10-Channel
Cordless Telephone
User’s Guide
2-9680
We bring good things to life.
FCC REGISTRATION INFORMATION
Your GE telephone equipment is registered with the Federal Communications Commission and is in compliance with
parts 15 and 68, FCC Rules and Regulations.
1 Notification to the Local Telephone Company
On the bottom of this equipment is a label indicating, among other information, the FCC Registration number and
Ringer Equivalence Number (REN) for the equipment. You must, upon request, provide this information to your
telephone company.
The REN is useful in determining the number of devices you may connect to your telephone line and still have all
of these devices ring when your telephone number is called. In most (but not all) areas, the sum of the RENs of all
devices connected to one line should not exceed 5. To be certain of the number of devices you may connect to your
line as determined by the REN, you should contact your local telephone company.
Notes
• This equipment may not be used on coin service provided by the telephone company.
• Party lines are subject to state tariffs, and therefore, you may not be able to use your own telephone equipment if
you are on a party line. Check with your local telephone company.
• Notice must be given to the telephone company upon permanent disconnection of your telephone from your
line.
2 Rights of the Telephone Company
Should your equipment cause trouble on your line which may harm the telephone network, the telephone
company shall, where practicable, notify you that temporary discontinuance of service may be required. Where
prior notice is not practicable and the circumstances warrant such action, the telephone company may temporarily
discontinue service immediately. In case of such temporary discontinuance, the telephone company must: (1)
promptly notify you of such temporary discontinuance; (2) afford you the opportunity to correct the situation; and
(3) inform you of your right to bring a complaint to the Commission pursuant to procedures set forth in Subpart E
of Part 68, FCC Rules and Regulations.
The telephone company may make changes in its communications facilities, equipment, operations of procedures
where such action is required in the operation of its business and not inconsistent with FCC Rules and Regulations.
If these changes are expected to affect the use or performance of your telephone equipment, the telephone
company must give you adequate notice, in writing, to allow you to maintain uninterrupted service.
INTERFERENCE INFORMATION
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference; and (2) This device must accept any interference received, including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna (that is, the antenna for radio or television that is “receiving” the
interference).
• Reorient or relocate and increase the separation between the telecommunications equipment and receiving
antenna.
• Connect the telecommunications equipment into an outlet on a circuit different from that to which the receiving
antenna is connected.
• Consult the dealer or an experienced radio/TV technician for help.
If these measures do not eliminate the interference, please consult your dealer or an experienced radio/television
technician for additional suggestions. Also, the Federal Communications Commission has prepared a helpful
booklet, “How To Identify and Resolve Radio/TV Interference Problems.” This booklet is available from the U.S.
Government Printing Office, Washington, D.C. 20402. Please specify stock number 004-000-00345-4 when
ordering copies.
HEARING AID COMPATIBILITY
This telephone system meets FCC standards for Hearing Aid Compatiblility.
FCC NUMBER IS LOCATED ON THE CABINET BOTTOM
REN NUMBER IS LOCATED ON THE CABINET BOTTOM
INTRODUCTION
Your GE cordless phone is designed to give you flexibility in use, and high
quality performance. To get the most from your new phone, we suggest
that you take a few minutes right now to read through this instruction
manual.
Read “Getting Started” and “Cordless Phone Basics” to learn how to
install, set up, and use the basic features of the phone.
The sections that follow show you the advanced features, and give you
maintenance and service information.
If you have any questions, be sure to check the Table of Contents on this
page, the Troubleshooting Guide, or the Index to quickly find the solution.
TABLE OF CONTENTS
GETTING STARTED ............................. 2
INSTALLATION AND SETUP ................ 3
MODULAR JACK REQUIREMENTS ... 3
CORDLESS PHONE BASICS ................... 4
MAKING A CALL ............................ 4
PHONE-IN-USE LIGHT .................. 4
REDIAL ...................................... 4
RECEIVING A CALL .......................... 4
VOLUME SWITCH ........................... 5
RINGER SWITCH ............................. 5
FLASH BUTTON ........................... 5
PAGING THE HANDSET .................... 5
ADVANCED FEATURES ......................... 6
CHANNEL BUTTON .......................... 6
THE MEMORY FEATURE ................... 6
STORING A NUMBER IN MEMORY .. 6
CHANGING A STORED NUMBER ..... 6
DIALING A STORED NUMBER ......... 6
CHAIN DIALING FROM MEMORY .....7
TEMPORARY TONE .......................... 7
CHANGING THE BATTERY ..................... 8
BATTERY SAFETY PRECAUTIONS .... 9
GENERAL PRODUCT CARE ................... 9
APPENDIX A: HANDSET SOUND
SIGNALS ...................................... 10
APPENDIX B: TROUBLESHOOTING
GUIDE ......................................... 10
APPENDIX C: CAUSES OF POOR
RECEPTION ................................... 12
SERVICE ......................................... 12
INDEX ............................................ 15
WARRANTY .................................... 16
GETTING STARTED
1
4
7
8
*
0
#
ABC DEF
JKL MNO
TUV
GHI
PRS WXY
OPER
MEMORY FLASH REDIAL
TONE
56
9
23
PHONE CHANNEL
ON/OFF
Make sure your package includes the items shown here.
CHARGE IN USE
PAGE/FIND
AC power supply
Telephone line cord
Base
Handset
BEFORE YOU BEGIN
Your GE phone has a lot of features that work behind the scenes to give
you better quality sound and more flexibility in use.
• 10-Channel Selection with AutoScan. Automatically scans channels
in order to find the one most likely to be clear of interference.
• Crystal Clear Sound™ with Compandor. Extends the effective
range of your cordless telephone and helps to eliminate static and
interference.
• Dual-Wave™ Noise Filter. Two-stage filtering system that removes
noise.
• Digital Security System. When you place the handset in the base, the
unit verifies it’s security code which prevents false ringing from other
cordless telephones. After a power outage or battery replacement, you
should place the handset in the base for about 20 seconds to reset the
code.
• Antennas. Sized smaller to give you greater flexibility for placement of
the base, and still maintain maximum range and mobility for the
handset.
• Distinctive Ring Capability. Lets you receive distinctive ringing
patterns if you have this service through your local phone company.
• FCC Registered
• UL Listed
• Hearing Aid Compatible
2
MODULAR JACK REQUIREMENTS
PAGE/FIND
IN USECHARGE
1
2
3
4
5
6
7
8
9
0
AREA CODE PHONE NUMBER
You need an RJ11 type modular jack, which is the most
common type of phone jack and might look like the one
pictured here. If you don’t have a modular jack, call your
local phone company to find out how to get one installed.
INSTALLATION AND SETUP
1 Plug the telephone line
cord into the base and
into a modular jack.
2 Plug the power supply
LSE/TONE
PULSE/TONE switch
NOTE: Use only the Thomson 5-2348 power supply that came with this unit.
Using other adapters may damage the unit.
3 Raise the base antenna.
4 Set the PULSE/TONE switch to TONE for Touch-Tone service, or PULSE
for rotary service. If you don’t know which type of service you have,
check with the phone company.
cord into the base, and
then the power supply in
an AC outlet.
5 Place handset in the base (facing either
direction) to charge for 12 hours.
The CHARGE/IN USE light comes on
indicating that the battery is charging.
6 Turn on the RINGER switch so the
handset rings for incoming calls.
CHARGE/IN USE light
PHONE CHANNEL
ON/OFF
ABC DEF
1
23
JKL MNO
GHI
4
56
TUV
PRS WXY
9
8
7
OPER
TONE
0
#
*
MEMORY FLASH REDIAL
IN USECHARGE
PAGE/FIND
RINGER switch
OR
3
CORDLESS PHONE BASICS
MAKING A CALL
The only two things you need to know to make a call are:
• Press the PHONE ON/OFF button before you dial.
• Press PHONE ON/OFF or place the handset in the base to hang up.
Otherwise, it works just like any other phone.
CAUTION: Because cordless phones operate on electricity, you should have at
least one phone in your home that isn’t cordless, in case the power in your
home goes out.
PHONE-IN-USE LIGHT
You know the phone is on when you see the Phone-inUse light on the handset come on.
REDIAL
Press the REDIAL button to redial the last number you called. If you get a
busy signal, and want to keep dialing the number, just press REDIAL again
(you don’t have to turn the phone off and back on).
PHONE CHANNEL
ON/OFF
Phone-in-Use Light
RECEIVING A CALL
The Auto Answer feature lets you just pick up and talk when you receive a
call while the handset is in the base. If a call is answered on an extension
phone, Auto Answer stays active for about 10 seconds after the call is
picked up.
To answer a call when the handset is out of the base, you must press
PHONE ON/OFF before you can talk.
4
TIP: Be careful when you pick up the handset from the base during an in-
258005
NORM
VOLUME
RINGER
ON
OFF
HIGH
coming call. If you press the PHONE ON/OFF button more than 2-3 seconds
after picking up the handset, you might hang up on the caller.
FLASH BUTTON
Use the FLASH button to activate customer calling services such as call
waiting or call transfer, which are available through your local phone
company.
TIP: Don‘t use PHONE ON/OFF to activate customer calling services such as
call waiting, or you‘ll hang up the phone.
VOLUME SWITCH
Handset VOLUME
control
Controls the volume of the handset's earpiece.
RINGER SWITCH
RINGER switch
The RINGER switch must be ON for the handset
to ring during incoming calls (or when paging the
handset). To conserve battery power, turn off the
RINGER switch when you are within hearing
range of an extension phone.
PAGING THE HANDSET
Press the PAGE/FIND button on the base to get
the attention of the person using the phone, or
to locate a misplaced handset. Remember that
the RINGER switch must be ON for the handset
to ring.
CHARGE IN USE
PAGE/FIND
PAGE/FIND button
5
ADVANCED FEATURES
1
4
7
8
*
0
#
ABC DEF
JKL MNO
TUV
GHI
PRS WXY
OPER
MEMORY FLASH REDIAL
TONE
56
9
23
PHONE CHANNEL
ON/OFF
CHANNEL BUTTON
You might need to manually change the channel in
order get rid of static. Press and release the CHANNEL
PHONE CHANNEL
ON/OFF
button to advance to the next channel (until you get a
clear channel).
CHANNEL button
THE MEMORY FEATURE
Store up to 10 numbers in memory for quick dialing.
STORING A NUMBER IN MEMORY
The phone must be OFF when you store numbers.
1 Press the MEMORY button.
2 Dial the number (up to 24 digits).
3 Press MEMORY and then press a number key (0-9) to
store the dialed number in that memory location.
4 Record whose number is stored in the location on the
memory directory card on the back of the handset.
MEMORY button
CHANGING A STORED NUMBER
Use the same procedure to change a stored number as you do to store a
number—in a sense, you’re just reassigning the memory location.
D
IALING A STORED NUMBER
1 Make sure the phone is ON.
2 Press MEMORY, and then press the number for that memory location.
CAUTION: If you make test calls to emergency numbers stored in memory,
remain on the line and briefly explain the reason for the call to the dispatcher.
Also, it’s a good idea to make these calls in off-peak hours, such as early
morning or late evening.
6
C
TON
HAIN DIALING FROM MEMORY
Use this feature to make calls which require a sequence of numbers, for
instance if you use a calling card for a frequently called long distance
number. Basically, you dial each part of the sequence from memory.
The following example shows how you can use chain dialing to make a
call through a long distance service:
The Number For Memory Location
Long distance access number 7
Authorization code 8
Frequently called long distance number 9
1 Make sure the phone is ON.
2 Press MEMORY and then press 7.
3 When you hear the access tone, press MEMORY and then press 8.
4 At the next access tone, press MEMORY and then 9.
TIP: Wait for the access tones before pressing the next memory button, or
your call might not go through.
TEMPORARY TONE
This feature enables Pulse (rotary) service phone users to access TouchTone services offered by banks, credit card companies, etc. by pressing the
TONE button to temporarily make the phone Touch-Tone compatible. To
get information about your bank account, for example, you would:
1 Call the bank’s information line.
2 Press the TONE button(
3 Follow the voice instructions to complete your transaction.
4 Hang up when finished. The phone returns to Pulse (rotary) service.
) after your call is answered.
*
7
CHANGING THE BATTERY
1
4
7
8
*
0
#
ABC DEF
JKL MNO
TUV
GHI
PRS WXY
OPER
MEMORY FLASH REDIAL
TONE
PAGE/FIND
IN USECHARGE
56
9
23
PHONE CHANNEL
ON/OFF
The handset runs on a consumer-replaceable nickel cadmium battery pack.
If you experience any of the following problems, you may need to replace
the battery pack:
• Short talk time • Poor sound quality
• Limited range • CHARGE/IN USE light fails to light
Make sure phone is OFF before you replace battery.
1 Slide open
the battery
compartment
door.
5 Replace and
plug in the new
battery pack
(use catalog
#BT-12 or AT&T
replacement
battery #4051.)
ON
RINGER
OFF
2 Unscrew and
remove the
bracket holding
battery in place.
Bracket
6 Replace the
bracket and
secure it with
the screw.
3 Pull out the
battery plug.
Plug
7 Replace the
battery
compartment
door.
4 Remove the
battery pack.
ON
RINGER
OFF
8 Charge the
battery for 12
hours before
use.
8
BATTERY SAFETY PRECAUTIONS
• Don’t disassemble, mutilate, puncture, wet, or dispose of battery in fire.
Like other batteries of this type, if it is burned or punctured, it could
release toxic materials which can cause injury.
• Keep batteries out of the reach of children.
Contains
Nickel-Cadmium
Rechargeable Battery
Ni-Cd
Must be Recycled or
Disposed of Properly
NOTE: Numerous states have enacted legislation regarding
proper disposal of rechargeable batteries. This product
contains a nickel-cadmium rechargeable battery and must
be recycled or disposed of properly. Check your Federal,
State, or Local regulations regarding recycling or disposal.
GENERAL PRODUCT CARE
To keep your telephone working and looking good, follow these guidelines:
• Avoid putting the phone near heating appliances and devices that
generate electrical noise (for example, motors or fluorescent lamps).
• DO NOT expose to direct sunlight or moisture.
• Avoid dropping the handset, as well as other rough treatment to the
phone.
• Clean the phone with a soft cloth.
• Never use a strong cleaning agent or abrasive powder because this will
damage the finish.
• Retain the original packaging in case you need to ship the phone at a
later date.
• Periodically clean the charge contacts on the handset and base with a
soft cloth.
9
A
PPENDIX
Signal Meaning
Three long beeps Page signal
A long warbling tone (with ringer on) Signals an incoming call
Four short beeps Out of range warning
A
PPENDIX
In case of difficulty, please check the following Troubleshooting Guide
before seeking service.
Problem Solution
No dial tone • Check installation:
A: H
B: T
ANDSET SOUND SIGNALS
ROUBLESHOOTING GUIDE
— Is the base power cord connected to a working
outlet?
— Is the Phone in Use light on?
— Is the telephone line cord connected to the base
unit and the wall jack?
• Disconnect the base from the wall jack and connect
another phone to the same jack. If there is no dial tone
in the second phone, the problem might be your
wiring or local service.
• Is the handset out of range of the base?
• Make sure the battery is properly charged (12 hours).
• Is the battery pack installed correctly? See page 8.
• Did the handset beep when you pressed the phone
button? Did the Phone in Use light come on? The
battery may need to be charged.
• Reset the security code by placing the handset in the
base for about 20 seconds.
10
Problem Solution
Dial tone is OK, but • Make sure the TONE/PULSE switch on the base is
can’t dial out correctly set (see page 3).
Handset does not ring • Make sure the RINGER switch on the handset is
You experience static, • Change channels
noise, or fading in • Is handset out of range? Move closer to the base.
and out • Does the base need to be relocated?
Unit beeps • Place handset in base for 20 seconds to reset the
Memory Dialing • Did you program the memory location keys correctly?
turned to ON.
• You may have too many extension phones on your
line. Try unplugging some phones.
• See solutions for “No dial tone.”
• Charge battery.
• Make sure base is not plugged into an outlet with
another household appliance.
security code. If that doesn’t work, charge battery for
12 hours.
• Clean charging contacts on handset and base with a
soft cloth, or an eraser.
• See solutions for “No dial tone.”
• Replace battery.
See page 6.
• Did you follow proper dialing sequence? See pp. 6-7.
• Make sure TONE/PULSE switch is correctly set.
See p. 3.
• Did you reprogram numbers into memory after power
outage or replacing battery?
11
APPENDIX C: CAUSES OF POOR RECEPTION
• Aluminum siding
• Foil backing on insulation
• Heating ducts and other metal construction can shield radio signals
• You’re too close to appliances such as microwaves, stoves,
computers, etc.
• Atmospheric conditions, such as strong storms
• Base is installed in the basement or lower floor of the house
• Base is plugged into an AC outlet with other electronic devices
• Baby monitor is using the same frequency
• Handset battery is low
• You’re out of range of the base
S
ERVICE
FCC requires this product to be serviced only by the manufacturer or its
authorized service agents. In accordance with FCC requirements, changes
or modifications not expressly approved by Thomson Consumer Electronics could void the user’s authority to operate this product. For instructions
on how to obtain service, refer to the warranty included in this Guide or
call Consumer Information, 1-800-448-0329.
Attach your sales receipt to the booklet for future reference or jot down the
date this product was purchased or received as a gift. This information will
be valuable if service should be required during the warranty period.
Purchase date _____________ Name of store
12
✂
CUSTOMER: CUT ALONG DOTTED LINE.
TOTAL
QUANTITY
PRICE*
CATALOG NUMBER
RDER FORM
$9.95
$14.95
BT-12
5-2348
$5.00
Sales Tax................................................... $_______________
We are required by law to collect the appropriate sales tax for
each individual state, county, and locality to which the
*Prices are subject to change without notice.
Total Merchandise...........................................$_______________
merchandise is being seENT.
Use VISA or MasterCard preferably .Money order or check must be in U.S. currency
only. No COD or Cash.
All accessories are subject to availability. Where applicable, we will ship a
superseding model.
Shipping, Handling, and Insurance............. $_______________
Total Amount Enclosed.................................$_______________
Mail order form and money order or check (in U.S. currency)
made payable to Thomson Consumer Electronics, Inc. to:
Consumer Electronics
Mail Order Department
P.O. Box 8419
Ronks, PA 17573-8419
This is your return label. Please print clearly.
To :
Name________________________________________________________
Address_____________________________________ Apt.____________
City ________________________State________ ZIP_________________
Please make sure that this form has been filled out completely.
O
DESCRIPTION
Replacement handset battery
Ac power supply adapter
ACCESSORY
Copy the number above your
For credit card purchases
Your complete charge card number, its expiration date and your
signature are necessary to process all charge card orders.
Copy your complete account number from your VISA card.
My card expires:
Copy your complete account number from your MasterCard.
name on the MasterCard
My card expires:
____________________________________________________________________
Authorized Signature
13
14
ORM
ORDER F
CCESSORY
A
To fulfill your communicating needs and enhance your life-style, a wide
range of GE extension phones, main phones, cordless phones and
answering systems is available.
Just stop by your nearest retailer and ask to see the wide range of GE
telephone products.
All are carefully engineered to offer you high quality and dependability,
modern easy-to-use features, and elegant styling at an affordable price.
Should you wish to purchase, insist on the GE brand for all your
communicating needs.
INDEX
A
Auto Answer 4
AutoScan 2
B
Battery
Installation 8
Battery Safety 9
Buttons
CHANNEL 6
FLASH 5
MEMORY 6, 7
PAGE/FIND 5
PHONE ON/OFF 4
REDIAL 4
TONE 7
C
Chain Dialing 7
chain dialing 7
CHANNEL Button 6
CHARGE/IN USE 8
CHARGE/IN USE light 3
cleaning the phone 9
Compandor Noise
Reduction 2
D
Distinctive Ring 2
F
FLASH button 5
H
Handset Sound Signals
10
I
Installation 3
M
Making a Call 4
MEMORY button 6, 7
Memory feature 6
memory location 6
N
nickel cadmium battery
pack 8
replacement of 8
P
PAGE/FIND button 5
Paging the Handset 5
PHONE ON/OFF 4
Product Care 9
R
REDIAL 4
Ringer Switch 5
Ringer switch 5
S
Security 2
Service 12
T
Temporary Tone 7
TONE button 7
15
WARRANTY
What does your warranty cover?
• Any defect in material or workmanship.
For how long after the original purchase?
• One year.
• The warranty for rental units begins with the first rental.
What will we do?
• Provide you with a new, or at our option, a refurbished unit.
• The exchange unit is warranted for the remainder of your product’s original one-year
warranty period.
How do you make a warranty claim?
• Properly pack your unit. Include any cables, etc., which were originally provided with
the product. We recommend using the original carton and packing materials.
• Include in the package a copy of the sales receipt or other evidence of date of original
purchase. If the unit was a gift, provide a statement specifying the date received. Also
print your name and address and a description of the defect.
Send standard UPS or its equivalent to:
Thomson Consumer Electronics, Inc.
Product Exchange Center
32 Spur Drive
El Paso, Texas 79906
• Pay any charges billed to you by the Exchange Center for service not covered by the
warranty.
• A new or refurbished unit will be shipped to you
prepaid freight.
What does your warranty not cover?
• Customer instruction. Your Owner’s Manual provides information regarding operating
instructions and user controls. For additional information, ask your dealer.
• Installation and set-up service adjustments.
• Batteries.
• Damage from misuse or neglect.
• Products which have been modified or incorporated into other products.
• Product purchased or serviced outside the USA.
• Acts of God, such as but not limited to lightning damage.
How does state law relate to this warranty?
• This warranty gives you specific legal rights, and you may also have other rights which
vary from state to state.
What if you purchased your product outside the United States?
• This warranty does not apply. Contact your dealer for details.
Model #2-9680
349A2658-0001 (Rev. 1)
94-51
Printed in Malaysia
© 1994 Thomson Consumer Electronics, Inc.
P.O. BOX 1976, Indianapolis, IN 46206
Trademark(s) ® Registered
Loading...
