EOD88 OPERATION MANUAL

Congratulations on the purchase of your new RANDALL EOD88 Amplifier! Some things in music are obviously inspired. There is a
famous interview with!Ozzy in which he talks about how Black Sabbath’s sound evolved in the early!days: “We were just a blues band
and then it took on an ELEMENT OF DOOM…”

So, In the spirit of that early pioneering of heavy metal, we have created the EOD88. With 3 gain modes, KT88 power design
and a built in fuzz circuit, this amp personifies old school but within a fresh modern approach and appeal.

We at Randall Amplification appreciate that you chose the EOD88 head Amplifier and wish you years with tons of gain, great
tone and enjoyable playing time. Please review the safety instructions below and be aware that the documentation provided in
this manual references 120volt USA versions of the models covered.
Note that the POWER listed on the back of the unit should be for your countries’ power standard.

“This apparatus is for professional use only.”

Front Panel Controls

INPUT JACK: input for guitar.

FUZZ: Controls the amount of Fuzz when engaged via

footswitch or panel switch.

Fuzz switch: Push in or via 2 button Randall footswitch to
engage Fuzz circuit w/Red LED identification.

GAIN: Overall gain control for tube preamp distortion.

Tube switch: Push in or via 2 button Randall footswitch to

engage 4th tube gain stage w/Red LED identification.

BASS: Passive interactive low frequency equalization.
MIDDLE: Passive interactive midrange frequency equalization.
TREBLE: Passive interactive high frequency equalization.

DEPTH: Power amp control of low frequency interaction between amplifier and

speakers.!

PRESENCE: Power amp control of high frequency variable feedback.
MASTER: Controls the overall output of the amplifier post EQ

STANDBY: Breaks the High Voltage from the power supply.!
POWER: On/off for the Mains.

Rear Panel Controls

FUZZ/TUBE: TRS switching jack for footswitch.

Tip to ground switching type. Tip=FUZZ and
Ring= TUBE select. (2 button non LED

footswitch included)

LINEOUT OUTPUT is tapped directly
off the speaker jack to be used for wet/
dry effects applications.

SERIES FX LOOP:

RETURN: Class A Discrete instrument level effects loop return. This plugs into external

pedal effects unit output to complete signal “loop”. Also serves as power amp input so
external preamp can be plugged directly to power amp section with active volume control.

SEND: Class A Discrete instrument level effects loop send. This plugs into external pedal
effects unit input and feeds signal from the Gain and Tone knobs. Also serves as
unbalanced preamp output send but will mute output unless return jack receives return

signal.

Rear Panel Controls

MAINS INPUT: AC wall power via included
IEC cord to a grounded outlet

Speaker outs:

1x4 OHM - connect one 4 ohm speaker cabinets here
2x8 OHM - connect two 8 ohm speaker cabinets here

1x8 OHM - connect one 8 ohm speaker cabinets here
2x16 OHM - connect two 16 ohm speaker cabinets here

1x16 OHM - connect one 16 ohm speaker cabinets here

DO NOT CONNECT MORE SPEAKERS THAN SHOWN ABOVE

For detailed product videos please visit our website at :www.randallamplification.com

Randall Amplifiers is a Division of U.S. Music Corp.
1000 Corporate Grove Drive • Buffalo Grove, IL 60089
Tel: [phone] • Fax: [phone]

Randall Warranty

Randall Amplifiers, a Division of U.S. Music Corporation warrants the product you have purchased to be free of defects in materials and workmanship in normal use for a period of two (2) years from the date of original purchase. This warranty shall run
to the original purchaser when purchased from an Authorized Randall Dealer. The manufacturer warrants speakers for a period of (1) years. The manufacturer warrants tubes for a period of (90) days. Defective parts found during the applicable
warranty period with proof of purchase will be replaced or repaired without charge if the complete product is returned to US Music Corp or any Authorized Randall Service Center within the U.S.A. Randall reserves the right to use materials readily
available at the time of the repair. All Warranty service requires Proof of Purchase (sales receipt) to be presented at time of service request. Any repair or service performed by any person of entity other than an Authorized Service Center is not covered
by this limited warranty. The customer pays transportation to and from Randall factory service or any Randall Authorized Service Center. Rental stock is warranted for (1) year from date of invoice to the Authorized dealer. Warranty on rental units is not
transferable.

What is covered against manufacturing defects: Parts and Labor to correct any defect in materials used and any defect attributable to workmanship.

What is not covered:

Shipping Damage. Report damage upon receipt of item to the carrier (i.e. UPS). Freight carrier must be notified upon receipt of items to insure freight damage claim resolution. Shipping damage not filed with carriers within (48) hrs upon receipt will not
be covered under warranty. Report any shipping damage within (48) hrs of receipt to the Randall Customer Service Dept at 1-847-949-0444, ext. 5120. Keep all original documents and packing materials to insure freight damage claim resolution.
Merchandise that has been modified after original shipment from the Randall factory. Products whose serial numbers have been altered or removed. Exterior normal wear and tear damage to the finish due to misuse, operation outside the specified
ratings, neglect or accident. Warranty claims by anyone other than the original purchaser. Randall is not responsible for any items left in protective covers or cases, (We strongly advise that all personal items such as chords, cables, tuners, etc… be
removed!) freight charges to and from the factory or an Authorized service center on customer owned goods, any and all charges incurred from priority service requests (Rush Service) or priority shipping for replacement parts. Any and all charges if no
problem is found.

Return Authorization!

All items being returned for any reason must have a Return Authorization number. This RA# must be placed on the outside of the carton of the item being returned or the carton will be refused upon delivery. Please call the customer service department
at 1-800-877-6863, ext. 5120, for the return authorization number. Dealer stock items will be returned to the dealer freight prepaid.

An Authorized Warranty Service Center must perform any and all field warranty service work. Customer will not pay for parts and/or labor provided the problem found is within warranty guidelines. Proof of purchase must be provided at the time of
service request. Transportation charges to and from the Authorized Warranty Service Center are the responsibility of the customer. Rush service charges and special freight charges for required parts are not covered under warranty and are also the
responsibility of the customer. If a unit is not easily transported to an authorized service center, the customer is responsible for technician travel charges. Any charges for labor or processing when no problem is found are also not covered under
warranty. Any charges incurred for work performed by an unauthorized service center are the responsibility of the customer.

Warranty terms may very per country, check warranty terms with local Distributor or at point of purchase.
