To reduce the risk of fire or electric shock, do
not expose this product to rain or moisture.
CAUTION
THIS PRODUCT UTILIZES A LASER. USE
OF CONTROLS OR ADJUSTMENTS OR
PERFORMANCE OF PROCEDURES OTHER
THAN THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION
EXPOSURE. DO NOT OPEN COVERS AND
DO NOT REPAIR YOURSELF. REFER
SERVICING TO QUALIFIED PERSONNEL.
Note:
This DVD player is designed and
manufactured to respond to the Region
Management Information. If the Region
number of a DVD disc does not
correspond to the Region number of this
DVD player, this DVD player cannot play
the disc. The Region number for this DVD
player is Region No 1.
CLASS 1
LASER
PRODUCT
CAUTION
RISK OF ELECTRIC SHOCK DO
NOT OPEN
This symbol indicates "dangerous
voltage" inside the product that
presents a risk of electric shock or
personal injury.
The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.
Refer to the identification/rating label located on the back panel of your product for its proper operating
voltage.
FCC Regulations state that unauthorized changes or modifications to this equipment may void the user’s
authority to operate it.
Caution: Using video games or any external accessory with fixed images for extended periods of time
can cause them to be permanently imprinted on the picture tube (or projection TV picture tubes). ALSO,
some network/program logos, phone numbers, black borders (sides, top and bottom), etc. may cause
similar damage. This damage is not covered by your warranty.
Cable TV Installer: This reminder is provided to call your attention to Article 820-40 of the National
Electrical Code (Section 54 of the Canadian Electrical Code, Part 1) which provides guidelines for proper
grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of
the building as close to the point of cable entry as practical.
Warning: Do not use the Freeze feature for an extended period of time. This can cause the image to be
permanently imprinted on the picture tube. Such damage is not covered by your warranty. Press any button
to unfreeze the picture at any time.
This symbol indicates that this product incorporates double
insulation between hazardous mains voltage and user
accessible parts. When servicing use only identical
replacement parts.
This symbol indicates important
instructions accompanying the
product.
Product Registration
Please fill out the product registration card (packed separately) and return it immediately, or register on-line at rca.com. Returning the card allows us to contact you
if needed.
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the serial and model numbers in case you need
them. These numbers are located on the product.
Model No. ____________________________________________________________________________________________________________________
Serial No. _____________________________________________________________________________________________________________________
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong. The wide blade or the third prong is provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and the point where they exit from the
apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
If an outside antenna is connected to the TV receiver, be sure the antenna system is
grounded so as to provide some protection against voltage surges and built up static
charges. In the U.S. Section 810-21 of the National Electrical Code and in Canada, Part
1 of the Canadian Electrical Code provides information with respect to proper
grounding of the antenna system. See the figure on the right for details.
To assure adequate ventilation for this product, maintain
a spacing of 4 inches from the top and sides of the TV
receiver and 2 inches from the rear of the TV receiver
and other surfaces.
Example of Antenna Grounding as per
(NEC) National Electrical Code
ELECTRIC SERVICE
EQUIPMENT
ANTENNA
LEAD IN
WIRE
GROUND CLAMP
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
1
Introduction
Key Features Overview
Your TV is equipped with features that will add to your TV viewing experience. The following information
summarizes a few of these features. Chapter 4 provides more information about the rest of the TV’s features and
how to use them.
DVI-HDTV Input
Lets you connect an HD receiver with a DVI output.
L/
MONO
DVI-HDTV
R
PIP example
• DVI (Digital Visual Interface) Provides an uncompressed, digital video interface developed for high-
bandwidth digital connection. It supports the overlay of high-resolution graphics needed by some
electronic program guide navigation and other interactive services. DVI, when combined with HDCP (High
bandwidth Digital Content Protection) technology, creates a protected digital connection. The signal
speed of the DVI connection is 1080i for HDTV at a rate of 1.78 Gigabits per second.
Dolby* Virtual
Available only for stereo signals. Creates a virtualized surround sound experience from two speakers using
the Dolby Pro Logic decoding. It provides the sensation of being surrounded by additional speakers.
PIP (Picture-In-Picture) and POP (Picture-Outside-Picture)
Description: PIP lets you watch two channels at one time — one channel on the main screen and the other
in a smaller window. POP also lets you watch two channels at one time- one channel on the left side of the
screen (the main picture) and the other on the right.
Requirements: Press the PIP button to bring up the PIP window. Press again to bring up POP. Chapter 4 has
detailed instructions on how to use the PIP and POP features.
POP example
MP3 Audio Disc Playback
Description: Your DVD player can play back compatible MP3 audio files recorded on CD-R discs.
Requirements: The discs must be recorded on compatible equipment (Chapter 3 has details) and the DVD
player must be on.
The On-Screen DVD Information Display
Description: The Info Display is a menu bar that you can bring up to access certain features while discs are
playing. Icons represent the different features supported by your TV/DVD when in DVD mode. By selecting
different Info Display icons, you can access features including Repeat, Audio, Subtitles, Bookmarks and
Camera Angle.
Requirements: Put your TV/DVD in DVD mode and insert a disc into the disc tray. Wait for the disc to play,
then press INFO to view the Info Display menu.
V-Chip: Parental Controls
Description: You can block programs and movies by content, age-based ratings, and/or movie ratings.
Requirements:
• Set up the Parental Control menu in the TV’s main menu (Chapter 4 has details).
• The broadcasters must use the rating system when they send the program to your TV in order for your TV
to block the program.
• Parental controls must be locked for these settings to take affect.
* Dolby is a trademark of Dolby Laboratories
2
Table of Contents
IMPORTANT SAFETY INSTRUCTIONS ................1
Introduction
Key Features Overview............................................... 2
• Connect all components before you plug any of their power cords into the wall outlet.
• Turn off the TV and/or component before you connect or disconnect any cables.
• Make sure all antennas and cables are properly grounded. Refer to the Important Safety Instructions on page 1.
Protect Components from Overheating
• Don’t block ventilation holes on any of the components. Arrange the components so that air can circulate freely.
• Don’t stack components.
• When you place components in a stand, make sure you allow adequate ventilation.
• If you connect an audio receiver or amplifier, place it on the top shelf so the heated air from it won’t flow around
other components.
Position Cables Properly to Avoid Audio Interference
• Insert each cable firmly into the designated jack.
• If you place components above the TV, route all cables down the side of the back of the TV instead of straight
down the middle of the TV.
• If your antenna uses 300-ohm twin lead cables, do not coil the cables. Also, keep the twin lead cables away from
audio/video cables.
Important Stand and Base Safety Information
Choose the location for your TV carefully. Place the TV on a stand or base that is of adequate size and strength to
prevent the TV from being accidentally tipped over, pushed off, or pulled off. This could cause personal injury and/or
damage the TV. Refer to the Important Safety Instructions on page 1.
Use Indirect Light
Don’t place the TV where sunlight or room lighting will be directed toward the screen. Use soft or indirect lighting.
Cables Needed to Connect Components to Your TV
The pictures below show the cables needed for the connections represented in this book.
Audio/Video cablesComponent Video (Y•Pb•Pr)
S-Video cableCoaxial cable
cables
Chapter 15
Connections & Setup
Choose Your Connection
There are several ways to connect your TV/DVD. Please use the following chart to determine which connection is
best for you. Proceed to the appropriate page and connect your TV/DVD.
Note: If you prefer, we can provide you with the name of an Authorized Service Representative who will visit your home for a fee to
install your electronic entertainment system and to instruct you in its operation. For details about this service, call 1-888-206-3359
or visit rcascenium.com.
ComponentsCablesConnectionGo to...
NeededTitle
Coaxial
TV/DVD +
HD Receiver + VCR
TV/DVD + Satellite
Receiver + VCR
TV/DVD
TV/DVD
D
H
e
c
e
R
Satellite
Audio/video
R
r
e
iv
C
V
Component video
Coaxial
Audio/video
R
C
V
S-Video
page 7
page 8
Coaxial
Audio/video
R
C
TV/DVD
For general information on connecting an A/V receiver or speakers to your TV/DVD, go to page 10.
V
Component video
TV/DVD + VCR
page 9
6Chapter 1
TV/DVD
HD RECEIVER
ANT IN
SAT IN
1A
ANT OUT
CABLE
S-VIDEO
O
R
VIDEO
OFF-AIR ANTENNA
AUDIO
R
Connections & Setup
L
P
BPR
Y
L
BPR
P
Y
R
L
R
HD
Receiver
VCR
1B
Satellite Receiver
3A
DIGITAL
OUTPUT
3B
AUDIO
L/
MONO
DVI-HDTV
R
3C
VCR
IN
OUT
ANTENNA IN
2B
Y
Y
EO
D
I
V
-
S
EO
D
I
V
S
VIDEO
VIDEO
2A
PBP
R
P
BPR
COMPONENT INPUTS
COMPOSITE INPUTS
L/
MONO
V
L/
MONO
V
4C
AUDIO
L
R
L
R
AUDIO
ANTENNA OUT
L/
L/
MONO
MONO
R
R
4B
R
CMP1
CMP
2
R
EXTERNAL SPEAKERS
V
I
D
1
ANTENNA/
V
CABLE
I
D
2
RIGHT
+
+
LEFT
AUDIO/VIDEO OUTPUT
V
VARIABLE
AUDIO
SUBWOOFER
EXT/INT
FIXED AUDIO
L
L
R
R
TV/DVD
4A
TV/DVD + HD Receiver + VCR
1. Make sure cable or antenna and/or satellite is connected to your VCR.
A. Connect the coaxial cable from your cable outlet or antenna to the antenna input on the HD Receiver.
B. Connect the satellite dish antenna to the satellite input on the HD Receiver.
2. Connect your HD Receiver to your TV/DVD.
A. Connect the audio (white and red) cables to the CMP1 L/MONO and R audio jacks on the back of the TV/DVD and to the Audio Output jacks on
the HD Receiver.
B. Connect three video grade cables to the CMP1 Y, P
Notes: The Y, PB, PR jacks are sending the digital cable signal to the TV/DVD.
If your HD Receiver has a DVI output, connect the HD Receiver to your TV /DVD using a DVI cable. Make sure to connect the left and right audio cables to the DVI L/MONO and R
jacks on the TV/DVD.
3. Connect your HD Receiver to your VCR.
A. Connect a coaxial cable to the HD Receiver’s antenna output and to VCR’s antenna input.
B. Connect the audio (white and red) cables to the Audio Output jacks on the HD Receiver and to the Audio Input jacks on the VCR.
C. Connect the video cable to the Video Output jack on the HD Receiver and to the Video Input jack on the VCR.
4. Connect your VCR to your TV/DVD.
A. Connect a coaxial cable to the VCR’s antenna output and to the ANTENNA/CABLE Input jack on the TV/DVD.
B. Connect the audio (white and red) cables to the VID2 L/MONO and R audio jacks on the back of the TV/DVD and to the Audio Output jacks on
the VCR.
C. Connect the video cable to the VID2 V (video) jack on the back of the TV/DVD and to the Video Output jack on the VCR.
, PR jacks on the back of the TV/DVD and to the Y, PB, PR jacks on the HD Receiver.
B
Go to page 13
Chapter 17
Connections & Setup
SATELLITE
AUDIO
VIDEO
S-VIDEO
L
RECEIVER
R
TV/DVD
Satellite
VCR
CABLE
O
R
DIGITAL
AUDIO
OUTPUT
DVI-HDTV
OFF-AIR ANTENNA
L/
3C
MONO
R
BPR
P
Y
P
BPR
Y
3B
COMPONENT INPUTS
COMPOSITE INPUTS
V
EO
D
I
V
S
EO
D
I
V
S
V
3A
L/
MONO
L/
MONO
1C
L/
MONO
R
CMP1
CM
P
2
L/
MONO
R
EXTERNAL SPEAKERS
R
V
I
D
1
ANTENNA/
V
CABLE
I
D
2
R
1B
VIDEO
VCR
IN
OUT
VIDEO
ANTENNA IN
RIGHT
+
EXT/INT
+
LEFT
AUDIO/VIDEO OUTPUT
V
VARIABLE
AUDIO
SUBWOOFER
AUDIO
L
R
O
L
L
R
AUDIO
ANTENNA OUT
FIXED AUDIO
L
L
R
R
1A
TV/DVD
2
TV/DVD + Satellite Receiver + VCR
1. Connect your VCR to your TV/DVD.
A. Connect a coaxial cable to the VCR’s antenna output and to the ANTENNA/CABLE Input jack on the TV/DVD.
B. Connect the audio (white and red) cables to the VID2 L/MONO and R Audio jacks on the back of the TV/DVD and to the Audio Output jacks on
the VCR.
C. Connect the video cable to the VID2 V (Video) jack on the back of the TV/DVD and to the Video Output jack on the VCR.
2. Make sure cable or antenna is connected to your VCR.
Connect the coaxial cable from your cable outlet or antenna to the antenna input on the VCR.
3. Connect your Satellite Receiver to your TV/DVD.
A. Connect the audio (white and red) cables to the VID1 L/MONO and R Audio jacks on the back of the TV/DVD and to the Audio Output jacks on
the Satellite Receiver.
B. Connect the video cable to the VID1 V (Video) jack on the back of the TV/DVD and to the Video Output jack on the Satellite Receiver.
C. If your Satellite Receiver has an S-Video jack, connect an S-Video cable (instead of the video cable in step B) to the S-VIDEO jack on the
TV/DVD and to the S-VIDEO jack on the satellite receiver.
Go to page 13
8Chapter 1
TV/DVD
DIGITAL
AUDIO
OUTPUT
DVI-HDTV
L/MONO
Connections & Setup
L/
MONO
BPR
P
Y
R
PBP
Y
COMPONENT INPUTS
R
CMP1
CM
P
2
L/
MONO
R
R
EXTERNAL SPEAKERS
RIGHT
EXT/INT
+
+
LEFT
TV/DVD
VCR
CABLE
O
R
OFF-AIR ANTENNA
COMPOSITE INPUTS
V
EO
D
I
V
S
EO
D
I
V
S
V
L/
L/
MONO
MONO
R
R
1B
V
I
D
1
V
I
D
2
1A
VCR
ANTENNA/
CABLE
OUT
VIDEO
IN
VIDEO
ANTENNA IN
AUDIO/VIDEO OUTPUT
FIXED AUDIO
V
VARIABLE
AUDIO
SUBWOOFER
AUDIO
L
R
O
L
L
R
AUDIO
ANTENNA OUT
R
L
R
L
1C
2
TV/DVD + VCR
1. Connect your VCR to your TV/DVD.
A. Connect a coaxial cable to the VCR’s antenna output and to the ANTENNA/CABLE Input jack on the TV/DVD.
B. Connect the audio (white and red) cables to the VID2 L/MONO and R Audio jacks on the back of the TV/DVD and to the Audio Output jacks on
the VCR.
C. Connect the video cable to the VID2 V (Video) jack on the back of the TV/DVD and to the Video Output jack on the VCR.
2. Make sure cable or antenna is connected to your VCR.
Connect the coaxial cable from your cable outlet or antenna to the antenna input on the VCR.
Go to page 13
Chapter 19
Connections & Setup
TV/DVD+ A/V Receiver or Speakers
These are two different ways your TV/DVD uses a component to hear audio.
1. Connect audio cables to either the FIXED or VARIABLE AUDIO L and R OUTPUT jacks and to the Audio Inputs on the A/V receiver.
•FIXED provides fixed-level audio output from the TV/DVD. This audio output is ideal for connecting to an A/V receiver that has its own
volume control.
•VARIABLE provides variable-level audio output. Volume levels can be controlled by the volume controls on the TV/DVD and TV remote
control.
-OR-
2. Use speaker wire to connect the TV/DVD to external speakers.
•The EXT/INT switch beside the jacks let you turn the TV/DVD’s internal speakers on or off. If you connect external speakers, slide the
switch to EXT so the audio is sent to the external speakers only. Choosing INT sends the audio to the TV/DVD’s speakers only.
Note: The external speaker rating is 8 ohms with 15 watts power handling capabilities.
A/V RECEIVER
VCR
CD
IN
IN
R
L
TV
TAPE
OUT
IN
IN
OUT
Connect to either FIXED or
VARIABLE Output
DIGITAL
AUDIO
OUTPUT
DVI-HDTV
1
L/
MONO
BPR
P
L/
Y
MONO
R
BPR
P
Y
COMPONENT INPUTS
COMPOSITE INPUTS
V
EO
D
I
V
S
EO
D
I
V
S
V
R
CMP1
CMP2
L/
MONO
R
EXTERNAL SPEAKERS
L/
MONO
R
V
I
D
1
ANTENNA/
V
CABLE
I
D
2
L/
MONO
R
+
RIGHT
EXT/INT
+
LEFT
AUDIO/VIDEO OUTPUT
V
VARIABLE
AUDIO
SUBWOOFER
FIXED AUDIO
L
L
R
R
TV/DVD
2
10Chapter 1
Connections & Setup
Explanation of Jacks
This section describes the jacks you can use to make connections. There are several ways to connect components to your TV/DVD.
DIGITAL AUDIO OUTPUT Lets you connect a Dolby Digital receiver to your TV/DVD, if your receiver has an
optical input. Use an optical cable (or SPDIF cable) to connect your TV/DVD to the receiver for theatre-quality
sound. Go to page 30 for more information on digital audio.
Note: This TV/DVD’s OPTICAL DIGITAL OUT jack fully complies with the international standard governing this type of jack
(IEC958), and is designed for connection to a Dolby Digital (AC-3® or PCM) receiver or Dolby Digital (AC-3 or PCM) decoder. Older
equipment, some of which is not fully compliant with IEC958, may not be compatible with the Dolby Digital bitstream. Such a
connection using anything other than Dolby Digital AC-3 or PCM receiver or decoder could create a high noise level, causing
damage to headphones or speakers.
DVI-HDTV Input Lets you connect an HD receiver with a DVI output.
• DVI (Digital Visual Interface) Provides an uncompressed, digital video interface developed for high-
bandwidth digital connection. It supports the overlay of high-resolution graphics needed by some
electronic program guide navigation and other interactive services. DVI, when combined with HDCP (High
bandwidth Digital Content Protection) technology, creates a protected digital connection. The signal speed
of the DVI connection is 1080i for HDTV at a rate of 1.78 Gigabits per second.
• L/MONO (Audio) Provides left audio connection when using the DVI jack. The left audio connector is
usually white.
• R (Audio) Provides right audio connection when using the DVI jack. The right audio connector is usually
red.
Note: Remember to connect the left and right audio cables because the DVI cable carries only the picture signal, not the sound.
COMPONENT INPUTS Lets you connect a component video source, such as a DVD player.
CMP1
CMP2
• CMP1 Y, P
three signals. Use three video-grade cables for the connection. When using CMP1 Y, P
connect left and right audio cables to the CMP1 L/MONO and R Audio Input jacks.
, PR (Component Video) Provides optimum picture quality because the video is separated into
B
• CMP1 L/MONO (Audio) Provides left audio connection. The left audio connector is usually white.
• CMP1 R (Audio) Provides right audio connection. The right audio connector is usually red.
• CMP2 Y, P
Their description is the same as CMP1 above. When using CMP2 Y, P
and right audio cables to the CMP2 Audio jacks.
, PR, and L/MONO and R Audio Allows you to connect a second component video source.
B
, PR, make sure you connect the left
B
COMPOSITE INPUTS Lets you connect another component such as a VCR, DVD player, or laserdisc player. Its
AUDIO jacks are the same as described for CMP1 above.
• VID1 S-VIDEO Provides better picture quality than the video jacks (VID1 and 2 Video) because the color
part of the signal is separated from the black and white part of the picture. When using VID1 S-VIDEO,
make sure to connect left and right audio cables to the VID1 L/MONO and R Audio Input jacks.
• VID1 V (Video) Provides composite video connection. The video connector is usually yellow.
• VID2 S-VIDEO, V and L/MONO and R Audio Allows you to connect a component such as a VCR, DVD
player, or laserdisc player. Their description is the same as VID1 above.
Note: Do not connect an S-Video and Video cable at the same time in either VID1 or VID2 jacks.
AUDIO/VIDEO OUTPUTS Lets you connect an amplifier or audio receiver for improved sound quality or an
external video monitor.
• FIXED AUDIO L/R Provides fixed-level audio output from the TV/DVD. This audio output is ideal for
connecting to an A/V receiver when you want to control the volume through the A/V receiver.
• VARIABLE AUDIO Provides variable-level audio output. Volume levels are controlled by the volume
controls on the TV/DVD and remote control.
• SUBWOOFER Provides lower bass audio frequencies out from the TV/DVD and to a subwoofer.
Note: If you’ve connected a subwoofer, make sure you set the External Subwoofer option in the Sound menu. Go to page 33 for
instructions.
EXTERNAL SPEAKERS
• Right and Left Speaker Terminals Let you connect external left and right speakers to the TV/DVD to
receive left and right sound.
• EXT/INT (switch) Lets you turn the TV/DVD’s internal speakers on or off. EXT sends audio to external
speakers only. INT sends audio to the TV/DVD’s internal speakers only.
ANTENNA/CABLE Lets you connect a coaxial cable to receive the signal from the antenna, cable, cable box, or
if using the examples on pages 7-9, a VCR.
DVI-HDTV
P
BPR
Y
P
B
Y
COMPONENT INPUTS
COMPOSITE INPUTS
V
O
E
D
I
V
S
O
E
D
I
V
S
V
AUDIO/VIDEO OUTPUT
V
VARIABLE
AUDIO
SUBWOOFER
+
RIGHT
EXTERNAL SPEAKERS
L/
MONO
P
R
L/
MONO
L/
MONO
FIXED AUDIO
L
L
+
LEFT
L/
L/
R
MONO
MONO
R
R
R
R
EXT/INT
R
R
V
ID
1
V
ID
2
, PR, make sure to
B
Chapter 111
Connections & Setup
The Front of Your TV/DVD
Front Inputs
The TV/DVD has front inputs for convenience: one set of audio/video inputs, an S-Video and a headphone jack. Locate the jacks either on the front of
the TV/DVD or on one of the sides. You can access the component you connected to the front of the TV/DVD by pressing the INPUT button on your
remote until FRNT appears on the screen. The jacks are ideal for using a video game console or a camcorder.
Note: When connecting a device that uses a monaural cable, such as some camcorders, use the Left (mono) input jack to get sound from both speakers.
PHONES Allows you to connect headphones to listen to the sound coming from the TV/DVD. To adjust volume control of the headphones, press the
VOL > or VOL < button (the volume display appears). Press the arrow up or down button (the headphone volume display appears), then press the right
or left arrow button to adjust the headphone volume.
L/MONO and R AUDIO IN Receives audio from another component such as a VCR, camcorder or video game console.
VIDEO IN Receives video from another component such as a VCR, camcorder or video game console.
S-VIDEO IN Allows you to connect an S-Video cable from another component. Make sure you also connect audio cables from the component to the
TV/DVD.
Front Panel Buttons
If you cannot locate your remote, you can use the front panel buttons of your TV/DVD to operate many of the TV/DVD’s features.
OPEN/CLOSE Press to open and close disc tray.
STOP Stops disc play.
PLAY Begins disc play.
MENU/OK Brings up the TV Main menu.When in the menu system, selects highlighted items.
CH v Scans down through the current channel list. In the TV menu system, acts like down arrow button on the remote control and adjusts menu
controls.
v
CH Scans up through the channel list. In the TV menu system, acts like up arrow button on the remote control and adjusts menu controls.
VOL < Decreases the volume. In the TV menu system, acts like left arrow button on the remote control and adjusts menu controls.
VOL > Increases the volume. In the TV menu system, acts like right arrow button on the remote control and adjusts menu controls.
POWER Turns the TV/DVD on and off.
Put batteries in the remote
• Remove the battery compartment cover from the back of the remote by pushing down on and sliding off the cover.
• Insert 2 “AA” fresh batteries. Make sure the polarities (+ and -) are aligned correctly.
• Replace the cover.
Turn on the TV/DVD
Press TV on the remote, or press POWER on the TV/DVD’s front panel.
Note: Pressing the TV button not only turns on the TV, but puts the remote into TV mode. “TV mode” means that the buttons on the remote control operate the TV’s functions.
Tip
To access the setup menus manually,
press MENU and choose SETUP.
Complete the Initial Setup
The menu system in your TV allows the TV’s features to work properly. The first time you turn on your TV/DVD,
the setup screens appear.
12Chapter 1
Connections & Setup
Set the Menu Language
The first part of the setup allows you to select your preferred language for the menu system.
1. Highlight your preferred language for the menu system using the arrow buttons.
2. Press OK to select that language (the Channel Setup screen appears with Auto channel search
highlighted).
Complete Auto Channel Search
This part of the setup allows the TV to search for all channels viewable through your antenna or
cable TV system. This is sometimes called auto programming. Press OK to begin auto channel
search. When the channel search is complete, press OK to access the List & Labels screen.
Changing Lists and Labels
The List & Labels part of the setup lets you edit your channel list and choose or create a personal
six-character label for each channel.
Note: Changing List and Labels can be time consuming. You can change these at a later time by accessing the
Setup menu.
1. Press the left or right arrow to scroll through the available channels and choose the channel
you want to edit.
2. Press the down arrow to highlight the In channel list option. Press the left or right arrow
button to add (the box is checked) or remove (the box is unchecked) the channel from the list.
3. Press the down arrow to highlight the Channel label option. Press the left or right arrow
button to scroll through the available list of 25 most common labels. The last option in the list
allows you to create your own six-character label for the channel (the first letter of the label
is highlighted).
4. Press the 1 or 2 number button to change the first letter of the label.
5. Press the right arrow to highlight the second letter, then press the 1 or 2 number button to
change the second letter, etc...
6. When you are finished creating your label, select Go back (the Auto Convergence menu
appears).
Auto Convergence
Your TV/DVD’s picture tubes might have been disturbed during delivery or after you moved the
TV/DVD, causing the color in your TV/DVD to be out of alignment. The colors adjust by starting
auto convergence.
1. Press OK to begin auto convergence.
2. When the auto convergence is complete, the Red center convergence menu appears. The cross
in the middle of the screen should be yellow. If it is not, use the arrow buttons to move the
red cross to overlap the green cross. Press OK when adjustments are complete.
3. The Blue center convergence menu appears with a cyan cross in the middle of the screen. If it
is not, use the arrow buttons to move the blue cross to overlap the green cross. Press OK (the
TV tunes to the last available channel in the channel list).
Chapter 113
Loading...
+ 33 hidden pages
You need points to download manuals.
1 point = 1 manual.
You can buy points or you can get point for every manual you upload.
