Rapoo Technology S900 Users Manual

It is forbidden to reproduce any part of this quick start guide
without the permission of Rapoo Technology Co., Ltd.

5606-02501-222

Quick Start Guide

Schnellstartanleitung

Guide de démarrage rapide

S900

Bluetooth Noise-Canceling NFC Headset

Bluetooth NFC Headset mit Geräuschunterdrückung

Casque Bluetooth NFC à Suppression de Bruit

English

Deutsch

Français

Italiano

Español

Nederlands

Português

українська мова

Русский Язык

Norsk Nynorsk

············

············

············

············

············

············

············

············

············

············

2

6

10

14

18

22

26

30

34

38

Ελληνική

České

Română

Magyar Nyelv

Български Език

Suomi

Dansk

Polski

يةبرعلا

תירבע

············

············

············

············

············

············

············

············

············

············

42

46

50

54

58

62

66

70

77

81

Bluetooth headset

USB to 3.5mm charging cable

3.5mm audio cable with remote control and
microphone

Airplane audio adapter

Quick start guide

Travel bag

Buttons and portsPackage Contents

Volume up button

Volume down button

Power button

Power indicator

Mode switch button

Mode selection

Built-in microphone

Turn on/off

To turn on, press and hold the power button;

To turn off, press and hold the power button.

2

Audio input & Charging port

Power indicator

The red LED will be on when charging. After it
is fully charged, the green LED will be on.

The blue LED will blink when the Bluetooth
connection is successful.

The green LED will blink once every 2.5s
when the Bluetooth connection has stopped.

Mode selection

The green LED will be on when the headset
enters into noise-canceling mode;

The blue LED will be on when the headset

enters into 3D sound effect mode;

The purple LED will be on when the headset

enters into noise-canceling & 3D sound effect

mode;

The LED will not be lit when the headset
enters into common mode.

Bluetooth ConnectionStatus Lights NFC Connection

The headset enters into pairing mode automatically
after turnning it on. Activate the Bluetooth feature on
your device, and scan and search for the headset. Enter
"0000" if a password is required."

Turn on the headset, activate the NFC settings on your
smartphone or other device, place your device's NFC
zone close to the headset’ s NFC zone (distance within
1 cm), the headset will automatically connect to your
device.

*This method is only available for NFC-enabled devices.

3

Multipoint Connection

Connect device 1, device 2 to the headset according to
the method of Bluetooth or NFC, The headset will work
normally when connected successfully.

Note: Up to two devices can be connected to one
headset at the same time.

4

To play/pause music, press the Bluetooth button
shortly.

Mode selection

The headset offers four modes including noise-cancel­ing mode, 3D sound effect mode, noise-canceling & 3D
sound effect mode and common mode. The headset is

in the common mode when it is turned on. To change
the mode, press the mode switch button shortly.

Wired ConnectionMusic Player

Connect the headset to a smartphone or tablet using
the 3.5 mm audio cable, and run the player.

Press the power button shortly to switch to Bluetooth
mode, and the headset will automatically connect to
the last connected Bluetooth device.

The audio cable with remote and micphone is compati­ble with many smartphones, tablets and other mobile
devices. In wired mode, the headset and the connected
device can be operrated by the buttons on the audio
cable:

To play/pause music, answer/end a call, press the
center button shortly.

Voice Call

1. To answer/end a call, press the power button shortly;
To reject an incoming call, press and hold the power
button.

2. To redial a call, double click the power button.

3. During a call, press and hold the power button to
switch between mobilephone and headset.

Use the charging cable to connect the headset to a
USB Charger, PC or other device with standard DC 5V
USB port.

Troubleshooting TroubleshootingCharging

1.No sound at all

· Make sure the Bluetooth connection is successful.

· Make sure you have charged the headset.

· Set the headset as the default audio device.

· Restart the media player.

2.I can not hear music or sound even though it is
connected to the laptop.

· Some laptops with Bluetooth function will work
normally after installing the driver Please check the
system description of laptop for more information.

3.NFC connection is unsuccessful

· Make sure NFC is enabled on your device and has
been activated.

· Make sure the distance between your device's NFC
zone and headset's NFC zone is within 1 cm.

4.Sound drops out within short transmitting distance

· Bluetooth transmission distance may vary according
to actual usage conditions, please make sure there are
no big objects between them.

· Move other working wireless devices away from the
audio device.

* If your problem is not solved, please contact the
helpdesk at www.rapoo.com.

5

Bluetooth Headset

USB/3,5 mm-Ladekabel

3,5-mm-Audiokabel mit Fernbedienung und Mikrofon

Flugzeugaudioadapter

Schnellstartanleitung

Transporttasche

Tasten und AnschlüssePackungsinhalt

Lauter-Taste

Leiser-Taste

Ein-/Austaste

Betriebsanzeige

Moduswechseltaste

Mode selection

Integriertes Mikrofon

Ein- und Ausschalten

Halten Sie zum Einschalten die Ein-/Austaste gedrückt.
Halten Sie zum Ausschalten die Ein-/Austaste gedrückt.

2

Audioeingang und Ladeanschluss

Betriebsanzeige:

Beim Aufladen leuchtet die rote LED. Nach
vollständiger Aufladung leuchtet die grüne

LED auf.

Die blaue LED blinkt bei erfolgreicher
Bluetooth-Verbindung auf.

Die grüne LED blinkt einmal alle 2,5 Sekunden,
wenn die Bluetooth-Verbindung getrennt ist.

Modusauswahl:

Die grüne LED leuchtet auf, wenn das
Headset den Rauschunterdrückungsmodus
aufruft;

Die blaue LED leuchtet auf, wenn das

Headset den 3D-Klangeffektmodus aufruft;

Die lilafarbene LED leuchtet auf, wenn das
Headset den Rauschunterdrückungs- und

3D-Klangeffektmodus aufruft;

Die LED leuchtet nicht, wenn das Headset
den allgemeinen Modus aufruft.

Bluetooth-VerbindungStatus Lights NFC-Verbindung

Das Headset ruft nach dem Einschalten automatisch
den Kopplungsmodus auf. Aktivieren Sie die
Bluetooth-Funktion an Ihrem Gerät und suchen Sie
nach dem Headset. Geben Sie „0000 “, falls ein
Kennwort erforderlich ist.

Schalten Sie das Headset ein, aktivieren die NFC-Ein­stellungen an Ihrem Smartphone bzw. Gerät, platzieren
die NFC-Zone Ihres Gerätes in der Nähe der NFC-Zone
des Headsets (Abstand innerhalb 1 cm) und das
Headset wird automatisch mit Ihrem Gerät verbunden.

*Diese Methode funktioniert nur mit NFC-fähigen
Geräten.

3
