interference . . . . .page 9
Improving reception . . . . . . . . . . . . . . . . . . . . . . . .page 9
Frequently Asked Questions . . . . . . . . . . . . . . . . . . .page 10
Receiving Cable Radio Signals . . . . . . . . . . . . . . .page 10
Important Safety Instructions . . . . . . . . . . . . . . . . . .page 11
Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 13
Contacting Us . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 14
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .page 15
Radiosophy MultiStream HD User's Guide
®
3
MultiStream HD User's Guide www.radiosophy.com
MultiStream HD at a Glance
The front controls are for radio operation. Most of the top controls are for the clock and alarm.
The LCD Display
Setting Clock Time To set the clock, press and hold CLOCK SET until you hear a
beep. The hour will flash in the display. Press ALARM/TIME until the desired hour appears. Holding the button down moves the time rapidly.
Press CLOCK SET once to set hour. Repeat to set minute and second.
Setting Sound and Brightness Preferences
Bass, treble and display brightness levels on the MultiStream HD radio can be customized to suit your tastes. To change these set­tings, press the MENU button on the front of the receiver. Adjust using the TUNE buttons. Press MENU again to move to the next setting.
3
2
Current Time
4
www.radiosophy.com MultiStream HD User's Guide
If you do not see any HD Radio indicators, stations in your area may not yet be broadcasting HD Radio.
Visit www.radiosophy.com/abouthdradio/hd_radio_map.html for a list of stations broadcasting in HD Radio in your area.
Acquiring... (you will briefly hear analog while a digital signal is being acquired)
A circle indicates that you are receiving a digital signal. If there is no circle you are receiving an analog signal. If the station is multicasting, each stream will have a number in a circle. (see examples above)
If your station provides it, your MultiStream HD can display text with song title, artist, weather alerts, news, sports or other information. This text appears when "Acquiring…" goes away. (also see page 3)
PLEASE NOTE: Text is provided at the option of each radio station. Only the radio station can answer questions about information displayed in the text.
The HD Radio logo lights up as the analog signal smoothly blends into a digital signal.
Multiple Streams Mean More Channels
As you tune through stations, you'll notice a great HD Radio feature - more channels! Many FM stations are moving from broadcasting to multicasting by adding additional streams to their frequency. (see below)
1
3
4
1
2
4
3
2
