Rapoo Technology 0100E0 User Manual

SPECIFICATION

Of

WMU91S Cordless Optical Mouse

Note:

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause undesired

operation.

Caution:

The manufacturer is not responsible for any radio or TV interference caused by unauthorized modifications

to this equipment. Such modifications could void the user authority to operate the equipment.

REV : 1.02

Prepared by MLK Technologies Limited

10. Jun.2003

Part 1.0 : General features and description

- Prevent Repetitive Strain Injury on your wrists and arms!

- Radio frequency : 27 MHz, single channel with 256 random ID, no more problems with radio

frequency interference .

- Battery suggestion: Two AA size alkaline batteries for mouse.

- The operation distance of 1.8M (typically under normal office environment).

- Mouse resolution of 800dpi counts per inch of motion.

- Sensor detects motion on all kinds of surface, including wood, plastics, pants, etc… ( Highly

reflective like mirror or deep dark color may not work properly).

- Compatible with windows 98/ME/2000/XP.

- Super 3D wheel scrolling functions, easy to scroll or zoom for the window and web.

- Compatible shape:

The comfortable shape provides easy control.

Part 2.0 : System Requirements

. IBM PC or compatible system

Part 3.0 : Preface

The functionality and performance requirements related to the mouse are defined in this

specification.

Part 4.0 : Version

- PS/2 Interface

- USB Interface

Part 5.0 : Physical characteristics and configuration

Item 5.1: Dimension

- Mouse : 123mm(L) x 74mm(W) x 42mm(H)

- Receiver:50mm(L) x 42mm(W) x 107mm(H)
