Ratoc Systems CFU2 User Manual
USB Host CF Card
CFU2
User’s Guide
Jan. 2007
Rev . 1.0
CFU2
1. Introduction .................................................................1
1-1. Features ................................................................................. 1
1-2. Package Confirmation .......................................................... 2
1-3. System Requirements and Restrictions ............................... 2
1-4. USB Device Support .............................................................. 3
1-5. Before installation................................................................. 4
2. Installation ..................................................................5
2-1. Confirming a folder structure ............................................. 6
2-2. Connecting the PDA to the PC with ActiveSync .................. 6
2-3. CFU2 Host Driver Set Up ..................................................... 7
2-4. CFU2 HID Driver Set Up ...................................................... 8
2-5. CFU2 Mass Storage Driver Set Up ...................................... 9
3. Uninstallation ............................................................ 10
4. Registration and Tech-Support ................................ 11
5. Specifications ............................................................ 12
1.Introduction
The CFU2 is a USB1.1 Host CF card for use in CF T ype II card enabled PDA.
This User’s Guide describes how to install, use the CFU2. The information in
the README file in the CD-ROM may include newer information. For the
latest information, go to our home page.
http://www.ratocsystems.com/english/
1-1. Features
• Just insert the CFU2 into a CF slot and USB1.1 Host Interface
will be available.
• USB HID Driver and USB Mass Storage Class Driver are included.
The drivers allow you to use USB keyboards, USB bar code readers,
USB Flash disks, etc.
• Power-saving design enables to run battery-driven PDAs for a long time.
• Support both 3.3V and 5V operation.
• CFU2 dongle cable is detachable from the CFU2 CF card.
• RoHS compliant.
1
1-2. Package Confirmation
Check Package Contents:
• CFU2 CF card
• Cable
• Software CD-ROM
• Pull-out sticker
• Quick Install Guide
• Software Lisence Agreement
NOTE
If any of these items are missing, contact the supplier immediately.
1-3. System Requirements and Restrictions OS
• Pockert PC 2003, Pocket PC 2003SE, Windows Mobile 5
Supported PDA
Refer to our home page and check the latest information.
http://www.ratocsystems.com/english/
2
NOTE
1. Some applications which needs a lot CPU power like an MP3 player,
data transfer rate may be getting slower or the peformance of the
applications may be getting poor.
2. To use the CFU2 on the PDA, PCMCIA Card or CF Type II slot is
required. For a PCMCA Card slot, a CF Type II PCMCIA adapter is
needed. The CF Type II Adapter PCMCIA adapter is not included in
the package.
1-4. USB Device Support
• USB keyboard
• USB bar code reader
• USB Flash Disk
• USB MO, ZIP
• USB HUB
For more information, refer to our web site
http://www.ratocsystems.com/english/
NOTE
1. The CFU2 can supply up to 100mA to USB bus. If the USB device
needs power from USB bus over 100 mA, we have to use a self-powered
USB hub.
2. NTFS format is not supported by Windows Mobile.
3
