TELEVISION
P52928
P60928
52/60
"
Projection Stereo
Monitor-Receiver
• Home Theatre™Video System with 900
Lines of Horizontal Resolution
2
➤Digital Focus
➤3-Line Digital Comb Filter
➤High Performance Scan Velocity Modulation
➤GUIDE Plus+
1
On-Screen Program Guide
➤Advanced Twin Tuner
™
Picture-In-Picture
➤Master Touch
®
Universal Glo-In-The-Dark
Remote
➤10-Watt
3
Stereo Amplifier
➤2 Sets of Audio/Video Inputs with Dual
S-Video Inputs/Audio Outputs
1
SERIES
Slimline
Projection
Televisions
Concealed
Casters
diagonal
Changing Entertainment. Again.
➤10-Watt3Stereo Amplifier
Built-in 10-watt amplifier enhances
stereo performance and can power
optional left/right or surround
speakers.
• Broadcast Stereo with dbx
5
Noise Reduction
Improves the clarity and fidelity of
stereo broadcasts by restoring dynamic range and suppressing unwanted noise.
• Low-Noise Audio System
Delivers a 60dB signal-to-noise ratio
for spectacular quality sound.
• Sound Logic™Audio Leveler
When turned on, eliminates the
annoying “blast” of sound during
commercial breaks. Additionally,
soft sounds are amplified, maintaining a constant volume level.
• Front-Fired Speaker System
Front-fired full-range frequency
drivers provide excellent imaging
while localizing voices at the
screen.
• Second Audio Program (SAP)
Decodes the second audio program
available on some broadcasts.
Remote
Sound
➤Master Touch®Universal Glo-
In-The-Dark Remote,
CRK76TA1
Ergonomic design with glo-in-thedark buttons provides complete TV
operation plus control of the primary
functions of virtually every brand of
remote-controllable VCRs and cable
boxes, and RCA Satellite Systems.
Also controls most functions of RCA
DVD Players and select functions of
some brands of audio components.
Frequently used buttons glow in the
dark, making it easy to find the correct functions even at night.
• Adjustable Picture Control
Custom picture settings are just a
button press away. Adjust and
store Contrast, Color, Tint, Black
Level, and Sharpness settings for
personal picture performance
depending on your own individual
tastes.
• Custom Convergence
Adjustment
When the Earth’s magnetic field
interferes with the Projection TV
alignment, adjustable convergence
provides fine tuning for red, blue,
and green Projection TV tubes. The
8-bit DA (digital-to-analog) converter allows much finer alignment for
restoring picture performance to its
original setting.
• High Resolution, High Gain
Screen
Utilizes double lenticular and
fresnel lenses to deliver bright
images over a wide viewing area.
• High Output, Liquid Cooledand-Coupled Picture Tubes
High output picture tubes are liquid
coupled to a precision optical system
to deliver bright, clear images.
• High Transmittance Lens
System
Hybrid glass/acrylic lens system
optimizes focus while providing
maximum brightness.
• First Surface Reflective
Mirror
Provides maximum picture brightness and sharpness by reflecting
more light from the front surface of
the mirror.
• Preferred Picture Presets
Optimize the picture by selecting
the correct setting depending on
the lighting conditions of the room.
Choose between four settings for
bright lighting, normal lighting, dim
(soft) lighting, and a customerselectable and savable “personal”
setting.
• Deluxe Shielded Tuner with
181-Channel Tuning
Capability
4
Special shielding dramatically
reduces ghosting caused from offair pick-up when watching cable
channels. Digitally-controlled
frequency synthesis tuning system
“locks on” to cable and standard
signals with unsurpassed accuracy.
181-channel tuning capability.
➤
Computer-aligned 10-bit digital
circuitry provides precise and consistent picture performance from
the moment the TV is turned on.
Combined with Dynamic Focus, it
maximizes picture brightness with
sharper corner focus ensuring a
beautifully detailed picture across
the entire screen.
➤3-Line Digital Comb Filter
New digital separation technology
for color and edge detail dramatically enhances picture resolution
by eliminating blurred edges
between colors and reducing dot
crawl, producing a new level of
picture sharpness and detail.
➤High Performance Scan
Velocity Modulation
Improved SVM circuitry automatically varies the scanning speed of
the picture tube’s electron beam
to improve sharpness and detail
especially in high contrast areas.
• Dynamic Focus
Improves corner and edge focus
for an overall sharper picture.
• Adaptive Video Noise
Reduction
Video noise filter greatly reduces
noisy picture interference by
automatically adjusting to the
incoming signal level, providing a
cleaner and more consistent
overall picture.
• Auto Color Balance
(also called Auto Kine Bias
— AKB)
Resets individual picture tube guns
(Red, Green, Blue) to maintain
consistent overall picture quality
for the life of the tube.
• Wide Band Video Amplifier
Delivers high resolution and clarity
by extending the video frequency
response. Optimizes performance
from high-resolution sources such
as the RCA Satellite System, DVD
players, and S-Video signals
(S-VHS, Hi8).
• Dynamic BlackStretch
Circuitry
Extends black levels in bright
scenes to enhance contrast and
detail.
•
Automatically maintains natural
tones and color fidelity from channel to channel and scene to scene.
• Adjustable Color Warmth
Customer-selectable color
temperature system allows for
background color balance adjustment of the picture to personal
preference. Setting choices are
Cool, Warm, or Normal.
• Contrast/Color Tracking
System
Synchronizes contrast and
color settings to maintain
vibrant images.
High-Performance Video System
Advanced circuitry delivers outstanding picture performance with up to 900 lines of horizontal resolution2.
P52928/P60928
➤Advanced Twin Tuner
™
Picture-In-Picture
Two built-in, independent tuning
systems allow both large-picture and
small-picture viewing without the
need for a second external video
source (e.g., VCR). In addition to the
standard RCA PIP feature of Swap,
the Twin Tuner PIP System also
provides:
–Continuous Move
Permits placement of the small
picture anywhere on the screen.
–Commercial Skip-to-PIP
This exclusive RCA feature allows
the main picture to move to the PIP
window simultaneously with the
activation of an on-screen countdown timer. The viewer can then
monitor the original program while
browsing through other channels
during commercial breaks.
•
Countdown timer returns TV
to original channel, so other
channels can be browsed during
program breaks.
• Auto Tune
After initial setup, just pressing one
component button on the TV’s
remote (either VCR, RCA Satellite
System, cable, or DVD) turns on both
the TV and the component and also
automatically tunes the TV to the
correct viewing channel. Just one
press!
• Picture Memory for Video
Inputs
Custom picture settings are activated
whenever direct video inputs are
selected. Allows tailored picture performance with each video source.
• Picture Reset
Instantly returns picture to factory
settings for Color, Tint, Contrast,
Brightness, and Sharpness.
• Advanced Auto Channel
Search
Auto Cable/Air Switch sets tuner to
cable or “off-air” frequencies during
initial setup. Then system automatically scans for and locks active
channels into channel memory.
• On-Screen Menu System
On-screen displays make it easy
to adjust most picture, sound, and
convenience features from either the
remote control or the TV front panel
buttons.
• Interactive Setup Menu
Convenient on-screen menu system
automatically steps user through the
initial setup procedures.
• Trilingual On-Screen Display
Allows the on-screen menu system
to be displayed in one of three
languages (English, French, or
Spanish).
• On-Screen Time and
Channel Display
Displays time and channel number
during channel change or at the
press of a button.
• Programmable Timer System
Convenient scheduling system can
be used in a variety of ways:
–Sleep Timer
Automatically turns off the TV after
a preset time period — for those
times when you drift off to sleep in
front of the television.
–Alarm Timer
Wake up to your favorite morning
show or turn on your television
automatically to catch your favorite
program.
–Scheduling Timer
Since the alarm setting remains in
the TV memory indefinitely, the TV
can be scheduled to turn on at the
same time every day.
•
Assign on-screen characters to easily
identify channels (e.g., NBC, HBO,
ESPN, VH-1).
• Front Panel Lockout
Completely disables front panel
controls to prevent toddlers from altering settings.
• V-Chip Parental Control
Puts control back into the hands of
the viewer by blocking unwanted
television broadcasts with NEW U.S.
Government required circuitry. Blocks
three types of programs: regular
television programs, broadcast
movies and unrated programs.
Program rating information is sent
by the broadcaster before the
beginning of each program. The
television will match program rating
to user preference and block the
entire program. User preference is
secured using a four-digit password.
• Non-Volatile Memory
In case of most power outages, the
picture adjustments and channel
selections are stored in electronic
memory.
• Remote Control Low-Battery
Indicator
Automatically notifies user of low
battery power with an appropriate
on-screen message.
• Caption Vision Closed
Caption Capability
7
Assists the hearing impaired, helps
children learn to read, and aids in the
teaching of English as a second
language. Built-in Closed Caption
Decoder displays the audio portion
of a program as text on the TV
screen (when program is aired with
the encoded signal).
• Slim Cabinet Design
Unique optics system utilizes radius
phosphor tubes to shorten the
interior light path resulting in
enhanced picture quality with a
super-slim cabinet profile with
reduced depth.
CC
:30
Convenience
“Command” Buttons
Information
Window
Promotional
Windows
Networks
Guide
Selector
Program
Grids
The Program Guide appears
on your television.
Program Listings and One-Touch
Record...Right through your
remote control!
2 ways to find your programs
And The Benefit
of One-Touch Record
Even if your VCR is flashing 12:00,
GUIDE Plus+
1
can record your favorite show.
Simply highlight the program you would like
to record and press the Record button on
the remote. In the Schedule Menu, you can
choose to record shows once, daily, or weekly.
➁
GUIDE Plus+1Interactive Program Guide
Find out what’s on! GUIDE Plus+1is a built-in feature that
provides an instant summary of your favorite TV shows at the
touch of a button—yet requires no monthly fee! The
two-day Guide also allows you to view listings up to 48 hours
in advance and delivers the capability for One-Touch Tuning
and VCR recording with the press of a button.
Using the directional arrow pads on your remote,
you may scroll through up-to-the-minute TV
listings, or scroll to future programs. As each
channel grid is highlighted, the current program
appears in the preview window, and a description
is shown in the information area to the right of
the window. Or if you can't tear yourself away
from the game, you can continue to watch your
program in the preview window while you scan
through the program grids.
The Grid Guide
Want to relax and watch a movie? SORT lists
movies by theme that are on for the next seven
days. SORT can also help you find your favorite
game or sports or children’s programs.
The Sort Guide
Press
Here.
➀
©1999 Thomson Consumer Electronics, Inc.
Form S-P52928/60928
Trademark(s) ® Registered
Marca(s) Registrada(s)
Photos and features subject to change
without notice. Illustration of product finish
may vary from actual color.
PC13111
➤Audio/Video Monitor Panel
with Dual S-Video Inputs
Color-coded monitor panel
provides direct audio and video
connections for optimum
performance and system flexibility.
Includes two audio/video inputs,
two S-Video inputs, plus switchable
audio outputs for fixed and variable
level control.
• One Pair of Switchable
(Variable/Fixed) Audio
Outputs
Connect TV to an external audio
source with speakers (AV receiver,
subwoofer, power amplifier) to
create a true home theater setup.
Switchable outputs offer maximum
flexibility for connecting various
types of external audio
components.
➤Dual S-Video Inputs with
Auto Detection
Two direct Y/C inputs connect TV
to compatible S-Video sources (e.g.,
DVD players, RCA Satellite Systems,
S-VHS VCRs/Hi8 VCRs/ camcorders,
or Internet set-top devices) for highresolution playback. Automatic
switching to S-VHS input upon
detection of the signal so there’s
no setup necessary.
1 GUIDE Plus+ is a trademark of Gemstar Development Corporation.
2 Lines per picture width, 675 lines based on EIA measurement criteria.
3 10 watts = 5 watts per channel, RMS rating into 8 ohms 50 Hz-20,000 Hz, ± 3dB with less than
1% THD.
4 Check your cable company’s compatibility requirements.
5 dbx is a registered trademark of Carillon Electronics Corporation.
6 This television receiver provides display of television closed captioning in accordance with
§15.119 of the FCC rules. This television receiver does not support color attributes of television
closed captioning.
Connections
Specifications
P52928 P60928
Screen Size (diagonal) 52" 60"
Finish Black Lava Black Lava
Cabinet Dimensions 52" H, 441⁄4" W, 261⁄4" D 611⁄4" H, 511⁄2" W, 26" D
Approx. Shipping Weight 256 Lbs.. 305 Lbs.
Concealed Casters Yes Yes
Lines of Horizontal Resolution 900
2
900
2
Audio Power 10 Watts 10 Watts
SuperShield™Model (Optional) QuikFit SSH531 QuikFit SSH533
P60928
P52928
Plus
• Limited Warranty
–90 days for labor charges.
–One year for parts.
–Two years for picture tube.
–See RCA dealer for complete
details.
INPUT 1
VIDEO
R
S-VIDEO
R
INPUT 2
VIDEO
CABLE/
ANTENNA
INPUT
S-VIDEO
L—AUDIO—R
VCR
CONTROL
AUDIO OUTPUT
AUDIO
L
L
AUDIO
• Back Panel
Changing Entertainment. Again.
Get more information on
RCA Consumer Electronics Products at www.rca.com
Loading...
