Rankin-Delux RD100 Specifications

by
RANKIN-DELUX
TM
INFRARED GRIDDLE
TM
THE EFFICIENT PERFORMER
INFRARED TYPE
MODEL RD100 SERIES
Gas Operated
Model RD100-36-C
COUNTER MODEL
by
RANKIN-DELUX
®
FLOOR MODEL
by
RANKIN-DELUX
Model RD100-36-F-C
Shown with casters, which are available at additional cost.
TM
This infrared Turbo Griddle™ is the griddle for the 21st Century, developed for high volume restaurants and quick service operations.
The Rankin-Delux
Turbo Griddle™ uses 30% less energy than the traditional
atmospheric-type griddle, and yet outperforms even the most efficient models available.
The
Turbo Griddle™ not only saves energy, but will withstand load after load of
frozen product with minimal temperature variation. You can’t “kill” this griddle.
Independent tests show that the
Turbo Griddle™ offered considerably less product
shrinkage than the other Infrared griddles that were tested.
Another benefit that this griddle offers is that unlike griddles that are heated with a flame, there is no carbon buildup on the bottom of the plate to diminish efficiency.
Designed for Commercial
Quality at an affordable price.
EASTERN REGIONAL OFFICE FACTORY
P.O. Box 270417 12862 East Florence Avenue
St. Louis, Missouri 63127 Santa Fe Springs, CA 90670
Phone: 636/296-2830 Fax: 636/296-2539 Phone: 562/944-7076 Fax: 562/941-7858
RANKIN-DELUX, INC.
P.O. BOX 4488
WHITTIER, CA 90607-4488
PAGE BB-1
GRIDDLE/INFRARED RD100 SERIES
FINISH: Stainless Steel front, nosing, rail, and sides with balance in aluminized steel.
CONSTRUCTION: All welded heavy gauge steel frame.
LEGS: Heavy duty Stainless Steel adjustable legs are standard on the
counter model. Legs on the floor models are furnished with the same fin­ish as the cabinet base.
GRIDDLE PLATE: Griddle plate is 1" thick steel, machine ground with a highly polished finish. Plates have bolts on the under­side for final leveling. Plates have welded stainless steel splash guards at the rear and both sides and a 3 1/8" wide stainless steel front trough.
GREASE DRAWER: Large grease drawer made from all welded heavy gauge stainless steel. Two drawers are furnished on 48", 60", 72" & 84" models.
DESIGNED FOR COMMERCIAL USE ONLY
RANKIN-DELUX, INC.
P.O. BOX 4488
WHITTIER, CA 90607-4488
EASTERN REGIONAL OFFICE FACTORY
P.O. Box 270417 12862 East Florence Avenue
St. Louis, Missouri 63127 Santa Fe Springs, CA 90670
Phone: 636/296-2830 Fax: 636/296-2539 Phone: 562/944-7076 Fax: 562/941-7858
FORM RD100000-5M ©Rankin-Delux, Inc.
®
BURNERS: Each 12" of griddle width has a ceramic infrared burner rated at 20,000 BTU per hour. Burners are designed to pro­vide maximum efficiency and ensure even heat distribution.
THERMOSTAT: A solid state thermostat controls each burner, the sensing bulb is embedded in the griddle plate to within 1/4" of the top surface. Accurate to less than 1° F.
IGNITION: A toggle switch is provided to electronically light the pilot and open the gas solenoid valve.
FLAME SWITCH: Each pilot is furnished with a flame switch, which proves the pilot and opens the burner solenoid.
APPROVALS: The RD100 series is NSF and CGA approved.
