RBI Spectrum series Installation And Operation Instructions Manual

SPMI0M-10

82-0255

Finned Copper Tube Gas Boilers (SB) & Water Heaters (SW)

Boiler Manual

Installation and Operation Instructions

is manual is intended only for use by a qualied heating installer/technician. Read and follow this manual, all supplements and related

instructional information provided with the boiler. Install, start and service the boiler only in the sequence and methods given in these instructions. Failure to do so can result in severe personal injury, death or substantial property damage.

Do not use the boiler during construction. Construction dust and particulate, particularly drywall dust, will cause contamination

of the burner, resulting in possible severe personal injury, death or substantial property damage. e boiler can only be operated with a dust-free air supply. Follow the instruction manual procedures to duct air to the boiler air intake. If the boiler has been contaminated by operation with contaminated air, follow the instruction manual guidelines to clean, repair or replace the boiler if necessary.

Ax these instructions near to the boiler. Instruct the building owner to retain the instructions for future use by a qualied service

technician, and to follow all guidelines in the User’s Information Manual.

02/14 Copyright Mestek, Inc.

Finned copper tube gas boilers & water heaters – Boiler Manual

If the information in this manual is not followed

exactly, a fire or explosion may result causing property, personal injury or loss of life.

Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other applianc

WHAT TO DO IF YOU SMELL GAS:

• Donottryto light anyappliance.

• Do not touch anyelectrical switch. Do not use any phoneinyourbuilding.

• Immediatelycallyourgassupplierfromaphoneoutside thebuilding.Followthegassupplier’sinstructions.

• If you cannot reach your gas supplier, call the fire department.

Installation and service must be performed by a qualified

installer,serviceagencyor thegassupplier.

Assurez-vous de bien suivre les instructions données

dans cette notice pour réduire au minimum le risque d’incendie ou d’explosion ou pour éviter tout dommoge matériel, toute blessure ou la mort

Ne pas entreposer ni utiliser d’essence ou ni d’autres vapeurs ou liquides inflammables à proximité de cet

appareiloudetout autre appareil.

QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:

• Nepastenterd’allumerd’appareil.

• Netouchezà aucuninterrupteur;ne pasvousservir destéléphonessetrouvantdansle bâtiment.

• Appelezimmédiatementvotrefournisseurdegasdepuis unvoisin.Suivezles intructionsdu fournisseur.

• Si vousnepurvez rejoindrele fournisseur,appelezle service des incendies.

L’installation et l’entretien doivent être assurés par un installateurou unservice d’entretien qualifié ou parle fournisseurdegaz.

Failure to properly vent this unit can cause excessive

amounts of carbon monoxide resulting in severe personal injury or death!

DESIGNEDAND TESTEDACCORDINGTOA.S.M.E. BOILER AND PRESSURE VESSEL CODE,SECTION

IV FOR A MAXIMUM ALLOWABLE WORKING

PRESSURE OF160PSI, 1103 kPaWATER .

INSTALLER, THESE INSTRUCTIONS TO BE AFFIXED ADJACENT TO THE HEATER.

CONSUMER, RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE PURPOSES.

BEFORE YOUR START . . . . . . . . . . . . . . . . PAGE 2

RATINGS & CAPACITIES . . . . . . . . . . . . . . . PAGE 3

BOILER/WATER HEATER LOCATION . . . . . . . . .PAGE 3

COMBUSTION AIR & VENTILATION . . . . . . . . . . PAGE 3

CHIMNEY & VENT PIPE CONNECTIONS . . . . . . PAGE 10

COMMON VENT SYSTEMS . . . . . . . . . . . . . PAGE 12

OUTDOOR VENTING . . . . . . . . . . . . . . . . . PAGE 13

GENERAL PIPING REQUIREMENTS . . . . . . . . PAGE 13

HEATING SYSTEM PIPING . . . . . . . . . . . . . PAGE 15

DOMESTIC WATER SUPPLY PIPING . . . . . . . . PAGE 18

GAS SUPPLY PIPING . . . . . . . . . . . . . . . . PAGE 21

ELECTRICAL WIRING . . . . . . . . . . . . . . . . PAGE 22

GENERAL OPERATION . . . . . . . . . . . . . . . PAGE 22

OPERATING INSTRUCTIONS . . . . . . . . . . . . PAGE 27

CHECKING & ADJUSTMENTS. . . . . . . . . . . . PAGE 29

CONTROL DESCRIPTION . . . . . . . . . . . . . . PAGE 30

MAINTENANCE . . . . . . . . . . . . . . . . . . . PAGE 32

REPAIR PARTS . . . . . . . . . . . . . . . . . . . . PAGE 37

BEFORE YOU START

is manual covers the application, installation, operation and maintenance of a Spectrum nned copper heating boiler/water heater/pool heater (Canada Only).

To obtain the safe, dependable, ecient operation and long life for which this heating boiler/water heater was designed, these instructions must be read, understood and followed.

e Spectrum nned copper heating boiler/water heaters have been design certied by CSA for use with natural and propane gas under the latest revision of ANSI-Z21.10.3/CSA 4.3, Gas Water Heaters, ANSI-Z21.13/CSA 4.9, Gas-Fired Low Pressure Steam and Hot Water Boilers and CAN-1-3.1, Industrial and Commercial Gas Fired Boilers. Each unit has been constructed and hydrostatically tested for a maximum working pressure of 160 psi, 1103 KPa in accordance with Section IV of the A.S.M.E. Boiler and Pressure Vessel Code.

All aspects of the boiler/water heater installation must conform to the requirements of the authority having jurisdiction, or, in the absence of such requirements, to the National Fuel Gas Code, ANSI Z223.1/NFPA54-latest revision.

In Canada, the installation must be in accordance with the requirements of CAN/CGA B149.1 or .2, Installation Code for Gas Burning Appliances and Equipment.

Finned copper tube gas boilers & water heaters – Boiler Manual

If installed in the Commonwealth of Massachuses, you MUST FOLLOW the additional instructions contained in RBI's instr uction sheet MACODE-3. If you do not have a copy, cal l your RBI distributor or contact the RBI Customer Service Department.

e owner should maintain a record of all service work performed with the date and a description of the work done. Include the name of the service organization for future reference.

Direct all questions to your RBI distributor or contact the RBI Customer Service Department, 260 North Elm Street, Westeld, MA 01085 for U.S. or 7555 Tranmere Drive, Mississauga ONT L5S 1L4 for Canada. Always include the model and serial numbers from the rating plate of the boiler/water heater in question.

2. An optimum site will be level, central to the piping system, close to a chimney and have adequate fresh air for combustion. Ensure that the boiler/water heater is level from front to back and from side to side. Use metal shims to level the boiler/water heater. Electrical and electronic components must also be protected from exposure to water during operation and maintenance. DO NOT install this boiler/water heater in a location that would subject any of the gas ignition components to direct contact with water or excessive moisture during operation or servicing.

3. Ensure that the oor is structurally sound and will support the weight of the boiler/water heater.

e Spectr um may be installed directly on combustible

ooring, only if RBI supplied special oor pan is used but never on carpeting, see Table 2.

RATINGS & CAPACITIES

Before undertaking the installation of the Spectrum boiler/water heater check the rating plate to ensure that the unit has been sized properly for the job. e "Net AHRI Ratings" specify the equivalent amount of direct cast iron radiation that the unit can supply under normal conditions. Also ensure that the unit has been set up for the type of gas available at the installation site. Other important considerations are the availability of an adequate electrical supply, fresh air for combustion and a suitable chimney or vent system.

BOILER/WATER HEATER LOCATION

1. is boiler/water heater is suitable for indoor and outdoor installations. Locate the boiler/water heater in an area that provides good access to the unit. Servicing may require the removal of jacket panels. Allow the minimum clearances between adjacent construction and the boiler/water heater as listed in Table 1.

Service clearances are not mandatory, but are

recommended to ensure ease of service should it be required.

Table 1

Clearance to Combustibles

Top 14 356 18 457

Back 6 152 18 457 Left Side 6 152 24 609 Right Side 6 152 24 609 Front 6 152 24 609 Flue 6 152 6 152

in mm in mm

Service

Clearance

Table 2 Special Base for Combustion Floors

Model Number Part Number

100 70-1248 150 70- 1249 200 70- 1250 250 70-1251 300 70-1252 350 70-1253 400 70-1254

4. Locate the boiler/water heater in an area that will prevent water damage to adjacent construction should a leak occur or during routine maintenance. If such a location doesn’t exist, a suitable drain pan that’s adequately drained must be installed under the unit. e pan must not restrict the ow of combustion air to the unit.

5. DO NOT place this boiler/water heater in a location that would restrict the introduction of combustion air into the unit or subject it to a negative pressure, see “GENEL VENTING GUIDELINES”.

6. NEVER place this boiler/water heater in a location that would subject it to temperatures at or near freezing. See the “Freeze Protection” section on page 8.

Never store combustible materials, gasoline or any

product containing ammable vapors or liquids in the vicinity of the boiler/water heater. Failure to comply with this warning can result in an explosion or fire causing extensive property damage, severe personal injury or death!

Units installed outdoors MUST be protected from ice

and snow accumulation or the unit will be damaged voiding the warranty!

Finned copper tube gas boilers & water heaters – Boiler Manual

COMBUSTION AIR & VENTILATION

is boiler/water heater must be supplied with

combustion air in accordance with Section 5.3, Air for Combustion & Ventilation, of the latest revision of the National Fuel Gas Code, ANSI Z223.1/NFPA 54 and all applicable local building codes. Canadian installations must comply with CSA B149.1 or .2 Installation Code for Gas Burning Appliances and Equipment, or applicable provisions of the local building codes. Failure to provide adequate combustion air for this boiler/water heater can result in excessive levels of carbon monoxide that can result in severe personal injury or death!

To operate properly and safely this boiler/water heater requires a continuous supply of air for combustion. NEVER store objects on or around the boiler/water heater!

Combustion air contaminated with uorocarbons or

other halogenated compounds such as cleaning solvents and refrigerants will result in the formation of acids in the combustion chamber. ese acids will cause premature failure of the boiler/water heater voiding the warranty!

If the boiler/water heater is operated w hile the building

is under construction it MUST be protected from wood, concrete, sheet rock and other types of dust. Failure to properly protect the unit from construction dust will damage the unit voiding the warranty!

All Air From Inside The Building

If the boiler/water heater is to be located in a conned space, minimum clearances listed in Table 1 must be maintained between the boiler/water heater and any combustible construction. When installed in a conned space, Figures 1 and 2, two permanent openings communicating with an additional room(s) are required. e combined volume of these spaces must have sucient volume to meet the criteria for an unconned space. e total air requirements of all gas utilization equipment, replaces, wood stoves or any type of exhaust fan must be considered when making this determination. Each opening must have a minimum free area of 1 in2/1000 Btu/hr, 2200 mm2/kW based on the total input rating of ALL gas utilization equipment in the conned area. Each opening must be no less than 100 in2, 64,516 mm2 in size. e upper opening must be within 12 in, 305 mm of, but not less than 3 in, 76 mm from, the top of the enclosure. e boom opening must be within 12 in, 305 mm of, but not less than 3 in, 76 mm from, the boom of the enclosure.

All Air From Outside The Building

When installed in a conned space two permanent openings communicating directly with, or by ducts to, the outdoors or spaces that freely communicate with the outdoors must be present. e upper opening must be within 12 in, 305 mm of, but not less than 3 in, 76 mm from, the top of the enclosure. e boom opening must be within 12 in, 305 mm of, but not less than 3 in, 76 mm from, the boom of the enclosure.

Where directly communicating with the outdoors or communicating with the outdoors through vertical ducts, each opening shall have a minimum free area of 1 in total input rating of all of the equipment in the enclosure.

Where communicating with the outdoors through horizontal ducts, each opening shall have a minimum free area of 1 in 1100 mm2/kW of the total input rating of all of the equipment in the enclosure.

When louvers and screens are used, they must have the same crosssectional area as the free area of the opening to which they connect.

When calculating the free area necessary to meet the make-up air requirements of the enclosure, consideration must be given to the blockage eects of louvers, grills and screens. Screens must have a minimum mesh size of 1/4 in, 6.4mm. If the free area through a louver or grill is not known, ducts should be sized per Table 3.

Canadian installations must comply with CSA B149.1 when air

supply i s provided by natural air ow from the outdoors for natural dra, partial fan-assisted, fan-assisted, or power dra-assisted burners, there shall be a permanent air supply opening(s) having

a cross-sectional area of not less than 1 in

(310 mm2 per kW) up to and including 1 million Btuh, plus 1 in2per14,000Btuh (155 mm2 per kW) in excess of 1 million Btuh.

Table 3 Make-up Air Louver Sizing

Input

(MBH)

1/4 in 6.4 mm

Wire Screen

100 25 161 33 213 100 645 150 37 858 50 322 150 967 200 50 322 67 432 200 1290 250 62 400 83 535 250 1612 300 75 484 100 645 300 1934 350 87 561 117 754 350 2257 400 100 645 133 858 400 2579

/4000 Btu/hr, 550 mm2/kW of the

/2000 Btu/hr,

per 7,000 Btuh

Required Cross Sectional Area

75% Free Area

Metal Louvers

25% Free Area

Wooden Louvers

Finned copper tube gas boilers & water heaters – Boiler Manual

CHIMNEY & VENT PIPE CONNECTIONS

e vent installation must be in accordance with Part

7, Venting of Equipment, of the latest revision of the National Fuel Gas Code, ANSI Z223.1/NFPA 54 or applicable provisions of the local building codes. Canadian installations must comply with CSA B149.1 or .2 Installation Code. Improper venting can result in excessive levels of carbon monoxide which can result in severe personal injury or death!

Never modify or alter any part of the boiler’s dra

hood. is includes the removal or alteration of any baes. Never install a vent pipe of a diameter dierent than that of the boiler dra hood ue collar. Failure to comply with this warning can result in severe personal injury or death!

Always provide a minimum clearance of 6 in,152 mm between type C vent pipe and any combustible materials. Type B1 vent may be used, clearance between it and any combustible material must be as listed.

Chimney Inspection & Sizing

A thorough inspection of the masonry chimney must be performed to ensure that the chimney is clean, properly constructed, lined and sized. Exterior masonry chimneys should not be used unless properly lined to prevent condensation and dra problems. Table 4 lists the equivalent breeching and ue sizes required for the boiler/water heater.

Table 4 Equivalent Breeching and Chimney Size

Model

Size

100 5 127 150 6 152 200 7 178 250 8 203 300 8 203 350 9 229 400 10 254

Note: These sizes are based on a 20 ft, 6.1 m chimney height.

Size

When more than one appliance is connected to the same chimney ue, the ue must be large enough to safely vent the combined output of all the appliances.

If an appliance using any type of a mechanical dra

system operating under positive pressure is connected to a chimney ue, never connect any other appliances to this ue. Doing so can result in the accumulation of carbon monoxide which can cause severe personal injury or death!

Vent Connections

Always use a type B or single wall galvanized metal vent pipe the same diameter as the dra hood ue collar, Table 4. Use the shortest, straightest vent system possible for the installation. If horizontal runs exceed 6 , 1.8 m they must be supported at 6 ,

1.8 m intervals with overhead hangers. e vent system should be sloped up toward the chimney at a minimum rate of 1/4 in/, 20 mm/m and terminate ush with the inside of the chimney ue. Fasten each connection with at least 3 corrosion resistant sheet metal screws.

Failure to maintain minimum clearances between vent

connectors and any combustible material can result in a re causing extensive property damage, severe personal injury or death!

To determine the appropriate power venter for the boiler/water heater, see Table 5, Power Venter Sizes. Follow the power venter manufacturer’s installation instructions.

Table 5 Power Venter Sizes

Spectrum Power Venter

Model Model

100-250 HS-1 100 31

300-400 HS-2 100 31

Max. Pipe Length

ft mm

COMMON VENT SYSTEMS

If an existing boiler/water heater is removed from a common venting system, the common venting system may then be too large for the proper venting of the remaining appliances connected to it. At the time of removal of an existing boiler/water heater, the following steps shall be followed with each appliance remaining connected to the common venting system placed in operation, while the other appliances remaining connected to the common venting system are not in operation.

Au moment du retrait d’une chaudière existante, les mesures suivantes doivent être prises pour chaque appareil toujours raccordé au système d’évacuation commun et qui fonctionne alors que d’autres appareils toujours raccordés au système d’évacuation ne fonctionnent pas: système d’évacuation.

a) Seal any unused openings in the common venting system.

Sceller toutes les ouvertures non utilisées du sys-tème d’évacuation.

b) Visually inspect the venting system for proper size and horizontal

pitch and determine there is no blockage or restriction, leakage, corrosion and other deciencies which could cause an unsafe condition.

Inspecter de façon visuelle le système d’évacuation pour

déterminer la grosser et l’inclinaison horizontale qui conviennent et s’assurer que le système est ex-empt d’obstruction, d’étranglement de fruite, de corrosion et autres défaillances qui pourraient présenter des risques.

Finned copper tube gas boilers & water heaters – Boiler Manual

c) Insofar as is practical, close all building doors and windows and

all doors between the space in which the appliances remaining connected to the common venting system are located and other spaces of the building. Turn on clothes dryers and any appliance not connected to the common venting system. Turn on any exhaust fans, such as range hoods and bath-room exhaust, so they will operate at maximum speed. Do not operate a summer exhaust fan for a boiler installation. Close replace dampers.

Dans la mesure du possible, fermer toutes les portes et les fenêtres

du bâtiment et toutes les portes entre l’espace où les appareils toujours raccordés du système d’évacuation sont installés et les autres espaces du bâtiment. Mere en marche les sécheuses, tous les appareils non raccordés au système d’évacuation commun et tous les ventilateurs d’extraction comme les hoes de cuisinère et les ventilateurs des salles de bain. S’assurer que ces ventilateurs fonctionnent à la vitesse maximale. Ne pas faire fonctionner les ventilateurs d’été. Fermer les registres des cheminées.

d) Place in operation the appliance being inspected. Follow the

lighting instructions. Adjust thermostat so appliance will operate continuously.

Mere l’appareil inspecté en marche. Suivre les instructions

d’allumage. Régler le thermostat de façon que l’appareil fonctionne de façon continue.

e) Test for spillage at the dra hood relief opening aer 5 minutes

of main burner operation. Use the ame of a match or candle, or smoke from a cigaree, cigar or pipe.

Faire fonctionner le brûleur principal pendant 5 min ensuite,

déterminer si le coupe-tirage déborde à l'ouverture de décharge. Utiliser la amme d'une allunee ou d'une chandelle ou la fumée d'une ciga-ree, d'un cigare ou d'une pipe.

f) Aer it has been determined that each appliance remaining

connected to the common venting system properly vents when tested as outlined above, return doors, windows, exhaust fans, replace dampers and any other gas-burning appliance to their previous condition of use.

Une fois qu’il a été déterminé, selon la métode indiquée ci-

dessus, que chaque appareil raccordé au système d’évacuation est mis à l’air libre de façor adéquate. Remere les portes et les fenêtres, les ventilateurs, les registres de cheminées et les appareils au gaz à leur position originale.

g) Any improper operation of the common venting system should

be corrected so the installation conforms with the National Fuel Gas Code, ANSI Z223.1/NFPA 54. When resizing any portion of the common venting system, the common venting system should be resized to approach the minimum size as determined using the appropriate tables in Part 11 in the National Fuel Gas Code, ANSI Z223.1/NFPA 54 and or CAN/CGA B149 Installation Codes.

Tout mauvais fonctionnement du systéme d’évacuation commun

devrait étré corrigé de façor que l’installation soit conforme au National Fue Gas Code, ANSI Z223.1/NFPA 54 et (ou) aux codes d’installation CAN/CGA-B149. Si la grosseur d’une section du système d’ évacuation doit étré modiée, le système devrait étré modié pour.

Finned copper tube gas boilers & water heaters – Boiler Manual

Figure 1 Vertical Venting with a Metal Chimney System and Inside Air

10 FT 3.1m

Figure 2 Vertical Venting using a Metal Chimney and Inside Air

RIOM-51

Finned copper tube gas boilers & water heaters – Boiler Manual

OUTDOOR VENTING

SPECTRUM

HEADER HOOD

SUPPLY/RETURN

HEADER HOOD

EXHAUST HOOD

COMBUSTION AIR HOOD

0.9 m

1.2 m

GENERAL PIPING REQUIREMENTS

When installed outdoors the Spectrum must be ed with the factory supplied outdoor hood assembly, see Figure 3. Multiple units must be spaced per Figure 3A.

e boiler/water heater must be at least 10 , 3.1 m from any door, window or gravity air inlet into any building and at least 3 , 0.9 m from any overhang unless local codes dictate dierently.

Avoid locations where wind deection o of adjacent walls, buildings or shrubbery might cause a down dra. e unit(s) should be located at least 3 , 0.9 m from structures. Outdoor installations are not

recommended in areas where the danger of snow blockage exists.

Do not place the boiler/water heater in a location that

would subject it to runo from adjacent buildings or damage may occur voiding the warranty!

Figure 3 Outdoor Venting

RIOM-53

Figure 3A Multiple Outdoor Units

Improper piping of this boiler/water heater will void the

manufacturer’s warranty and can cause boiler failure resulting in ooding and extensive property damage! Excessive water hardness causing lime build-up in the copper heat exchanger tubes is NOT covered under the manufacturer’s warranty. Excessive piing and erosion of the internal surface of the copper heat exchanger tubes is NOT covered under the manufacturer’s warranty if the result of high water ow rates, see Table 7 or 8. Return water temperatures below 110°F, 43°C will result in heat exchanger damage from excessive condensation voiding the manufacturer’s warranty, see Primary/Secondary Piping Figure 5.

Shut o valves and unions should be installed at the

inlet and outlet connections of the boiler water heater to provide for isolation of the unit should servicing

be necessary.

Freeze Protection

is boiler/water heater is CSA designed certied for outdoor installation. Outdoor installations in areas where the danger of freezing exists are not recommended unless proper freeze protection is provided. If the unit is to be installed in such an area the following precautions MUST be observed:

1. A continuous ow of water through the boiler/water heater MUST be maintained! e pump responsible for ow through the boiler/water heater must run continuously!

2. An ethylene glycol/water mixture suitable for the minimum temperature that the unit will be exposed to must be used. e pump must be capable of producing 15% more ow and overcoming a 20% increase in head loss. Domestic water systems must be isolated from the water heater by the use of a heat exchanger or other approved method.

3. If the boiler/water heater must be shut o for any reason the electric, gas and water supplies MUST be shut o and the unit and its pump completely drained.

Improper outdoor installation of this boiler/water heater

can cause boiler failure voiding the manufacturer's warranty!

RIOM-54

Finned copper tube gas boilers & water heaters – Boiler Manual

Relief Valve

1",

25 mm

Pipe the discharge of the pressure relief valve to prevent scalding in the event of a discharge, see Figure 4. e discharge piping must be sized the same as the pressure relief valve outlet and installed to allow complete drainage of both the relief valve and the discharge piping.

Figure 4

RIOM-57

Never install any type of valve bet ween the boiler/water

heater and the relief valve or an explosion causing extensive property damage, severe personal injury or death may occur!

e thermal expansion of the system must be considered when supporting the system. A minimum system pressure of 12 psig,

82.7 kPa must be maintained.

Heating Boiler Piping Connections

e supply and return connections should be sized to suit the system, see Table 6.

Table 6 Supply and Return Pipe Sizing

Model Size Supply Size Return Size

100 thru 400 1 1/2” NPT 1 1/2” NPT

Pump Requirements

is low mass boiler requires a continuous minimum water ow for proper operation. e boiler pump must be sized to overcome the head loss of the boiler and the near piping in order to achieve the required temperature rise. Table 7 and 8 provides the heat exchanger pressure drop and temperature rise gures.

e temperature rise across the boiler must never exceed 30°F,

16.7°C. A pump delay is installed, the pump delay turns the pump

on each time the burners re and runs the pump up to 10 minutes aer the call for heat is satised.

A temperature rise outside of the range listed in Tables

7 or 8 indicates that the ow rate through the heat exchanger is incorrect which will damage the heat exchanger voiding the warranty!

Flow Switch

e ow switch supplied with the boiler/water heater must be wired to the terminal strip in the control panel to prevent the boiler from ring unless there’s adequate water ow through the unit. e ow switch must be installed in the supply piping adjacent

to the boiler outlet connection.

Failure to properly install the ow switch may result

in damage to the boiler/water heater heat exchanger voiding the warranty!

HEATING SYSTEM PIPING

General Piping Requirements

All heating system piping must be installed by a qualied technician in accordance with the latest revision of the ANSI/ASME Boiler and Pressure Vessel Code, Section IV, and ANSI/ASME CSD-1, Standard for Controls and Safety Devices for Automatically Fired Boilers. All applicable local codes and ordinances must also be followed. A minimum clearance of 1 in, 25 mm must be maintained between heating system pipes and all combustible construction. All heating system piping must be supported by suitable hangers not the boiler.

e maximum allowable ow rate through a Spectrum

boiler with copper heat exchanger is 92 GPM,

5.8 L/s (2-pass heat exchanger) and 46 GPM,

2.9 L/s (4-pass heat exchanger).

Low Water Cuto

If a boiler is installed above any radiation elements it must be ed with a low water cuto device.

Refer to wiring diagram supplied with the boiler/water heater for proper wiring connections.

Expansion Tank

An expansion tank or other means to control thermal expansion must be installed in the heating system. An expansion tank must be installed close to the boiler on the suction side of the system pump.

Primary/Secondary Piping

Boilers connected to heating systems using zone valves, zone pumps, or systems that have excessive ow rates or return water temperatures less than 110°F, 43°C must be isolated from these systems to protect the boiler.

Finned copper tube gas boilers & water heaters – Boiler Manual

Table 7 Temperature Rise Table – 2 Pass Headers

∆T = 10°F ∆T = 5.5°C ∆T = 20°F ∆T = 11.1°C ∆T = 30°F ∆T = 16.7°C

Flow Rate

Pres.

Drop

Flow Rate

Pres.

Drop

Flow Rate

Pres.

Drop

Flow

Rate

Pres.

Drop

Flow Rate

Pres.

Drop

Model

Number

GPM

L/s kPa GPM

100 16.4 0.05 1.0 0.1 — — — — — — — —

150 24.6 0.13 1.6 0.4 — — — — — — — —

200 32.4 0.27 2.0 0.8 16.2 0.07 1.0 0.2 — — — —

250 40.5 0.48 2.6 1.4 20.3 0.13 1.3 0.4 — — — —

300 49.8 0.82 3.1 2.4 24.9 0.23 1.6 0.7 16.6 0.10 1.0 0.3

350 58.1 1.23 3.7 3.6 29.1 0.34 1.8 1.0 19.4 0.20 1.2 0.5

400 66.4 1.77 4.2 5.2 33.2 0.49 2.1 1.4 22.1 0.20 1.4 0.7

Note: Unit equipped with 4-pass headers, see Table 8.

Table 8 Temperature Rise Table – 4 Pass Headers

∆T = 10°F ∆T = 5.5°C ∆T = 20°F ∆T = 11.1°C ∆T = 30°F ∆T = 16.7°C

Flow Rate

Pres.

Drop

Flow Rate

Pres.

Drop

Flow Rate

Pres.

Drop

Flow

Rate

Pres.

Drop

Flow Rate

Pres.

Drop

Model

Number

GPM

L/s kPa GPM

Flow

Rate

Pres.

Drop

L/s kPa

Flow

Rate

Pres.

Drop

L/s kPa

100 16.4 0.34 1.0 1.0 — — — — — — — —

150 24.6 0.94 1.6 2.8 — — — — — — — —

200 32.4 1.92 2.0 5.7 16.2 0.53 1.0 1.6 — — — —

250 40.5 3.46 2.6 10.2 20.3 0.96 1.3 2.8 — — — —

300 49.8* 5.89 3.1 17.3 24.9 1.63 1.6 4.8 16.6 0.80 1.0 2.3

350

29.1 2.47 1.8 7.3 19.4 1.20 1.2 3.4

See Note

400 33.2 3.54 2.1 10.4 22.1 1.70 1.4 4.9

Note: Unit equipped with 2-pass headers, see Table 7. *Flow exceeds recommended maximum use a greater temperature rise or consult manufacturer. Cupro-nickel heat exchanger should be considered.

Finned copper tube gas boilers & water heaters – Boiler Manual

Figure 5 Typical Primary/Secondary Piping System

(See Notes)

NOTES:

1. Boiler circuit piping must be sized large enough to handle maximum ow through unit.

2. Boiler pump sized to boiler design ow requirements.

3. All boilers furnished with factory mounted outlet water temperature gauge.

4. Boiler pump purging required. Use terminals supplied.

Notice: These drawings show suggested piping conguration and valving. Check with local codes and ordinances for specic requirements.

H-1 Rev 4

Pump

Gate Valve

Globe Valve

Angle Valve

Bufferfly Valve

Balance Valve

Ball Valve

Motorized Valve

Solenoid

Operated Valve

Self-Operated

Valv e

Figure 6 Low Temperature Piping with Thermostatic Valve

(See Notes)

H-18 Rev 3

Pressure

Reducing Valve

Check Valve

Pressure

Relief Valve

Flow Switch

Thermometer

Aquastat Union

Pressure Switch

Gas Pressure

Regulator

Automatic

Air Vent

BackflowPrevention

Device

3-Way Valve

NOTES:

1. For pump selection consult factory.

2. Boiler pump sized to boiler and thermostatic 3-way valve design ow requirements.

3. Boiler circuit piping must be sized large enough to handle maximum ow through unit.

4. All boilers furnished with factory mounted outlet water temperature gauge.

5. Boiler pump purging required. Use terminals supplied.

6. Valve is precalibrated for 140°F return temperature.

Notice: These drawings show suggested piping conguration and valving. Check with local codes and ordinances for specic requirements.

Expansion

Tank

Finned copper tube gas boilers & water heaters – Boiler Manual

Figure 6 Low Temperature Piping

(See Notes and Adjustment Procedures)

Pu m p

G a te Val v e

Adjustment Procedure

To Maintain Inlet Temperature

Above Dew Point

T1-Temp-Min=110°F For Atmospheric

T1-Temp-Min=125°F Sealed Combusion

1. Turn heater on and open valves A & B.

2. After steady-state operation, if T1 is less than Temp-Min slowly close valve B until T1 climbs to desired operating temperature above Temp-Min.

3. If T1 is greater than desired operating temperature, slowly close valve A to adjust to lower desired temperature above Temp-Min.

4. Check after system operating temperature has stabilized. Make nal adjustments.

5. Follow same adjustment procedure for sealed combustion.

Figure 6A Multiple Boiler Piping

(See Notes)

NOTES:

1. Boiler circuit piping must be sized large enough to handle maximum ow through unit.

2. Boiler pump sized to boiler

design ow requirements.

3. All boilers furnished with

factory mounted outlet water temperature gauge.

4. Boiler pump purging required.

Use terminals supplied.

Notice: These drawings show suggested piping conguration and valving.Check with local codes and ordinances for specic requirements.

H-3 Rev 6

G l obe Val v e

A ngl e Val v e

B u ffe r f l y Va l v e

B a l ance Va l v e

B a ll V a lv e

Moto r i z ed Val v e

S o l e noi d

O per ate d Va l v e

S e l f -Operated

Va l v e

Pr e s s u r e

Reduc i ng Val v e

Check Val v e

Pr e s s u r e

Reli e f Va l v e

Fl o w Swi t ch

H-15 Rev 5

NOTES:

1. Boiler circuit piping must be large enough to handle maximum ow through unit.

2. Boiler pump sized to boiler design ow requirements.

3. All boilers furnished with factory mounted outlet water temperature gauge.

4. Boiler pump purging required. Use terminals supplied.

5. Secondary loop pipe diameter must be sized large enough to handle maximum ow through all units.

Notice: These drawings show suggested piping conguration and valving. Check with local codes and ordinances for specic requirements.

The r momet e r

A quasta t U n i o n

P r es sure S w i t ch

G a s Pressur e

Reg u lator

A u tomati c

A i r Vent

BackflowPrevention

Device

Expansion

Tank

Finned copper tube gas boilers & water heaters – Boiler Manual

Variable Water Flows

Figure 5 shows a typical primary/secondary piping system. A dedicated pump is used to maintain a constant water ow through the boiler. is boiler pump is sized to overcome the head loss of the boiler and near piping while supplying the ow rate required to maintain the desired temperature rise across the boiler heat exchanger. e system pump is sized to provide the required ow to the heating system.

Low Return Water Temperatures

To prevent the problems associated with condensation of the products of combustion due to low return water temperatures a primary/secondary piping system with a bypass and bypass valve must be installed, see Figures 6 and 6A. e bypass and bypass valve must be sized the same as the secondary piping. A balancing valve must also be installed in the supply side of the secondary piping downstream of the bypass. e balancing valve should be adjusted to divert some of the heated discharge water into the return water until the required inlet water temperature is achieved. e primary and secondary pumps should be sized to provide the required ow through each system.

Multiple Boiler Systems

Systems using multiple boilers can also be installed using a primary/ secondary manifold system, Figure 7.

Piping For Use With Cooling Units

e boiler, when used in connection with a refrigeration system, must be installed so the chilled medium is piped in parallel with the boiler. Appropriate valves must be used to prevent the chilled water from entering the boiler.

When a boiler is connected to a heating coil that may be exposed to refrigerated air from an air handling device, the piping system must be equipped with ow-control valves or some other automatic means of preventing gravity circulation of the boiler water during the cooling cycle.

DOMESTIC WATER SUPPLY PIPING

Proper controls must be used to prevent water

supplied for domestic use from exceeding 130°F, 54°C or a scald injury will occur! When higher water temperatures are required for appliances such as a dishwasher, a mixing valve or some other tempering means must be installed. Households with small children may require water temperatures less than 120°F, 49°C. Local codes must be complied with!

General Piping Requirements

Ensure that the water heater is equipped with bronze headers. Piping and components connected to the water heater must be suitable for use with potable water. e water heater must not be connected to any heating system piping or components previously used with a non-potable water heating appliance. No toxic chemicals, such as those used for boiler treatment, are to be introduced into any potable water used for space heating. If a hot water storage tank is used in the system, it must be equipped with a temperature and pressure relief valve that complies with ANSI Z21.22 or CAN-4.4 and CAN-4.6.

e storage tank must be located as close to the water

heater as possible to prevent excessive head loss which will reduce ow.

Water Chemistry

e required temperature rise across the water heater is based on water having a hardness between 5 and 25 grains per gallon with a level of dissolved solids not exceeding 350 ppm. Water having a hardness less than 5 grains can cause excessive corrosion of the heat exchanger. Water that has a hardness greater than 25 grains per gallon and/or a level of dissolved solids exceeding 350 ppm will require a recalculation of the pump size and temperature rise.

A cupro-nickel heat exchanger may also be required. e manufacturer should be consulted when these water conditions are encountered. See Table 9A.

RBI water heaters are designed to run scale free. Due to the extreme variables of water conditions world wide it is necessary to consider pH values and water hardness in relationship to scaling. It is crucial to consider these two variables when making heat exchanger and pump selections. If local water conditions are extreme follow the guidelines in the Heat Exchanger Selection Table (Table 9A) and the Pumping Performance Table (Table 9B). Scale free operation can be achieved by using water with a hardness between 8 and 18 and by maintaining the pH between 5 and 9. Follow the conditions listed under NORMAL in the table. In some areas of the country additional precautions must be observed due to unusual characteristics of the local water supply. Call the nearest RBI representative for details.

To properly size the pump a grain hardness and pH test must be taken at the installation site before the order is placed. Proper pump sizing will improve heater performance and help ensure heater longevity.

Expansion Tank

An expansion tank or other means to control thermal expansion must be installed in the water heating system if back ow prevention devices are installed.

Finned copper tube gas boilers & water heaters – Boiler Manual

Pump Requirements

is low-mass water heater requires a continuous minimum water ow for proper operation. e factory recommended circulating pump has been sized to overcome the head loss of the water heater plus a 30 foot piping loop under normal water conditions. Table 9B provides the heat exchanger pressure drop chart and temperature rise table. etemperaturerise acrossthewater

heatermust neverexceed 30°F, 16.7°C.

e max imum allowable ow rate through a Spectrum

water heater is 92 GPM, 5.8 L/s (2-pass heat exchanger) and 46 GPM, 2.9 L/s (4-pass heat exchanger). e cupro-nickel heat exchanger allows for 100 GPM, 6.3 L/s (2-pass heat exchanger) and 50 GPM, 3.2 L/s (4-pass heat exchanger). See Table 9B.

Cold Water Supply

e cold water supply must be piped to the storage tank on the water heater’s outlet piping between the water heater and the hot water storage tank. is will prevent untempered water from entering the water heater, see the Temperature Rise Control section. A typical water heating system is shown in Figures 8 and 9.

Temperature Rise Control

Water returned to the water heater inlet must not be less than 110°F, 43°C or excessive condensation of the products of combustion will damage the water heater voiding the warranty. e method outlined below can be employed to prevent this condition from occurring.

A balancing valve should be installed on the outlet side of the water heater for purposes of adjusting the ow rate through the heat exchanger. ermometers are installed on both the inlet and outlet of the water heater for determining the temperature rise through the unit.

e proper velocity through the water heater must be maintained in accordance with Table 9B for ecient operation and long life. If the temperature rise through the water heater is lower than recommended, the water velocity is too high. Premature erosion of the heat exchanger will occur. Conversely, if the temperature rise is higher than recommended in Table 9B the ow rate is too low.

Scaling and soening of the heat exchanger will occur.

Thermostatic Mixing Valve - Water Above 140°F, 60°C

Water can be stored at temperatures above 140°F, 60°C provided that a thermostatically controlled mixing valve is used to temper the hot water to an acceptable temperature before it’s supplied for domestic use.

e mixing valve MUST be set to prevent a scald injury from occurring, see the caution against scalding.

Storage of water for domestic use above 140°F, 60°C will provide an increased quantity of tempered water and help prevent the growth

of water born bacteria.

Finned copper tube gas boilers & water heaters – Boiler Manual

Table 9A Spectrum Heat Exchanger Selection Graph

Table 9B Spectrum Pumping Performance Requirement Table

Finned copper tube gas boilers & water heaters – Boiler Manual

Figure 8 Typical Water Heating Piping (MW Models Only)

(See Notes)

Attention:

Not all RBI stock storage tanks

incorporate this tapping: See Note 1.

Figure 9 Multiple Water Heating Piping (MW Models Only)

(See Notes)

SELF BALANCING DOUBLE REVERSE RETURN MAKE-UP & SUPPLY, CIRCULATION

D-1 Rev 6

Pump

Valve

Globe Valve

Angle Valve

Bufferfly Valve

Balance Valve

Ball Valve

Motorized Valve

Solenoid

Operated Valve

Self-Operated

Valve

Pressure

Reducing Valve

Check Valve

Pressure

Relief Valve

incorporate this tapping: See Note 1.

NOTES:

1. Optional cold water make up and recirculation line location.

2. When using intermittent pump and pump delay, locate remote aquastat well in lower 1/3 of tank. Install aquastat with heat sensing compound.

3. Thermal expansion tank may be required, check local codes.

4. When using optional factory mounted pump, max pipe length 30 ft total, 6-90° elbows, full pipe size.

5. CAUTION: MEASURE WATER HARDNESS AND pH AT JOB SITE. The pH and water hardness must be measured before selecting heat exchanger and pump. Consult the Heat Exchanger Graph and

Pumping Performance Table before making selection.

6. Common piping must be sized for maximum combined heater ow.

7. Hot water tanks should be equipped with a combination temperature & pressure relief valve.

8. MA Code requires an 1/8 in hole in check valve to compensate for thermal expansion.

Notice: These drawings show suggested piping conguration and valving. Check with local codes and ordinances for specic requirements.

D-4 Rev 6

Attention:

Not all RBI stock storage tanks

Flow Switch

Thermometer

Aquastat Union

Pressure Switch

Gas Pressure

Regulator

Automatic

Air Vent

Temperature &

Pressure

Relief Valve

Vacuum

Relief Valve

Drain Valve

(Typ.)

Finned copper tube gas boilers & water heaters – Boiler Manual

GAS SUPPLY PIPING

Check the boiler/water heater rating plate

to make sure that the boiler/water heater is for the type of gas that will be used. If it isn’t, do not connect the boiler/water heater to the gas supply. Gas supply piping must be in accordance with the National Fuel Code, ANSI Z223.1-latest revision or applicable provisions of the local building codes. Canadian Installations must comply with CAN/CGA B149.1 or .2 Installation Code. Failure to comply with this warning can result in extensive property damage, severe personal injury or death!

e Spectrum boiler/water heaters come from the factory ready to be piped to the gas supply. If for any reason the boiler/water heater is not for the type of gas available at the installation site, call the nearest RBI representative to resolve the problem.

A minimum gas supply pressure of 5 in, 127 mm WC

natural or 12 in, 305 mm WC propane and maximum gas supply pressure of 14 in, 356 mm WC natual or propane, must be available at the safety shuto valve inlet with the unit(s) operating.

Table 10 should be used to ensure that the gas supply piping is sized properly. If more than one appliance is supplied by the same supply pipe, the piping must be sized based on the maximum possible demand. Do not neglect the pressure drop due to pipe ings. Table 10 should be used in conjunction with Table 11 to ensure that the gas supply piping has the capacity to meet the demand.

Table 11 Equivalent Pipe Length

Nominal Iron Pipe

Size

1" 2.6 5.2 0.6 1.5 1 1/4" 3.5 6.9 0.8 1.9 1 1/2" 4.0 8.0 0.9 2.3

2" 5.2 10.3 1.2 3.0 2 1/2" 6.2 12.3 1.4 3.7

3" 7.7 15.3 1.8 4.5

4" 7.7 15.3 1.8 4.5

Notes: 1. For ow through branch.

2. For ow at full open.

90˚ Elbow Tee

Type of pipe tting

Gate Valve2Gas Cock

Equivalent pipe length, (ft)

Figure 10 depicts the proper way to connect the boiler/water heater to the gas supply piping. e manual shut-o valve MUST be installed in the supply piping. It should be installed 5 , 1.5 m above the oor where required by local codes. Provide a sediment trap at the boom of the vertical section of the gas supply pipe upstream of the gas controls.

A ground joint union should be installed between the boiler gas controls and the supply piping. Each of these items are needed to ensure long life and ease of servicing. Always use a pipe sealant that

is suitable for use with LP gas.

Figure 10 Gas Supply Piping

Table 10 Gas Pipe Capacity

Maximum pipe capacity in ft3/hr based on 0.60 specic gravity gas at a pressure of 0.5 psig or less and a 0.3" WC pressure drop.

Nominal Iron Pipe

Size

3/4" 278 190 152 130 115 105 90 79 64

1" 520 350 285 245 215 195 170 150 120 1 1/4" 1050 730 590 500 440 400 350 305 250 1 1/2" 1600 1100 890 760 670 610 530 460 380

2" 3050 2100 1650 1450 1270 1150 990 870 710 2 1/2" 4800 3300 2700 2300 2000 1850 1600 1400 1130

3" 8500 5900 4700 4100 3600 3250 2800 2500 2000

Note: Multiply the gas volume by 0.62 for propane ow capacity in ft Multiply the propane ow capacity by 2500 Btu/ft the propane Btu/hr capacity for a given pipe size and length.

10 20 30 40 50 60 80 100 150

Maximum gas volume of pipe, (ft

17,500 12,000

Pipe length in feet

/hr)

9700 8300 7400 6800 5800 5100 4100

to determine

/hr.

RIOM-47

Always use a wrench on the gas valve body when

making gas connections to it. Never over-tighten the piping entering the gas valve body or gas valve failure may result!

Finned copper tube gas boilers & water heaters – Boiler Manual

When applicable, provisions for vent, bleed and gas relief lines must be made in accordance with the latest revision of ANSI Z223.1/ NFPA 54.

Safe lighting and other performance criteria were met with the gas manifold and control assembly provided on the boiler. All gas connections MUST be leak tested before puing the boiler into operation.

Never use an open ame to test for gas leaks. Always

use an approved leak detection method. Failure to comply with this warning can cause extensive property damage, severe personal injury or death!

Whenever the gas supply piping is pressure tested the boiler/water heater gas controls must be protected. If the test pressure is equal to, or less than 1/2 psig, 3.5 kPa isolate the boiler/water heater by closing it’s manual shut o valve, see Figure 10. If the test pressure is greater than, or equal to 1/2 psig, 3.5 kPa, disconnect the boiler/ water heater and its individual shut-o valve.

Required Gas Pressure

Provide gas supply pressure at inlet to boiler gas train as follows:

LP Nat Minimum (in WC) 12 5

Maximum (in WC) 14 14

Measure pressure when boiler is ring at full rate. Low gas pressure could indicate undersized gas line or insucient gas supply.

"Static and operating gas pressure required at the gas valve inlet is between 5 in WC and 14 in WC for natural gas and 12 in WC and 14 in WC for propane. If the gas pressure is above this limit, a lock-up style regulator suitable for dead end service such as an Equimeter or Fisher must be installed to prevent increase (creep) of gas pressure when the units are not operating. is pressure regulator (supplied by others) may be installed at the service entrance to each unit or a "master" regulator sized to handle multiple units may be utilized. Consult local gas utility or regulator manufacturer for recommendations to meet specic job site requirements."

ELECTRICAL WIRING

Electrical Power Connections

Label all wires prior to disconnection when servicing

controls. Wiring errors can cause improper and dangerous operation! Verify proper operation aer servicing!

AENTION. Au moment de l’entretien des

commandes, étiquetez tous les ls avant de les débrancher. Des erreurs de câblage peuvent entraîner un fonctionnement inadéquat et dangereux. S’assurer que l’appareil fonctionne adéquatement une fois l’entretirn terminé.

e electrical connections to this boiler/water heater must be made in accordance with all applicable local codes and the latest revision of the National Electrical Code, ANSI/NFPA-70. Installation should also conform with CSA C22.1 Canadian Electrical Code Part I if installed in Canada.

Install a separate 120 volt 15 amp circuit for the boiler/water heater and circulator pump. A shut-o switch should be located at the boiler/water heater. e boiler/water heater must be grounded in accordance with the authority having jurisdiction, or if none, the latest revision of the National Electrical Code, ANSI/NFPA-70.

Line voltage eld wiring of any controls or other devices must conform to the temperature limitation of type T wire at 95°F, 35°C above room temperature. Use copper conductors with a minimum size of #14 awg.

Refer to the wiring diagram supplied with the boiler/water heater for proper wiring connections.

Finned copper tube gas boilers & water heaters – Boiler Manual

GENERAL OPERATION

Before proceeding read and fully understand the

instructions contained in this manual. Do not aempt to operate this boiler/water heater if it has not been installed in accordance with the guidelines set forth in this manual. Failure to comply with this warning can result in extensive property damage, severe personal injury or death!

Should overheating occur or the gas supply fail to shut o, turn o the manual gas control valve to the appliance. Do not interrupt water ow through the boiler/water heater.

En cas de surchaue ou si l’alimentation en gaz ne s’arrête pas, fermez manuellement le robinet d’arrêt de l’admission de gaz.

Hydronic Heating Boilers

Open the make-up water valve and slowly ll the boiler and all of the radiation with water. Ensure that all bleed and drain valves are closed.

Adjust the make-up water pressure regulator so a minimum 12 psig, 82.7 kPa system pressure is maintained at the highest point in the system piping. If a make-up water pump is used adjust to maintain a minimum 12 psig, 82.7 kPa system pressure.

Open the system bleed and drain valves, one at a time, to purge the air trapped in the heating system piping.

With the boiler o, run the system pump for at least 30 minutes and bleed the system piping using the bleed valves. If strainers are used in the system piping, the make-up water valve should be closed and the strainers checked and cleaned.

e system expansion tank should be checked to ensure that the correct water level in the tank is maintained. e tank should be less than half full of water with the system full and adjusted to the correct operating pressure.

Start the boiler as described in the “LIGHTING AND OPETING INSTRUCTIONS” on the next page. Run the boiler for at least an hour. e system pump(s) and all radiation units must be operated during this time. Ensure that the make-up water valve is open.

Shut the boiler o and open the bleed valves to purge the air trapped in the heating system piping. Close the make-up water valve and check and clean the strainers and make-up water pressure reducing valve.

Open the make-up water valve and adjust the system pressure if necessary. e system should be checked and bled aer three days of operation.

Finned copper tube gas boilers & water heaters – Boiler Manual

FOR YOUR SAFETY READ BEFORE OPERATING

PRESSURE REGULATOR

OUTLET PRESS. TAP

GAS INLET

WARNING: If you do not follow these instructions exactly, a ﬁre or explosion may result causing property damage, personal injury or loss of life.

A. If this appliance is equipped with an electronic

ignition device, this automatically lights the burner. Do

not try to light the burner by hand.

B. BEFORE OPERATING smell all around the appliance

area for gas. Be sure to smell next to the oor because some gas is heavier than air and will settle on the oor.

C. Use only your hand to push in or turn the gas

control knob. Never use tools. If the knob will not push

in or turn by hand, don't try to repair it, call a qualied

service technician. Force or attempted repair may re-

sult in a re or explosion.

D. Do not use this appliance if any part has been under

water. Immediately call a qualied service technician to inspect the appliance and to replace any part of the control system and any gas control that has been under water.

OPERATING INSTRUCTIONS

DANGER: Propane gas may not always be detected by smell. Propane gas is heavier than air and can collect in low areas.

Propane gas can ignite or explode if an ignition source is present and result in death, serious injury and property damage!

FOR YOUR SAFETY:

• Have only qualied licensed professionals install,

service and maintain this appliance and your gas system in accordance with all applicable codes.

• Install a nationally listed combustible gas detector(s)

in your home.

• If you suspect a leak:

1. Have everyone leave the building immediately.

2. Do not attempt to light any appliance.

3. Do not touch any electrical or electronic switches in the building.

4. Do not use any phone in the building.

Call your gas supplier from a phone outside of

the building.

6. If you cannot reach your gas supplier call the re

department.

1. STOP! Read the safety information above.

2. Set the thermostat to lowest setting.

3. Turn off all electric power to the appliance.

4. This appliance is equipped with an ignition device, which automatically lights the pilot. Do not try to light the pilot by hand!

ADJUSTMENT (UNDER CAP SCREW)

OFF

GAS CONTROL KNOB

GROUND TERMINALS (2)

GAS OUTLET

TO TURN OFF GAS TO APPLIANCE

1. Set the thermostat to lowest setting.

2. Turn off all electric power to the appliance if service is to be performed.

3. Remove control access panel.

5. Remove control access panel.

6. Push in gas control knob slightly and turn clockwise to “OFF”.

Wait ve (5) minutes to clear out any gas. Then smell for

gas, including near the oor. If you smell gas, STOP! Follow “B” in the safety information above (to the left)

on this label. If you do not smell gas, go to the next step.

8. Turn the gas control knob counterclockwise to

“ON”.

9. Replace control access panel.

10. Turn on all electric power to the appliance.

11. Set thermostat to desired setting.

12. If the appliance will not operate, follow the instructions

“TO TURN OFF GAS TO APPLIANCE” and call your service technician or gas supplier.

4. Push in gas control knob slightly and turn

clockwise

to “OFF”. Do not force.

5. Replace control access panel.

Finned copper tube gas boilers & water heaters – Boiler Manual

CHECKING & ADJUSTMENTS

Pilot Adjustment

e pilot burner ame should envelope 3/8 in to 1/2 in,

9.5 mm to 12.7 mm of the ame sensing probe, Figure 11. To adjust the pilot the following steps must be taken:

1. Remove the pilot gas pressure regulator cap.

2. Turn the pressure regulator adjustment screw clock-wise to decrease the ame and counterclockwise to increase it.

3. Replace the pressure regulator adjustment screw cap.

Figure 11 Pilot Flame Adjustment

RIOM-48

Gas Pressure Adjustment

Input Rate, Natural Gas

Gas appliances are rated based on sea level operation with no adjustment required at elevations up to 2000 , 610 m. At elevations above 2000 , 610 m, input ratings should be reduced by 4% for each additional 1000 , 305 m.

Check the input rate as follows:

1. Turn o all other gas appliances that use the same gas meter as the boiler/water heater.

2. Call your gas supplier and ask for the heating value of the gas.

3. Start the boiler/water heater and let it run for 15 minutes.

4. Using the gas meter and a stopwatch, clock the time that it takes to burn 10 

5. Insert the heating value and the time, in seconds, into the formula below.

6. Input = (heating value, Btu/hr)(3600)/(time, seconds)

7. If the computed rate deviates by more than 5% from the rated input value of the unit adjust the manifold pressure accordingly. DO NOT adjust the manifold pressure by more than 5%. If a proper rate cannot be maintained without adjusting the manifold pressure beyond the 5% limit, the main burner orices must be replaced. If the input rate is too low, go to the next larger size of main burner orices. If the input rate is too high, go to the next smaller size.

0.28m3 of gas and divide this time by 10.

Never increase the input to the boiler/water heater

above that for which it is rated. Doing so can cause premature failure of the unit!

e maximum inlet gas pressure listed on the rating

plate must not be exceeded or damage to the boiler/ water heater may occur!

e minimum supply pressure listed on the rating plate is for input adjustment.

NATUL GAS: Optimum results are obtained when the boiler/ water heater is operated at its full input rating, with 3.8into4.2in,

96.5 mm to 106.7 mm WC of manifold pressure. e manifold pressure should not vary outside this range. e gas valve pressure regulator has been preset at the factory. If adjustment is necessary the following steps must be followed:

1. Aach a 20 in, 508 mm WC manometer to the tap on the

manifold.

2. Remove the regulator adjustment screw cap from the gas regulator. On systems that do not use a separate gas regulator, remove the adjustment screw cap from the gas valve body on the valve closest to the gas supply piping.

3. Rotate the regulator adjustment screw clockwise to increase the manifold pressure, counterclockwise to decrease it.

4. Replace the regulator adjustment screw cap and manifold pressure tap plug.

Never force the regulator adjustment screw beyond

the stop limits or damage to the regulator will occur!

PROPANE GAS: A manifold pressure of 11 in, 279 mm WC must be maintained for proper operation of the boiler. If the manifold pressure is o by more than 5% adjust it according to steps 1 through

CONTROL DESCRIPTION

Low Water Cuto

If the boiler is to be installed above radiation or if required by other codes or regulations, install a low water cuto in appropriate piping.

If installed, ensure that the low water cuto device(s) function properly. Test in accordance with the manufacturer’s instructions included with the device(s).

Boiler Thermostat

If a thermostat is to be used to control the boiler always follow the instructions included with the thermostat. Proper location of the thermostat will ensure ecient trouble-free operation of the boiler. Mount the thermostat to an inside wall at a height approximately ve feet above the oor.

Avoid placing the thermostat in areas that will not provide an accurate measurement of the room temperature. Locating the thermostat behind a door, in an alcove, close to a source of thermal radiation or in a dray area will cause poor or sporadic heating.

For a thermostat that employs an adjustable heat anticipator, adjust the anticipator to match the current measured in the thermostat circuit. An increased anticipator seing may be necessary if the unit cycles frequently. If the room temperature over-shoots the thermostat seing, reduce the anticipator seing.

Finned copper tube gas boilers & water heaters – Boiler Manual

Operating Control

Per DOE mandate, the operating control incorporates an automatic means (thermal purge) of adjusting the boiler water temperature for hot water heating. e preferred control seing for potable hot water is 130°F, 54°C. e operating control should be set to the lowest seing that will satisfy the consumer's needs.

Seing the thermostat or operating control too high

can result in scalding resulting in severe personal injury!

Servicing , inspection and adjustment must be done by

a trained technician in accordance with all applicable local and national codes. Improper servicing or adjustment can damage the boiler/water heater!

e ceramic combustion chamber contains crystalline

silica. Wear a tightly ed dust mask when removing the burners or heat exchanger to prevent inhalation of airborn bers. Crystalline silica bers have been identied as carcinogenic, or possibly carcinogenic when inhaled.

High Limit (Aquastat)

e high limit is located in the top control area of the boiler/water heater. A remote capillary bulb is run to a well on the outlet side of the supply header.

e water heater high limit should be set a minimum of 20°F, 11°C higher than the operating control. Refer to the HOT WATER SUPPLY section for the proper supply water temperature.

Flow Switch

A ow switch is provided in the water outlet piping to prevent the boiler/water heater from ring without adequate water ow through the heat exchanger.

MAINTENANCE

Disconnect electrical power and close the manual gas

shut o valve before performing maintenance or severe personal injury may result!

Improper installation, adjustment, alteration, service

or maintenance can cause property damage, personal injury, exposure to hazardous materials or loss of life. Installation and service must be performed by a qualied installer, service agency or the gas supplier who must read and follow the supplied instructions before installing, ser vicing or removing this boiler. is boiler contains crystalline silica materials that have been identied as carcinogenic or possibly carcinogenic to humans when inhaled.

AVERTISSMENT: Une instqallation, un réglage, une

réparation ou un entretien non comforme aux normes peut entraîner des dommages matériels, des blessures,exposition à des matiéres dangereuses ou la mort. L’installation et l’entretien doivent être eectués par un installateur ou un service d’entretien qualié ou le foumisseur de gaz qui doivent avoir lu les instructions foumies avant de faire l’installation, l’entretien ou l’enlèvement de la chaudière et les respecter, Cee chaudière contient des matériaux qui ont été identiés comme étant cancérogènes ou pouvant l’être.

e boiler/water heater should be cleaned and inspected once a year and before each heating season. Make sure that the burners and ignition components are free from dust, soot, dirt, corrosion or other deposits that would impair the boiler’s performance. Refer to page 24 for component identication.

Improper burner servicing can result i

burner failure voiding the warranty!

n premature

Burner Drawer & Burner Removal

1. Close the manual shuto valves in the gas supply lines and turn o electrical power to the boiler/water heater.

2. Disconnect the gas train from the gas supply piping at the ground joint union.

3. Remove the ame roll-out shield.

4. Remove the two screws that aach the burner drawer to the base panel, Figure 12.

5. Disconnect the electrical wires going to the gas valve and burner drawer.

6. On intermient pilot models disconnect the ignition cable from the ignition module.

7. Pull the burner drawer out until the burners are fully exposed.

8. Inspect each burner for damage or signs of deterioration. Use a brush or compressed air to remove any debris from the burner ports.

9. DO NOT install damaged or badly corroded burners, replace them.

10. Reinstall the burner drawer and ame roll-out shield following the removal steps in reverse order.

11. Reconnect all electrical wires.

12. Reconnect the gas piping.

Figure 12 Burner Drawer Assembly

RIOM-55

Finned copper tube gas boilers & water heaters – Boiler Manual

Combustion Chamber Inspection

NORMAL

(HARD FLAME)

LIFTING

(TOO MUCH AIR)

YELLOW TIPPING

(MARGINAL)

YELLOW FLAME

(TOO LITTLE AIR)

1. Remove the burner drawer following the instructions above.

2. Inspect the combustion chamber panels using a mirror and light. If any of the combustion chamber panels are damaged or show signs of deterioration replace them.

3. Replacement of the combustion chamber panels requires that the heat exchanger be removed as outlined below.

4. Reinstall the burner drawer as outlined above.

Heat Exchanger Inspection & Cleaning

1. Close the manual shuto valve in the gas supply line and turn o electrical power to the boiler/water heater.

2. Close the shut o valves in the inlet and outlet piping. Relieve the system pressure from the boiler/water heater by carefully opening the drain valve.

3. Disconnect the boiler/water heater from the system piping.

4. Remove the le and right headers and mounting studs.

5. Disconnect the ue pipe at the boiler/water heater.

6. Remove the top jacket panel.

7. On indoor units remove the dra hood from the back of the unit. On outdoor units remove the rear jacket panel.

8. Remove the ue collector.

9. Carefully li the heat exchanger out of the unit and thoroughly inspect it.

10. e outside surfaces of the copper tubes should be free of any soot deposits. A slight black smudge is normal with some types of gases. Black soot indicates poor combustion. Green deposits indicate condensation due to low return water temperatures. In either case the heat exchanger must be cleaned thoroughly with water and the problem resolved before the boiler/water heater is returned to service.

11. Replace the cleaned heat exchanger and other components in the reverse order of their removal.

12. e torque values for the Spectum header bolts are all the same: 17-20 . lbs. the bolts should be fastened then tightened in the following sequence:

1) Middle Top

2) Middle Boom

3) Right Top

4) Le Boom

5) Le Top

6) Right Boom

Vent System

oroughly inspect the vent system for any signs of blockage, corrosion or leakage. Immediately replace any unsound vent system piping.

Controls

Use the “GENEL OPETION” and “CHECKING AND ADJUSTMENTS” sections of this manual for reference.

1. Check the thermostat or operating controls for proper operation.

2. A oat type low water cuto device must be ushed out per the manufacturers’ instructions. e probe on a probe low water cut o must be removed, cleaned and inspected at least once a year. Ensure that the low water cutos operate properly. If not, replace them.

3. e ow switch contacts must be open when water ow is not present.

4. e relief valve should not weep or discharge water at normal system pressure. If it does contact a qualied service technician to have it inspected. NEVER try to clean or repair the relief valve! If the valve fails to operate properly, have it replaced!

5. e aquastat high limit controls the maximum water temperature in the boiler. It should be set at least 20°F, 11°C above the operator set point. If the water temperature reaches the set temperature before the demand for heat has been met, the aquastat high limit should shut the boiler o. e water temperature should never exceed the maximum set 240°F, 116°C. e aquastat high limit cannot be repaired. If it fails to function properly, replace it.

6. Visually check the pilot and main burner ames to ensure proper operation, see Figures 11 & 13.

Yellow, oating ames indicate a lack of combustion

air. A liing ame indicates too much combustion air. Do not operate the boiler until the problem is solved or severe personal injury or death may occur!

Figure 13 Main Burner Flames

point of

Heat Exchanger Replacement

1. Sagging or distorted heat exchanger tubes are an indication of low water ow through the system.

2. A damaged heat exchanger must be replaced and the condition that caused the damage resolved before the boiler/water heater

is returned to service.

RIOM-49

Finned copper tube gas boilers & water heaters – Boiler Manual

REPAIR PARTS

Figure 14 Replacement Parts

Finned copper tube gas boilers & water heaters – Boiler Manual

REPAIR PARTS (ConTinued)

Model Size with Item Quantities Below

Ref # Name of Part Part # 100 150 200 250 300 350 400

1 Combustion Chamber Base Assembly

(Outdoor) 70-1222 1

Combustion Chamber Base Assembly

Combustion Chamber Rear Panel

Combustion Chamber Front Panel

Combustion Chamber Side Panel, Left & Right

2 Rear Refractory Panel

3 Upper Refractory Channel 03-0884 2 2 2 2 2 2 2 4 Side Refractory Panel, Left & Right 05-0033 2 2 2 2 2 2 2

5 Front Refractory Panel

70-1221 1

70-1223 1 70-1224 1 70-1225 1 70-1226 1 70-1227 1 70-1240 1 70-1241 1 70-1242 1 70-1243 1 70-1244 1 70-1245 1 70-1246 1 03-0886 1 03-0887 1 03-0888 1 03-0889 1 03-0890 1 03-0891 1 03-0892 1 03-0894 1 03-0895 1 03-0896 1 03-0897 1 03-0898 1 03-0899 1 03-0900 1

03-0901 2 2 2 2 2 2 2 05-0035 1 05-0036 1 05-0037 1 05-0038 1 05-0039 1 05-0040 1 05-0041 1

05-0043 1 05-0044 1 05-0045 1 05-0046 1 05-0047 1 05-0048 1 05-0049 1

Finned copper tube gas boilers & water heaters – Boiler Manual

REPAIR PARTS (ConTinued)

Model Size with Item Quantities Below

Ref # Name of Part Part # 100 150 200 250 300 350 400

2, 4, 5 Tile Kit

7 Flue Collector

8 Jacket Rear Panel

9 Draft Hood Assembly

10 Jacket Rear Panel (Outdoor)

11 Jacket Left Side Panel 03-0774 1 1 1 1 1 1 1 12 Jacket Right Side Panel 03-0775 1 1 1 1 1 1 1

13 Jacket Front Panel

70-1554K 70-1555K 70-1556K 70-1557K 70-1558K 70-1559K 70-1560K

70-1256 1 70-1257 1 70-1258 1 70-1259 1 70-1260 1 70-1261 1 70-1262 1 03-0749 1 03-0750 1 03-0751 1 03-0752 1 03-0753 1 03-0754 1 03-0755 1 70-1272 1 70-1273 1 70-1274 1 70-1275 1 70-1276 1 70-1277 1 70-1278 1 03-0719 1 03-0720 1 03-0721 1 03-0722 1 03-0723 1 03-0724 1 03-0725 1

03-0767 1 03-0768 1 03-0769 1 03-0770 1 03-0771 1 03-0772 1 03-0773 1

Finned copper tube gas boilers & water heaters – Boiler Manual

REPAIR PARTS (ConTinued)

Model Size with Item Quantities Below

Ref # Name of Part Part # 100 150 200 250 300 350 400

14 Jacket Upper Front Panel

15 Jacket Front Panel (Outdoor)

16 Outdoor Hood Assembly

NS Vent Cap & Collar Kit (Outdoor)

17 Jacket Top Panel

NS Jacket Top Panel (Outdoor)

18 Spill Switch 14-0226 1 1 1 1

03-0757 1 03-0758 1 03-0759 1 03-0760 1 03-0761 1 03-0762 1 03-0763 1 03-0727 1 03-0728 1 03-0729 1 03-0730 1 03-0731 1 03-0732 1 03-0733 1 70-1213 1 70-1214 1 70-1215 1 70-1216 1 70-1217 1 70-1218 1 70-1219 1 09-0121 1 09-0122 1 09-0123 1 09-0124 1 1 09-0125 1 09-0126 1 03-0741 1 03-0742 1 03-0743 1 03-0744 1 03-0745 1 03-0746 1 03-0747 1 70-1205 1 70-1206 1 70-1207 1 70-1208 1 70-1209 1 70-1210 1 70-1211 1

Finned copper tube gas boilers & water heaters – Boiler Manual

REPAIR PARTS (ConTinued)

Model Size with Item Quantities Below

Ref # Name of Part Part # 100 150 200 250 300 350 400

19 Flame Roll-Out Switch 14-0225 1 1 1 1

20 Tube Bundle (Copper)

Tube Bundle (Cupronickel)

NS O Ring, Inlet/Outlet & Return Headers 06-0001 16 16 16 16 16 16 16 NS Nut, Inlet/Outlet & Return Headers 57-0492 12 12 12 12 12 12 12 NS Stud, Inlet/Outlet & Return Headers 57-0220 12 12 12 12 12 12 12

Inlet/Outlet Header, Cast Iron

Inlet/Outlet Header, Bronze NS Inlet/Outlet Header, Cast Iron (Mod) NS Inlet/Outlet Header, Bronze (Mod) NS Inlet/Outlet Header, Bronze (4 Pass) NS

Inlet/Outlet Header Bronze (Pool Heater) (Canada Only)

Return Header, Cast Iron

Return Header, Bronze NS Return Header, Bronze (4 Pass) 24 Return Cover (Outdoor) 03-0737 1 1 1 1 1 1 1

NS Heat Exchanger “V” Bae

25 Flame Roll-Out Shield

26 Burner Tube, Stainless Steel 10-0251 2 3 4 5 6 7 8

70-1312 1 70-1313 1 70-1314 1 70-1315 1 70-1316 1 70-1317 1 70-1318 1 70-1320 1 70-1321 1 70-1322 1 70-1323 1 70-1324 1 70-1325 1 70-1326 1

01-0008S 01-0010.1 01-0008M 01-0010M

01-0010-1.1

01-00275

01-0009S 01-0011.1

01-0011-1.1

03-0869 7 03-0870 7 03-0871 7 03-0872 7 03-0873 7 03-0874 7 03-0875 7 03-0904 1 03-0905 1 03-0906 1 03-0907 1 03-0908 1 03-0909 1 03-0910 1

1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

Finned copper tube gas boilers & water heaters – Boiler Manual

REPAIR PARTS (ConTinued)

Model Size with Item Quantities Below

Ref # Name of Part Part # 100 150 200 250 300 350 400

27 Manifold

Gas Valve, VR8304M, Int, NG 11-0056 1 1 1 1 1 1 1

Gas Valve, VR8304M, Int, LP 70-1076 1 1 1 1 1 1 1 Gas Valve, VR8304Q, NG (2-Stage) 11-0084 1 1 1 1 1 1 1 Gas Valve, VR8304Q, LP (2-Stage) 70-1579 1 1 1 1 1 1 1 Ignitor, PSE-NA29, NG 70-9019 1 1 1 1 1 1 1

Ignitor, PSE-NA29, LP 70-9020 1 1 1 1 1 1 1

NS Thermocouple, Q309A 10-0211 1 1 1 1 1 1 1

Ignition Module, S9361A (SB) 16-0061 1 1 1 1

Ignition Module, S9361A (SB On/O) 16-0051 1 1 1 1 1 1 1 Ignition Module, S8610M (SB 2-Stage) 16-0054 1 1 1 Ignition Module S8610M (SW) 16-0054 1 1 1 1 1 1 1

31 Transformer, 50 VA 15-0007 1 1 1 1 1 1 1

High Limit, EMf-1, (SB) 14-0118 1 1 1

High Limit, EMF-5, (SB) 14-0009 1 1 1 1 High Limit, EMf-1, (SW) 14-0116 1 1 1 High Limit, EMf-5, (SW) 14-0008 1 1 1 1 Operator, EMf-1, (SB) 14-0118 1 1 1 1 1 1 1

Operator, EMf-23, (SB) 2-Stage 14-0007 1 1 1 1 1 1 1 Operator, EMf-1, (SW) 14-0116 1 1 1 1 1 1 1 Operator, EMf-23, (SW) 2-Stage 14-0010 1 1 1 1 1 1 1 Operator, T6031A

Inlet Thermometer 14-0004 1 1 1 1 1 1 1

Outlet Thermometer 14-0004 1 1 1 1 1 1 1 NS Thermometer Well, 3/8 x 2 13-0102 2 2 2 2 2 2 2 NS High Limit Well, 3/8 x 3 13-0104 2 2 2 2 2 2 2

33 High Limit/Operator Knob 14-0120 1 1 1 1 1 1 1 34 Light Package 40-0052 1 1 1 1 1 1 1

35 Relay, 24VAC 15-0113 1 1 1 1 1 1 1 NS Pressure Relief Valve 30# 13-0004 1 1 1 1 1 1 1 NS Pressure Relief Valve 125# 30-0364 1 1 1 1 1 1 1 NS Flow Switch 14-0203 1 1 1 1 1 1 1 NS Flow Switch (Outdoor) 14-0205 1 1 1 1 1 NS Flow Switch (Potter) 14-0201 1 1 1 1 1 1 1 NS Flow Switch (Potter Outdoor) 14-0202 1 1 1 1 1 1 1 NS Tridicator (SB) 13-0308 1 1 1 1 1 1 1 NS Tridicator (SW) 13-0305 1 1 1 1 1 1 1

37 On/O Switch 48-0010 1 1 1 1 1 1 1

(pool heater) (Canada Only)

10-0452 1 10-0453 1 10-0454 1 10-0455 1 10-0456 1 10-0457 1 10-0458 1

14-0003 1 1 1 1 1 1 1

Finned copper tube gas boilers & water heaters – Boiler Manual

REPAIR PARTS (ConTinued)

Model Size with Item Quantities Below

Ref # Name of Part Part # 100 150 200 250 300 350 400

Orice, #30, NG 10-0035 2 3 4 5 6 7 8

Orice, #31 (2,000 ft - 3,999 ft), NG 10-0036 2 3 4 5 6 7 8 Orice, #32 (4,000 ft - 5,999 ft), NG 10-0037 2 3 4 5 6 7 8 Orice, #34 (6,000 ft - 7,999 ft), NG 10-0043 2 3 4 5 6 7 8 Orice, #47, LP 10-0038 2 3 4 5 6 7 8 Orice, #49 (2,000 ft - 3,999 ft), LP 10-0040 2 3 4 5 6 7 8 Orice, #50 (4,000 ft - 5,999 ft), LP 10-0041 2 3 4 5 6 7 8

Orice, #51 (6,000 ft - 7,999 ft), LP 10-0042 2 3 4 5 6 7 8 NS Rating Plate 82-0054 1 1 1 1 1 1 1 NS Paint 66-0013 1 1 1 1 1 1 1

Vent Termination Hood 4 in 09-0134 1 1 1 1

Vent Termination Hood 6 in 09-0112 1 1 1

Vent Damper 5 in 09-0007 1

Vent Damper 6 in 09-0008 1

Vent Damper 7 in 09-0009 1

Vent Damper 8 in 09-0010 1 1

Vent Damper 9 in 09-0012 1

Vent Damper 10 in 09-0011 1

NS Combustible Floor Pan

70-1248 1 70-1249 1 70-1250 1 70-1251 1 70-1252 1 70-1253 1 70-1254 1

Finned copper tube gas boilers & water heaters – Boiler Manual

Commonwealth of Massachusetts

NOTICE!

Installation Requirements MACODE-3

In the Commonwealth of Massachusetts, the

installation must be performed by a licensed plumber or gas tter.

1. For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above nished grade, in the area of the venting, including but not limited to decks and porches, the following requirements shall be satised:

d. INSTALLATION OF CARBON MONOXIDE DETECTORS. At the

time of installation of the side wall horizontal vented gas fueled equipment, the installing plumber or gastter shall observe that a hard wired carbon monoxide detector with an alarm and battery back-up is installed on the oor level where the gas equipment is to be installed. In addition, the installing plumber or gastter shall observe that a battery operated or hard wired carbon monoxide detector with an alarm is installed on each additional level of the dwelling, building or structure served by the side wall horizontal vented gas fueled equipment. It shall be the responsibility of the property owner to secure the services of qualied licensed professionals for the installation of hard wired carbon monoxide detectors.

i. In the event that the side wall horizontally vented gas

fueled equipment is installed in a crawl space or an attic, the hard wired carbon monoxide detector with alarm and battery back-up may be installed on the next adjacent oor level.

ii. In the event that the requirements of this subdivision can

not be met at the time of completion of installation, the owner shall have a period of thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30) day period, a battery operated carbon monoxide detector with an alarm shall be installed.

e. APPROVED CARBON MONOXIDE DETECTORS. Each carbon

monoxide detector as required in accordance with the above provisions shall comply with NFPA 720 and be ANSI/UL 2034 listed and IAS certied.

f. SIGNAGE. A metal or plastic identification plate shall be

permanently mounted to the exterior of the building at a minimum height of eight (8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or equipment. The sign shall read, in print size no less than one-half (1/2) inch in size, “GAS VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OBSTRUCTIONS”.

g. INSPECTION. The state or local gas inspector of the side wall

horizontally vented gas fueled equipment shall not approve the installation unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in accordance with the provisions of 248 CMR 5.08(2)(a)1 through 4.

Improper venting can result in excessive levels of

carbon monoxide which can cause severe personal injury or death!

2. Exemptions — The following equipment is exempt from 248 CMR 5.08(2)(a) 1 through 4:

a. The equipment listed in Chapter 10 entitled “Equipment Not

Required To Be Vented” in the most current edition of NFPA 54 as adopted by the Board; and

b. Product Approved side wall horizontally vented gas fueled

equipment installed in a room or structure separate from the dwelling, building or structure used in whole or in part for residential purposes.

3. MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM PROVIDED.

a. When the manufacturer of Product Approved side wall

horizontally vented gas equipment provides a venting system design or venting system components with the equipment, the instructions provided by the manufacturer for installation of the equipment and the venting system shall include:

i. Detailed instructions for the installation of the venting

system design or the venting system components; and

ii. A complete parts list for the venting system design or

venting system.

4. MANUFACTURER REQUIREMENTS – GAS EQUIPMENT VENTING SYSTEM NOT PROVIDED.

a. When the manufacturer of a Product Approved side wall

horizontally vented gas fueled equipment does not provide the parts for venting the flue gases, but identifies “special venting systems”, the following requirements shall be satised by the manufacturer:

i. The referenced “special venting system” instructions shall

be included with the appliance or equipment installation instructions; and

ii. The “special venting systems” shall be Product Approved

by the Board, and the instructions for that system shall include a parts list and detailed installation instructions.

5. A copy of all installation instructions for all Product Approved

side wall horizontally vented gas fueled equipment, all venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance or equipment at the completion of the installation.

Improper venting can result in excessive levels of

carbon monoxide which can cause severe personal injury or death!

LIMITED WARRANTY

Boilers/Water Heaters

Industrial, Commercial and Other Non-Residential Use

e “Manufacturer” warrants to the original owner at the original installation site that the heat exchanger of the Industrial, Commercial, and other Non-Residential Use Boiler (the “Product”) will be free from defects in material or workmanship for ten (10) years from the date of installation. Additional twenty one (21) year thermal shock warranty on heat exchanger. If upon examination by the Manufacturer the Product is shown to have a defect in material or workmanship during the warranty period, the Manufacturer will repair or replace, at its option, that part of the Product which is shown to be defective. All other RBI supplied Boiler/Water Heater parts are warranted against defects in material and workmanship for one (1) year from date of installation or 18 months from date of shipment from RBI.

e “Manufacturer” warrants to the original owner at the original installation site that the heat exchanger of the Industrial, Commercial, and other Non-Residential Use Water Heater (the “Product”) will be free from defects in material or workmanship for five (5) years from the date of installation. Additional twenty one (21) year thermal warranty on heat exchanger. If upon examination by the Manufacturer the Product is shown to have a defect in material or workmanship during the warranty period, the Manufacturer will repair or replace, at its option, that part of the Product which is shown to be defective. All other RBI supplied Boiler/Water Heater parts are warranted against defects in material and workmanship for one (1) year from date of installation or 18 months from date of shipment from RBI.

is limited warranty does not apply: (a) if the Product has been subjected to misuse or neglect, has been accidentally or intentionally damaged, has not been installed,

maintained or operated in accordance with the furnished wrien instructions, or has been altered or modied in any way.

ese include but not limited to:

• Excessivewaterhardnesscausingalimebuild-upintheheatexchangertubesisnotafaultoftheequipmentandisnotcovered

under the manufacturer’s warranty.

• Excessivepiingand erosionon the insideoftheheatexchangertubes causedbyhighwatervelocitythroughthetubes and

is not covered by the manufacturer’s warranty. (See Installation Instructions for proper pump performance.)

• Chemical corrosion,nocorrosivechemical(freon,dry cleaningchemicals,degreasingliquids,chlorine oranychemicalsthat

produce hydrochloric acid) can be present in the boiler room as it rapidly destroys the heating equipment and voids the warranty.

• Allcoppernboilersshouldnotoperatewithareturnwatertemperaturelessthan110°F,43°Catmosphericcombustion,125°F,52°Cfan

assist combustion. If a lower temperature is required, an external bypass should be installed to prevent condensation. e manufacturer’s warranty does not cover damage done by condensation.

(b) to any expenses, including labor or material, incurred during removal or reinstallation of the Product or

parts thereof. (c) to damage as a result of selement, distortion, collapse, or cracking of any foundation area, beams or pipes surrounding the Product. (d) to any workmanship of any installer of the Product; or to Products installed outside the continental United States or Canada.

is limited warranty is conditional upon: (a) shipment, to the Manufacturer, of that part of the Product thought to be defective. Goods can only be returned with prior wrien

approval from the Manufacturer. All returns must be freight prepaid. (b) determination in the reasonable opinion of the Manufacturer that there exists a defect in material or workmanship.

Repair or replacement of any part under this Limited Warranty shall not extend the duration of the warranty with respect to such repaired or replaced part beyond the stated warranty period.

THIS LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EITHER EXPRESS OR IMPLIED, AND ALL SUCH OTHER WARRANTIES, INCLUDING WITHOUT LIMITATION IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED AND EXCLUDED FROM THIS LIMITED WARRANTY. IN NO EVENT SHALL THE MANUFACTURER BE LIABLE IN ANY WAY FOR ANY CONSEQUENTIAL, SPECIAL, OR INCIDENTAL DAMAGES OF ANY NATURE WHATSOEVER, OR FOR ANY AMOUNTS IN EXCESS OF THE SELLING PRICE OF THE PRODUCT OR ANY PARTS THEREOF FOUND TO BE DEFECTIVE. THIS LIMITED WARRANTY GIVES THE ORIGINAL OWNER OF THE PRODUCT SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH MAY VARY BY EACH JURISDICTION.

260 North Elm Street 7555 Tranmere Drive Westeld, MA 01085 Mississauga, Ontario L5S 1L4 Canada Phone: (413) 568-9571 Phone: (905) 670-5888 Fax: (413) 568-9613 Fax: (905) 670-5782

www.rbiwaterheaters.com

RBI Spectrum series Installation And Operation Instructions Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
