Raypak 1000-10 Parts List

CATALOG NO. 9300.73
Effective: 07-15-06
Replaces: 05-10-06

THE PARTS LISTED ARE FOR STANDARD EQUIPMENT FOR THIS MODEL TYPE. RAYPAK RESERVES
THE RIGHT TO SUBSTITUTE, DELETE OR CHANGE ANY PART WITHOUT NOTIFICATION. THE
ADDITION OF OPTIONS MAY ALSO CHANGE SOME OF THE PARTS. ORDER REPLACEMENT PARTS
FROM ACTUAL HEATER COMPONENTS.

Raypak, Inc., 2151 Eastman Avenue, Oxnard, CA 93030

[phone] Fax [phone]

Litho In U.S.A.

RAYPAK ILLUSTRATED PARTS LIST

FOR DETAILED INSTRUCTIONS, SEE "HOW TO USE YOUR RAYPAK ILLUSTRATED PARTS LIST",
CATALOG NO. 9001.10

COMMERCIAL
CHX (CONDENSING HEAT EXCHANGER)

MODEL SIZES: 500, 750, 1000, 1500
MODEL TYPE: CHX

DATE OF MANUFACTURE: 2004 THRU CURRENT
