DEEP FRYER

INSTRUCTION MANUAL

MODEL: RM/370

Read this manual thoroughly before using and save it for future reference

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be followed, including the

following:

1. Read all instructions.

2. Do not touch hot surface. Use handles or knobs.

3. To protect against electric shock do not immerse cord, plugs, or housing in water or other liquid.

4. Close supervision is necessary when any appliance is used by or near children.

5. Unplug from outlet when not in use and before cleaning. Allow to cool down before putting on or taking

off parts, and before cleaning the appliance.

6. Do not put the appliance on a soft working surface or a desktop covered with table cloth, make sure

the appliance is working on a rigid surface.

7. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or has

been damaged in any manner. Return appliance to the nearest authorized service facility for

examination, repair or adjustment.

8. The use of attachments not recommended by the appliance manufacturer may cause injuries.

9. Do not let cord hang over edge of table or counter, or touch hot surfaces.

10. Do not use this appliance when missing oil reservoir, oil and any other materials, or the oil is not

enough.

11. Do not place on or near a hot gas or electric burner, or in a heated oven.

12. Extreme caution must be used when moving fryer containing hot oil.

13. Make sure handles are properly assembled to basket and locked in place. See detailed assembly

instructions.

14. Before use, always ensure that the oil reservoir is positioned correctly.

15. Never connect the fryer to the electricity supply without placing oil in the oil reservoir first.

16. The oil in the oil reservoir will be still hot after it is switched off. Never attempt to move your fryer until

it is completely cool down, lift the oil reservoir use the handles.

17. Though the detachable oil reservoir can be completely immersed in water and clean, it must be

thoroughly dried before next use to prevent electric shock.

18. Never overfill the fryer with oil. Fill only between the minimum and maximum levels, as indicated

inside the oil reservoir.

19. Do not add food with ice crystals or if it is wet to the hot oil.

20. This appliance can be used by children aged from 8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of experience and knowledge if they have been given

supervision or instruction concerning use of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be

made by children without supervision.

21. On completion of frying, always raise the basket and wait a few seconds to allow steam pressure to

subside.

22. Do not use appliance for other than intended use.

22. Do not use outdoors.

23. Store the appliance indoors to prevent electronic parts failure.

24. WARNING: Serious hot oil burns may result from a deep fryer being pulled off a countertop. Do not

allow the power cord to hang over the edge of a counter where it may be grabbed by children or

become entangled with the user.

25. The appliance is not intended to be operated by means of an external timer or a separate

remote-control system.

26. This appliance is intended to be used in household and similar applications such as:

– Staff kitchen areas in shops, offices and other working environments;

– Farm houses;

– By clients in hotels, motels and other residential type environments;

– Bed and breakfast type environments.

27. Save these instructions.

HOUSEHOLD USE ONLY

This appliance has a polarized plug, to reduce the risk of electric shock, this plug is intended to fit into a

polarized outlet only one way, if the plug does not fit fully into the outlet, reverse the plug, if it still does

not fit, contact a qualified electrician, do not attempt to modify the plug in any way.

1. A short power-supply cord is to be provided to reduce the risk resulting from becoming entangled in or

tripping over a longer cord.

2. Longer detachable power-supply cords or extension cords are available and may be used if care is

exercised in their use.

Exception: An extension cord or longer detachable cord is not recommended for use with deep-fat fryer.

3. If a long detachable power-supply cord or extension cord is used.

1) The marked electrical rating of the cord or extension cord should be at least as great as the electrical

rating of the appliance.

2) The longer cord should be arranged so that will not drape over the countertop or table top where it can

be pulled on by children or tripped over unintentionally.

Oil tank

Housing

Basket asm

Lid handle

Viewing window

Filter cover

Filter

Control box asm

Lift handle

Lid

NOTES ON THE POLARIZED PLUG

NOTES ON THE CORD

KNOW YOUR DEEP FRYER

Increase/Decrease Time/Temp

On/Off Button

Power Indicator Light

Heating Indicator Light

Time/Temp Button

Digital Display

Filter cover

Black filter

White filter

Note: The large basket can be loaded about 1200g potato chips.

Remove all the packaging materials, labels and/or stickers from the deep fryer.

WARNING: Do not plug in the deep fryer when the control panel is not installed in the deep fryer body.

Only plug in the deep fryer when the unit is fully assembled and the heating element is immersed in oil.

WARNING: Do not immerse the control panel, cord or plug in water.

WARNING: This unit should not be used to boil water.

CLEANING PRIOR TO FIRST USE

The body, oil reservoir, frying basket, frying basket handle, filters and the lid can be washed in warm

soap water. Dry thoroughly before use.

WARNING: Do not immerse the control panel, power cord, or plugs into liquid of any kind.

1. Lift the control panel with heating element out of its slots by pushing it up from the bottom with one

hand while holding the body of the deep fryer with your other hand.

2. Remove the oil reservoir from the body of the deep fryer.

3. Wash the oil reservoir and the frying basket with hot water, a nonabrasive sponge, and dishwashing

liquid or other non-poisonous detergent.

Basket ASM Stainless Steel Lid with Double filters and window

USING FOR THE FIRST TIME

To wash the deep fryer:

ASSEMBLYING THE DEEP FRYER

1. Place the oil reservoir into the deep fryer housing. (Fig. 1)

2. Insert the guide edges on the control panel into the guide rails

mounted on the metal body. (Fig.2).

3. Slide the guide edges down as far as they can go.

Note: The deep fryer has an automatic safety switch (Fig.3) to

ensure that the unit will not operate unless the control panel has

been inserted securely into the guide rails on the body of the

deep fryer.

Safety Switch

Guide Edges

4. Attach the fryer basket handle to the fryer basket by squeezing the handle bars together and inserting

them into the metal bracket on the basket. Make sure that the ends of the bars are inserted into the

bracket holes. Lift the handle up to lock in place (Fig. 4).

WARNING: Never plug in the deep fryer before filling the oil reservoir with oil. Always make sure that the

control panel is securely in place in the housing of the deep fryer and that the heating element is inside

the oil in the oil reservoir before plugging in.

Guide Rails

Guide Edges

Slide Down

Fig.1

Fig. 2

Fig.3

Fig. 4

USING THE DEEP FRYER

Filling the Oil Reservoir:

1. Pour cooking oil into the oil reservoir making sure that it is between the “Min” and “Max” fill lines in the

oil container. Do not under fill or overfill. The oil levels must be maintained between the minimum

(3.5L) and the maximum levels (4.5L) marked inside the oil container. (Fig. 5)

Fig. 5

2. You can use blended vegetable oil, corn oil, or canola oil. Do not use olive oil, margarine, lard or

drippings. Never mix old and new oil together or different oils and fat.

Using Solid Fat:

WARNING: Do not put solid shortening in the oil reservoir or the frying basket.

1. If using solid vegetable shortening, melt it first in a separate container and then very carefully pour the

melted fat into the oil reservoir.

2. Previously used solid vegetable shortening which has curdled and hardened in the oil reservoir should

be removed from the oil reservoir and melted in a separate pan before reusing.

WARNING: If you try to melt the solidified fat in the oil reservoir, there is a risk of hot melted fat suddenly

sputtering from below through the solid top layer of fat.

For the first use the oil tank and basket may emit odor, it is normal and will not occur again after several

uses.

After the unit is plugged in, the power indicator will be illuminated while a beep will be heard for 1S. The

LED readout will display “00:00”.

Under the mode of “Stand-by”, pressing down the TIME/TEMP button and “▲” simultaneously may

choose manual mode and preset mode alternatively.

1. Under the mode of “Stand-by”, press down the START/PAUSE button, the deep fryer will go into the

manual mode and will start to preheat.

2. Under the manual mode, press “TIME/TEMP” button, the LED will display the manual preset

temperature and will display the manual preset time after press “TIME/TEMP” button again. When the

LED displays the preset time, you can adjust the preset time by “▲” and “▼” buttons at the increase or

decrease of 30 seconds every time and the time range is between 2 to 30 minutes. When the LED

displays the preset temperature, you can adjust the preset temperature by “▲” and “▼” buttons at the

increase or decrease of 5℃ every time and the preset temperature range is between 150 and 190℃.

1) The deep fryer will be kept in the condition of keep warm or heating during the process of manual

setting.

2) When the oil temperature reaches the preset temperature, put the food into the oil slowly, at this

time press START/PAUSE, into count down preset time mode, the time used for frying the food

means the above mentioned preset time. USING THE PREPROGRAMMED SETTINGS

1. To access the Preset Mode, press down the TIME/TEMP and “▲” buttons simultaneously, the LED

readout will display “P01”, with the “01” flashing. This signifies that the unit is ready to be set. Following

the “Using the Preprogrammed Settings” chart below (10 settings in total), select the preset number

you are going to use by using the “▲” button. You can scroll up “▲” or “▼” down to find the correct

setting you want to use. Once you have selected a preset setting, press “START/PAUSE” button again,

the temperature and time will be automatically programmed into the unit as outlined in the following

HOW TO USE YOUR DEEP FRYER

AFTER POWER-UP

USING THE MANUAL SETTING

Note:

“Using the Preprogrammed Settings” chart.

2. Press the “START/PAUSE” button to preset the oil. The green “Heating” light will illuminate to indicate

that the oil is preheating.

3. Once the oil is preheated, it will beep 3times circularly and continually, until you

press“START/PAUSE”on to change temperature. The green “Heating” light will flash and the unit will

pause. Lower the food slowly into the oil and press the “START/PAUSE” button again to begin the

countdown timer. The display will default back to temperature reading. To check time, press the

TIME/TEMP control once.

4. After the preset time has run its course, you will hear ten beeps. The LED display will read the

program code that you just used.

5. Lift the basket up out of the oil and place on drain hooks to allow excess oil to drain away. If another

batch of the same food is desired, press the “START/PAUSE” button once to repeat the previous setting

and repeat the above steps.

Note:

The preset settings can be stopped at anytime during the cooking cycle by pressing the

“START/PAUSE” button once and unplugging the unit from the electric outlet.

Using the Preprogrammed Settings:

CODE

FOOD

TIME(MIN)

TEMP(℃)

P01

FROZEN FRENCH FRIES
