Rational Combi CBRC48 Parts List

i

500664 - 2 Piece Lid

Unit Information

7.5 Amps.

22,000 No Load

i HP motor

16

COMMEICIAL

CCB144

Coffee Cooler Blender

CCB14C

Coffee Cooler Blender /CSA

CBR48

Baskin Robbins Blender

18

CBRC48

Baskin Robbins Blender /CSA

WCB48

Cappuccino Cooler Blender /Ciirtis

These Units Are No Longer In Production

502589

Container with Blending Assy.

8

9

G

C__o 10

11

Jar

10

25

26

28

129

c 30

31

32

27

35 E======;;;

36

501832

PDF compression, OCR, web optimization using a watermarked evaluation copy of CVISION PDFCompressor

Blending Assy. Parts

Graphic By: Sandra A. Montysko Revised January 23, 2004 Page 1 of 3

Catalog Model

CCB114 37BL60

CCB14C 37BL95
CBR48 38BL12
CBRC48 38BL21

WCB48 38BL35

Illustration # Part # Description

1 011700 Center Lid

2 013442 Outer Lid /vinyl
3 501832 Blending Assy.

4 019560 Container /48 oz. polycarbonate

5 013304 NSF Seal

6 502240 Blade and Shaft Assy.

7 002903 Washer /fairprene

8 501752 Bearing Holder

-

Waring Factory Service

314 Ella T. Grasso Ave.

rrington, CT 06790

ele. 1-800-269-6640

860-496-90

C1Fax

www.waringproçrIAL

9

10 003537 Washer /stainless steel

11 003509 Washer ¡neoprene (rubber)

12 009780
13 003526 Washer ¡phenolic
14 006937 Washer /stainless steel
15 003138 Coupling (wagon wheel)

16 018999 Coupling

17 003507 Washer

18 017777 Cushion Ring
19 007558

20 015377 Top Housing ¡black

21 012698 Switch /toggle

22 014603 Locking Ring
23 014604 Washer
24 016236

009724 Washer ¡nylon

Hex Nut

Screw 4Req.d

Hex Nut

25 019937 Housing Seal
26 701191 Motor for CCB144, CBR48, WCB48

701718 Motor for CCB14C, CBRC48

27 013365 Baffle

28 009051 Wire Nut 2 Req.d for CCB144, CBR48, WCB48

012409 Crimp Connector 2 Req.d for CCB14C, CBRC48

29 002436 Screw
30 002943 Washer

Page 2 of 3 Revised January 23, 2004
