AVS10 – 1
Ramsey Electronics Model No. AVS10
Don’t miss a beat; watch 4 cameras on one monitor! Perfect for
multiple video camera installation, stores, household
surveillance systems, and more!
• Automatic sequential switching of up to 4 separate video sources
• Perfect for security cameras and baby monitors
• Enable or disable video sources with the flick of a switch
• Manual “hold” selection of any source
• Variable front panel timing control
• Easy one evening assembly
• Add our matching case and knob set for a pro look
AUTOMATIC
SEQUENTIAL VIDEO
SWITCHER
AVS10 – 2
RAMSEY TRANSMITTER KITS
• FM100B Professional FM Stereo Transmitter
• FM25B Synthesized Stereo Transmitter
• AM1, AM25 AM Transmitters
• TV6 Television Transmitter
RAMSEY RECEIVER KITS
• FR1 FM Broadcast Receiver
• AR1 Aircraft Band Receiver
• SR2 Shortwave Receiver
• AA7 Active Antenna
• SC1 Shortwave Converter
RAMSEY HOBBY KITS
• SG7 Personal Speed Radar
• SS70A Speech Scrambler
• ECG1 Heart Monitor
• WCT20 Wizard Cable Tracer
• PG13 Plasma Generator
• LABC1 Lead Acid Battery Charger
RAMSEY AMATEUR RADIO KITS
• DDF1 Doppler Direction Finder Kit
• HR Series HF All Mode Receivers
• QRP Series HF CW Transmitters
• CW7 CW Keyer
• CPO3 Code Practice Oscillator
• QRP Power Amplifiers
RAMSEY MINI-KITS
Many other kits are available for hobby, school, Scouts and just plain FUN. New
kits are always under development. Write or call for our free Ramsey catalog.
AUTOMATIC VIDEO SWITCHER KIT INSTRUCTION MANUAL
Ramsey Electronics publication No. MAVS10 Revision 2.2
First printing: January 2001
COPYRIGHT
2001 by Ramsey Electronics, Inc. 590 Fishers Station Drive, Victor, New York
14564. All rights reserved. No portion of this publication may be copied or duplicated without the
written permission of Ramsey Electronics, Inc. Printed in the United States of America.
AVS10 – 3
AUTOMATIC
SEQUENTIAL VIDEO
SWITCHER
Ramsey Publication No. MAVS10
Manual Price Only $5.00
TABLE OF CONTENTS
Introduction ................................... 4
Circuit Description ......................... 4
Block Diagram ................................ 5
Parts List ........................................ 6
Parts Layout Diagram .................... 7
Schematic diagram ....................... 8
Assembly instructions ................. 10
Initial Testing ............................... 13
Troubleshooting ........................... 13
Ramsey Warranty ........................ 15
INSTRUCTION MANUAL FOR
RAMSEY ELECTRONICS, INC.
590 Fishers Station Drive
Victor, New York 14564
Phone (585) 924-4560
Fax (585) 924-4555
www.ramseyelectronics.com
AVS10 – 4
INTRODUCTION
In today’s world there are many situations that require monitoring, but no one
can be in four places at once. Now, with the AVS10, you have the opportunity
to see four different locations and keep an eye on your precious property.
The front doorbell is ringing, the baby is napping, one of your children is
playing with friends on the backyard trampoline and another is shooting
hoops in the driveway. Of course, you need to be in the kitchen or home
office and even with the proverbial parental “eyes in the back of your head”
you can’t possibly keep an eye on everyone! With the AVS10 and four
inexpensive video cameras you can do the impossible. And if you see a
situation that requires a longer look, simply press the SCAN/STOP button
and take as long as you need to assure you that all is well. The AVS10 is the
perfect baby/playroom monitor, allowing you the freedom to monitor the
action without having to be physically present. You can keep an eye on your
shed, boat or other outdoor property as well. We believe you’ll find dozens of
applications for this useful kit and at a fraction of the cost of commercial
video switchers!
.
CIRCUIT DESCRIPTION
The AVS10 takes advantage of the Motorola 68HC908 family’s power, thus
eliminating the need for bulky logic gates to control the switching of up to 4
input video signals. By periodically testing the state of each enable switch
(S1:1 – S1:4), the microcontroller (U1) will activate the respective video
control switch (U2:A – D) enabling each individual video feed.
The 68HRC908JK1 microcontroller uses an RC (Resistor & Capacitor)
network to set up the controlling frequency. Resistors R1, R2 (variable front
panel potentiometer), and R3 along with the fixed value capacitor C1 make
up the timing circuit for the system. The front panel speed control (R2,
variable potentiometer) lets us vary the control frequency from about 2MHz to
8MHz. This is how the scan rate between the input video signals is controlled
giving the user full range from approximately 1 to 5 second switching times.
The SCAN/STOP button (S3) lets the user stop on any active video channel
and hold that particular feed for indefinite viewing. The active low enabling of
the IRQ line (U1 pin 1) from S3, the SCAN/STOP button, gives easy access
to the end user for other remote scan stop triggering in custom applications.
Using the CD4066 Bilateral Switch (U2) as the actual video control switcher
lends itself nicely to this application. The quad bilateral switch was intended
for the transmission or multiplexing of analog or digital signals with a switch
“ON” frequency response of up to 40 MHz! This is really overkill for a video
switch unit but it offers great performance and extremely low switch leakage
between the video channels when powered.
AVS10 – 5
Micro
Initialization
Check
Switch
1
Turn ON
Video 1
Conrol Line
1 to 5
Second
Delay
Turn OFF
Video 1
Conrol Line
Video
Enabled
STOP/SCAN
Not Pressed
Video
Disabled
STOP/SCAN
Pressed IN
Check
STOP/SCAN
Switch
Check
Switch
2
Turn ON
Video 2
Conrol Line
1 to 5
Second
Delay
Turn OFF
Video 2
Conrol Line
Video
Enabled
STOP/SCAN
Not Pressed
Video
Disabled
STOP/SCAN
Pressed IN
Check
STOP/SCAN
Switch
Check
Switch
3
Check
Switch
4
Check 3 the same as switch 1 and 2 above.
Check 4 the same as switch 1 and 2 above.
AVS10 Block Diagram
