Variable Speed
Pool and Spa Pumps
PS165VSP- VARIABLE SPEED PUMP
• High performance, medium head variable speed pump.
• Self priming pump. Motor will run for 3 minutes at
3450rpm. After priming mode is complete, pump will
start at the user programmed speed.
• Robust mechanical shaft seal allows pump to
accidentally run dry for up to 1 hour.
• Easy to program variable speed controller complete
with a built in 24 hour timer. Allows up to 3 program
modes; cleaner cycle, low rpm filtration cycle, high
speed or o≠ cycle. Less than 5 minutes to program.
• Override button for full pump control without
interrupting 24 hour program cycle. 24 hour program
runs invisibly in the background and resumes once
override function is complete.
• Programming will stay intact during power outage.
Pump will automatically resume operation at beginning
of the program when power is restored.
• Built-in freeze protection, runs pump at 2600rpm for 8
hours when ambient drops below 39°F.
• Compatible with most major automation controllers.
See I/O manual for wiring instructions.
Remote Controller
•
(optional)
: Same controller used on
the PS270VSP. View advanced diagnostic information,
remote mount controller. Ability to perform advanced
programming. Uses RS485 connection.
Limited Warranty:
•
2 years from date of installation.
See
actual warranty.
RPM MAX POWER CONSUMPTION
3450 1500W
3100 1175W
2850 930W
2600 720W
2350 540W
2100 395W
1850 280W
1600 195W
1350 130W
1100 80W
850 45W
600 35W
PS270VSP- VARIABLE SPEED PUMP
• High performance, medium head variable speed pump.
• Self priming pump. Motor will run for 1 minute at
2600rpm
(programmable)
. After priming mode is
complete, pump will start at the user programmed
speed.
• Robust mechanical shaft seal allows pump to
accidentally run dry for up to 1 hour.
• Easy to program variable speed controller complete
with a built-in “real time” clock. Allows up to 3 program
modes; cleaner cycle, low rpm filtration cycle, high
speed or o≠ cycle. Less than 5 minutes to program.
• Programming will stay intact during power outage.
Pump will automatically resume operation when power
is restored.
RPM MAX POWER CONSUMPTION
3450 2400W
3100 1780W
2850 1400W
2600 1075W
2350 800W
2100 590W
1850 420W
1600 290W
1350 190W
1100 120W
850 70W
600 40W
• Built-in freeze protection, runs pump at 2600rpm for 8
hours when ambient drops below 39°F
(programmable).
• View diagnostic fault codes to help with trouble
shooting.
• Controller can be remotely mounted away from pump.
Uses RS485 connection.
• Ability to view motor speed and power in real time.
• Adjust motor speeds in 25rpm increments.
• Adjustable screen contrast.
• Power saver override button, runs on low speed. High
speed override button for cleaning and service.
Limited Warranty:
•
2 years from date of installation.
See
actual warranty.
HOW A VARIABLE SPEED PUMP SAVES YOU MONEY
Work Smarter, Not Harder
The Raypak Professional series VS pumps allow you to tailor fit your
pump to your pools requirements. No longer are homeowners locked
into a one size fits all pool pump. Your service technician can adjust the
Raypak pump to run at a lower speed for a longer length of time, allowing
you to save BIG money while your pool stays sparkling clear. It can also
be set to run at higher speeds for your automatic pool cleaner then dropping to a low speed for the remainder of the filtration cycle. Below is a
simple explanation that shows you how a Raypak VS pool pump really
can save you money!
Goal:
24 hours (1 turn).
Pool Gallons:
kW/hr Cost:
Completely filter the total water volume in the pool every
30,000
0.20
Pump
type
1HP Single
Speed
Variable
Speed
Pump
GPM
Pump
GPH
Hours
for 1 turn
Pump
55 3300 9.09 3450 1.35 12.27 $2.46 $895
32 1920 15.63 1850 0.28 4.38 $0.87 $319
RPM
kW
per hour
Total kW
per day
Cost
per day
Cost
per year
Savings per year . $576
1HP pump takes just over 9 hours for 1 turn using 1.35kWh at a cost of $2.46 a day.
Raypak VS pump takes just over 15 hours for 1 turn using .28kWh at a cost of $0.87 a day.
The Raypak VS pump runs just under
INSTALLATION FLEXIBILITY
twice as long
, but at
1/5th the cost per kWh!
3rd Party Remote Compatible
The Raypak Professional series VS pumps can communicate with most 3rd party remote systems. The pump comes with input ability for up to 4 separate channels. Also
standard is an RS485 connection.
Optimized Performance with Raypak Heat Pump Pool Heaters
Enjoy hassle free connectivity with current Raypak analog and digital heat pumps. If
you don’t have a remote system to control your heater and pump, the Raypak heat
pumps have the ability to let the pump know when there is a call for heat and turn
the pump on to the proper heating speed for maximum energy savings.
2 Year Warranty- Parts and Labor
As with all Raypak products, we stand behind what we sell. We back all of our Professional series pumps with a 2 year parts and labor limited warranty for both residential
and commercial applications. Even the seal is covered for normal wear and tear.
actual warranty for details.)
(See
THE HEART AND SOUL OF THE PROFESSIONAL PUMP
CLEAR LID
Allows for easy
viewing of strainer
basket.
2” PVC
CONNECTION
Industry standard, allows
for glue and go installation.
DRAIN PLUG
Easy winterization.
COOLING
STRAINER BASKET
Bright white basket allows
for excellent contrast when
viewing debris.
IMPELLER
Di-electric shaft sleeve for
absolute electrical isolation.
Precision balanced for
smooth operation.
SEAL
Robust industry
leading seal design.
FAN
IT’S THE LITTLE DETAILS THAT MAKE A BIG DIFFERENCE
Oversized Mechanical Shaft Seal
The Raypak Professional series pumps utilize a heavy duty shaft seal with an industry leading design and
the highest quality materials. The Achilles heal of most swimming pool pump designs is an unforgiving main
shaft seal. Run it dry and the wet end is lost. With the Raypak Professional pump, it can withstand dry running longer than any other pump. This built in forgiveness allows the homeowner and the dealer peace of
mind. In the event a seal would ever need replacing, they are readily available and priced equal to other
pool pump seals.
RAYPAK SEAL
2
7.1"
16.6"
17.0"
12.1"
12.7"
13.6"
8.9"
4.3"
6.8"
0.4"
5.1"
6.9"
9.7"
28.0"
16.6"
17.0"
12.1"
12.7"
13.6"
8.9"
4.3"
6.8"
0.4"
5.1"
6.9"
9.7"
TM
Technical Data
Professional Pool Pumps
PS165VSP - 1.65THP Variable Speed Pump
PS270VSP - 2.70THP Variable Speed Pump
Model THP Volts Amps
PS165VSP 1.65 208-230 11.0 2” 41
PS270VSP 2.70 230 10.5 2” 52
Raypak, Inc. 2151 Eastman Avenue, Oxnard, CA 93030, (805) 278-5300. Fax (800) 872-9725 www.raypak.com
Litho in U.S.A. ©2012-2013 Raypak, Inc. Catalog No. 6200.18A Effective: 01-01-2013
Water
Connection
Shipping
Weights (lbs)
