Page 1
TV/VCR
User's Guide
Changing Entertainment. Again.
Page 2
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dangerous voltage within the product's
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS POLARIZED PLUG WITH AN EXTENSION
CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE FULLY INSERTED
TO PREVENT BLADE EXPOSURE.
WARNING:
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
Product Registration
Please fill out the product registration card (packed separately) and return it immediately. For U.S. customers: Your
RCA Consumer Electronics product may also be registered at www.rca.com/productregistration. Registering this
product allows us to contact you if needed.
Product Information
Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it here and record the
serial and model numbers. These numbers are located on the product.
Model No. _____________ Serial No. _____________ Purchase Date: ______________
Dealer/Address/Phone:_____________________________________________________
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
CAUTION:
Changes or modifications not expressly approved by the
party responsible for compliance with the FCC Rules
could void the user's authority to operate this equipment.
IMPORTANT SAFEGUARDS
1. READ INSTRUCTIONS
All the safety and operating instructions should be
read before the unit is operated.
2. RETAIN INSTRUCTIONS
The safety and operating instructions should be
retained for future reference.
3. HEED WARNINGS
All warnings on the unit and in the operating
instructions should be adhered to.
2
4. FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
5. CLEANING
Unplug this unit from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning the exterior cabinet
only.
6. ATTACHMENTS
The manufacturer of this unit does not make any
recommendations for attachments, as they may
cause hazards.
Page 3
IMPORTANT SAFEGUARDS
7. WA TER AND MOISTURE
Do not use this unit near water. For example, near a
bathtub, washbowl, kitchen sink, laundry tub, in a
wet basement, or near a swimming pool.
8. ACCESSORIES
Do not place this unit on an unstable cart, stand,
tripod, bracket, or table.
The unit may fall, causing serious injury, and
serious damage to the unit.
8A. An appliance and cart
combination should be
moved with care.
Quick stops, excessive
force, and uneven
surfaces may cause
the appliance and cart
combination to overturn.
9. VENTILATION
Slots and openings in the cabinet back or bottom are
provided for ventilation, and to ensure reliable
operation of the unit, and to protect it from overheating. These openings must not be blocked or covered.
The openings should never be blocked by placing the
unit on a bed, sofa, rug, or other similar surface. This
unit should never be placed near or over a radiator or
heat source. This unit should not be placed in a builtin installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instructions have been adhered to.
10. POWER SOURCES
This unit should be operated only from the type of
power source indicated on the rating plate. If you are
not sure of the type of power supply to your home,
consult your appliance dealer or local power
company. For units intended to operate from battery
power, or other sources, refer to the operating
instructions.
11. GROUNDING OR POLARIZATION
This unit is equipped with a polarized alternatingcurrent line plug (a plug having one blade wider than
the other). This plug will fit into the power outlet only
one way. This is a safety feature. If you are unable to
insert the plug fully into the outlet, try reversing the
plug. If the plug should still fail to fit, contact your
electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the polarized plug, if
your unit is equipped with a 3-wire grounding-type
plug, a plug having a third (grounding) pin. This plug
will only fit into a grounding-type power outlet. This
too, is a safety feature. If you are unable to insert the
plug into the outlet, contact your electrician to replace
your obsolete outlet.
Do not defeat the safety purpose of the groundingtype plug.
PORTABLE CART WARNING
(symbol provided by RETAC)
S3126A
12. POWER-CORD PROTECTION
Power-supply cords should be routed so that they are
not likely to be walked on or pinched by items placed
upon or against them, paying particular attention to
cords at plugs, convenience receptacles, and the point
where they exit from the appliance.
13. LIGHTNING
To protect your unit from a lightning storm, or when it
is left unattended and unused for long periods of
time, unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent damage to
the unit due to lightning and power line surges.
14. POWER LINES
An outside antenna system should not be located in
the vicinity of overhead power lines or other electric
light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside
antenna system, extreme care should be taken to
keep from touching such power lines or circuits, as
contact with them might be fatal.
15. OVERLOADING
Do not overload wall outlets and extension cords, as
this can result in a risk of fire or electric shock.
16. OBJECT AND LIQUID ENTRY
Do not push objects through any openings in this unit,
as they may touch dangerous voltage points or short
out parts that could result in fire or electric shock. Never
spill or spray any type of liquid into the unit.
17. OUTDOOR ANTENNA GROUNDING
If an outside antenna or cable system is connected to
the unit, be sure the antenna or cable system is
grounded to provide some protection against voltage
surges and built-up static charges, Section 810 of the
National Electrical Code, ANSI/NFPA 70, provides
information with respect to proper grounding of the
mast and supporting structure, grounding of the leadin wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit,
connection to grounding electrodes, and requirements for the grounding electrode.
18. SERVICING
Do not attempt to service this unit yourself as
opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all
servicing to qualified service personnel.
3
Page 4
IMPORTANT SAFEGUARDS
19. DAMAGE REQUIRING SERVICE
Unplug this unit from the wall outlet and refer
servicing to qualified service personnel under the
following conditions:
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen
into the unit.
c. If the unit has been exposed to rain or water.
d. If the unit does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operat-
ing instructions, as an improper adjustment of
other controls may result in damage and will
often require extensive work by a qualified
technician to restore the unit to its normal
operation.
e. If the unit has been dropped or the cabinet has
been damaged.
f . When the unit exhibits a distinct change in
performance, this indicates a need for service.
EXAMPLE OF ANTENNA GROUNDING AS PER THE
NATIONAL ELECTRICAL CODE
20. REPLACEMENT PARTS
When replacement parts are required, be sure the
service technician uses replacement parts specified
by the manufacturer or those that have the same
characteristics as the original part.
Unauthorized substitutions may result in fire, electric
shock or other hazards.
21. SAFETY CHECK
Upon completion of any service or repairs to this
unit, ask the service technician to perform safety
checks to determine that the unit is in proper
operating condition.
22. HEAT
The product should be situated away from heat
sources such as radiators, heat registers, stoves, or
other products (including amplifiers) that produce heat.
23. NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system
installer’s attention to Article 820-40 of the NEC that
provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be
connected to the grounding system of the building,
as close to the point of cable entry as practical.
4
GROUND CLAMP
ELECTRIC SERVICE
EQUIPMENT
NEC-NATIONAL ELECTRICAL CODE
S2898A
ANTENNA LEAD IN WIRE
ANTENNA DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
Page 5
PRECAUTIONS
TABLE OF CONTENTS
MOISTURE CONDENSATION
DO NOT OPERATE ANY FUNCTIONS ON THIS UNIT
FOR AT LEAST TWO OR THREE HOURS WHEN
MOISTURE IN THE AIR CONDENSES ON IT. LET THE
UNIT STAND WITH POWER ON (SEE BELOW).
WHAT IS MOISTURE CONDENSATION?
When a cold liquid is poured into a glass, for example, water vapor in the air will condense on the
surface of the glass. This is called moisture condensation.
MOISTURE WILL CONDENSE ON THE UNIT IN
THE FOLLOWING CASES;
• When you move the unit from a cold to a warm
place.
•After heating a cold room or under extremely humid
conditions.
WHEN YOU EXPERIENCE THE ABOVE CONDITIONS,
Plug the power cord into an AC outlet, press the
POWER button to turn on and leave the unit at room
temperature until moisture condensation disappears.
Depending on the surrounding conditions, this may
take two or three hours.
LOCA TION AND HANDLE
• If you cause a static discharge when touching the unit,
and the unit fails to function, simply unplug the unit
from the wall outlet, wait 10 minutes and plug it back
in. The unit should return to normal operation.
• Avoid extreme heat or cold.
(41˚F/5˚C - 104˚F/40˚C)
• Do not place the unit on or near appliances which may
cause electromagnetic interference (e.g. speakers,
etc). Doing so may cause erratic operation of the unit
including picture and/or sound distortion or noise.
• Avoid extreme moisture and dust.
• The ventilation holes prevent overheating. Do not
block or cover these holes. Especially avoid covering
the holes with soft materials such as cloth or paper.
• Do not insert fingers or any other objects into the
cassette loading slot. Do not spray cleaner or wax
directly on the unit or use forced air to remove dust.
• Avoid places subject to strong vibration. Use in a
horizontal (flat) position only.
• Keep the unit away from flower vases, sinks, etc.
If liquids should be spilled into the unit, serious damage
will result. If you spill any liquids into the unit, unplug the
AC power cord immediately and consult qualified
service personnel before attempting to use it again.
• When you finish operating the unit, always unload the
cassette and turn off the power.
• When you leave your home for a long time, unplug the
AC power cord.
• To protect the unit from a lightning storm, unplug the
AC power cord from the wall outlet and disconnect the
antenna.
CAUTIONS
IMPORT ANT SAFEGUARDS ..................................... 2
PRECAUTIONS.......................................................... 5
PREPARATION
FEATURES................................................................. 6
LOCATION OF CONTROLS....................................... 7
REMOTE CONTROL.................................................. 8
POWER SOURCE...................................................... 9
ANTENNA CONNECTIONS ..................................... 10
CABLE TV CONNECTIONS ..................................... 11
SETTING THE LANGUAGE ..................................... 11
AUTO CLOCK SETTING.......................................... 12
MANUAL CLOCK SETTING ..................................... 13
TV OPERATION
TV OPERATION ....................................................... 13
TO MEMORIZE CHANNELS .................................... 15
SETTING THE V-CHIP ............................................. 16
TO SET THE ON TIMER .......................................... 18
TO SET THE OFF TIMER......................................... 18
PICTURE CONTROL ADJUSTMENTS .................... 19
SOUND CONTROL ADJUSTMENTS....................... 19
PLAYBACK
LOADING AND UNLOADING.....................................
PLAYBACK............................................................... 20
SPECIAL PLAYBACK ............................................... 21
20
RECORDING
RECORDING A TV PROGRAM................................ 21
ONE-TOUCH TIMER RECORDING (OTR) .............. 22
TIMER RECORDING................................................ 22
ADDITIONAL INFORMATION
USING THE REAL TIME TAPE COUNTER.............. 23
STEREO RECORDING AND PLAYBACK ................ 24
SECOND AUDIO PROGRAM (SAP) ........................ 24
DUPLICATING A VIDEO TAPE................................. 25
TROUBLESHOOTING GUIDE ................................. 26
RECEPTION DISTURBANCES................................ 28
VIDEO HEAD CLEANING ........................................ 28
SPECIFICATIONS.................................................... 29
LIMITED WARRANTY .............................................. 30
5
Page 6
FEATURES
Color TV With Video Cassette Recorder - Unique
space saving design combines a color TV and a video
cassette recorder.
High Quality Picture Technology - This TV/VCR
equipped “HQ” incorporates VHS High Quality technology. A built-in detail enhancer is used to boost the
recorded signal and provide maximum picture quality
during playback. It is compatible with other VHS video
cassette recorders.
181 Channel Tuner - Receives standard VHF and UHF
broadcast channels and up to 113 cable channels. The
actual number of channels received depends upon
channel reception in your area or your cable system.
Closed Caption Decoder With Full Text Mode -
Displays text captions or screen text on the screen for
hearing impaired viewers.
8-Programs/1-Month Programmable Timer With
Everyday/Every Week Capability - The built-in timer
allows automatic absentee recording of up to 8 TV
programs within 1 month. It is also possible to record a
program which is broadcast at the same time everyday
or every week.
Automatic Clock Set - Once your TV/VCR is plugged
into the AC outlet, it automatically sets the correct date
and time.
On-Screen TV Display And VCR Programming -
When you select a channel or make other changes, the
TV will show an indicator on the screen for a few
seconds. Timer recording can be programmed and
confirmed on the screen.
Picture Adjustments Using The Remote Control -
The On-Screen display allows precise remote control
adjustment of BRIGHTNESS, CONTRAST, COLOR,
TINT and SHARPNESS.
Automatic Playback/Rewind-Stop-Eject - When
loading a cassette tape without the erase prevention
tab, this TV/VCR will automatically play back the
cassette tape at the correct
its end during play-back, recording
and Timer Record) and fast forward, it will automatically
stop, rewind, stop and eject the tape.
speed. When a tape reaches
(except during OTR
V-Chip - The V-Chip function can read the rating of a TV
program or movie content if the program is encoded with
this information. V-chip will allow you to set a restriction
level.
Automatic Repeat Play System - When Auto Repeat
option is turned on, the TV/VCR will automatically play
back the same cassette tape repeatedly.
One-touch Timer Recording (OTR) - Simply by
pressing the REC/OTR button, the TV/VCR can be
programmed for up to 5 hours of recording with an
immediate start.
Audio/Video Input/Output Jacks - A VCR or other
video device may be hooked up to this TV/VCR for
dubbing or playback purposes.
Skip Search - When the SKIP•SEARCH button on the
remote control is pressed during playback, the TV/VCR
will automatically search forward in 30 second increments to a maximum of 3 minutes with each press of the
SKIP•SEARCH button, and then return to normal
playback.
2 Speed Picture Search - 3 or 5 times normal speed in
SP mode (7X or 9X in LP and 9X or 15X in SLP).
3 Speed Playback - Plays three tape speeds (SP, LP,
SLP).
2 Speed Record - Records two tape speeds (SP, SLP).
Digital Auto Tracking - Automatically adjusts tracking
during playback for the best possible picture.
On-Screen 3 Language Display - You can select one of
3 languages, English, Spanish or French for on-screen
programming.
TV Monitor - When the TV/VCR button on the remote
control is pressed during playback, the TV channel
selected on the TV/VCR can be viewed.
Hi-Fi Stereo Sound - With a frequency response of 20
to 20,000 Hz and a dynamic range of better than 90dB,
this VCR provides a level of excellence that rivals
compact discs.
Programmable ON/OFF Timer - Allows you to automatically turn on or off the TV/VCR at a set time.
Programmable TV Sleep Timer - Operable from the remote control, the TV can be programmed up to 120 minutes to turn off automatically.
6
Page 7
LOCATION OF CONTROLS
FRONT REAR
1
2
43 567
108 11 12 13 14
9
DESCRIPTION OF CONTROLS
FRONT:
1. Cassette Loading Slot - To insert or remove a
video tape.
2. POWER Button - Press to turn the TV/VCR on or off.
3. T.REC Indicator - Lights when the unit is in the
Timer Record Mode.
4. REC/OTR Indicator - Lights up when the TV/VCR
is recording.
5. CH ▲ / ▼ Buttons - Press to select a channel for
viewing or recording.
33
55
6.
3/
5 (ST OP/EJECT) Button - Press once to stop the
33
55
tape in any mode. Press again to eject the tape.
99
7.
9 (Forward) Button - In the Stop mode,
99
this button rapidly winds the tape forward. In the
Play mode, this button activates forward search.
8. Remote Sensor - Signals from the Remote Control
are received here.
9. REC/OTR Button - Press once to start normal
recording. Additional presses activate One-touch
Timer Recording.
10. VOL ▲ / ▼ Buttons - Press to raise or lower the
level of the sound.
VIDEO
L
(MONO)
AUDIO
UHF/
R
VHF
OUT LINE1
15
16
17
11
11.
1 (PLAY) Button - Press to play a prerecorded tape.
11
88
12.
8 (Reverse) Button - In the Stop mode, this
88
18
button rapidly winds the tape backwards. In the
Play mode, this button activates reverse search.
13. AUDIO (L/R)/VIDEO IN (LINE 2) Jacks - Audio and
video signal cables from an external source can be
connected here.
14. PHONES Jack - Plug monaural headphones or an
earphone with an 1/8" miniplug into this jack for
private listening.
REAR:
15. UHF/VHF Antenna Jack - Connect the 75 ohm
coaxial cable from the antenna or Cable TV service
to this jack.
16. AUDIO (L/R)/VIDEO OUT Jacks - Used to output
audio and video signals to a TV , amplifier or VCR.
17. AUDIO (L/R)/VIDEO IN (LINE 1) Jacks - Audio and
video signal cables from an external source can be
connected here.
18. AC Power Cord - Connect to a 120V, 60Hz outlet.
7
Page 8
S
E
T
/
T
R
K
+
S
E
T
/
T
R
K
–
EJECT INPUT
MUTING
AUTO
TRACK
STOP
REVERSE
T.REC SPEED
TV/VCR
PROGRAM
FORWARD RESET
SKIP
•
SEARCH
PAUSE
SLOW
GO BACK
SOUND
REMOTE CONTROL
1
EJECT INPUT
2
3
4
5
6
7
AUTO
TRACK
STOP
REVERSE
FORWARD RESET
MUTING
R
T
/
K
T
E
S
S
E
T
/
T
R
SEARCH
T.REC SPEED
TV/VCR SOUND
GO BACK
+
SLOW
–
K
PAUSE
SKIP
•
PROGRAM
8
9
DESCRIPTION OF CONTROLS
1. POWER Button - Press to turn the TV/VCR on.
Press again to turn the TV/VCR off.
2. Direct Channel Selection Buttons (0-9) - Allows
direct access to any channel.
3. CALL Button - Displays the present time/day of the
week, channel, counter, speed selection (and VCR
mode if VCR is playing) on the TV screen.
4. AUTO TRACK Button - Allows automatic adjustment
of tracking to minimize picture noise during playback.
5. MENU Button - Press to display the On-Screen
menu function.
6. STOP Button - Press once to stop the tape.
7. REVERSE Button - In the Stop mode, this button
rapidly winds the tape backwards. In the Play mode,
this button activates reverse search.
8. REC/OTR Button - Press once to start normal
recording. Additional presses activate One-touch
Timer Recording.
9. SLEEP Button - Sets the TV to turn off automatically
after up to 120 minutes.
10. CH +/– Buttons - Press the + button to change to a
higher numbered channel set into memory. Press the
– button to change to a lower numbered channel set
into memory.
11. VOL +/– Buttons - Press the + button to increase, or
12. GO BACK Button - Switches between the present
13. SLOW Button - Slow motion playback.
14. CANCEL Button - Used to clear the selected
15. PAUSE Button - During recording, this button
the – button to decrease the volume level.
channel and the last channel selected.
program and to move the cursor backward.
temporarily stops the tape. During playback, it stops
the tape and displays a still image on the TV screen.
10
11
12
13
14
15
16
17
18
19
20
25
26
27
21
22
23
24
16. RESET Button - Used to reset the counter to
"00:00:00".
17. PROGRAM Button - Press to confirm the programmed timer recording and ON/OFF TIMER.
18. SOUND Button -
and stereo when receiving broadcasts in stereo.
19. EJECT Button - Press to eject the tape.
20. SET/TRK + / – Buttons - Used to set or adjust in the
menu mode. During playback, they are used to adjust
tracking manually.
21. PLAY Button - Press to play a prerecorded tape.
22. FORWARD Button - In the Stop mode, this button
rapidly winds the tape forward. In the Play mode, this
button activates forward search.
23. T. REC Button - Used to set the TV/VCR to start recording at a preset time.
24. CAPTION Button - Switches between Caption, Text
and TV modes for Closed-Captioned programs.
25. INPUT Button - Switches the program for
viewing between the VCR and external input sources.
26. MUTING Button - Press to turn off the sound. Press
again to turn the sound back on.
27. ENTER Button - Press to enter or select information
for on-screen operations.
28. SKIP• SEARCH Button - Press in the playback
mode to search forward in 30 second increments to a
maximum of 3 minutes.
29. SPEED Button - Sets the tape speed for recording.
30. TV/VCR Button - Used to temporarily view a TV
channel selected on the VCR while in the playback
mode.
Switches sound between mono
28
29
30
8
Page 9
POWER SOURCE
BATTERY INSTALLATION
Slide the battery compartment cover.
Install two “AAA” batteries, paying attention to the
polarity diagram in the battery compartment.
Replace the compartment cover.
BATTERY PRECAUTIONS
The precautions below should be followed when using
batteries in this device:
1. Use only the size and type of batteries specified.
2. Be sure to follow the correct polarity when installing
the batteries as indicated in the battery compartment.
Reversed batteries may cause damage to the device.
3. Do not mix different types of batteries together (e.g. Alkaline and Carbon-zinc) or old batteries with fresh ones.
4. If the device is not to be used for a long period of
time, remove the batteries to prevent damage or
injury from possible battery leakage.
5. Do not try to recharge batteries not intended to be
recharged; they can overheat and rupture (Follow
battery manufacturer’s directions).
Use the AC polarized line cord provided for operation on
AC. Insert the AC cord plug into a standard 120V 60Hz
polarized AC outlet.
NOTES:
• Never connect the AC line cord plug to anything other
than the
specified voltage (120V 60Hz). Use the attached power
cord only.
• If the polarized AC cord does not fit into a
nonpolarized AC outlet, do not attempt to file or cut
the blade. It is the user's responsibility to have an
electrician replace the obsolete outlet.
• If you cause a static discharge when touching the unit,
and the unit fails to function, simply unplug the unit
from the AC outlet, wait 10 minutes, and plug it back
in. The unit should return to
normal operation.
AC Outlet
Wider Hole
and Blade
Polarized AC Cord Plug
(One blade is wider than the other)
EFFECTIVE DISTANCE OF THE REMOTE CONTROL
15 FEET (5m)
30˚
30˚
NOTES:•When there is an obstacle between the TV/
VCR and the remote control, the remote
control may not operate.
When direct sunlight, an incandescent lamp,
•
fluorescent lamp or any other strong light
shines on the Remote sensor of the TV/
VCR, the remote operation may be unstable.
9
Page 10
ANTENNA CONNECTIONS
If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna
system. If you are using a cable TV service (CATV), see page 11 for Cable TV connections.
Combination VHF/UHF Antenna (Single 75 ohm cable or 300 ohm twin-lead wire
Connect the 75 ohm cable from the combination VHF/UHF antenna to the Antenna Jack.
If your combination VHF/UHF antenna has a 300 ohm twin-lead wire, the use of the 300-75 ohm Matching
Transformer may be necessary.
Antenna Jack
75 ohm
Coaxial
Cable
300-75 ohm Matching Transformer
Combination VHF/UHF Antenna (Separate VHF and UHF 300 ohm twin-lead wires
Connect the UHF 300 ohm twin-lead wire to the Combiner (not supplied). Connect the VHF 300 ohm twin-lead wire
to the 300-75 ohm Matching Transformer. Attach the Transformer to the Combiner, then attach the Combiner to the
Antenna Jack.
Antenna Jack
300-75 ohm Matching
Transformer
Combiner
Antenna Jack
)
)
UHF 300 ohm
VHF 300 ohm
Separate VHF/UHF Antennas (75 ohm VHF cable and 300 ohm UHF twin-lead wires
Connect the VHF 75 ohm cable and UHF 300 ohm twin-lead wire to the Combiner (not supplied). Attach the
Combiner to the Antenna Jack.
Antenna Jack
VHF 75 ohm
Combiner
UHF 300 ohm
10
)
Page 11
CABLE TV CONNECTIONS
This TV/VCR has an extended tuning range and can tune most cable channels without using a Cable TV
converter box. Some cable companies offer "premium pay channels" in which the signal is scrambled.
Descrambling these signals for normal viewing requires the use of a descrambler device which is generally
provided by the cable company.
FOR SUBSCRIBERS WITH BASIC CABLE TV SERVICE
For basic cable service not requiring a Converter/Descrambler box,
connect the CATV 75 ohm Coaxial Cable directly to the Antenna Jack
on the back of the TV/VCR.
75 ohm
Coaxial Cable
FOR SUBSCRIBERS WITH SCRAMBLED CABLE TV SERVICE
If you subscribe to a cable TV service which requires the use of a Converter/Descrambler box, connect the incoming
75 ohm Coaxial Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial Cable, connect the output jack
of the Converter/Descrambler box to the Antenna Jack on the TV/VCR. Follow the connections shown below. Set the
TV/VCR to the output channel of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/
Descrambler box to select channels.
Incoming 75 ohm
CATV cable
Converter/Descrambler
75 ohm Cable to TV/VCR
FOR SUBSCRIBERS WITH BASIC CABLE TV SERVICE AND SCRAMBLED
PREMIUM CHANNELS
If you subscribe to a cable TV service in which basic channels are unscrambled and premium channels require the
use of a Converter/Descrambler box, you may wish to use a signal splitter and an A/B Switch box (available from the
Cable company or an electronics supply store). Follow the connections shown below. With the switch in the "B"
position, you can directly tune any nonscrambled channels on your TV/VCR. With the switch in the "A" position, tune
your TV/VCR to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the Converter/
Descrambler box to tune scrambled channels.
Antenna Jack
Antenna Jack
Incoming
Converter/Descrambler
75 ohm
CATV cable
Splitter
A/B Switch
SETTING THE LANGUAGE
This TV/VCR can display the on screen language in
English, Spanish or French.
On-screen language selection (step 3) will automatically appear on the screen when you press the MENU
button initially. Select the language you prefer first,
then proceed with the other menu options.
1 Press the MENU button.
Press the SET + or – button to
select the SYSTEM SET-UP
option, then press the ENTER
button.
M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP
〈
+/–/ENTER/MENU
〉
75 ohm cable
A
to TV/VCR
B
2 Press the SET + or – button to
select the LANGUAGE option,
then press the ENTER button.
3 Press the SET + or – button to
select the desired language:
English (ENGLISH), Spanish
(ESPAÑOL) or French
(FRANCAIS), then press the
ENTER button.
4 Press the MENU button until the
MENU screen is cleared.
Antenna Jack
SYSTEM SET-UP
CLOCK SET
LANGUAGE/IDIOMA/LANGUE
AUTO CLOCK ON OFF
STANDARD TIME
DAYLIGHT SAVING TIME
〈
+/–/ENTER/MENU
LANGUAGE/IDIOMA/LANGUE
ENGLISH
ESPAÑOL
FRANCAIS
〈
+/–/ENTER/MENU
〉
〉
11
Page 12
AUTO CLOCK SETTING
The Auto Clock function will automatically set the
built-in clock (Month, Day, Year and Time) when the
TV/VCR is connected to an Antenna or Cable system
and it is turned off. As the TV/VCR searches for a
receivable station in your area and it receives a
broadcast signal for Auto Clock, the Auto Clock needs
several minutes to set itself.
AUTO CLOCK SETTING
1 Connect the Antenna or Cable system.
• If you use a cable box, turn it on.
2 Plug the AC Power cord to the AC outlet.
3 Make sure the TV/VCR is turned off.
• If you press the POWER button, the Auto Clock set is
not effective.
4 Wait at least three minutes and press the POWER
button.
5 Press the CALL button to check the clock on the screen.
6 If the clock is not set, check the Antenna condition. The
Auto Clock may not function properly if the reception
condition is not good.
AUTO CLOCK ADJUSTMENT
The Auto Clock Adjustment will be performed at 12:00 PM
everyday if you turn off the TV/VCR.
• If you use a cable box and you want Auto Clock adjust-
ment to be performed, the cable box must be left on.
• The Auto Clock Adjustment is not effective when there
is a difference of more than 5 minutes exists between
the built-in clock time and the actual time.
TO SET AUTO CLOCK TO OFF
When shipped from factory the AUTO CLOCK option is
set to ON.
But if you do not want Auto Clock set (Adjustment):
1 Turn on the TV/VCR.
2 Press the MENU button.
3 Press the SET + or – button to select the SYSTEM
SET-UP option, then press the ENTER button.
4 Press the SET + or – button to select the AUTO CLOCK
option.
5 Press the ENTER button to select OFF.
6 Press the MENU button repeatedly to return to the
normal screen.
• When the AUTO CLOCK is set to OFF , the Auto Clock
adjustment does not function.
• Set the clock manually (see page 13).
TO SET STANDARD TIME
In the rare event that you live within broadcast range of
two stations in two different time zones, the TV/VCR
may recognize the wrong station for the Auto Clock set.
To correct the situation:
1 Press the MENU button.
2 Press the SET + or – button to select the SYSTEM
SET-UP option, then press the ENTER button.
3 Press the SET + or – button to select the STANDARD
TIME option, then Press the ENTER button.
4 Press the SET + or – button to select your time zone,
then press the ENTER button.
ATLANTIC : GMT – 4 hours
(GMT: Greenwich Mean Time)
EASTERN : GMT – 5 hours
CENTRAL : GMT – 6 hours
MOUNTAIN : GMT – 7 hours
PACIFIC : GMT – 8 hours
ALASKA : GMT – 9 hours
HAWAII : GMT – 10 hours
AUTO : AUTO SET
5 Press the MENU button twice to return to the normal
screen.
NOTES: •To be able to select the standard time, the
clock must first be set by “AUTO CLOCK”
once.
• If you live in Newfoundland and the Auto
Clock does not function properly, set the
AUTO CLOCK menu option to OFF and set
the clock manually.
DAYLIGHT SAVING TIME SETTING
You can set the Daylight saving time automatically or
manually.
1 Press the MENU button. Press
the SET + or – button to sel e c t t he
SYSTEM SET-UP option, then
press the ENTER button.
2 Press the SET + or – button to
select the DAYLIGHT SAVING
TIME option, then press the
ENTER button.
3 Press the SET + or – button to
select one of the options, then
press the ENTER button. Press
the MENU button until the MENU
screen is cleared.
ON: for manual setting
(forward one hour)
OFF: for manual setting
(back one hour)
AUTO: for automatic setting
(read XDS in the signal)
When you want to set the Daylight Saving Time manually ,
on the first Sunday in April you set to “ON”, and on the last
Sunday in October you set to “OFF”.
NOTES: • When shipped from factory, the DAYLIGHT
SAVING TIME option is set to AUTO position.
• When the clock is not set, Daylight Saving
Time setting is not available.
• When there is no Daylight Saving Time in your
area, always select OFF position in step 3.
M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP
〈
+/–/ENTER/MENU
〈
+/–/ENTER/MENU
DAYLIGHT SAVING TIME
〈
+/–/ENTER/MENU
〉
SYSTEM SET-UP
CLOCK SET
LANGUAGE/IDIOMA/LANGUE
AUTO CLOCK ON OFF
STANDARD TIME
DAYLIGHT SAVING TIME
〉
ON
OFF
AUTO
〉
12
Page 13
VOLUME 32
MANUAL CLOCK SETTING
TV OPERATION
You must set the date and time manually for Timer
Recordings, ON/OFF Timer and Daylight Saving Time
if the Auto Clock process did not set them correctly.
EXAMPLE: Setting the clock to “8:30 AM”, 27th (SAT)
March, 2004.
1 Press the MENU button.
Press the
select the SYSTEM
option, then press the ENTER
button.
SET + or –
button to
SET-UP
2 Press the SET + or – button to
select the CLOCK SET option,
then press the ENTER button.
3 Press the SET + or – button to set
the month, then press the ENTER
button.
4 Set the day, year and time as in
step 3.
After setting the clock, date and time
starts functioning automatically.
M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP
〈
+/–/ENTER/MENU
〈
+/–/ENTER/MENU
CLOCK SET
〈
+/–/ENTER/ CANCEL/MENU
CLOCK SET
á
+/–/ENTER/CANCEL/MENU
〉
SYSTEM SET-UP
CLOCK SET
LANGUAGE/IDIOMA/LANGUE
AUTO CLOCK ON OFF
STANDARD TIME
DAYLIGHT SAVING TIME
〉
MONTH
3
DAY
1 (MON)
YEAR
2005
TIME
12 : 00 AM
MONTH
3
DAY
27 (SAT)
YEAR
2004
TIME
8 : 30 AM
8 : 30 AM SAT
NOTES: •After a power failure or disconnection of the
power plug, the time display will be lost. In
this case, set the present time again if the
Auto Clock did not set correctly.
•To move cursor backward, press the CANCEL
button.
1 To turn on the TV/VCR, press the POWER button.
2 Adjust the volume level by
pressing the VOL + or – button.
The volume level will be indicated
on the screen by green bars. As
the volume level increases, so do
the number of bars. If the volume
decreases, the number of green
bars also decreases.
3 Set the TV/CATV menu option to the appropriate
position (See page 15).
TV - VHF/UHF Channels
CATV - CABLE TV Channels
VHF/UHF/CATV CHANNELS
TV
VHF
2-13
UHF
14-69
〉
CATV
VHF
2-13
STD/HRC/IRC
14-36 (A) (W)
37-59 (AA) (WW)
60-85 (AAA) (ZZZ)
86-94 (86) (94)
95-99 (A-5) (A-1)
100-125 (100)(125)
01 (5A)
4 Press the Direct Channel selection buttons to select
the channel.
ñ
• TV mode direct channel selection
When the TV/CATV menu option is in the TV
position, all channels can be instantly selected by
using two buttons (for example, to select channel 2,
press "0", then "2". If you press only "2", channel
selection will be delayed for a few seconds). For
channels 10 and above, press the 2 digits in order.
• CATV mode direct channel selection
When the TV/CATV menu option is in the CATV
position, channels can be selected as follows:
• TO SELECT CATV CHANNELS:
1-9 Press "0" twice, then 1-9 as needed.
10-12 Press "0", then the remaining 2 digits.
13-99 Press the 2 digits in order.
100-125 Press the 3 digits in order.
NOTE FOR CHANNELS 1-12:
If only 1 or 2 buttons are pressed,
the corresponding channel will be
selected in 2 seconds.
Example, to select channel 2, press "002".
Example, to select channel 12, press "012".
Example, to select channel 36, press "36".
Example, to select channel 120, press "120".
CH 012
NOTES: •If a channel with no broadcast is selected,
the sound will automatically be muted.
•If a station being viewed stops broadcasting,
the TV will automatically shut itself off after
15 minutes.
13
Page 14
TV OPERATION
MUTING
Press MUTING button to switch
off the sound. The TV/VCR’s
sound will be silenced and “MUTING” will briefly appear on the
screen. The sound can be
switched back on by pressing this
button again or one of the VOL + or –
buttons.
MUTING
CHANNEL + / –
Press and release the CH + or –
button. The channel automatically
stops at the next channel set
into memory. For proper operation,
before selecting channels, they
should be set into the memory.
See pages 15 and 16 “To memorize
channels”.
CH 012
CALL
Press the CALL button. The clock, date, channel number ,
real time tape counter, tape speed and VCR operation will
be indicated.
Press CALL button again to disappear the call display.
Current time
8:47AM THU
HI-FI
Real Time Counter
HI-FI stereo
NOTE: To listen through the headphones, insert a
CH 012
Channel No.
Auto Repeat
00:04:38 SP
headphones (not supplied) with a 1/8" mini plug
into PHONES jack on the front. The sound from
the TV speaker is muted.
Tape In
Tape Speed
VCR operation
: Play
: Reverse
: Forward
: Eject
: Recording
: Pause
: Stop
SLEEP
To set the TV/VCR to turn off after a preset amount of
time, press the SLEEP button on the remote control.
The clock will count down 10 minutes for each press of
the SLEEP button (120, 110, ...10, 0). After the sleep time
is programmed, the display will appear briefly every ten
minutes to remind you that the sleep timer is operating.
To confirm the sleep timer setting,
press the SLEEP button and the
remaining time will be momentarily
displayed. T o cancel the sleep timer ,
press the SLEEP button repeatedly
until the display turns to 0.
SLEEP
120
GO BACK
This button allows you to go back
to the last channel selected by
pressing the GO BACK button.
Press this button again to return to
the last channel you were watching.
CH 012
CAPTION
Press CAPTION button to switch
between normal TV and the two
closed caption modes (captions and
screen text). Closed captioning will
display text on the screen for
hearing impaired viewers.
NOTES:
• If using an indoor antenna or if TV reception
is very poor, the Closed Caption Decoder text
may not appear. In this case, adjust the
antenna for better reception or use an outdoor
antenna.
•When activating the Closed Captioned
Decoder, there will be a short delay before
the Closed Captioned text appears on the
screen.
•Closed Captioned text is only displayed in
locations where it is available.
•If the Call display is on, the Closed Captioning
text will not appear.
WHAT IS CLOSED CAPTIONING?
This television has the capability to decode and display
Closed Captioned television programs. Closed Captioning
will display text on the screen for hearing impaired
viewers or it will translate and display text in another
language.
CLOSED CAPTIONING WITH A VCR
Closed Captioned programs can be recorded and played
back on a VCR with the Closed Captioned text intact.
The Closed Captioned text will disappear during Cue
(Fast Forward Search), Review (Rewind Search) and
Pause Modes or if the VCR tracking is not adjusted
properly.
TO VIEW CLOSED CAPTIONS
Press the CAPTION button on the remote control to
switch between normal TV and the two Closed Caption
Modes (Captions and Screen Text).
CAPTION CH 1
14
Page 15
CH SET-UP
TV CATV
AUTO CH MEMORY
ADD/DELETE
〈
+/–/ENTER/MENU
〉
M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP
〈
+/–/ENTER/MENU
〉
Captions: This Closed Caption Mode will display text on
M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP
〈
+/–/ENTER/MENU
〉
CH SET-UP
TV CATV
AUTO CH MEMORY
ADD/DELETE
〈
+/–/ENTER/MENU
〉
the screen in English or another language (depending
on the setting of the Closed Captions CH. 1 or 2).
Generally, Closed Captions in English are transmitted on
Captions Channel 1 and Closed Captions in other
languages are transmitted on Captions Channel 2.
Text: The Text Closed Caption Mode will usually fill the
screen with a programming schedule or other information.
After selecting a Closed Caption Mode, it will stay in
effect until it is changed, even if the channel is changed.
If the Captions signal is lost due to a commercial or a
break in the signal, the Captions will reappear when the
signal is received again. If the channels are changed,
the Captions will be delayed approximately 10 seconds.
The Captions will appear in places on the screen where
they will least interfere with the picture, usually on the
bottom of the screen. News programs will usually show
three-line Closed Captions which scroll onto the screen.
Most other shows provide two or three lined Captions
placed near the character who is speaking so the viewer
can follow the dialogue.
Words in italics or underlined describe titles, words in
foreign languages or words requiring emphasis. Words
that are sung usually appear enclosed by musical notes.
For television programs broadcasting with Closed Captions, look in your TV guide for the Closed Captions
symbol (CC).
• When selecting Closed Captions, the captioning will
be delayed approximately 10 seconds.
• If no caption signal is received, no captions will
appear, but the television will remain in the Caption
Mode.
• When Captions are being displayed, on-screen
displays, such as volume and mute may not be seen
or may interfere with Closed Captions.
• Misspellings or unusual characters may occasionally
appear during Closed Captioning. This is normal with
Closed Captioning, especially with live programs. This
is because during live programs, captions are also
entered live. These transmissions do not allow time for
editing.
• Some cable systems and copy protection systems
may interfere with the Closed Captioned signal.
• If using an indoor antenna or if TV reception is very
poor, the Closed Caption Decoder may not appear or
may appear with strange characters or misspelled
words. In this case, adjust the antenna for better
reception or use an outdoor antenna.
TO MEMORIZE CHANNELS
This TV/VCR is equipped with a channel memory
feature which allows channels to skip up or down to
the next channel set into memory, skipping over
unwanted channels. Before selecting channels, they
must be programmed into the TV/VCR’s memory. In
addition to normal VHF and UHF channels, this TV/
VCR can receive up to 113 Cable TV channels. To
use this TV/VCR with an antenna, set the TV/CATV
menu option to the TV mode. When shipped from the
factory, this menu option is in the CATV mode.
TV/CATV SELECTION
1 Press the MENU button.
2 Press the SET + or – button to
select the CH SET-UP mode,
then press the ENTER button.
VHF/UHF/CATV CHANNELS
TV
VHF
2-13
UHF
14-69
CATV
VHF
2-13
STD/HRC/IRC
14-36 (A) (W)
37-59 (AA) (WW)
60-85 (AAA) (ZZZ)
86-94 (86) (94)
95-99 (A-5) (A-1)
100-125 (100)(125)
01 (5A)
3 Press the SET + or – button to
select the TV/CATV mode.
4 Press the ENTER button to
select the TV or CATV mode.
The arrow indicates the selected mode.
TV - VHF/UHF channels
CATV - CABLE TV channels
5 Press the MENU button until the MENU screen is cleared.
AUTOMATIC MEMORY TUNING
1 Press the MENU button.
2 Press the SET + or – button to
select the CH SET-UP mode,
then press the ENTER button.
3 Press the SET + or – button to
select the AUTO CH MEMORY
mode, then press the ENTER
button. The TV/VCR will begin
memorizing all the channels
available in your area.
Channel numbers will remain red
until auto memorizing is complete.
4 Press the MENU button until the MENU screen is
cleared.
15
Page 16
TO MEMORIZE CHANNELS
SETTING THE V-CHIP
TO ADD/DELETE CHANNELS
1 Press the MENU button.
2 Press the SET + or – button to
select the CH SET-UP mode,
then press the ENTER button.
3 Press the SET + or – button to
select the ADD/DELETE mode,
then press the ENTER button.
4 Select the desired channel to be
memorized or deleted using SET
+ or – button, or using the
Direct Channel Selection
buttons (10 keys, 0-9), or CH +
or – button.
5 Press the ENTER button to
select the ADD or DELETE mode.
If you select an unmemorized
channel, the Channel indication
will be red. If you select the ADD mode, the Channel
indication changes from red to green and the channel
will be memorized. If you select a memorized channel,
the Channel indication will be green. If you select the
DELETE mode, the Channel indication changes from
green to red and the channel will be deleted from the
memory.
6 Press the MENU button until the MENU screen is
cleared.
M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP
〈
+/–/ENTER/MENU
CH SET-UP
TV CATV
AUTO CH MEMORY
ADD/DELETE
〈
+/–/ENTER/MENU
〈
0–9/+/–/ENTER/MENU
An age limitation can be set to forbid children to see
and hear violent scenes or pictures for adults, etc.
The unit corresponds to “TV RATING” and “MOVIE
RATING”. To use the V-Chip function, you must
register a password.
〉
TO REGISTER PASSWORD
1
Press the MENU button in the TV/VCR mode. The
TV/VCR menu screen will appear.
Press SET + or – to select “TV
2
〉
CH 003ADD
〉
SET-UP”, then press the ENTER
button.
Press SET + or – to select “V-
3
CHIP SET”, then press the
ENTER button.
Enter the password (4 digits)
4
using Direct Channel Selection
button (10key, 0-9), then press
M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP
á
+/–/ENTER/MENU
á
+/–/ENTER/MENU
V-CHIP SET
TV SET-UP
V-CHIP SET
ON/OFF TIMER
AUDIO
SAP ON OFF
NEW
PASSWORD:
ñ
ñ
the ENTER button.
If you put a wrong number,
á
0-9/ENTER/CANCEL/MENU
ñ
press the CANCEL button.
“ ” appears instead of the number.
Enter the same password again
5
for the safety, then press the
ENTER button.
V-CHIP SET
CONFIRM
PASSWORD:
Now the password is registered
and V-Chip setting menu will
appear on the display.
á
0-9/ENTER/CANCEL/MENU
ñ
16
NOTE:
If you forget the password...
•
Disconnect the AC cord plug from the AC outlet and leave
1
the unit unplugged for more than two minutes.
Insert the AC cord plug again, and turn the volume level to
2
a minumum.
Press the VOL – button on the unit and the 0 button on
3
the remote control for more than 2 second simultaneously.
Page 17
TO SET THE V-CHIP
V-CHIP SET
V-CHIP : ON
TV RATING :
TV-PG
MOVIE RATING : PG
-
13
CHANGE
PASSWORD
NEW
PASSWORD:
- - - -
á
0-9/ENTER/CANCEL/MENU
ñ
M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SE-TUP
á+
/–/ENTER/MENU
ñ
V-CHIP SET
V-CHIP : ON
TV RATING : TV
-
PG
MOVIE RATING : PG
-
13
CHANGE PASSWORD
á+
/–/ENTER/MENU
ñ
V-CHIP SET
PASSWORD:
á
0-9/ENTER/CANCEL/MENU
ñ
TV SET-UP
V-CHIP SET
ON/OFF TIMER
AUDIO
SAP ON OFF
á
+/–/ENTER/MENU
ñ
In the V-CHIP SET menu, press
1
the SET + or – button to select
“TV RATING”, then press the
ENTER button.
Press the SET + or – button to
2
display the desired setting, then
press the ENTER button.
OFF : TV RATING is not set
TV-Y : All children
TV-Y7: 7 years old and above
TV-G : General Audience
TV-PG: Parental guidance
TV-14 : 14 years old and above
TV-MA: 17 years old and above
When you select TV- Y7, TV-PG, TV-14 or TV-MA, press
the CALL button to show the contained rating. Press the
SET + or – button to select the desired item you want.
Press the ENTER button to select the setting “ON” or
“OFF”.
Press the SET + or – button to
3
select “MOVIE RATING”, then
press the ENTER button.
Press the SET + or – button to
4
select
desired rating
the ENTER button.
OFF :
G:All ages
PG : Parental guidance
PG-13 : Parental guidance
R:Under 17 years old
NC-17 : 17 years old and above
X:Adult only
Press the SET + or – button to
5
select “V-CHIP”.
MOVIE RATING is not set
less than 13 years old
Parental guidance
suggested
, then press
V-CHIP SET
V-CHIP : OFF
TV RATING : OFF
MOVIE RATING : OFF
CHANGE PASSWORD
á
+/–/ENTER/MENU
CALL TO SET CONTENTS
á
+/–
á
+/–/ENTER/MENU
á+
+/–
ñ
V-CHIP SET
V-CHIP : OFF
TV RATING : TV
MOVIE RATING : OFF
CHANGE PASSWORD
ñ
/ENTER/MENU
V-CHIP SET
V-CHIP : OFF
TV RATING : TV
MOVIE RATING : OFF
CHANGE PASSWORD
ñ
V-CHIP SET
V-CHIP : OFF
TV RATING : TV
MOVIE RATING : PG
CHANGE PASSWORD
ñ
/–/ENTER/MENU
V-CHIP SET
V-CHIP : OFF
TV RATING : TV
MOVIE RATING : PG
CHANGE PASSWORD
/ENTER/MENU
-
-
TO CHANGE PASSWORD
Press the MENU button in the TV/VCR mode. The
1
TV/VCR menu screen will appear.
Press the SET + or – button to
2
select “TV SET-UP” then press
the ENTER button.
PG
Press the SET + or – button to
3
select the “V-CHIP SET”, then
press the ENTER button.
Enter the Password using Direct
4
Channel Selection buttons (10
key, 0-9), then press the
ENTER button.
If you put a wrong number,
press the CANCEL button.
Press the SET + or – button to
5
-
PG
select “CHANGE PASSWORD”,
then press the ENTER button.
Enter the new password using
6
-
PG
Direct Channel Selection buttons
-
13
(10 key, 0-9), then press the
ENTER button.
Enter the same password again
7
to confirm, then press the
ENTER button.
PG
Press the MENU button repeat-
8
-
13
edly to return to normal screen.
V-CHIP SET
V-CHIP : ON
TV RATING :
MOVIE RATING : PG-13
CHANGE
CONFIRM
PASSWORD:
á
0-9/ENTER/CANCEL/MENU
TV-PG
PASSWORD
- - - -
ñ
Press the ENTER button to
6
display “ON”. Now your settings
are set into the memory.
Press the MENU button until the
7
V-CHIP SET
V-CHIP : ON
TV RATING : TV
MOVIE RATING : PG
CHANGE PASSWORD
+/–
MENU screen is cleared.
To use the TV after the TV is protected.
When the program applied to the V-Chip setting is
received, enter the password, then press the ENTER
button. When the password is entered correctly the
protection will be temporarily overridden.
NOTE:
The V-Chip function is activated only on programs
and tapes that have the rating signal.
/ENTER/MENU
-
PG
-
13
17
Page 18
TO SET THE ON TIMER
This feature allows you to have the TV/VCR automatically turn “ON” at a predetermined time. If you
program the “ON TIMER” once, the TV/VCR will turn
“ON” on the programmed day (daily/weekly) at the
same time to the same channel.
EXAMPLE: Turning on the TV to channel 12 at 7:00
AM, MONDAY-FRIDAY.
1 Press the MENU button.
Press the SET + or – button to
select the TV SET-UP option,
then press the ENTER button.
2 Press the SET + or – button to
select the ON/OFF TIMER
option, then press the ENTER
button.
3 Press the SET + or – button to
select the ON TIMER option,
then press the ENTER button.
4 Press the SET + or – button to
set the desired hour, then press
the ENTER button.
M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP
〈
+/–/ENTER/MENU
á
+/–/ENTER/MENU
〈
+/–/ENTER/CANCEL/MENU
〈
+/–/ENTER/CANCEL/MENU
〉
TV SET-UP
V-CHIP SET
ON/OFF TIMER
AUDIO
SAP ON OFF
ñ
ON/OFF TIMER
ON TIMER
12:00AM CH001
SUN-SAT CANCEL
OFF TIMER
12:00AM CANCEL
ON/OFF TIMER
ON TIMER
7:00AM CH001
SUN-SAT CANCEL
OFF TIMER
12:00AM CANCEL
5 Set the desired minute, channel
and daily or weekly timer date
as in step 4.
〈
+/–/ENTER/CANCEL/MENU
6 Press the SET + or – button to
select the SET mode, then press
the ENTER button. Press the
MENU button repeatedly to return
to normal screen.
NOTES: • The TV/VCR will automatically turn off approxi-
mately 1 hour later after the ON TIMER turns on
if no OFF TIMER has been set. To continue
watching the TV, press any button to cancel the
one hour automatic shut off.
• To cancel ON TIMER, follow above steps 1-5,
then press the
SET + or – button to select the
CANCEL. Press the MENU button repeatedly to
return to the normal screen.
〉
• After setting the ON TIMER, "
will flash on and off. If you wish to set the OFF
TIMER, press the ENTER button then follow the
steps 4-6 on " TO SET THE OFF TIMER" .
• If you want to correct the digits while setting,
press the CANCEL button until the item you
〉
want to correct, then press the
button to correct the desired setting.
〈
+/–/ENTER/CANCEL/MENU
" of the OFF TIMER
SET + or –
ON/OFF TIMER
ON TIMER
7:00AM CH012
MON-FRI CANCEL
OFF TIMER
12:00AM CANCEL
ON/OFF TIMER
ON TIMER
7:00AM CH012
MON-FRI SET
OFF TIMER
12:00AM CANCEL
〉
〉
TO SET THE OFF TIMER
This feature allows you to have the TV/VCR turn
“OFF” automatically at a predetermined time. If you
program the OFF TIMER once, the TV/VCR will
automatically turn off at the same time everyday.
EXAMPLE: Turning off the TV at 11:30 PM.
1 Press the MENU button.
Press the SET + or – button to
select the TV SET-UP option,
then press the ENTER button.
2 Press the SET + or – button to
select the ON/OFF TIMER
option, then press the ENTER
button.
3 Press the SET + or – button to
select the OFF TIMER option,
then press the ENTER button.
M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP
〈
+/–/ENTER/MENU
á
+/–/ENTER/MENU
〈
+/–/ENTER/CANCEL/MENU
〉
TV SET-UP
V-CHIP SET
ON/OFF TIMER
AUDIO
SAP ON OFF
ñ
ON/OFF TIMER
ON TIMER
7:00AM CH012
MON-FRI SET
OFF TIMER
12:00AM CANCEL
18
4 Press the SET + or – button to
set the desired hour, then press
the ENTER button.
5 Press the SET + or – button to
set the desired minute, then
press the ENTER button.
6 Press the SET + or – button to
select the SET mode, then
press the MENU button repeatedly to return to the normal
screen.
NOTES: • If a station being viewed
〉
stops broadcasting, the
TV will automatically shut
itself off after 15 minutes.
• To cancel OFF TIMER, follow above steps 1-5, then
press the SET + or – button
to select CANCEL. Press
the MENU button to return
to the normal screen.
• To confirm the ON/OFF TIMER:
Press the PROGRAM button twice to
indicate the programs on the screen.
ON/OFF TIMER
ON TIMER
7:00AM CH012
MON-FRI SET
OFF TIMER
11:00PM CANCEL
〈
+/–/ENTER/CANCEL/MENU
ON/OFF TIMER
ON TIMER
7:00AM CH012
MON-FRI SET
OFF TIMER
11:30PM CANCEL
〈
+/–/ENTER/CANCEL/MENU
ON/OFF TIMER
ON TIMER
7:00AM CH012
MON-FRI SET
OFF TIMER
11:30PM SET
〈
+/–/ENTER/CANCEL/MENU
〉
〉
〉
Page 19
SHARPNESS 0
〈
+/–/ENTER/CANCEL/MENU
〉
COLOR 0
〈
+/–/ENTER/CANCEL/MENU
〉
TINT 0
〈
+/–/ENTER/CANCEL/MENU
〉
PICTURE CONTROL ADJUSTMENTS
Picture controls are factory preset but you can
adjust them individually as follows:
1 To display the picture adjust-
ment screen, press the MENU
button. Press the SET + or –
button to select the TV SET-UP
option, then press the ENTER
M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP
〈
+/–/ENTER/MENU
〉
button.
2 Press the SET + or – button to
select the PICTURE option, then
press the ENTER button.
TV SET-UP
V-CHIP SET
ON/OFF TIMER
AUDIO
SAP ON OFF
á
+/–/ENTER/MENU
ñ
BRIGHTNESS
Press the ENTER button until
“BRIGHTNESS” appears on the
screen, then press the SET + or –
button to adjust the brightness of the
BRIGHTNESS 0
〈
+/–/ENTER/CANCEL/MENU
picture. When the SET + button is
pressed, the darker portions of the picture become lighter.
CONTRAST
Press the ENTER button until
“CONTRAST” appears on the
screen, then press the SET + or –
button to adjust the contrast of the
picture. Pictures look sharpest in the
daytime (bright light) by increasing the contrast. At night
(dim light), the sharpest picture is obtained by reducing
the contrast.
NOTE:The CONTRAST default setting is set to maxi-
mum at the factory.
CONTRAST 32
〈
+/–/ENTER/CANCEL/MENU
COLOR
Press the ENTER button until
“COLOR” appears on the screen,
then press the SET + or – button to
adjust the color intensity of the
picture. The control should be set
when colors appear normal in
intensity and brilliance.
TINT
Press the ENTER button until
“TINT” appears on the screen, then
press the SET + or – button to
adjust the tint of the picture. This
determines how accurately the
colors are reproduced by the TV.
Adjusting the tint for natural facial tone is the best method
of obtaining accurate color reproduction of the entire picture.
〉
SHARPNESS
Press the ENTER button until
“SHARPNESS” appears on the
screen, then press the SET + or –
button to adjust the sharpness of
the picture.
CANCEL
〉
Pressing the CANCEL button while making picture
adjustments will return all adjustments to the factory
preset levels.
NOTE:The On-screen display will disappear 6 seconds
after finishing an adjustment or by pressing the
MENU button three times. The settings can only
be adjusted when they are displayed on the TV
screen.
SOUND CONTROL ADJUSTMENTS
Sound controls are factory preset but you can
adjust them individually as follows:
1 To display the audio adjustment
screen, press the MENU button.
Press the SET + or – button to
select the TV SET-UP option,
then press the ENTER button.
2 Press the SET + or – button to
select the AUDIO optio n, t h e n
press the ENTER button.
M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP
〈
+/–/ENTER/MENU
TV SET-UP
V-CHIP SET
ON/OFF TIMER
AUDIO
SAP ON OFF
á
+/–/ENTER/MENU
3 Press the ENTER button to
select the item you want
to adjust. Press the SET + or –
button to adjust the setting.
BASS 0
〈
+/–/ENTER/CANCEL/MENU
〉
ñ
BASS:
Press the SET + or – button to adjust the bass sound.
TREBLE:
Press the SET + or – button to adjust the treble sound.
BALANCE:
Press the SET + or – button to obtain an equal sound
level from both speakers.
CANCEL
Pressing the CANCEL button while making audio
adjustments will return all adjustments to the factory
preset levels.
NOTE: The On-screen display will disappear 6 seconds
〉
after finishing an adjustment or by pressing the
MENU button three times. The settings can only
be adjusted when they are displayed on the TV
screen.
19
Page 20
LOADING AND UNLOADING
PLAYBACK
Use only video cassette tapes marked
.
LOADING
Push the center of the tape until it is automatically
retracted into the TV/VCR.
AUTOMATIC POWER ON AND PLAY
When loading a cassette tape without the erase prevention tab intact, the TV/VCR will turn on automatically
and playback will start immediately.
Insert the cassette with its labeled side facing you.
An inverted video cassette cannot be inserted.
UNLOADING
To unload a video cassette, press the
5 EJECT button on the remote
control, or press the 3/5 (STOP/
EJECT) button on the TV/VCR twice.
The first press will stop the tape in
any mode. The second press will
eject the tape.
AUTOMATIC EJECT
If the TV/VCR automatically rewinds the tape to the
beginning (AUTO REWIND FEA TURE), the tape will
be ejected automatically (See NOTE on page 21).
NOTES: • Always eject the tape when not in use.
• The cassette tape can be ejected even if the
POWER is “OFF”.
TO PREVENT ACCIDENTAL ERASURE
After recording, break off the erase prevention tab if
you do not wish to record over the tape.
Screwdriver
Erase prevention tab
TO RECORD AGAIN
Cover the hole with adhesive tape.
Be careful the tape does not extend past the edges of
the video cassette housing.
Adhesive tape
20
To play a prerecorded tape.
TO START PLAYBACK
Load a prerecorded tape (When
loading a cassette tape without the
erase prevention tab, playback will
start automatically).
Press the PLAY button to begin
playback.
“
” will appear on the screen.
NOTE: This TV/VCR selects the playback tape speed
SP, LP or SLP automatically.
TO STOP PLAYBACK
Press the STOP button once.
The tape will stop, but remain fully
loaded and ready to play.
“
” will appear on the screen.
TO REWIND OR FORWARD THE
TAPE RAPIDLY
Press the REVERSE or FORWARD button in the Stop
mode.
“
” or “ ” will appear on the screen.
FORWARD/REVERSE PICTURE SEARCH
If you want to see the tape during REVERSE or
FORWARD mode, press and hold the REVERSE or
FORWARD button. The backward or forward visual
search picture will be seen on the screen. Release to
return to the REVERSE or FORWARD mode.
DIGITAL TRACKING CONTROLS
When a tape is played, the Digital
Auto Tracking system automatically
adjusts the tracking to obtain the
best possible picture. If noise bars
appear during playback, adjust the
tracking manually as follows:
• Press the TRK + or – button to
obtain the best possible picture.
“MANUAL TR.” will appear for 4
seconds on the screen.
To resume automatic tracking,
press the AUTO TRACK button.
“AUTO TR.” will appear for 4 seconds on the screen.
MANUAL TR.
–
AUTO TR
.
+
TO MONITOR A TV PROGRAM
Press the TV/VCR button while in the playback mode.The
video tape will continue to play while the picture switches to
the TV channel selected on the TV/VCR. Press the button
to return to the playback picture.
Page 21
00:00:00 SP
CH 012
SPECIAL PLAYBACK
RECORDING A TV PROGRAM
TO VISUALLY SEARCH FOR DESIRED
POINTS
When either the FORWARD or REVERSE button is
pressed in the PLAYBACK mode, the speed search
picture will appear. When pressed twice, the search
picture will increase speed. Speed search time depends
upon the speed used (SP, LP or SLP) during recording.
See chart below.
To visually search backward or forward, press the
REVERSE or FORWARD button once or twice in the
PLAYBACK mode.
Press the PLAY button to resume normal viewing speed.
SPEED SEARCH TIMES
TAPE SPEED
SP (Standard Play)
LP (Long Play)
SLP (Super Long Play)
PICTURE SEARCH SPEED
PRESS ONCE
PRESS ONCE
3 X
7 X
9 X
PRESS TWICE
PRESS TWICE
5 X
9 X
15 X
SKIP SEARCH
Press the SKIP• SEARCH button in the PLAY mode. The
VCR will search forward through approximately 30
seconds of the tape (e.g. unwanted commercial time) for
each press of the SKIP• SEARCH button (maximum six
presses) and then resume normal playback.
TO WATCH STILL PICTURE
Press the PAUSE button in the PLAYBACK mode.
Press the PLAY button or PAUSE button to resume
normal playback.
NOTES: • The audio output is muted during Speed
Search and Still.
• A few noise bars will appear on the TV screen
during Speed Search and Still.
• To prevent damage to the tape, Still and Speed
Search mode is automatically changed to the
Playback mode after 5 minutes.
SLOW MOTION
During playback press the SLOW button.
To return to playback : Press the PLAY button.
TO WATCH A TAPE REPEATEDLY
1 Press the MENU button.
2 Press the SET + or – button to
select the AUTO REPEA T option.
3 Press the ENTER button to select
the ON position.
4 Press the MENU button. If you press the PLAY button,
the tape will play over and over until the repeat mode is
canceled.
M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP
〈
+/–/ENTER/MENU
〉
RECORDING AND VIEWING THE
SAME TV PROGRAM
1 Load a cassette tape with the erase prevention tab
intact.
2 Press the SPEED button to
select the desired tape speed
SP or SLP. The counter and SP
or SLP will appear on the screen
about 4 seconds.
3 Set the TV/CATV option to the appropriate position
(See page 15).
TV - VHF/UHF channels
CATV - CABLE TV channels
NOTES: • If power is switched off during recording,
the TV set goes off and the VCR continues
to record. Press the STOP button to halt
the recording and turn off the VCR.
• The TV/VCR Channel cannot be changed
during recording.
4 Press the Direct Channel Selection buttons or CH +
or – button to select the channel to be recorded.
5 Press the REC/OTR button.
" ● " and the channel number will
appear on the screen and the
REC/OTR indicator will light.
TO STOP RECORDING
Press the STOP button to stop recording.
“ ■ ” will appear on the screen.
TO STOP RECORDING TEMPORARILY
Press the PAUSE button to avoid recording unwanted
material.
“
” will appear on the screen and the REC/OTR
indicator will blink on and off. Press the PAUSE button
or the REC/OTR button to continue the recording.
NOTE: The PAUSE mode will be changed to STOP mode
after five minutes to prevent damage to the tape.
NOTES: • AUTO REWIND FEATURE
This TV/VCR will automatically rewind the video
cassette when the tape has ended (except
during OTR and Timer Record). It will also eject
the video cassette.
• If the erase prevention tab is removed, the tape
will eject when the REC/OTR button is pressed
for recording.
NOTE: To cancel repeat mode, follow above steps 1 and
2, then press the ENTER button to select the OFF
position. Press the MENU button to return to the
TV. The repeat function is canceled automatically
when the unit is switched off or the tape is ejected.
21
Page 22
ONE-TOUCH TIMER
〈
+/–/ENTER/CANCEL/MENU
〉
----- --:-- --- -
----- --
:
--
--
:
--
--
:
--
--
:
--
--
:
--
--
:
--
--
:
--
23 TH
007
--:--
--
:
--
--
:
--
--
:
--
--
:
--
--
:
--
--- -
----- --- -
----- --- -
----- --- -
----- --- -
----- --- -
7:00PM9:30
PM
SLP
Press
once
twice
3 times
4 times
5 times
6 times
7 times
8 times
9 times
)
Recording time
NORMAL REC
NORMAL REC
RECORDING (OTR
The One-Touch Timer Recording feature provides a
simple and convenient way to make a timed recording.
EXAMPLE: One-touch Timer Recording for 30 minutes.
1 Press the POWER button to turn on the TV/VCR.
2 Load a video cassette with the erase prevention tab
intact.
3 Press the SPEED button to
select the desired tape speed
(SP or SLP). SP or SLP will
appear on the screen.
4 Set the TV/CATV option to the
appropriate setting (See page 15).
TV - VHF/UHF channels
CATV - CABLE TV channels
5 Press the Direct Channel Selection buttons or CH +
or – button to select the channel to be recorded.
6 Press the REC/OTR button to
begin recording. Press the button
again to stop recording after 30
minutes. Each additional press of
the REC/OTR button will increase
recording time as shown below,
up to a maximum of 5 hours.
“OTR” will appear on the screen.
NOTES: • Press the REC/OTR
button to increase the
time needed for recording
(See the chart right).
• To cancel OTR, press
the STOP button.
• The TV/VCR channel
cannot be changed
during recording.
TIMER RECORDING
Timer recording can be programmed on-screen with
the remote control. The built-in timer allows automatic
unattended recording of up to 8 programs within 1
month.
EXAMPLE: Program a timer recording for 23rd day , channel
007 (CATV), 7:00 - 9:30 PM (Tape speed : SLP).
• Load a video cassette with the erase prevention tab
intact. The TV/VCR will automatically turn on.
• Set the TV/CATV selection to the appropriate position
(See page 15).
1 Press the MENU button.
2 Check the TIMER REC SET
option is selected, then press
the ENTER button.
22
M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP
〈
+/–/ENTER/MENU
00:00:00 SP
OTR 0 : 30
CH 012
0:30
1:00
1:30
2:00
3:00
4:00
5:00
〉
TIMER RECORDING
3 Press the SET + or – button to
select the PROGRAM position,
then press the ENTER button.
4 Press the SET + or – button to
select the date, then press the
ENTER button.
5 Set the start time, end time,
channel and tape speed as in step 4.
TIMER REC SET
DATE
23 (THU)
START
7 : 00 PM
END
9 : 30 PM
CH
007
SPEED
SLP
〈
+/–/ENTER/CANCEL/MENU
〉
6 To set the timer for another program, press the SET +
or – button until the number of the second program
blinks, then press the ENTER button. Repeat steps 4
to 5 to set the second program.
7 Press the T. REC button. The T.REC indicator will light.
The Timer is programed, when the programed time is
reached, the recording is automatically started.
To cancel timer recording, press the button again and
T.REC indicator will go out.
NOTES: • If programming is performed without a tape in
the TV/VCR, or with a tape without an erase
prevention tab, the Timer Recording is not
possible. If a tape without an erase prevention
tab is in the TV/VCR, the tape will be ejected.
• To record from the external equipment press
the
SET + or – button repeatedly until "L1
(from AUDIO/VIDEO LINE 1 jacks on the rear)"
or "L2 (from AUDIO/VIDEO IN jacks on the
front)" appears when setting the channel in
step 5.
• The VCR section cannot be used while the
T.REC indicator is lit. If you want to use the
VCR operation, press the T. REC button to
deactivate the timer.
• After a power failure or disconnection of the
power plug, all programmed recording setting
and time display will be lost upon resumption of
power. In this case, reset the clock (see pages
12-13) and reprogram any timer recordings.
• If you want to correct the digits while setting,
press the CANCEL button until the item you
want to correct, then press the
to correct the desired setting.
:
-- --- ---:--
----- --
----- --:-- --- -
----- --
----- --- -
----- --- -
----- --- -
----- --- -
----- --- -
〈
+/–/ENTER/CANCEL/MENU
TIMER REC SET
〈
+/–/ENTER/CANCEL/MENU
--
--
--
--
--
DATE
START
END
CH
SPEED
:
--
:
--
:
--
:
--
:
--
:
--
:
--
--
--- -
:
--
--
--
:
--
--
:
--
--
:
--
--
:
--
--
:
--
23 (THU)
8 : 30 AM
-- : -012
SP
SET + or – button
〉
〉
Page 23
TO SET DAILY/WEEKLY TIMER
When setting the date in the step 4 on page 22, press the
SET – button repeatedly when the current day is displayed.
The setting changes as follows:
Example
The current day (Friday) SUN-SAT (Sunday to Saturday)
One month later
minus one day MON-FRI (Monday to Friday)
WKL-WED WKL-THU (Weekly Thursday)
(Weekly Wednesday)
MON-SAT (Monday to Saturday)
TO CONFIRM THE SETTINGS
Press the PROGRAM button once. The TV screen
displays the timer program list. Press the PROGRAM
button again. The TV screen displays the ON/OFF TIMER
setting.
(once)
007
--
--:--
--
--
--
--
--
SLP
PM
:
--
--- -
:
--
:
--
:
--
:
--
:
--
〉
23 TH
7:00PM9:30
----- --:-- --- -
----- --
:
--
----- --- -
--
:
--
----- --- -
--
:
--
----- --- -
--
:
--
----- --- -
--
:
--
----- --- -
--
:
--
〈
+/–/ENTER/CANCEL/MENU
(twice)
ON/OFF TIMER
ON TIMER
7:00AM CH012
MON-FRI SET
OFF TIMER
11:30PM SET
〈
+/–/ENTER/CANCEL/MENU
〉
Press the PROGRAM button 3 times. The screen returns
to the normal screen.
TO CANCEL A PROGRAM
Press the SET + or – button to
select the TIMER REC SET option
in the MENU, then press the
ENTER button.
Press the SET + or – button to
select the unnecessary program,
and press the CANCEL button to
cancel the program.
:
-- --- ---:--
----- --
----- --:-- --- -
----- --
----- --- -
----- --- -
----- --- -
----- --- -
----- --- -
〈
+/–/ENTER/CANCEL/MENU
:
--
--
--- -
:
--
:
--
--
--
--
:
--
:
--
--
--
:
--
:
--
--
--
:
--
:
--
--
--
:
--
:
--
--
--
:
--
:
--
IF THE PROGRAM OVERLAPS ANOTHER
NOTE: Do not overlap programs as portions of the
conflicting programs will be lost. The first
recording time has priority over the next recording
time as shown in the diagram.
Program 1
Program 2
Program 3
Recording
Control Settings
8 : 00
Prog.1
9 : 00
Deleted Parts
Non Recorded Portion Parts
Prog.2 Prog.3
10 : 00
11 : 00
USING THE REAL TIME
TAPE COUNTER
The On-Screen Real Time Tape Counter shows the tape
running time in Hours, Minutes and Seconds.
You can easily determine how long the tape has been
running or how much time is left on the tape.
TO VIEW THE COUNTER DISPLAY
1 Press the CALL button.
2 Press the RESET button to set
the counter to “00:00:00”.
3 Begin Playback or Recording to
start the tape, the counter will
display the elapsed time.
4 When you wish to make the
counter disappear, press the
CALL button once again.
NOTES: • If you rewind the tape from “00:00:00”, a minus
sign (“–”) will be displayed in front of the time.
• When you load a tape, the counter will reset to
“00:00:00”.
• The counter does not function on nonrecorded
(blank) sections of the tape. When you rewind,
fast forward or play tapes through blank
sections, the counter stops.
〉
8:40AM THU
9:00AM THU
CH 012
00:30:50
SP
CH 012
00:00:00 SP
NOTES: • The everyday/every week recording can be
made continuously until the recording is
canceled or the tape reaches the end.
• During timer recording, the automatic
rewinding mechanism does not function.
• You can correct or cancel the programmed
setting in program confirm mode.
23
Page 24
STEREO RECORDING
SAP
STEREO
AND PLAYBACK
RECORDING STEREO BROADCASTS
The VHS Hi-Fi audio system permits high fidelity
recording of MTS STEREO TV broadcasts.
When an MTS STEREO
broadcast is received, the
STEREO will appear on the
screen and the program can
be viewed or recorded in
stereo. The Hi-Fi STEREO
recording procedure is the
same as for normal recordings.
NOTE: When using a CATV system, stereo TV programs
may be transmitted over a mono cable channel.
In this case the word “STEREO” will not appear
and the sound will be in mono.
SECOND AUDIO
PROGRAM (SAP
Your TV/VCR is fitted with an SAP broadcast system
which enables you to switch to a SECOND AUDIO
PROGRAM when viewing a selected channel.
This function applies only when the program is
broadcast in multi-languages through the SAP
broadcast system.
CHECK BEFORE YOU BEGIN
• Turn ON the TV and set to the video channel 3 or 4.
• Turn ON the VCR POWER button.
• Press the TV/VCR selector button to select the VCR
mode.
When a TV is connected with an audio/video cable, turn
the TV on and select the video input mode on the TV.
1 To display the picture adjust-
ment screen, press the MENU
button. Press the SET + or –
button to select the TV SETUP option, then press the
ENTER button.
)
M E N U
TIMER REC SET
TV SET-UP
CH SET-UP
AUTO REPEAT ON OFF
SYSTEM SET-UP
〈
+/–/ENTER/MENU
〉
OUTPUT SELECTION
When viewing an MTS STEREO TV program, or playing
a prerecorded VHS Hi-Fi STEREO videotape, press the
SOUND button to allow the audio to be heard through
both speakers. Normally set to the Hi-Fi STEREO
position, this button can be set to the MONO position if
the stereo broadcast or videotape audio is of poor
quality. The “R” and “L” positions allow the audio from
the Right or Left Hi-Fi channel to be heard over both TV
speakers. This button has no effect when viewing a
MONO videotape or TV program. Each time you press
the button, the OUTPUT SELECTION display appears
on the screen for several seconds. Refer to the chart
below.
OUTPUT
SELECTION
STEREO
L CH
R CH
MONO
NOTES: • When playing back a tape that is not recorded
in Hi-Fi stereo mode, the audio will automatically be monaural.
• When listening to a VHS Hi-Fi video tape or
MTS broadcast through the VHF/UHF jack,
the sound will be monaural.
SOUND HEARD ON BOTH
SPEAKERS
STEREO
LEFT CHANNEL AUDIO
RIGHT CHANNEL AUDIO
MONO
2 Press the MENU button.
Press the SET + or – button to
select the SAP option.
3 Press the ENTER button to
select the ON position.
TV SETUP
V-CHIP SET
ON/OFF TIMER
AUDIO
SAP ON OFF
á
+/–/ENTER/MENU
TV SET-UP
V-CHIP SET
ON/OFF TIMER
AUDIO
SAP ON OFF
á
+/–/ENTER/MENU
ñ
ñ
4 Press the MENU button again.
LISTENING TO SAP
When the TV/VCR is turned on or a channel selection is
made, make certain “SAP” appears on the screen. This
means that the “Second Audio Program” broadcasting is
available.
STEREO SAP
OR
24
Page 25
DUPLICATING A VIDEO TAPE
If you connect the TV/VCR to another VCR or
Camcorder, you can duplicate a previously recorded
tape. Make all connections before turning on the power.
1 Insert a blank cassette with the erase prevention tab
intact into the TV/VCR.
Insert a previously recorded cassette into the play
back VCR or Camcorder.
2 Press the INPUT button
twice to select AUDIO/VIDEO
input position. The “LINE 2” will
appear on the screen.
NOTE: You can also use the rear AUDIO/VIDEO LINE1
Jacks. Select “LINE 1” by pressing the INPUT
button.
LINE 2
3 Press the REC/OTR button on the remote control of
the TV/VCR, then press the PAUSE button.
4 Press the PLAY button on the playback VCR, then
press the PAUSE/STILL button.
5 Release the recording pause and the playback still
simultaneously to begin the duplicating process.
NOTES: • It is recommended that the tape speed be set
to the SP mode on the TV/VCR for best result.
• Unauthorized recording of copyrighted
television programs, films, video cassettes
and other materials may infringe the rights of
copyright owners and be contrary to copy
right laws.
CONNECTION TO ANOTHER VCR
Recording TV/VCR
Playback VCR
OUT
To AUDIO
OUT
Audio/Video Cord (not supplied)
To Video In
To Audio In
To VIDEO
CONNECTION TO CAMCORDER
For duplicating a previously recorded tape from a
camcorder, follow the camcorder manufacturer’s instructions. A typical camcorder dubbing hookup is shown
below.
Recording TV/VCR
Playback
Camcorder
To AV Jack
To Video/Audio In
Audio/Video Cord (not supplied)
25
Page 26
TROUBLESHOOTING GUIDE
Check the following chart before requesting service.
SYMPTOM CAUSE POSSIBLE SOLUTION PAGE
POWER
No power.
Although the power is on,
the TV/VCR does not
operate.
TV BROADCAST RECEPTION
Poor or no picture.
Poor or no color.
Picture wobbles or drifts.
No CATV reception.
No reception above
channel 13.
Poor or no sound.
The AC power cord is not connected.
Cassette is not inserted.
T. REC button is depressed.
TV station experiencing problems.
Picture control is not adjusted.
Possible local interference.
Antenna (CATV) connector is not
connected or possible local interference.
TV station experiencing problems.
Picture control is not adjusted.
Possible local interference.
Antenna (CATV) connector is not
connected or possible local
interference.
TV station experiencing problems.
Antenna (CATV) connector is not
connected or possible local
interference.
Cable TV channel is scrambled.
CATV connector is not connected.
TV/CATV Mode menu option is set to
the TV mode.
Cable TV service interrupted.
TV/CATV Mode menu option is not
set to the appropriate mode.
UHF antenna is not connected.
TV station experiencing problems.
Antenna (CATV) connector is not
connected or possible local
interference.
Possible local interference.
MUTING button is depressed.
Connect the AC power cord to the
AC outlet.
Insert a video cassette.
Press the T.REC button.
Try another channel.
Check picture control adjustments.
Check for source of reception
disturbance.
Check CATV connection or VHF/
UHF antenna, reposition or rotate
antenna.
Try another channel.
Check picture control adjustments.
Check for source of reception
disturbance.
Check CATV connection or VHF/
UHF antenna, reposition or rotate
antenna.
Try another channel.
Check CATV connection or VHF/
UHF antenna, reposition or rotate
antenna.
Try another channel.
Check all CATV connections.
Set the TV/CATV Menu option to
the CATV mode.
Contact your Cable TV company.
Make sure TV/CATV menu option is
in the appropriate mode.
Check UHF antenna.
Try another channel.
Check CATV connection or VHF/
UHF antenna, reposition or rotate
antenna.
Check for source of reception
disturbance.
Check that MUTING button has not
been pressed.
9
20
22
13
19
28
10,11
13
19
28
10,11
13
10,11
13
11
15
11
15
10
13
10, 11
28
14
26
Page 27
SYMPTOM CAUSE POSSIBLE SOLUTION PAGE
TV shuts off.
Closed caption is not
activated.
RECORDING
TV recording does not work.
Timer recording does not
work.
PLAYBACK
Noise bars appear on the
screen.
REMOTE CONTROL
Remote control does not
operate.
TV station stopped broadcasting.
Sleep timer is set.
TV station experiencing problems or
program tuned is not closed caption.
TV signal is weak.
The CAPTION button is not depressed.
The video cassette's erase prevention
tab is broken off.
The time is not set correctly.
The recording start/end time is not
set correctly.
The T. REC button has not been
pressed (The T .Rec indicator is not lit).
Tape is old or worn.
Tracking adjustment is beyond range
of automatic tracking circuit.
Video heads are dirty.
The remote control is not aimed at
the sensor.
Distance is too far or too much light
in the room.
There is an obstacle in the path of
the beam.
The batteries are weak.
The batteries are not inserted
correctly.
Tune new channel.
Set Sleep Timer to "0".
Try another channel.
Check CATV connection of VHF/
UHF antenna, reposition or rotate
antenna.
Press the CAPTION button to turn
on the closed caption.
Place a piece of vinyl tape over the
hole.
Reset the present time.
Reset the start/end time.
Press the T.REC button (The T.Rec
indicator is lit).
Replace the tape.
Adjust tracking manually using the
TRK + or – buttons on the remote
control.
Clean the video heads.
Aim the remote control at the
remote sensor.
Operate within 15 feet or reduce
the light of the room.
Clear the path of the beam.
Replace the batteries.
Insert correctly.
13
14
13
10,11
14
20
13
22
22
—
20
28
9
9
9
9
9
27
Page 28
RECEPTION DISTURBANCES
Most types of television interference can be remedied
by adjusting the height and position of the VHF/UHF
antenna. Outdoor antennas are recommended for
best results. The most common types of television
interference are shown below. If one of these symptoms
appear when the TV/VCR is connected to a Cable TV
system, the disturbance may be caused by the local
Cable TV company broadcast.
IGNITION
Black spots or horizontal streaks
may appear, the picture may
flutter or drift. Usually caused by
interference from automobile
ignition systems, neon lamps or
AC powered tools and
appliances such as drills or hair
dryers.
GHOSTS
Ghosts are caused by the
television signal following two
paths. One is the direct path and
the other is reflected by tall
buildings, hills or other large
objects. Changing the direction
or position of the antenna may
improve the reception.
CARE AND MAINTENANCE
To prevent fire or shock hazard, disconnect the TV/VCR
from the AC power sources before cleaning.
The finish on the cabinet may be cleaned with mild soap
and a soft, damp cloth and cared for as other furniture.
Use caution when cleaning or wiping the plastic parts.
VIDEO HEAD CLEANING
VIDEO HEAD CLOGGING
The video heads are the means by which the TV/VCR
reads the picture from the tape during playback. In the
unlikely event that the heads become dirty enough to be
clogged, no picture will be played back. This can easily
be determined if, during playback of a known good tape,
there is good sound, but no picture (picture is extremely
snowy). If this is the case, use a high quality head
cleaning system or have them cleaned professionally.
SNOW
If the TV/VCR is located far from
the TV station, in a fringe
reception area where the signal
is weak, small dots may appear
in the picture. If the signal is
extremely weak, the installation
of a larger external antenna may
be necessary.
RADIO FREQUENCY INTERFERENCE
(RFI)
Caused by two-way radios, this
type of interference produces
moving ripples or diagonal
streaks in the picture. Some
cases may cause a loss of
contrast in the picture. Changing
the direction and position of the
antenna or installing an RFI filter
may improve the picture.
PICTURE SIZE VARIATION
A slight picture size variation is
normal when you adjust the
CONTRAST or BRIGHTNESS
settings.
28
Good Picture Snowy Picture
VIDEO HEAD CLEANING
Video head cleaning is needed when the playback
picture becomes unclear. This signifies that the heads
are getting dirty and can occur when playing poor quality
or damaged tapes. If the heads require cleaning, use a
equivalent high quality chemical non-abrasive (wet)
head cleaning tape or have them cleaned professionally.
If playing a head cleaning tape in the VCR once does
not improve the picture, play it several times before
requesting service.
DO NOT ATTEMPT TO CLEAN THE VIDEO HEADS OR
SERVICE THE UNIT BY REMOVING THE T OP COVER.
NOTES: • Video heads may eventually wear out and
should be replaced when they fail to produce
clear pictures.
• To help prevent video head clogging, use
only good quality VHS tapes. Discard worn
out tapes.
Page 29
SPECIFICATIONS
TELEVISION
Picture Tube: 19" (measured diagonally)
Tuner T ype: Quartz PLL Frequency Synthesized
Receiving Channels: VHF 2-13
Antenna Input: VHF/UHF In 75 ohms coaxial
Speaker: 3", 8 ohms x 2
Audio Output Power: 1.5W + 1.5W
VCR
Video System: VHS, 4 Rotary Heads Helical Scanning System
Video Signal: NTSC Color
Cassette T ape: VHS
Audio Track: Hi-Fi Sound - 2 Tracks
Tape Speed: SP: 33.35 mm/sec.
F.FWD/REW Time at 25˚C (77˚F):
Speed Search: SP 3 & 5 x Normal Speed
Hi-Fi Frequency Response:
Hi-Fi Dynamic Range: More than 90dB
UHF 14-69
CATV 14-36 (A)-(W)
37-59 (AA)-(WW)
60-85 (AAA)-(ZZZ)
86-94 (86)-(94)
95-99 (A-5)-(A-1)
100-125 (100)-(125)
01 (5A)
MONO Sound - 1 Track
LP: 16.67 mm/sec.
SLP: 11.12 mm/sec.
F.FWD: Approx. 4 minutes 50 seconds
REW: Approx. 2 minutes 30 seconds
(T-120 Cassette)
LP 7 & 9 x Normal Speed
SLP 9 & 15 x Normal Speed
20Hz to 20,000Hz
GENERAL
Power Source: AC 120V 60Hz
Power Consumption: 86 Watts (AC 120V)
Dimensions: W 19-1/4" x D 18-3/16" x H 19-1/16"
Weight: 41.9 Ibs
Inputs: Video: In (RCA) 1Vp-p/75 ohm
Storage T emperature: –20¡C to 60¡C (–4¡F to 140¡F)
Operating T emperature: 5¡C to 40¡C (41¡F to 104¡F)
Accessories:
Specifications are subject to change without notice.
Audio: In (RCA) –8dBm/50K ohm
Remote Control
Batteries (AAA) x 2
29
Page 30
Limited Warranty
What your warranty covers:
• Defects in material or workmanship.
For how long after your purchase:
• 90 days from date of purchase for labor charges.
• One year from date of purchase for parts.
•Two years from date of purchase for picture tube.
The warranty period for rental units begins with the first rental or 45 days from date
of shipment to the rental firm whichever comes first.
What we will do:
• Pay any Authorized RCA VCR Service Center the labor charges to repair your TV/
VCR.
• Pay any Authorized RCA VCR Service Center for the new or, at our option, rebuilt
replacement parts and picture tube required to repair your TV/VCR.
How you get service:
•For screen sizes of 26” and smaller: Take your RCA TV/VCR to any Authorized RCA
VCR Service Center and pickup when repairs are complete.
•For screen sizes larger than 26”: Request home or pick up, repair and return
service from any Authorized RCA VCR Service Center, provided that your TV/VCR is
located within the geographic territory covered by an Authorized RCA VCR Service
Center. If not, you must take your TV/VCR to the Service Center location at your
own expense, or pay for the cost the Service Center may charge to transport your
unit to and from your home.
•To identify your nearest Authorized RCA Service Center, ask your dealer, visit
www.rca.com, look in the Yellow Pages, or call 1-800-336-1900.
•Proof of purchase in the form of a bill of sale or receipted invoice which is
evidence that the product is within the warranty period must be presented to
obtain warranty service. For rental firms, proof of first rental is also required.
What your warranty does not cover:
• Customer instruction. (Your Owner’s Manual describes how to install, adjust, and
operate your television. Any additional information should be obtained from your
dealer.)
•Installation and related adjustments.
• Signal reception problems not caused by your TV/VCR.
• Damage from misuse or neglect.
•Cleaning of audio/video heads.
• Batteries.
•A TV/VCR that has been modified or incorporated into other products or is used
for institutional or other commercial purposes.
•Images burnt onto the screen.
•Acts of nature, such as but not limited to lightning damage.
•A TV/VCR purchased or serviced outside the U.S.A.
30
Page 31
Product Registration:
•Please complete and mail the Product Registration Card packed with your set or
register on-line at www.rca.com/product registration. It will make it easier to
contact you should it ever be necessary. The return of the card is not required for
warranty coverage.
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS
PRODUCT. ALL OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL
IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE) ARE HEREBY DISCLAIMED. NO VERBAL OR WRITTEN INFORMATION
GIVEN BY THOMSON INC., ITS AGENTS OR EMPLOYEES SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER. THOMSON INC. SHALL NOT BE LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS
PRODUCT OR ARISING OUT OF ANY BREACH OF ANY EXPRESS OR IMPLIED
WARRANTY ON THIS PRODUCT. THIS DISCLAIMER OF WARRANTIES AND LIMITED
WARRANTY ARE GOVERNED BY THE LAWS OF THE STATE OF INDIANA. EXCEPT TO
THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS
LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.
How state law relates to this warranty:
•Some states do not allow the exclusion nor limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the above
limitations or exclusions may not apply to you.
• This warranty gives you specific legal rights, and you also may have other rights
that vary from state to state.
If you purchased your product outside the United States:
• This warranty does not apply. Contact your dealer for warranty information.
Service calls which do not involve defective materials or workmanship are
not covered by this warranty. Costs of such service calls are the sole responsibility of the purchaser.
31
Page 32
This Class B digital apparatus complies with Canadian ICES-003
Visit the RCA web site at www.rca.com
Please do not send any products to the Indianapolis address listed in this
manual or on the carton. This will only add delays in service for your product.
Thomson Inc.
10330 North Meridian Street
Indianapolis, IN 46290
©2003 Thomson Inc.
Trademark(s)® Registered
Marca(s) Registrada(s)
TOCOM 16320470
THOMSON
Printed in Thailand
03/12 K
Loading...
