Ray Displays Ray User Manual
Table of C o n t e n t s
1 The Ray Pico Projector
Installation Preparation
2 Ray Box Contents
3 Ray Features
4 Getting Started with Ray
Basic Connections
Setup Information
5 Watching Videos
5 Connecting Equipment
8 Charging Ray
8 Specification
9 Safety and Cleaning
Handling Ray
Repairing Ray
10 Using the Ray USB Power Adapter
11 Important Maintenance & Operating Information
12 Regulation Compliance
13 Battery Replacement
14 Disposal and Recycling Information
15 Warranty
i
The
Ray
Pico Projector
Congratulations on choosing the
Ray
Projector Display. Thank
you for your support. For optimum benefits, please read the
instruction manual carefully before using the
Ray Projector
and
keep it for future reference. Heed all warnings and follow all
instructions. We hope you will be fully satisfied and enjoy the
Ray Pico Protector
to share your videos, photos and
presentations with friends and business associates anywhere,
any time. The small battery operated
Ray Pico Projector
,
convenient to store and carry on business/personal trips,
produces a large 60 inch picture for excellent viewing.
Installation Preparation:
For best results it is advisable to learn how to correctly utilize the Ray
Pico Projector and its numerous products including:
• Digital cameras—to show pictures to friends and family.
• Camcorders— to share family videos with friends.
• iPhone, video iPod, MPEG3, MPEG4 or portable DVD players—to
present pictures and videos.
• Notebook or netbook computers—to project professional
presentations or entertainment videos.
1
Ray
Please check and identify the supplied accessories.
Box Contents
1
2
6
1.
Ray
Pico Projector
2. AC adapter with mini USB Plug—Input: 100-240V
~50-60Hz Output: 5V 2000mA
3. Tripod
4. Audio Video Cable: 2.5mm 4-pole to 2.5mm 4-pole
5. Audio Video Cable: 2.5mm 4-pole to 3.5mm 4-pole
6. Audio Video Cable: 2.5mm 4-pole to 3.5mm 4-poleBlack Cable with White Band ( maybe a White Cable)
7. RCA Audio\Video Cable: 2.5mm 4-pole AV jack to
RCA connectors
8. RCA Coupler
9. User manual
3 4
7
8
5
9
2
Ray
Heat Vent
Features
Ray Projector Controls and Features
Left Speaker
Right Speaker
Lens
Power Input
TV Input
Focus
On/Off
Power/Charge
Tri Pod Attachment
Bottom View
3
