RCA M4004, M4008, M4018, MC4004, MC4008 User Manual
...
M4004
M4008
M4018
MC4004
MC4008
MC4018
user manual
It is important to read this instruction book prior to using your new product for the first time.
Contents
2
Safety information
FCC information ..........................................3
Product registration ....................................4
For your records
Service information
Technical specification
Important Safety Instruction ......................5
End user license agreement .......................6
Before you begin
Unpacking your player ...............................8
Computer system requirements
Secure music download requirements
Warning
Caution
Headset safety
Caution while driving .................................9
Back up your data
Software setup
Inserting the included CD into CD drive ...9
Connecting to the computer
Connecting the player to the Computer ...10
Charging the battery
Important battery information
Caution
Transferring files to the player
Transferring files to the player...................11
Transferring files via Yahoo! Music
TM
Jukebox
(Windows® XP or Windows VistaTM)
Transferring files via Windows Explorer
(Drag-and-drop) .........................................12
In Windows® XP (with Windows Media
Player 10 installed)
In Windows® 2000 or Windows® XP (without
Windows Media Player 10 or above
installed)
In Windows® XP or Windows Vista
TM
(with
Windows Media Player 11 or above installed)
Deleting files from the player
Disconnecting your player from the
computer .....................................................13
General controls
Before you begin ........................................14
Overview
Navigation display.......................................15
Navigation menus
Selecting what you want to play
Listening, viewing and recording
Music playback ............................................17
Music playback display
Audiobooks playback
Picture viewing............................................18
Video viewing
Video converter...........................................19
Voice recording ...........................................20
Playback voice recording ............................21
Deleting recorded files
My Selections
Player’s menus
Accessing the Player’s Menus .....................22
Navigation and selection
Shuffle
Repeat
DSP
Slideshow.....................................................23
Skipping
Add to MySel
Clear MySel
Settings
System info
Additional information
Tips and troubleshooting ...........................24
Check for updates .......................................25
Specifications
Limited warranty
For US...........................................................26
For Canada...................................................27
3
Safety information
FCC information
This device complies with part 15 of the FCC
rules. Operation is subject to the following
two conditions: (1) This device may not cause
harmful interference, and (2) This device must
accept any interference received including
interference which may cause undesired
operation.
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed
and used in accordance with the instructions,
may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in
a particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged
to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio / TV technician for help.
In accordance with FCC requirements,
changes or modifications not expressly
approved by Thomson Inc. could void the
user’s authority to operate this product.
This Class B digital apparatus complies
with Canadian ICES-003.
Cet appareil numérique de la class B est
conforme à la norme du NMB-003 du
Canada
RCA
M4004
RCA
M4008
RCA
M4018
RCA
MC4004
RCA
MC4008
RCA
MC4018
Manufacturer/Responsible Party
Thomson, Inc.
P.O. Box 1976
Indianapolis, IN 46206-1976
1-866-449-7112
CAUTION
RISK OF ELECTRIC SHOCK
THE LIGHTNING
FLASH AND ARROWHEAD WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
"DANGEROUS
VOLTAGE" INSIDE
THE PRODUCT.
SEE MARKING ON BOTTOM / BACK OF PRODUCT
WARNING: TO PREVENT FIRE
SHOCK HAZARD,
TO RAIN OR MOISTURE.
DO NOT OPEN
CAUTION: TO REDUCE THE
RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER
(OR BACK). NO USERSERVICEABLE PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE
PERSONNEL.
DO NOT EXPOSE THIS PRODUCT
THE EXCLAMATION
POINT WITHIN THE
TRIANGLE IS A
WARNING SIGN
ALERTING YOU OF
IMPORTANT
INSTRUCTIONS
ACCOMPANYING
THE PRODUCT.
OR ELECTRICAL
Safety information
4
Product registration
Please fill out the product registration card
and return it immediately. Returning this card
allows us to contact you if needed. You can
go to www.rcaaudiovideo.com for online
registration as well.
For your records
Keep your sales receipt for proof of purchase
to obtain warranty parts and service.
In the event that service should be required,
you may need both the model number and
the serial number. In the space below, record
the date and place of purchase, and the serial
number:
Date of Purchase
Place of Purchase
Serial No.
Service information
This product should be serviced only by those
specially trained in appropriate servicing
techniques. For instructions on how to obtain
service, refer to the warranty included in this
Guide.
Technical specification
Product: Digital Audio Player
Brand: RCA
Model: M4004, M4008, M4018, MC4004,
MC4008, MC4018
Electrical Consumption: 3.7V Lithium battery
(built-in)
IMPORTER
Comercializadora Thomson de México,
S.A. de C.V.
Álvaro Obregón No. 151. Piso 13.
Col. Roma. Delegación Cuauhtémoc
C.P. 06700. México, D.F.
Telefono: 52-55-11-020360
RFC: CTM-980723-KS5
This unit may temporarily cease to function if
subjected to electrostatic disturbance. To
resume normal operation, you may press the
RESET button on the back of the player with
a non-metal pointed object (e.g. toothpick) to
reset the player.
Do not separately recharge, disassemble,
incinerate, or expose to high temperatures.
Examples of high temperatures that may
damage your product include leaving it in a
locked car in the summer, or putting it on top
of other heat generating electronics devices
(such as power amplifiers and computer
monitors).
Illustrations contained within this publication
are for representation only and subject to
change.
The descriptions and characteristics given in
this document are given as a general
indication and not as a guarantee. In order
to provide the highest quality product
possible, we reserve the right to make any
improvement or modification without prior
notice. The English version serves as the final
reference on all products and operational
details should any discrepancies arise in other
languages.
5
Some of the following information may not
apply to your particular product; however, as
with any electronic product, precautions
should be observed during handling and use.
• Read these instructions.
• Keep these instructions.
•Heed all warnings.
•Follow all instructions.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings.
Install in accordance with the
manufacturer’s instructions.
• Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that
produce heat.
• Do not defeat the safety purpose of the
polarized or grounding-type plug. A
polarized plug has two blades with one
wider than the other. A grounding type
plug has two blades and a third grounding
prong. The wide blade or the third prong
is provided for your safety. If the provided
plug does not fit into your outlet, consult
an electrician for replacement of the
obsolete outlet.
• Protect the power cord from being walked
on or pinched particularly at plugs,
convenience receptacles, and the point
where they exit from the apparatus.
• Only use attachments/accessories specified
by the manufacturer.
• Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
• Unplug this apparatus during lightning
storms or when unused for long periods of
time.
• Refer all servicing to qualified service
personnel. Servicing is required when the
apparatus has been damaged in any way,
such as power-supply cord or plug is
damaged, liquid has been spilled or objects
have fallen into the apparatus, the
apparatus has been exposed to rain or
moisture, does not operate normally, or
has been dropped.
• ADDITIONAL SAFETY INFORMATION
• Apparatus shall not be exposed to
dripping or splashing and no objects filled
with liquids, such as vases, shall be placed
on the apparatus.
• Always leave sufficient space around the
product for ventilation. Do not place
product in or on a bed, rug, in a bookcase
or cabinet that may prevent air flow
through vent openings.
• Do not place lighted candles, cigarettes,
cigars, etc. on the product.
• Connect power cord only to AC power
source as marked on the product.
• Care should be taken so that objects do
not fall into the product.
• Do not attempt to disassemble the cabinet.
This product does not contain customer
serviceable components.
• IF YOUR PRODUCT OPERATES ON
BATTERIES, adhere to the following
precautions:
A. Any battery may leak electrolyte if mixed
with a different battery type, if inserted
incorrectly, or if all batteries are not
replaced at the same time.
B. Any battery may leak electrolyte or
explode if disposed of in fire or an attempt
is made to charge a battery not intended
to be recharged.
C. Discard leaky batteries immediately. Leaking
batteries can cause skin burns or other personal
injury. When discarding batteries, be sure to
dispose of them in the proper manner, according
to your state/provincial and local regulations.
PLEASE READ AND SAVE FOR FUTURE REFERENCE
IMPORTANT SAFETY INFORMATION
]
Portable Cart Warning
End user license agreement
6
IMPORTANT: READ CAREFULLY BEFORE DOWNLOADING OR
INSTALLING THIS SOFTWARE!
THIS END USER LICENSE AGREEMENT (THIS “EULA”) IS A
LEGAL AGREEMENT BETWEEN YOU AND THOMSON INC., OR
ANY THOMSON GROUP ENTITY, AS DEFINED BELOW
(COLLECTIVELY “THOMSON ENTITY”), FOR THE RCA OR
THOMSON BRANDED PORTABLE DIGITAL AUDIO/VIDEO
DEVICE APPLICATION/DRIVER SOFTWARE PROGRAM AND
ASSOCIATED DOCUMENTATION, IF ANY (COLLECTIVELY, THE
“PROGRAM”). THIS EULA CONTAINS IMPORTANT LEGAL
LIMITATIONS, RESTRICTIONS AND DISCLAIMERS, AND ALSO
SPECIFIES THE DURATION OF YOUR LICENSE.
BY INSTALLING THE PROGRAM OR CLICKING ON THE
ACCEPTANCE BUTTON OF THE PROGRAM, COPYING OR
OTHERWISE USING THE PROGRAM, YOU ACKNOWLEDGE
AND AGREE THAT YOU HAVE READ THIS EULA,
UNDERSTAND IT, AND AGREE TO BE BOUND BY ITS TERMS
AND CONDITIONS. YOU MAY USE THE PROGRAM ONLY IN
ACCORDANCE WITH THIS EULA, AND ANY SUCH USE IS
HEREBY UNDERSTOOD TO BE CONDITIONAL UPON YOUR
SPECIFIC AGREEMENT TO THE UNMODIFIED TERMS SET
FORTH HEREIN. IF YOU DO NOT AGREE WITH ALL OF THE
TERMS OF THIS EULA, CLICK ON THE REJECTION BUTTON
AND/OR DO NOT INSTALL THE PROGRAM AND/OR DO NOT
USE THE PROGRAM.
1. LICENSE
a) Under this EULA, you are granted a license (i) to use the
Program on a single workstation, and (ii) to make one (1)
copy of the Program into any machine-readable form for
backup of the Program, provided the copy contains all of
the original Program's proprietary notices.
b) You may transfer the Program and license to another
party only as a part of the Thomson/RCA branded
Portable Digital Audio/Video Device (“A/V Device”), and
only if the other party agrees to accept the terms and
conditions of this EULA. If you transfer the Program, you
must at the same time either transfer all copies to the
same party or destroy any copies not transferred.
c) The terms of this EULA will govern any software
upgrades or updates provided by THOMSON Entity that
replace and/or supplement the original Program, unless
such upgrade or update is accompanied by separate
license terms and conditions in which case the terms of
that separate license will govern. You acknowledge and
agree that THOMSON Entity may automatically
download upgrades or updates to the Program software
to your computer in order to update, enhance, and/or
further develop the Program.
2. LICENSE RESTRICTIONS
a) Except for the licenses expressly granted to you in this
EULA, no other licenses or rights are granted or implied.
b) You may not (i) make the Program available over a
network where it could be used by multiple computers at
the same time; (ii) modify, translate, reverse engineer,
decompile, disassemble (except to the extent that this
restriction is expressly prohibited by law), or create
derivative works based upon the Program; or (iii) copy
the Program, except as expressly permitted herein. You
agree that you shall only use the Program in a manner
that complies with all applicable laws in the jurisdictions
in which you use the Program, including, but not limited
to, applicable restrictions concerning copyright and other
intellectual property rights.
c) The Program may contain pre-release code that does not
perform at the level of a final code release. In such case,
the Program may not operate properly. Updated versions
of the Program may be downloaded from
www.rcaaudiovideo.com/downloads.
d) THOMSON Entity is not obligated to provide support
services for the Program.
e) The Program is provided with “RESTRICTED RIGHTS”.
Use, duplication, or disclosure by the U.S. Government is
subject to restrictions as set forth in subparagraph
(c)(1)(ii) of DFARS 252.227-7013, or FAR 52.227-19, or in
FAR 52.227-14 Alt. III, as applicable.
3. TERM AND TERMINATION
a) Your license is effective on the date you accept this EULA
and remains in effect until this EULA is terminated by
either party.
b) You may terminate this EULA and the associated license,
without any notice or delay, by destroying or
permanently erasing the Program and all copies thereof.
c) If you fail to comply with any of the terms of this EULA,
in whole or part, your license will automatically
terminate without notice from THOMSON Entity.
d) Upon termination of this EULA and your associated
license, you shall cease all use of the Program and
destroy or permanently erase the Program and all full or
partial copies thereof.
4. WARRANTY DISCLAIMER
THE PROGRAM IS PROVIDED “AS IS” WITHOUT WARRANTY
OF ANY KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING,
BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE,
TITLE OR NON-INFRINGEMENT. THE ENTIRE RISK AS TO THE
QUALITY AND PERFORMANCE OF THE PROGRAM IS WITH
YOU. SHOULD THE PROGRAM PROVE DEFECTIVE, YOU (AND
NOT THOMSON ENTITY, ITS SUPPLIERS, OR ITS DEALERS)
ASSUME THE ENTIRE COST FOR ALL NECESSARY REPAIR OR
CORRECTION.
This exclusion of warranty may not be allowed under some
applicable laws. As a result, the above exclusion may not
apply to you, and you may have other rights depending on
the law that applies to you.
5. OWNERSHIP RIGHTS
All title and intellectual property rights in and to the
Program and any copies thereof are owned by THOMSON
Entity or its suppliers. All title and intellectual property
rights in and to the content which may be accessed through
use of the Program is the property of the respective content
owner and may be protected by applicable copyright or
other intellectual property laws and treaties. This license
grants you no rights to use such content.
6. LIMITATION OF LIABILITY
a) TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE
LAW, IN NO EVENT SHALL THOMSON ENTITY, OR ITS
DEALERS BE LIABLE FOR ANY SPECIAL, INCIDENTAL,
INDIRECT, OR CONSEQUENTIAL DAMAGES WHATSOEVER
(INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS
OF PROFITS, BUSINESS INTERRUPTION, CORRUPTION OF
FILES, LOSS OF BUSINESS INFORMATION, OR ANY OTHER
PECUNIARY LOSS) REGARDLESS OF CAUSE OR FORM OF
ACTION, INCLUDING CONTRACT, TORT, OR NEGLIGENCE,
ARISING OUT OF YOUR USE OF OR INABILITY TO USE THE
PROGRAM, EVEN IF THOMSON ENTITY HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
BECAUSE SOME STATES AND JURISDICTIONS DO NOT
ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY OF
CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE
LIMITATION MAY NOT APPLY TO YOU.
b) YOU ASSUME RESPONSIBILITY FOR THE SELECTION OF
THE APPROPRIATE PROGRAM TO ACHIEVE YOUR
7
End user license agreement
INTENDED RESULTS, AND FOR THE INSTALLATION, USE,
AND RESULTS OBTAINED.
7. WINDOWS MEDIA™
The software embedded within your A/V Device (the “Device
Firmware”) contains software licensed from Microsoft that
enables you to play Windows Media Audio (WMA) files
(“WMA Software”). The WMA Software is licensed to you
for use with your A/V Device under the following conditions.
By installing and using this version of the Device Firmware,
you are agreeing to these conditions. IF YOU DO NOT
AGREE TO THE END USER CONDITIONS OF THIS SECTION 7,
DO NOT INSTALL OR USE THIS VERSION OF THE DEVICE
FIRMWARE.
The WMA Software is protected by copyright and other
intellectual property laws. This protection also extends to
documentation for the WMA Software, whether in written
or electronic form.
GRANT OF LICENSE.
The WMA Software is only licensed to you as follows:
You may use this version of the Device Firmware containing
the WMA Software only as such use relates to your A/V
Device.
You may not reverse engineer, decompile, or disassemble the
WMA Software, except and only to the extent that such
activity is expressly permitted by applicable law.
You may transfer your right to use the Device Firmware only
as part of a sale or transfer of your A/V Device, on the
condition that the recipient agrees to the conditions set
forth herein. If the version of the Device Firmware that you
are transferring is an upgrade, you must also transfer all
prior versions of the Device Firmware that you have which
include the WMA Software.
MICROSOFT IS NOT PROVIDING ANY WARRANTY OF ANY
KIND TO YOU FOR THE WMA SOFTWARE, AND MICROSOFT
MAKES NO REPRESENTATION CONCERNING THE OPERABILITY
OF THE WMA SOFTWARE.
The WMA Software is of U.S. origin. Any export of this
version of the Device Firmware must comply with all
applicable international and national laws, including the U.S.
Export Administration Regulations, that apply to the WMA
Software incorporated in the Device Firmware.
Content providers are using the digital rights management
technology for Windows Media contained in your A/V Device
(“WM-DRM”) to protect the integrity of their content
(“Secure Content”) so that their intellectual property,
including copyrights, in such content is not misappropriated.
Your A/V Device uses WM-DRM software to play Secure
Content (“WM-DRM Software”). If the security of the WMDRM Software in your A/V Device has been compromised,
owners of Secure Content (“Secure Content Owners”) may
request that Microsoft revoke the WM-DRM Software’s right
to acquire new licenses to copy, display, and/or play Secure
Content. Revocation does not alter the WM-DRM Software's
ability to play unprotected content. A list of revoked WMDRM Software is sent to your A/V Device whenever you
download a license for Secure Content from the Internet or
from a computer. Microsoft may, in conjunction with such
license, also download revocation lists onto your A/V Device
on behalf of Secure Content Owners.
8. THIRD PARTY SOFTWARE
ANY THIRD PARTY SOFTWARE THAT MAY BE PROVIDED
WITH THE PROGRAM IS INCLUDED FOR USE AT YOUR
OPTION. IF YOU CHOOSE TO USE SUCH THIRD PARTY
SOFTWARE, THEN SUCH USE SHALL BE GOVERNED BY SUCH
THIRD PARTY'S LICENSE AGREEMENT, AN ELECTRONIC COPY
OF WHICH WILL BE INSTALLED IN THE APPROPRIATE FOLDER
ON YOUR COMPUTER UPON INSTALLATION OF THE
SOFTWARE. THOMSON ENTITY IS NOT RESPONSIBLE FOR
ANY THIRD PARTY’S SOFTWARE AND SHALL HAVE NO
LIABILITY FOR YOUR USE OF THIRD PARTY SOFTWARE.
9. GOVERNING LAW
If you acquired this A/V Device in the United States, this
EULA shall be governed and construed in accordance with
the laws of the State of Indiana, U.S.A. without regard to its
conflict of laws principles. If you acquired this A/V Device
outside the United States or the European Union, then local
law may apply.
10. GENERAL TERMS
This EULA can only be modified by a written agreement
signed by you and THOMSON Entity, and changes from the
terms and conditions of this EULA made in any other manner
will be of no effect. If any portion of this EULA shall be held
invalid, illegal, or unenforceable, the validity, legality, and
enforceability of the remainder of the Agreement shall not
in any way be affected or impaired thereby. This EULA is the
complete and exclusive statement of the agreement between
you and THOMSON Entity, which supersedes all proposals or
prior agreements, oral or written, and all other
communications between you and THOMSON Entity, relating
to the subject matter of this hereof. “THOMSON Group
Entity” when used in this EULA shall mean any person,
corporation, or other organization, domestic or foreign,
including but not limited to subsidiaries, that is directly or
indirectly controlled by Thomson S.A. For purposes of this
definition only, the term “control” means the possession of
the power to direct or cause the direction of the
management and policies of an entity, whether by ownership
of voting stock or partnership interest, by contract, or
otherwise, including direct or indirect ownership of more
than fifty percent (50%) of the voting interest in the entity
in question.
Before you begin
8
Computer system requirements
• Pentium III 500MHz or higher
recommended
• Windows® 2000 (Service Pack 3) or
Windows® XP (Service Pack 1 or higher) or
Windows Vista
TM
• Internet Explorer 6.0 or higher with
Internet access
• 250MB or more free hard disk space for
the software
• 128MB RAM (256MB recommended)
• CD drive capable of digital audio
extraction
• USB port (2.0 recommended)
• Installed sound card
• Installed 16-bit color video card
Secure music download requirements
• Windows® XP (Service Pack 1 or higher) or
Windows Vista
TM
• Internet Explorer 6.0 or higher with
Internet access
• Windows Media Player 10 or higher
•Yahoo! Music
TM
Jukebox (Included in the
CD)
Warning
Use of this player is for your personal use
only. Unauthorized recording or duplication
of copyrighted material may infringe upon
the rights of third parties and may be
contrary to copyright laws.
Caution
• Keep player out of direct sunlight.
Exposure to direct sunlight or extreme
heat (such as inside a parked car) may
cause damage or malfunction.
• Do not expose to rain or moisture.
Headset safety
Have a Blast- Just Not in Your
Eardrums
Make sure you turn down the volume on the
unit before you put on headphones. Increase
the volume to the desired level only after
headphones are in place.
• Do not play your headset at a high
volume. Hearing experts warn against
extended high-volume play.
Dear RCA Customer,
Thank you for purchasing the Player. This
product will play open mp3 and Windows
Media
TM
audio (WMA) content as well as
content purchased from most online music
download services.
After purchasing and downloading music to
your PC, you are now ready to move content
to your player. To transfer the music, you
must use Windows Media Player or the
application recommended by the online music
download service.
(Note: Services and applications must be
Windows Media audio-compliant and support
Digital Rights Management.)
Unpacking Your Player
Your player came with everything you need
to make music portable — all of the items
shown below should have been packed in the
box with your player.
RCA Player
Music Management CD
contains software
applications
USB cable: Plug the Line-in
end into the earphone jack
on your player, and plug the
USB end into your
computer’s USB port.
Earphones
9
Before you begin
Software setup
• If you experience a ringing in your ears,
reduce volume or discontinue use.
•You should use extreme caution or
temporarily discontinue use in potentially
hazardous situations.
• Even if your headset is an open-air type
designed to let you hear outside sounds,
don’t turn up the volume so high that you
are unable to hear what is around you.
Caution While Driving
Use of headphones while operating an
automobile or moving vehicle is not
recommended and is unlawful in some states
and areas. Be careful and attentive on the
road. Stop operation of the player if you find
it disruptive or distracting while driving.
Back up your data
As with any portable player, you must back
up the drive regularly. RCA and Thomson are
not responsible for lost data.
The Music Management CD that comes with
your player contains all of the necessary
software components you need to make your
player work properly.
These components do the following:
• enable you to transfer files from your
computer to your player
• convert video files
• format and sort the contents, update the
system files.
Inserting the included CD into CD drive
1. Turn on your computer and place the
Music Management CD that came with
your player into your computer.
IMPORTANT: Don’t connect the USB cable to
the PC or the player before or during the CD
installation.
2. If the setup screen does not appear,
double-click My Computer, double click
your CD drive icon, and double click Install
to run the installer.
• The Music Management CD also
contains Yahoo! Music
TM
Jukebox
that can help transfer music content
to your player. Please refer to the section
on your installed software for detailed
operations.
• Refer to "Transferring Files to the Player"
on page 11 for details.
Loading...
