RCA F36444 User Manual
F36444
36" (Diagonal) Stereo Television
Features Benefits
YPrPb Component Inputs - For Direct Connection of
Video Devices with YPrPb Outputs such as DVD Players,
Satellite Receivers, or Digital Cable Boxes
Digital 3-Line Comb Filter
Guide Plus+ GOLD¹ On-Screen Program Guide
High Performance Video System
Two Sets of Stereo Audio Video Inputs with S-Video,
Component Video Inputs (YPrPb), One Pair Switchable
Audio Outputs. And Front Audio Video Inputs.
Sound Logic™ Audio Leveler
Broadcast Stereo with dbx³ Noise Reduction and FrontFired Speaker System
Improves video quality by separating the signal (3 connectors) to minimize interference thereby providing a more
vibrant, sharper image compared w/ using 1 VIDEO jack.
Separates black-and-white detail from color information to
virtually eliminate edge crawls and rainbow effects while
enhancing picture resolution.
Find out What's On! The Guide Plus+ GOLD¹ feature is a
free, built-in service that provides instant listings of all your
TV shows at the touch of a button.
Advanced circuitry delivers outstanding picture
performance.
Simplifies connecting other components such as a game
system, digital camera, DVD, etc. Switchable outputs offer
maximum flexibility when connecting audio components.
Eliminates the annoying "blast" of sound during
commercial breaks. Also amplifies soft sounds
maintaining a constant volume level.
Improves the clarity and fidelity of stereo broadcasts.
Front-fired full-range frequency drivers provide excellent
imaging while localizing voices at the screen.
THOMSON MULTIMEDIA INC.
10330 N MERIDIAN STREET
INDIANAPOLIS, INDIANA 46290
F36444
Technical Specifications :
BRAND
Brand RCA
Screen Size - diagonal (inch) 36
Category Table TV
Aspect Ratio 4x3
Screen Type Optimum Contrast
Adjustable Color Temperature Yes
Auto Color Balance (AKB) Yes
Auto Color Control Yes
Comb Filter Digital 3-Line
Dynamic BlackStretch Circuitry Yes
Preferred Picture Presets 3+Personal
Scan Velocity Modulation (SVM) -
SOUND
Sound Type Brdcst Str w/dbx³ Noise Reduction
Second Audio Program (SAP) Yes
Sound Logic™ Audio Leveler Yes
Tone Control Bass & Treble + Balance
Balance Control Yes
Front Speakers (number) 2
Front-Fired Speaker System Yes
RECEPTION
Tuning Capability NTSC
CONVENIENCE
Auto Channel Search Yes
Channel Labeling Yes
Commercial Skip Yes
Guide Plus+ Program Guide¹ Gold (Free Service)
Interactive Set-up w/ Menus Yes
Multilingual On-Screen Display English/French/Spanish
On-Screen Time & Channel Display Yes
One-Touch VCR Record (Gemstar) Yes
One Button Launch for Inputs Yes - Auto Tune
Parental Control (V-Chip) Yes
Pic Memory Presets for Vid Inputs Yes
Picture Reset Yes
Picture-in-Picture Programmable Timer System Clock/Sleep/Turn-On/Scheduler
REAR CONNECTORS
RCA VPORT™ Audio/Video Inputs (Composite) 2 L&R Audio, 2 Video
S-Video Input 1 - Auto-Detectible
Component Video Input (YPrPb) Yes
Audio Outputs 1 Set - L&R Audio
Audio Outputs (Type) Switchable - Variable/Fixed
G-Link¹ Connector Yes
RF Input (Antenna) 1
FRONT CONNECTORS
Audio/Video Inputs (Composite) 1 L&R Audio, 1 Video
S-Video Input Headphone Jack -
SPECIFICATIONS
Finish Silver Shark
Product Size (WxHxD) inches 33.6 x 30.9 x 24.3
Approx. Shipping Weight, lbs 190
AC/DC Power Options AC Only
REMOTE CONTROL
Remote Model Number CRK76TE1
Remote Type Universal
INCLUDED ACCESSORIES
Instruction Book Languages English/French
DC Cigarette Lighter Adapter VPORT™ Component Video Cable -
1 - Guide Plus+ GOLD and G-LINK are trademarks of Gemstar-TV Guide International Inc.
3 - dbx is a registered trademark of Carillon Electronics Corporation.
©2002 Thomson multimedia Inc.
Trademark(s) ® Registered
Marca(s) Registrada(s)
Photos and features subject to change without notice. Illustration of product finish may vary
from actual color.
Revised 5/6/02
