Ratoc Systems PE51EX User Manual
Limitation of Liability
- Information presented by RATOC in this manual is believed to be accurate and reliable. RATOC assumes
no responsibility for its use. No license is granted by implication or otherwise to any rights of RATOC.
- In no event shall the liability of RATOC (or their officers, directors, employees or agents) for any
damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of
profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed
the actual price paid for the product. Some states do not allow the exclusion or limitation of incidental or
consequential damages. If such laws apply, the limitations or exclusions contained in this statement may
not apply to you.
Trademark References
Trademarks and registered trademarks are proprietary to their respective manufactures.
Advisories
Three types of advisories are used throughout this manual to provide helpful information, or to alert you
to the potential for hardware damage or personal injury. They are Note, Caution and Warning. The
followings is an example of each type of advisory.
NOTE
Used to amplify or explain a comment related to procedural steps or text.
WARNING
Used to indicate and prevent the following step from causing injury.
CAUTION
Used to indicate and prevent the following procedure or step from causing damage to the equipment.
1
Introduction
1
Thank you for purchasing the RATOC PCI Express to ExpressCard Adapter. This device allows to use
ExpressCard on a desktop computer. Normally ExpressCard is need to inserted into the ExpressCard slot
before system boot and never allow to exchange ExpreassCard after system boot both Windows PC and
MAC pro. This product provide ExpressCard Hot-plug capable driver for Windows PC and MAC Pro. To
install ExpressCard Hot-plug driver you can exchange ExpressCard at any time.
1-1.Feature
To assure PCI Express signal quality signal repeater is located on the PCI Express board.
To enable ExpressCard Hot-Plug capability Hot-Plug driver is provided for Windows PC and MAC Pro.
Recommended as a SxS
https://www.oss-formats.org/en/sxs/outline/index.html
1-2.Pre-Installation Information
Before using ExpressCard adapter you should perform the following steps:
1. Inventory the shipping carton contents for all of the required parts
2. Read this manual
1-3.Package Contents
Pro compliant product on the web site below.
ExpressCard Adapter PCI Express add-in card Low Profile bracket PCI Express extension Cable
CD-ROM Manual
1-4.System Requirements
Supported Operating System
Windows 7 / Windows Vista / Windows XP( x32/x64, Latest Service Pack should be installed)
Mac OSX 10.4.11 or later / 10.5.6 or later / 10.6 or later
Supported Computer
Windows PC PCI Express slot equipped.
Intel Mac Pro
NOTE
If any of these items are missing, contact the
supplier immediately.
2
1-5.Supported ExpressCard
ExpressCard/34 ( ExpressCard/54 is not supported. )
Sony SxS Card
SxS Pro SBP-8/SBP-16, SxS-1 SBS-32G1
Sony MemoryStick DUO Adapter MSAC-EX1
NOTE
1-6.Layout
ExpressCard Slot
For the latest information, go to our web site.
http://www.ratocsystems.com/english
ExpressCard Adapter
Connector for
PCI Express expansion cable
Eject lever
PCI Express add-in card
Connector for
PCI Express expansion cable
3
2-1.Installing the PCI Express add-in card and ExpressCard adapter
Shut down all power connected to the host
computer
2
Setup
CAUTION
As an added step to ensure safe
installation, unplug the power supply from
the computer.
After the host computer is off and all power
cords disconnected, remove the cover and
insert the card into a vacant PCI Express
slot by gently pushing the card until it is
firmly seated. Be sure to secure the card
with a retaining screw.
CAUTION
PCI Express add-in card
Windows PC
Mac Pro
Electrostatic Discharge (ESD) is the enemy of semiconductor devices. You should always take precautions
to eliminate any electrostatic charge from your body and clothing before touching any semiconductor
device or card by using an electrostatic wrist strap and/or conductive mat.
4
Connect PCI Express add-in card and
ExpressCard Adapter by the PCI Express
extension cable
NOTE
PCI Express extension cable
.
If PCI Express slot of your
computer is low profile, you
need to change the bracket of
PCI Express add-in card to low
profile bracket
Standard bracket
turn a screw
Low profile bracket
5
2-2.Windows Software Installation Steps
NOTE
Installation Steps
Following steps are example under Windows 7.
Insert provided CD into your disc drive.
You will see the AutoPlay dialog box, click “Run
RATOC-PE51HotPlugTool-Setup.exe”.
At the first system boot you will see the balloon message below. You do not
need to do anything, go ahead to the installation steps below.
Under Windows 7 or Windows Vista you will see “User
Account Control” dialog box.
Click “Yes” button.
Installation will start, click “Next >” button.
6
Confirm the destination location and click
“Next >” button.
Click “Install” button.
Security warning message will be shown
up.
Click “Install” button.
7
