Raspberry Pi 4
Case Fan
Published in November 2020
by Raspberry Pi Trading Ltd.
www.raspberrypi.org
Overview
The Raspberry Pi 4 Case Fan is an ocial accessory for Raspberry Pi 4, for
use with the ocial Raspberry Pi 4 Case. Designed for over-clockers and
other power users, it keeps your Raspberry Pi 4 at a comfortable operating
temperature even under heavy load.
2 Raspberry Pi 4 Case Fan
Features
• Fits perfectly into the lid of the Raspberry Pi 4 Case
• Temperature-controlled fan delivers up to 1.4 CFM of air ow over the
processor, memory, and power management IC
• 18 mm × 18 mm × 10 mm heatsink with self-adhesive pad improves heat
transfer from the processor
Specication
Input voltage:
Fan speed control:
Maximum airow: 1.4 CFM
Case material: Clear PC
Compliance: For a full list of local and regional product approvals,
www.raspberrypi.org/documentation/hardware/
5V DC supplied via 40-pin GPIO header on Raspberry
Pi 4
Pulse width modulation control via user-selectable
GPIO pin
please visit
raspberrypi/conformity.md
3 Raspberry Pi 4 Case Fan
Fitting instructions
1 Remove any SD card, then put your Raspberry Pi into the lower half (base)
of the case. Take care to align the mounting holes in the corners with the
bumps in the case.
2 Insert the fan into the upper half (lid) of the case, with the green label facing
away from the lid. Push gently but rmly so that the two tabs on the fan
housing click neatly into place inside the tabs on the lid. The slightly curved
edge of the housing should be ush with the underside of the lid.
3 If you are also tting the heatsink, remove the backing paper from the
self-adhesive pad on the base of the heatsink, position it centrally over the
processor, and gently press it into position.
4 Connect the three leads from the fan to the Raspberry Pi 4’s GPIO pins, as
shown in the table and diagram below. Take care to connect each lead to the
correct pin.
Lead Colour GPIO pin
5v RED 4
Ground BLACK 6
GPIO 14 BLUE 8
5 Fit the lid of the case onto the base.
3V3
GPIO 2 (SDA)
GPIO 3 (SCL)
GPIO 4 (GPCLK0)
GPIO 19 (PCM_FS)
GND
GPIO 17
GPIO 27
GPIO 22
3V3
GPIO 10 (MOSI)
GPIO 9 (MISO)
GPIO 11 (SCLK)
GND
GPIO 8 (ID_SD)
GPIO 5
GPIO 6
GPIO 13 (PWM1)
GPIO 26
GND
1 2
5v
3 4
5v
5 6
GND
7 8
GPIO 14 (TXD)
9 10
GPIO 15 (RXD)
11 12
GPIO 18 (PCM_CLK)
13 14
GND
15 16
GPIO 23
17 18
GPIO 24
19 20
GND
21 22
GPIO 25
23 24
GPIO 8 (CE0)
25 26
GPIO 7 (CE1)
27 28
GPIO 1 (ID_SC)
29 30
GND
31 32
GPIO 12 (PWM0)
33 34
GND
35 36
GPIO 16
37 38
GPIO 20 (PCM_DIN)
39 40
GPIO 21 (PCM_DOUT)
4
2
5
3
1
4 Raspberry Pi 4 Case Fan
Physical dimensions
62.18
49.86
25.00
25.00
28.17
Note: all dimensions in mm
WARNINGS
• This product should only be used in conjunction with Raspberry Pi 4 Model B and the ocial Raspberry
Pi 4 Case.
• This product should be operated in a well-ventilated environment and the case should not be covered.
SAFETY INSTRUCTIONS
To avoid malfunction or damage to this product, please observe the following:
• Do not expose to water or moisture, or place on a conductive surface whilst in operation.
• Do not expose to heat from any external source; the Raspberry Pi Case Fan is designed for reliable
operation at normal ambient temperatures.
• Take care whilst handling to avoid mechanical or electrical damage to the fan and connectors.
• Avoid handling the fan whilst it is powered.
