RAM Chassis Cab 3500 2013, Chassis Cab 4500 2013, Chassis Cab 5500 2013 User's Guide

If you are the first registered retail owner of your vehicle, you may obtain a complimentary printed copy of the Owner’s Manual, Navigation/Uconnect

Manuals or Warranty Booklet by calling 1-866-726-4636 (U.S.) or 1-800-387-1143 (Canada) or by contacting your dealer.

IMPORTANT

This User Guide is intended to familiarize you with the important features of your vehicle. The DVD enclosed contains your Owner’s Manual,

Navigation/Uconnect Roadside Assistance (new vehicles purchased in the U.S.) or Roadside Assistance (new vehicles purchased in Canada) in electronic format.

The driver’s primary responsibility is the safe operation of the vehicle. Driving while distracted can result in loss of vehicle control, resulting in a collision and personal injury. Chrysler Group LLC strongly recommends that the driver use extreme caution when using any device or feature that may take their attention off the road. Use of any electrical devices such as cell phones, computers, portable radios, vehicle navigation or other devices by the driver while the vehicle is moving is dangerous and could lead to a serious collision. Texting while driving is also dangerous and should never be done while the vehicle is moving. If you ﬁnd yourself unable to devote your full attention to vehicle operation, pull off the road to a safe location and stop your vehicle. Some States or Provinces prohibit the use of cellular telephones or texting while driving. It is always the driver’s responsibility to comply with all local laws.

Manuals, Warranty Booklets, Tire Warranty and

INTRODUCTION/WELCOME

WELCOME FROM CHRYSLER

GROUP LLC ..................3

CONTROLS AT A GLANCE

DRIVER COCKPIT ..............6

INSTRUMENT CLUSTER ..........8

GETTING STARTED

KEYFOB ...................10

KEYLESS ENTER-N-GO™ .........11

REMOTE START ..............13

THEFT ALARM ................13

SEATBELT ..................13

SUPPLEMENTAL RESTRAINT SYSTEM

(SRS) — AIR BAGS .............14

CHILD RESTRAINTS ............15

FRONT SEATS ................ 21

HEATED/VENTILATED SEATS ....... 23

HEATED STEERING WHEEL ........24

TILT STEERING COLUMN .........25

OPERATING YOUR VEHICLE

ENGINE BREAK-IN

RECOMMENDATIONS ...........26

TURN SIGNALS/WIPER/WASHER/HIGH

BEAMS LEVER ................ 27

HEADLIGHT SWITCH ............ 28

SPEED CONTROL ..............29

ELECTRONIC RANGE SELECT (ERS)

OPERATION .................31

MANUAL CLIMATE CONTROLS WITHOUT

TOUCH-SCREEN ...............32

MANUAL CLIMATE CONTROLS WITH

TOUCH-SCREEN ...............33

AUTOMATIC CLIMATE CONTROLS WITH

TOUCH-SCREEN ...............34

POWER SLIDING REAR WINDOW .... 35

WIND BUFFETING ............. 35

ELECTRONICS

YOUR VEHICLE'S SOUND SYSTEM . . . 36

IDENTIFYING YOUR RADIO ........ 38

Uconnect Uconnect®8.4A AND Uconnect®8.4AN)

(IF EQUIPPED) ................39

Uconnect Uconnect Uconnect Uconnect STEERING WHEEL AUDIO

CONTROLS ..................98

ELECTRONIC VEHICLE INFORMATION

CENTER (EVIC) ............... 98

PROGRAMMABLE FEATURES .......99

UNIVERSAL GARAGE DOOR OPENER (HomeLink

Access (AVAILABLE ON

3.0 ................49

5.0 ................51

8.4A ...............58

8.4AN ..............78

) ................ 101

POWER INVERTER ............104

POWER OUTLETS ............105

OFF-ROAD CAPABILITIES

FOUR-POSITION/PART TIME

TRANSFER CASE ............. 106

UTILITY

TOWING & PAYLOAD ...........107

TOW/HAUL MODE ............ 108

INTEGRATED TRAILER BRAKE

MODULE .................. 108

AUXILIARY SWITCHES .......... 109

RECREATIONAL TOWING

(BEHIND MOTORHOME, ETC.) ..... 110

DIESEL

DIESEL ENGINE BREAK-IN

RECOMMENDATIONS ...........112

DIESEL ENGINE STARTING

PROCEDURES ............... 112

DIESEL EXHAUST BRAKE

(ENGINE BRAKING) ........... 114

IDLE-UP FEATURE (AUTOMATIC

TRANSMISSION ONLY) .........115

ENGINE MOUNTED FUEL FILTER/WATER

SEPARATOR ................116

UNDERBODY MOUNTED FUEL

FILTER/WATER SEPARATOR ....... 117

EXHAUST REGENERATION ....... 118

COOL-DOWN IDLE CHART ........ 119

DIESEL EXHAUST FLUID ........ 120

WHAT TO DO IN EMERGENCIES

ROADSIDE ASSISTANCE ......... 122

INSTRUMENT CLUSTER WARNING

LIGHTS ................... 122

IF YOUR ENGINE OVERHEATS ..... 126

JACKING AND TIRE CHANGING .... 127

HOISTING ................. 133

JUMP-STARTING ............. 133

EMERGENCY TOW HOOKS .......135

SHIFT LEVER OVERRIDE ........136

TOWING A DISABLED VEHICLE ....137

FREEING A STUCK VEHICLE ...... 138

EVENT DATA RECORDER (EDR) .... 139

MAINTAINING YOUR VEHICLE

OPENING THE HOOD .......... 140

ENGINE COMPARTMENT ........ 141

FLUIDS AND CAPACITIES ........143

MAINTENANCE SCHEDULE –

GASOLINE ENGINE ............ 146

MAINTENANCE SCHEDULE –

DIESEL ENGINE .............. 151

FUSES ....................156

TIRE PRESSURES .............160

WHEEL AND WHEEL TRIM CARE . . . 161

EXTERIOR BULBS ............161

TABLE OF CONTENTS

CUSTOMER ASSISTANCE

CHRYSLER GROUP LLC CUSTOMER

CENTER .................. 162

CHRYSLER CANADA INC. CUSTOMER

CENTER .................. 162

ASSISTANCE FOR THE HEARING

IMPAIRED .................162

PUBLICATIONS ORDERING ....... 162

REPORTING SAFETY DEFECTS IN THE

UNITEDSTATES ..............163

MOPAR ACCESSORIES

AUTHENTIC ACCESSORIES BY MOPAR

INDEX

................164

....................169

FAQ (How To?)

FREQUENTLY ASKED QUESTIONS . . . 165

INTRODUCTION/WELCOME

WELCOME FROM CHRYSLER GROUP LLC

Congratulations on selecting your new Chrysler Group LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essentials that are traditional to our vehicles.

Your new Chrysler Group LLC vehicle has characteristics to enhance the driver's control under some driving conditions. These are to assist the driver and are never a substitute for attentive driving. They can never take the driver's place. Always drive carefully.

Your new vehicle has many features for the comfort and convenience of you and your passengers. Some of these should not be used when driving because they take your eyes from the road or your attention from driving. Never text while driving or take your eyes more than momentarily off the road.

This guide illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This guide may also include a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equipment described in this guide that are not available on this vehicle. Chrysler Group LLC reserves the right to make changes in design and specifications and/or make additions to or improvements to its products without imposing any obligation upon itself to install them on products previously manufactured.

This User Guide has been prepared to help you quickly become acquainted with the important features of your vehicle. It contains most things you will need to operate and maintain the vehicle, including emergency information.

The DVD includes a computer application containing detailed owner's information which can be viewed on a personal computer or MAC computer. The multimedia DVD also includes videos which can be played on any standard DVD player (including the Uconnect on the back of the DVD sleeve.

Touch-Screen Radios). Additional DVD operational information is located

INTRODUCTION/WELCOME

For complete owner information, refer to your Owner's Manual on the DVD in the owner’s kit provided at the time of new vehicle purchase. For your convenience, the information

contained on the DVD may also be printed and saved for future reference.

Chrysler Group LLC is committed to protecting our environment and natural resources. By converting from paper to electronic delivery for the majority of the user information for your vehicle, together we greatly reduce the demand for tree-based products and lessen the stress on our environment.

VEHICLES SOLD IN CANADA

With respect to any vehicles sold in Canada, the name Chrysler Group LLC shall be deemed to be deleted and the name Chrysler Canada Inc. used in substitution.

WARNING!

• Pedals that cannot move freely can cause loss of vehicle control and increase the risk of serious personal injury.

• Always make sure that objects cannot fall into the driver foot well while the vehicle is moving. Objects can become trapped under the brake pedal and accelerator pedal causing a loss of vehicle control.

•

Failure to properly follow floor mat installation or mounting can cause interference with the brake pedal and accelerator pedal operation causing loss of control of the vehicle.

• Never use the ‘PARK’ position as a substitute for the parking brake. Always apply the parking brake fully when parked to guard against vehicle movement and possible injury or damage.

• Refer to your Owner's Manual on the DVD for further details.

INTRODUCTION/WELCOME

USE OF AFTERMARKET PRODUCTS (ELECTRONICS)

The use of aftermarket devices including cell phones, MP3 players, GPS systems, or chargers may affect the performance of on-board wireless features including Keyless Enter-N-Go™ and Remote Start range. If you are experiencing difficulties with any of your wireless features, try disconnecting your aftermarket devices to see if the situation improves. If your symptoms persist, please see an authorized dealer.

CHRYSLER, DODGE, JEEP, RAM TRUCK, SRT, ATF+4, MOPAR and Uconnect are registered trademarks of Chrysler Group LLC.

CONTROLS AT A GLANCE

DRIVER COCKPIT

CONTROLS AT A GLANCE

L. Shifter

M. Keyless Engine Starting/

• Diesel Exhaust Brake

K. Switch Panel

Stopping pg. 12

• Tow/Haul pg. 108

N. Speed Control pg. 29

• Electronic Stability Control pg. 122

at base of instrument panel) pg. 140

O. Hood Release (below steering wheel

• Air Suspension System

P. Parking Brake Release

• Front Heated Seats pg. 23

Q. Power Mirrors

• Front Ventilated Seats pg. 23

R. Power Windows

• Heated Steering Wheel pg. 24

S. Power Door Locks

Module pg. 108

• Integrated Trailer Brake

• Engine Stop Start

A. Headlight Switch pg. 28

B. Turn Signal/Wiper/Washer/High

Beams Lever pg. 27

C. Electronic Vehicle Information

Center (EVIC) Controls pg. 98

D. Electronic Vehicle Information

Center (EVIC) Display pg. 9

E. Instrument Cluster pg. 8

F. Four Wheel Drive Operation pg. 106

G. Identify Your Audio System pg. 38

H. Audio System Hard Controls pg. 36

I. Power Inverter Outlet pg. 104

J. Manual Climate Controls pg. 33

CONTROLS AT A GLANCE

INSTRUMENT CLUSTER

Warning Lights

- Low Fuel Warning Light

- Charging System Light**

- Oil Pressure Warning Light**

- Anti-Lock Brake (ABS) Light**

- Air Bag Warning Light**

- Electronic Throttle Control (ETC) Light

- Engine Temperature Warning Light

- Transmission Temperature Warning Light

- Seat Belt Reminder Light

BRAKE

(See page 122 for more information.)

- Brake Warning Light**

- Malfunction Indicator Light (MIL)**

- SERV (Service) 4WD Indicator Light

- Low Coolant Level Indicator Light

CONTROLS AT A GLANCE

Indicators

- Turn Signal Indicators

- High Beam Indicator

- Park/Headlight ON Indicator*

- Front Fog Light Indicator

- Vehicle Security Indicator*

- TOW/HAUL Indicator*

- Four-Wheel Drive LOW Mode Indicator

- Four-Wheel Drive and 4LOCK Mode Indicator

- 4WD Auto Indicator

EVIC Messages

* If equipped

** Bulb Check with Key On

- Electronic Stability Control (ESC) Indicator Light*

- Electronic Stability Control (ESC) Off Indicator

- Cargo Lamp On Indicator

- Door Ajar Indicator

- Electronic Speed Control Set Indicator

- Check Fuel Filler

NOTE:

Refer to Electronic Vehicle Information Center (EVIC) in this guide or your owners manual for additional information.

GETTING STARTED

KEY FOB

Locking And Unlocking The Doors

• Press and release the UNLOCK button on the RKE transmitter once to unlock the driver’s door (EVIC can be setup for driver door first, otherwise this will unlock all doors), or press the unlock button twice within five seconds to unlock all doors, the tailgate and the

RamBox nal lights will flash to acknowledge the unlock signal. The illuminated entry system will also turn on.

All doors can be programmed to unlock

• on the first press of the UNLOCK button. Refer to Programmable Features in this guide.

Panic Alarm

• Press the PANIC button once to turn the panic alarm on.

• Wait approximately three seconds and press the button a second time to turn the panic alarm off.

(if equipped). The turn sig-

Emergency Key

• Should the battery in the vehicle or the Key Fob transmitter go dead, there is an emergency key located in the Key Fob that can be used for locking and unlocking the doors. To remove the emergency key, slide the button at the top of the Key Fob sideways with your thumb and then pull the key out with your other hand.

WARNING!

• Never leave children alone in a vehicle, or with access to an unlocked vehicle. Allowing children to be in a vehicle unattended is dangerous for a number of reasons. A child or others could be severely injured or killed. Children should be warned not to touch the parking brake, brake pedal, or the shift lever. Do not leave the Key Fob in or near the vehicle, or in a location accessible to children, and do not leave a vehicle equipped with Keyless Enter-N-G0™ in the ACC or ON/RUN mode. A child could start the vehicle, operate power windows, other controls, or move the vehicle.

• Do not leave children or animals inside parked vehicles in hot weather. Interior heat build-up may cause them to be severely injured or killed.

GETTING STARTED

KEYLESS ENTER-N-GO™

• The Keyless Enter-N-Go™ system is an enhancement to the vehicle's Key Fob. This feature allows you to lock and unlock the vehicle's door(s) without having to press the Key Fob lock or unlock buttons, as well as starting and stopping the vehicle with the press of a button.

To Unlock From The Driver or Passenger Side:

With a valid Keyless Enter-N-Go™ Key

• Fob located outside the vehicle and within 5 ft (1.5m) of the driver or passenger side door handle, grab either front door handle to unlock the door automatically.

To Lock The Vehicle’s Doors

• With a valid Keyless Enter-N-Go™ Key Fob transmitter within 5 ft (1.5 m) of the driver or passenger front door handles, press the door handle LOCK button to lock all doors.

• DO NOT grab the door handle, when pressing the door handle lock button. This could unlock the door(s).

NOTE:

• After pressing the door handle LOCK button, you must wait two seconds before you can lock or unlock the doors, using either Passive Entry door handle. This is done to allow you to check if the vehicle is locked by pulling the door handle, without the vehicle reacting and unlocking.

• The Passive Entry system will not operate if the RKE transmitter battery is dead.

The vehicle doors can also be locked by using the RKE transmitter lock button or the lock button located on the vehicles interior door panel.

GETTING STARTED

Engine Starting/Stopping

Starting

• With a valid Keyless Enter-N-Go™ Key Fob inside the vehicle.

• Place the shift lever in PARK or NEUTRAL.

• While pressing the brake pedal, press the ENGINE START/STOP button once. If the engine fails to start, the starter will disengage automatically after 10 seconds.

• To stop the cranking of the engine prior to the engine starting, press the button again.

NOTE:

In case the ignition switch does not change with the push of a button, the RKE transmitter (Key Fob) may have a low or dead battery. In this situation a back up method can be used to operate the ignition switch. Put the nose side of the Key Fob (side opposite of the Emergency Key) against the ENGINE START/STOP button and push to operate the ignition switch.

Stopping

• Bring the vehicle to a complete stop.

• Place the shift lever in the PARK position.

• Press the ENGINE START/STOP button once. The ignition switch will return to the OFF position.

NOTE: If the shift lever is not in PARK and the vehicle is in motion, the ENGINE START/STOP button must be held for two seconds with the vehicle speed above 5 mph (8 km/h) before the engine will shut off.

GETTING STARTED

REMOTE START

• Press the REMOTE START button Pressing the REMOTE START

• To drive the vehicle, press the UNLOCK button, insert the Key Fob in the ignition and turn to the ON/RUN position.

• With remote start, the engine will only run for 15 minutes (timeout) unless the ignition Key Fob is placed in the ON/RUN position.

• The vehicle must be started with the Key Fob after two consecutive timeouts.

• Do not start or run an engine in a closed garage or confined area. Exhaust gas contains Carbon Monoxide (CO) which is odorless and colorless. Carbon Monoxide is poisonous and can cause you or others to be severely injured or killed when inhaled.

• Keep Key Fob transmitters away from children. Operation of the Remote Start System, windows, door locks or other controls could cause you and others to be severely injured or killed.

THEFT ALARM

To Arm:

•

Press the Key Fob LOCK button or the power door lock switch while the door is open.

on the Key Fob twice within five seconds.

button a third time shuts the engine off.

WARNING!

To Disarm:

• Press the Key Fob UNLOCK button or turn the ignition to the ON/RUN position.

SEAT BELT

• Be sure everyone in your vehicle is in a seat and using a seat belt properly.

• Position the lap belt across your thighs, below your abdomen. To remove slack in the lap portion, pull up a bit on the shoulder belt. To loosen the lap belt if it is too tight, tilt the latch plate and pull on the lap belt. A snug belt reduces the risk of sliding under the belt in a collision.

• Position the shoulder belt on your chest so that it is comfortable and not resting on your neck. The retractor will withdraw any slack in the belt.

• A shoulder belt placed behind you will not protect you from injury during a collision. You are more likely to hit your head in a collision if you do not wear your shoulder belt. The lap and shoulder belt are meant to be used together.

A belt that is too loose will not protect you properly. In a sudden stop you could move

• too far forward, increasing the possibility of injury. Wear your seat belt snugly.

GETTING STARTED

• A frayed or torn belt could rip apart in a collision and leave you with no protection. Inspect the belt system periodically, checking for cuts, frays, or loose parts. Damaged parts must be replaced immediately. Do not disassemble or modify the system. Seat belt assemblies must be replaced after a collision if they have been damaged (bent retractor, torn webbing, etc.).

• A deployed air bag must be replaced immediately.

WARNING!

In a collision, you and your passengers can suffer much greater injuries if you are not buckled up properly. You can strike the interior of your vehicle or other passengers, or you can be thrown out of the vehicle. Always be sure you and others in your vehicle are buckled up properly.

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) — AIR BAGS

• This vehicle has Advanced Front Air Bags for both the driver and right front passenger as a supplement to the seat belt restraint system. The Advanced Front Air Bags will not deploy in every type of collision.

• Advanced Front Air Bags are designed to provide additional protection by supplementing the seat belts in certain frontal collisions depending on several factors, including the severity and type of collision. Advanced Front Air Bags are not expected to reduce the risk of injury in rear, side, or rollover collisions.

If the Air Bag Warning Light is not on during starting, stays on, or turns on while

• driving, have the vehicle serviced by an authorized service center immediately.

• Refer to the Owner's Manual on the DVD for further details regarding the Supplemental Restraint System (SRS)

WARNING!

• Relying on the air bags alone could lead to more severe injuries in a collision. The air bags work with your seat belt to restrain you properly. In some collisions, the air bags won't deploy at all. Always wear your seat belts even though you have air bags.

• Being too close to the steering wheel or instrument panel during Advanced Front Air Bag deployment could cause serious injury, including death. Air bags need room to inflate. Sit back, comfortably extending your arms to reach the steering wheel or instrument panel.

• Do not drive your vehicle after the air bags have deployed. If you are involved in another collision, the air bags will not be in place to protect you.

• After any collision, the vehicle should be taken to an authorized dealer immediately.

GETTING STARTED

CHILD RESTRAINTS

• Children 12 years and under should ride properly buckled up in a rear seat, if available. According to crash statistics, children are safer when properly restrained in the rear seats rather than in the front.

• Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems. This is the law, and you can be prosecuted for ignoring it.

NOTE:

For additional information, refer to www.seatcheck.org or call 1–866–SEAT-CHECK

• (1–866–732–8243).

•

Canadian residents, should refer to Transport Canada’s website for additional

informationhttp://www.tc.gc.ca/eng/roadsafety/safedrivers-childsafety-index-53.htm.

Installing The LATCH - Compatible Child Restraint System

• Your vehicle’s second row passenger seats are equipped with the child restraint anchorage system called LATCH, which stands for Lower Anchors and Tether for CHildren. LATCH child restraint anchorage systems are installed in the rear seat outboard positions.

LATCH equipped seating positions have both lower anchor bars, located at the back

• of the seat cushion, and tether strap anchorages, located behind the seat back.

Installing The Lower Attachments:

• The vehicle lower anchorages are round bars located at the rear of the seat cushion where it meets the seatback. The rear seat lower anchors can be readily identified by the symbol just visible when you lean into the rear seat to install the child restraint.

Loosen the child seat adjusters on the

• lower straps and on the tether strap so that you can attach the hooks or connectors to the vehicle anchors more easily.

• Attach the lower hooks or connectors over the top of the seatcover material.

Then tighten the straps as you push the

• child restraint rearward and downward into the seat.

located on the seatback directly above the anchorages and are

GETTING STARTED

Tether Anchorage Points At The Right And Center Front Seat (Regular Cab - All Seats):

•

Place the child restraint on the seat and adjust the tether strap so that it will reach over

the seat back under the head restraint to the tether anchor directly behind the seat.

• Lift the cover (if equipped), and attach the hook to the square opening in the sheet metal.

• Install the child restraint and remove the slack in the tether strap according to the manufacturer's instructions.

Child Restraint Installation Sequence (Mega Cab® - Rear Seats):

•

Place a child restraint on each outboard rear seat and adjust the tether strap so that

it will reach under the head restraint to the tether anchor directly behind the seat.

• Lift the cover, and attach the hook to the square opening in the sheet metal.

• Install the child restraint and remove the slack in the tether strap according to the manufacturer's instructions.

Child Restraints Installation Sequence (Quad Cab®/Crew Cab - Rear Seats)

The top tether anchorages in this vehicle are tether strap loops located between the rear glass and the back of the rear seat. There is a tether strap loop located behind each seating position. Follow the steps below to attach the tether strap of the child restraint.

GETTING STARTED

Right or Left Outboard Seats:

1. Raise the head restraint and reach between the rear seat and rear glass to access the tether strap loop.

Head Restraint In Raised Position Tether Strap Loop With Center Head

2. Place a child restraint on the seat and adjust the tether strap so that it will reach over the seat back, under the head restraint, through the tether strap loop behind the seat and over to the tether strap loop behind the center seat.

3. Pass the tether strap hook under the head restraint behind the child seat, through the tether strap loop behind the seat and over to the center tether strap loop.

Restraint In Raised Position

Tether Strap Through Outboard Tether Strap

Loop

GETTING STARTED

4. Attach the hook to the center tether strap loop (see diagram). Tighten the tether strap according to the child seat manufacturer’s instructions.

NOTE:

If there are child seats in both of the outboard (left and right) seating positions, the tether strap hooks of both child seats should be connected to the center tether strap loop. This is the correct way to tether two outboard child seats.

Tether Strap Through Outboard Tether Strap

Loop And Attached To Center Tether Strap Loop

Center Seat:

1. Raise the head restraint and reach between the rear seat and rear glass to access the tether strap loop.

3. Pass the tether strap hook under the head restraint behind the child seat, through the tether strap loop behind the seat and over to the right or left outboard tether strap loop.

Tether Strap Loop With Head Restraint In

Raised Position

Tether Strap Through Center Tether Strap Loop

GETTING STARTED

4. Attach the hook to the outboard tether strap loop (see diagram). Tighten the tether strap according to the child seat manufacturer’s instructions.

Tether Strap Through Center Tether Strap

Loop And Attached To Outboard Tether Strap

Installing Three Child Restraints:

Place a child restraint on each out-

1. board rear seat. Route the tether straps following the directions for right and left seating positions, above.

2. Attach both hooks to the center tether strap loop, but do not tighten the straps yet.

Place a child restraint on the center rear seat. Route the tether strap following the directions for the center seating position, above.

4. Attach the hook to the outboard tether strap loop.

5. Tighten the tether straps according to the child seat manufacturer’s instructions, tightening the right and left tether straps before the center tether strap.

Left Outboard And Center Seating Position

Loop

Shown

GETTING STARTED

Installing The Child Restraint Using The Vehicle Seat Belts

• To install a child restraint, first, pull enough of the seat belt webbing from the retractor to route it through the belt path of the child restraint and slide the latch plate into the buckle.

• Next, extract all the seat belt webbing out of the retractor and then allow the belt to retract into the retractor. Finally, pull on any excess webbing to tighten the lap portion around the child restraint. Any seat belt system will loosen with time, so check the belt occasionally, and pull it tight if necessary.

• Route the tether strap to provide the most direct path for the strap between the anchor and the child seat, preferably between the head restraint posts underneath the head restraint.

• Attach the tether strap hook of the child restraint to the tether anchor and remove slack in the tether strap according to the child restraint manufacturer’s instructions.

NOTE:

Ensure that the tether strap does not slip into the opening between the seatbacks as you remove slack in the strap.

WARNING!

• In a collision, an unrestrained child, even a tiny baby, can become a projectile inside the vehicle. The force required to hold even an infant on your lap could become so great that you could not hold the child, no matter how strong you are. The child and others could be severely injured or killed. Any child riding in your vehicle should be in a proper restraint for the child's size.

• Improper installation of a child restraint to the LATCH anchorages can lead to failure of an infant or child restraint. The child could be severely injured or killed. Follow the manufacturer’s directions exactly when installing an infant or child restraint.

• An incorrectly anchored tether strap could lead to increased head motion and possible injury to the child. Use only the anchor positions directly behind the child seat to secure a child restraint top tether strap.

• Rearward-facing child seats must never be used in the front seat of a vehicle with a front passenger air bag. An air bag deployment could cause severe injury or death to infants in this position.

GETTING STARTED

FRONT SEATS

Power Seats

• The seat switch controls forward/ backward and up/down.

• The recline switch controls the angle of the seatback. Push switch forward or rearward and the seatback will move in either direction.

Power Lumbar

•

The lumbar controls are located on the outboard side of the seat cushion. The lumbar support can be increased by pressing the front of the switch and decreased by pressing the back of the switch.

Memory Seat

•

The memory seat feature allows you to save the driver's seat position (excluding lumbar position), driver's outside mirror position, adjustable brake and accelerator pedals, Automatic Temperature Control (ATC) temperature setting and radio station preset settings. The driver's memory buttons are located on the outboard side of the driver's seat cushion.

• Adjust all memory profile settings, press the middle button S (SET), then press 1 or 2 within five seconds.

• To program a Key Fob to the memory position, place the ignition switch in the LOCK position and remove the Key Fob, press and release the LOCK button on the Key Fob to be programmed within 5 seconds of pressing button 1 or 2.

• Press 1 or 2 to recall the saved positions, or press UNLOCK on the programmed Key Fob.

• Refer to the Owner's Manual on the DVD for further details.

GETTING STARTED

Manual Seats

Forward/Rearward

•

Lift up on the adjusting bar located at the front of the seat near the floor and release it when the seat is at the desired position. Then, using body pressure, move forward and backward on the seat to be sure that the seat adjusters have latched.

Recliner

• Lift the recliner lever located on the outboard side of the seat, lean back and release at the desired position.

CAUTION!

Do not place any article under a power seat or impede its ability to move as it may cause damage to the seat controls. Seat travel may become limited if movement is stopped by an obstruction in the seat’s path.

WARNING!

• Adjusting a seat while the vehicle is moving is dangerous. The sudden movement of the seat could cause you to lose control. The seat belt might not be properly adjusted, and you could be severely injured or killed. Only adjust a seat while the vehicle is parked.

• Actuating the recliner handle will allow the seatback to swing (dump) forward on manual recliner seats. Do not stand or lean in front of the seat while actuating the handle. The seatback may swing forward and hit you, causing injury. This dump feature allows access to the storage bin behind the seat. To avoid injury, place your hand on the seatback and actuate the handle, then position the seatback in the desired position.

• Do not ride with the seatback reclined so that the seat belt is no longer resting against your chest. In a collision, you could slide under the seat belt and be severely injured or killed. Use the recliner only when the vehicle is parked.

GETTING STARTED

HEATED/VENTILATED SEATS

Front Heated Seats

• The controls for front heated seats are located on the center instrument panel below the climate controls and there are soft keys in the radio that control the front heated seats.

• Press the switch once to select Highlevel heating. Press the switch a second time to select Low-level heating. Press the switch a third time to shut the heating elements Off.

If the High-level setting is selected, the

• system will automatically switch to Lowlevel after approximately 20 minutes. The Low-level setting will turn Off automatically after approximately 40 minutes.

Front Ventilated Seats

• Located in the seat cushion are small fans that draw the air from the passenger compartment and pull air through fine perforations in the seat cover to help keep the driver and front passenger cooler in higher ambient temperatures.

• The ventilated seat switches are located in the switch bank in the center stack of the instrument panel just below the climate controls as well as soft keys in the radio. The fans operate at two speeds, HIGH and LOW. Press the switch once to select High speed. Press the switch a second time to select Low speed. Press the switch a third time to turn the fans Off.

REAR HEATED SEATS

Second row heated seat switches are

• located on the rear of the center console.

• Press the switch once to select Highlevel heating. Press the switch a second time to select Low-level heating. Press the switch a third time to shut the heating elements Off.

• If the High-level setting is selected, the system will automatically switch to Low-level after approximately 20 minutes. The Low-level setting will turn Off automatically after approximately 40 minutes.

GETTING STARTED

WARNING!

• Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaustion or other physical conditions must exercise care when using the seat heater. It may cause burns even at low temperatures, especially if used for long periods of time.

• Do not place anything on the seat that insulates against heat, such as a blanket or cushion. This may cause the seat heater to overheat. Sitting in a seat that has been overheated could cause serious burns due to the increased surface temperature of the seat.

HEATED STEERING WHEEL

• The steering wheel contains a heating element that heats the steering wheel to one temperature setting.

• The heated steering wheel switch is located on the center instrument panel below the climate controls.

• The heated steering wheel is also controlled by soft keys in the radio screen.

• Press the switch once to turn the heating element On. Press the switch a second time to turn the heating element Off.

• Once the heated steering wheel has been turned on, it will operate for approximately 30 to 95 minutes before automatically shutting off. The heated steering wheel can shut off early or may not turn on when the steering wheel is already warm.

GETTING STARTED

TILT STEERING COLUMN

• The tilt lever is located on the steering column below the turn signal lever.

• To tilt the column, simply pull the tilt lever rearward toward you and then move the steering wheel upward or downward as desired.

Release the tilt lever to lock the steering

• wheel into position.

ADJUSTABLE PEDALS

• Press the switch located on the left side of the steering column forward to move the brake and accelerator pedals away from the driver and press the switch rearward to move the pedals closer to the driver.

NOTE:

The pedals cannot be adjusted when the vehicle is in REVERSE or when the Electronic Speed Control is set.

CAUTION!

Do not place any article under the adjustable pedals or impede its ability to move, as it may cause damage to the pedal controls. Pedal travel may become limited if movement is stopped by an obstruction in the adjustable pedal's path.

WARNING!

• Tilting the steering column while the vehicle is moving is dangerous. Without a stable steering column, you could lose control of the vehicle and have a collision. Adjust the column only while the vehicle is stopped. Be sure it is locked before driving.

• Do not adjust the pedals while the vehicle is moving. You could lose control and have a collision. Always adjust the pedals while the vehicle is parked.

OPERATING YOUR VEHICLE

ENGINE BREAK-IN RECOMMENDATIONS

• A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle.

• Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km), speeds up to 50 or 55 mph (80 or 90 km/h) are desirable.

• While cruising, brief full-throttle acceleration within the limits of local traffic laws contributes to a good break-in. Wide-open throttle acceleration in low gear can be detrimental and should be avoided.

• The engine oil installed in the engine at the factory is a high-quality energy conserving type lubricant. Oil changes should be consistent with anticipated climate conditions under which vehicle operations will occur. For the recommended viscosity and quality grades, refer to “Maintaining Your Vehicle”.

NOTE:

A new engine may consume some oil during its first few thousand miles (kilometers) of operation. This should be considered a normal part of the break-in and not interpreted as an indication to an engine problem or malfunction.

CAUTION!

Never use Non-Detergent Oil or Straight Mineral Oil in the engine or damage may result.

DIESEL ENGINE BREAK-IN RECOMMENDATIONS

For diesel engine break-in recommendations, refer to Diesel Engine Break-In Recommendations on pg. 112

OPERATING YOUR VEHICLE

TURN SIGNALS/WIPER/WASHER/HIGH BEAMS LEVER

Turn Signals/Lane Change Assist

• Tap the lever up or down once and the turn signal (right or left) will flash three times and automatically turn off.

Wipers

Intermittent, Low And High Operation

• Rotate the end of the lever to the first detent position for one of five intermittent settings, the second detent for low wiper operation and the third detent for high wiper operation.

Washer Operation

• Push the end of the lever inward to the second detent and hold for as long as spray is desired.

Mist Feature

• When a single wipe to clear off road mist or spray from a passing vehicle is needed, push the washer knob, located on the end of the multifunction lever, inward to the first detent and release. The wipers will cycle one time and automatically shut off.

High Beams

• Push the lever away from you to activate the high beams.

A high beam symbol will illuminate in the cluster to indicate the high beams are on.

•

NOTE:

For safe driving, turn off the high beams when oncoming traffic is present to prevent headlight glare and as a courtesy to other motorists.

OPERATING YOUR VEHICLE

HEADLIGHT SWITCH

Automatic Headlights/Parking Lights/Headlights

• Rotate the headlight switch, located on the instrument panel to the left of the steering wheel, to the first detent

for parking lights and to the

second detent for headlights

With the parking lights or low beam

• headlights on, push the headlight switch once for fog lights.

•

Rotate the headlight switch to “AUTO”

for AUTO headlights.

• When set to AUTO, the system automatically turns the headlights on or off based on ambient light levels.

SmartBeams™

• This system automatically controls the use of the headlight high beams. Refer to Programmable Features in Electronics for further details.

Instrument Panel Dimmer

•

Rotate the dimmer control to the extreme left position to fully dim the instrument

panel lights and prevent the interior lights from illuminating when a door is opened.

• Rotate the dimmer control right to increase the brightness of the instrument panel when the parking lights or headlights are on.

• Rotate the dimmer control right to the next detent position to fully brighten the odometer and radio when the parking lights or headlights are on. Refer to your Media Center/Radio User Manual on the DVD for display dimming.

• Rotate the dimmer control right to the last detent position to turn on the interior lighting.

Cargo Light

The cargo light is strategically placed lighting that helps illuminate the bed area of

• the truck. A cargo light symbol will illuminate in the cluster to indicate the light is on.

• Push the button to turn ON/OFF the cargo lighting.

OPERATING YOUR VEHICLE

SPEED CONTROL

• The speed control switches are located on the steering wheel.

Cruise ON/OFF

• Push the ON/OFF switch to activate the Speed Control.

• The cruise symbol Control is on.

• Push the ON/OFF switch a second time to turn the system off.

Set

• With the Speed Control on, push and release the SET/DECEL switch to set a desired speed.

will appear on the instrument cluster to indicate the Speed

OPERATING YOUR VEHICLE

Accel/Decel

•

Push and hold the RESUME/ACCEL switch to accelerate or push and hold the SET/DECEL switch to decelerate the vehicle; release the switch to save the new set speed.

• Once a speed is set, pushing the RESUME/ACCEL switch once or the SET/DECEL switch once will increase or decrease the set speed approximately 1 mph (2 km/h).

Resume

• To resume a previously selected set speed in memory, push the RESUME/ACCEL switch and release.

Cancel

• Push the CANCEL switch or apply the brakes to cancel the set speed and maintain the set speed memory.

• Push the ON/OFF switch to turn the system off and erase the set speed memory.

WARNING!

• Leaving the Electronic Speed Control system on when not in use is dangerous. You could accidentally set the system or cause it to go faster than you want. You could lose control and have a collision. Always leave the Electronic Speed Control system off when you are not using it.

• Electronic Speed Control can be dangerous where the system cannot maintain a constant speed. Your vehicle could go too fast for the conditions, and you could lose control. A collision could be the result. Do not use Electronic Speed Control in heavy traffic or on roads that are winding, icy, snow-covered or slippery.

OPERATING YOUR VEHICLE

ELECTRONIC RANGE SELECT (ERS) OPERATION

•

Electronic Range Select (ERS) allows you to limit the highest available transmission gear, and can be activated during any driving condition. When towing a trailer or operating the vehicle in off-road conditions, using ERS shift control will help you maximize both performance and engine braking.

• Toggle the switch on the column shift lever down (-) or up (+) to select the desired top gear.

• For maximum deceleration (engine braking) toggle the switch on the column shift lever down (-). Your vehicle will automatically select the lowest safe gear for optimal engine braking.

• To disable ERS, push and hold the column shift lever switch up (+) until “D” is displayed in the odometer.

• Switching between ERS and DRIVE mode can be done at any vehicle speed.

• Refer to your Owner's Manual on the DVD for further details.

OPERATING YOUR VEHICLE

MANUAL CLIMATE CONTROLS WITHOUT TOUCH-SCREEN

Air Recirculation /Max A/C

• Rotate the Temperature Control to the MAX A/C position to automatically turn on both Air Conditioning and Recirculation.

• For window defogging, turn the recirculation button off.

• Recirculation is not allowed in defrost

Recirculation is allowed in floor mode and defrost/floor (mix modes) for approxi-

• mately five minutes.

Heated Mirrors

• The mirrors are heated to melt frost or ice. This feature is activated whenever you turn on the defroster.

OPERATING YOUR VEHICLE

MANUAL CLIMATE CONTROLS WITH TOUCH-SCREEN

Touch-Screen Manual Climate Controls

Climate Control Knobs

Air Recirculation

• Use recirculation for maximum A/C operation.

• For window defogging, turn the recirculation button off.

Heated Mirrors

• The mirrors are heated to melt frost or ice. This feature is activated whenever you turn on the defroster.

OPERATING YOUR VEHICLE

AUTOMATIC CLIMATE CONTROLS WITH TOUCH-SCREEN

Touch-Screen Automatic Climate Controls

Climate Control Knobs

• Press the AUTO button or AUTO soft-key.

• Select the desired temperature by pushing the up or down temperature buttons for the driver or passenger.

• The system will maintain the set temperature automatically.

OPERATING YOUR VEHICLE

Air Conditioning (A/C)

• If the air conditioning button is pressed while in AUTO mode, the system will exit AUTO mode and stay in A/C. The mode and blower will be set at the closest mode and blower position that the system was operating in AUTO.

SYNC Temperature Soft-Key

• Touch the SYNC soft-key on the Uconnect passenger temperatures simultaneously. Touch the SYNC soft-key a second time to control the temperatures individually.

Air Recirculation

• Use recirculation for maximum A/C operation.

• For window defogging, turn the recirculation button off.

• If the Recirculation button is pushed while in the AUTO mode, the indicator light may flash three times to indicate the cabin air is being controlled automatically.

Heated Mirrors

• The mirrors are heated to melt frost or ice. This feature is activated whenever you turn on the defroster.

POWER SLIDING REAR WINDOW

•

The switch for the power sliding rear window is located on the overhead console.

•

Push the switch right to open the glass and pull the switch left to close the glass.

radio to control the driver and

WIND BUFFETING

•

Wind buffeting can be described as a helicopter-type percussion sound. If buffeting occurs with the rear windows open, adjust the front and rear windows together.

• If buffeting occurs with the sunroof open, adjust the sunroof opening, or adjust any window. This will minimize buffeting.

ELECTRONICS

YOUR VEHICLE'S SOUND SYSTEM

ELECTRONICS

IDENTIFYING YOUR RADIO

Uconnect® 3.0

• Two hard-keys on either side of the display

Uconnect® 5.0

• 5” Touch-Screen

• Three hard-keys on either side of the display

Uconnect® 8.4A

• 8.4” Touch-Screen

• Climate soft key in lower menu bar

• HD Button will NOT be visible on right side of screen when viewing AM or FM

SiriusXM Travel Link feature NOT listed

• within Apps

Uconnect® 3.0

Uconnect® 5.0

Uconnect® 8.4A

ELECTRONICS

Uconnect® 8.4AN

• 8.4” Touch-Screen

• Climate soft key in lower menu bar

• HD Button will be visible on right side of screen when viewing AM or FM

SiriusXM Travel Link feature listed

• within Apps

Uconnect® 8.4AN

Uconnect® Access (AVAILABLE ON Uconnect® 8.4A AND Uconnect® 8.4AN) (IF EQUIPPED)

• Uconnect®Access enhances your ownership and driving experience by connecting your vehicle with a 3G cellular connection. Uconnect

• The ability to remotely lock/unlock your doors and start your vehicle from virtually anywhere, with the Uconnect and Uconnect network coverage).

• The functionality to turn your vehicle into a WiFi Hotspot on demand.

• Theft Alarm Notification via text or E-mail.

• Bing™ to help find things, places, businesses and other locations when you need them.

• Voice Texting so you can compose, send and receive text messages with your voice while keeping your hands on the wheel.

• Before you drive, familiarize yourself with the easy-to-use Uconnect

1. The ASSIST and 9-1-1 buttons are located on your rearview mirror. The ASSIST Button is used for contacting Roadside Assistance, Vehicle Care and Uconnect Care. The 9-1-1 Button connects you directly to emergency assistance.

NOTE: Vehicles sold in Canada and Mexico DO NOT have 9-1-1 Call system capabilities. 9-1-1 or other emergency line operators in Canada and Mexico may not answer or respond to 9-1-1 system calls.

2. The Uconnect radio touch screen. This is where you can begin your registration process, manage your Apps and purchase WiFi on demand.

3. The Uconnect left side of your steering wheel. These buttons let you use your voice to give commands, make phone calls, send and receive text messages hands-free, enter navigation destinations, and control your radio and media devices.

Care (Vehicle must be within the United States and have

“Apps” soft-key on the menu bar at the bottom right corner of the

Voice Command and Uconnect®Phone buttons are located on the

Access App, Owner Connect website

Access provides:

System.

ELECTRONICS

Included Trial Period for New Vehicles

• Your new vehicle may come with an included trial period for use of the Uconnect Access Services starting at the date of vehicle purchase*. To activate the trial, you must first register with Uconnect customers can purchase additional Services and Apps over the lifetime of their vehicle ownership.

Features and Packages

• After the trial period, you can subscribe to continue your service by visiting the

Uconnect

Store located within the Mopar Owner Connect website (MoparOwnerConnect.com). If you need assistance, U.S. residents can call Uconnect 855-792-4241.

• For the latest information on packages and pricing information for U.S. residents only, visit www.DriveUconnect.com.

Uconnect® Access Registration

Access. Once registered, Uconnect®Access

Care at

NOTE:

To unlock the full potential of Uconnect register with Uconnect

From the parked vehicle with the radio touch screen powered on, select the “Apps”

Access.

Access in your vehicle, you first need to

soft-key located near the bottom right-hand corner of the radio touch screen.

NOTE:

Should you require assistance anytime during the registration process, simply press the ASSIST button located on the rear view mirror to be connected with a Uconnect Care agent.

2. Touch Register on the reminder screen or select the “Uconnect Registration”

soft-key which appears in the “Favorites Tab” on the Apps list.

3. The Uconnect

Access Registration App will open and display step-by-step

instructions to start your registration.

4. Enter your E-mail address into the radio touch screen.

5. This message will display on the touch screen indicating your mail submission

was accepted. In a few minutes, you will receive an mail which will allow you to

Access registration within 24 hours.

Access. You should open this mail and begin

6. A final message will display on the touch screen allowing you to check on the

status of your mail submission. To exit the registration, press the X in the upper right corner.

ELECTRONICS

NOTE:

For security reasons, this link is valid for 24 hours from the time you submit your mail address into the radio touch screen. If the link has expired, simply re-enter your mail address into the Uconnect another link.

• The secured registration link will take you through the Uconnect registration process step by step.

• To unlock the full potential of Uconnect create or validate an existing Mopar Owner Connect account (previously Owner Center). Uconnect one destination to manage all of your vehicle needs- from managing your

Uconnect

Access account to tracking service history and finding recommended accessories for your vehicle. If you already have a Mopar Owner Connect account, log in to the website with your existing user name and password. For assistance with this web based registration process, call Uconnect

• At this point your vehicle is registered with Uconnect downloaded the next time you start your vehicle. It may take over 30 minutes for all of the apps to install. If the apps have not appeared after 24 hours, please contact Uconnect

• Set up your Payment Account. (Provides the option to purchase packages and apps, such as WiFi Hotspot)

• Download the Uconnect such as Remote Door Unlock)

Download the Uconnect® Access App

• If you own a compatible iOS or Android App allows you to remotely lock or unlock your doors, start your engine or activate your horn and lights from virtually anywhere (Vehicle must be within the United States and have network coverage). You can download the App from Mopar Owner Connect or from the Apple App or Google Play store. For Uconnect customer support and to determine if your device is compatible:

• U.S. residents - visit www.UconnectPhone.com or call 1–877–855–8400

Canadian residents - call 1–800–465–2001 (English) or 1–800–387–9983 (French)

•

Registration App on the radio touch screen to receive

Access

Access in your vehicle, you will need to

along with Mopar Owner Connect have joined forces to create

Care at 855-792-4241.

Access. Apps will be

Care. The recommended next steps are to:

Access App. (Allows you to utilize the Remote Services

powered device, the Uconnect Access

Phone

ELECTRONICS

Purchasing Apps and WiFi

NOTE:

Apps and WiFi can be purchased from the Uconnect online at Mopar Owner Connect. You must first register and set up a Uconnect Payment account.

Purchasing Apps and WiFi for your vehicle

1. With the vehicle parked and the radio powered on, select the “Apps” soft-key located near the bottom right-hand corner of the radio touch screen.

2. To launch the Uconnect

3. From the Uconnect

Store, select Tools and then select Uconnect®Store.

Store, select the Application (App) you wish to purchase.

4. This will launch the selected App into purchase mode along with providing additional information. The purchase process begins when you touch the “Buy” soft-key.

5. The Uconnect

Store will display a “Purchase Overview” message confirming the financial details for the App you are about to purchase. Touch the “Purchase” key to continue.

6. The Uconnect

Store will ask you to “Confirm Payment” using your default payment method on file in your Payment Account. Touch the Complete key to continue.

7. The Uconnect

Payment Account will then ask for your “Payment Account PIN”.

After entering this four digit PIN, touch the Complete key to make the purchase.

8. You will receive a confirmation message that your purchase has been submitted. Touch the OK to end the process.

NOTE:

Purchased apps can take up to 30 minutes to download, depending on your vehicle’s cellular coverage at time of purchase. If your download takes more than 30 minutes, please contact Uconnect

Care by pressing the ASSIST button on the rear view mirror.

• You can also purchase apps or renew your subscription to a package from the

Mopar Owner Connect website. Log In to the Mopar Owner Connect website (www.moparownerconnect.com) with your user name and password, and click on the “Store” tab.

Store within your vehicle, and

ELECTRONICS

Using Uconnect® Access

Getting Started with Apps

• Applications (Apps) in your Uconnect services that are customized for the driver and are certified by Chrysler Group, LLC. Two different types are:

• Built-In Apps – use the built-in 3G Cellular Network on your Uconnect® radio.

• Brought-In Apps – Uconnect or device’s data plan and connection to stream content from Chrysler Group, LLC certified apps into your vehicle and control them using the Uconnect touch-screen, steering wheel controls, and voice recognition.

• Get started with your Uconnect soft-key on the menu bar at the bottom right corner of the radio touch screen. Available apps and features are organized by the tabs on the left of the screen.

• Favorite Apps – this is the default screen when you first press the Apps soft-key, and is a good place to put the apps you use most frequently. To make an App a “favorite”, press the settings soft-key to the right of the app, and select “Make a favorite”.

• Media Apps, Information Apps, and Tools – Organizes your Uconnect apps (when available) into three categories, depending on the type of app.

• Running Apps – press this tab to see which apps are currently running.

Access will allow you to use your own smartphone

Access apps by pressing the Uconnect®“Apps”

Access system deliver features and

radio

Access

ELECTRONICS

Maintaining Your Uconnect® Access Account

Reinstalling an App

• You can easily correct many Application related issues you may be experiencing by resetting the App back to the factory setting. From the vehicle’s radio touchscreen, complete the following steps:

1. Touch the Uconnect

2. In My Apps, select Settings and then Reinstall App and lastly, Continue.

3. Your Apps have been successfully re-installed.

Canceling Your Subscription

•

Should you want to cancel your subscription, you can remove your account informa-

tion using the same procedure contained in the Selling Your Vehicle section.

Selling Your Vehicle

When you sell your vehicle, we recommend that you remove your Uconnect®Access

• Account information from the vehicle. You can do this using the radio touch screen in the vehicle or on the Mopar Owner Connect website (www.MoparOwnerConnect.com). Removing your account information cancels your subscription and makes your vehicle factory-ready for a new owner/subscriber.

From your vehicle’s radio touch-screen, select the Uconnect®Store from the Apps icon.

2. Select My apps, then Settings, and then Remove Uconnect®Account.

3. Enter your Uconnect

Uconnect Account”.

• For further assistance call Uconnect www.MoparOwnerConnect.com. On the Owner Connect site, go to Uconnect Store, and click on “Remove My Vehicle” button.

In Vehicle Features

1. Assist Call – The rear view mirror contains an ASSIST push button which

automatically connects the vehicle occupants to one of these predefined destinations for immediate support:

• Roadside Assistance Call – If you get a flat tire, or need a tow, you’ll be connected

to someone who can help anytime. Additional fees may apply. Additional information in this section.

• Uconnect® Access Care – In vehicle support for Uconnect

and Features.

• Vehicle Care – Total support for your Chrysler Group LLC vehicle.

App and open the Uconnect®Store and go to My Apps.

Security PIN, select “Proceed to Remove Vehicle from

Care at 855-792-4241, or visit

Access System, Apps

ELECTRONICS

2. Emergency 9-1-1 Call (If Equipped) – The rear view mirror contains a 9-1-1 button

that, when pressed, will place a call to a local 9-1-1 operator to request help from local police, fire or ambulance personnel in the event of an emergency. If this button is accidentally pressed, you will have 10 seconds to cancel the call. To cancel, press the 9-1-1 Call button again or press the cancellation button shown on the touch screen. After 10 seconds has passed, the 9-1-1 call will be placed and only the 9-1-1 operator can cancel it. The LED light on the Rearview Mirror will turn green once a connection to a 9-1-1 operator has been made. The green LED light will turn off once the 9-1-1 call is terminated. Have an authorized dealer service the vehicle if the Rearview Mirror light is continuously red. If a

connection is made between a 9-1-1 operator and your vehicle, you understand and agree that 9-1-1 operators may, like any other 9-1-1 call, record conversations and sounds in and near your vehicle upon connection.

3. Roadside Assistance (If Equipped) - If your vehicle is equipped with this feature and

within wireless range, you may be able to connect to Roadside Assistance by pressing the “Assist” button on the Rearview Mirror. You will be presented with Assist Care options. Make a selection by touching the prompts displayed on the radio If Roadside Assistance is provided to your vehicle, you agree to be responsible for any additional roadside assistance service costs that you may incur. In order to provide Uconnect your conversations with Roadside Assistance, Uconnect whether such conversations are initiated through the Uconnect vehicle, or via a landline or mobile telephone, and may share information obtained through such recording and monitoring in accordance with regulatory requirements. You acknowledge, agree and consent to any recording, monitoring or sharing of information obtained through any such call recordings.

4. Bing™ - Customers have the ability to search for nearby destinations or a point of

interest (POI) either by category or custom search by using keywords (for example, “Italian restaurant”). Searching can be done by voice or using the touch-screen keypad. Using the touch-screen, launch Bing™ by selecting the Apps icon, touch Information Apps tab, and then touch Bing™. Using voice recognition press the VR button on the steering wheel and say “Launch Bing” or just say “Bing” to launch the app.

5. Theft Alarm Notification - The Theft Alarm Notification feature notifies you via

E-mail or text message (SMS) when the vehicle’s factory-installed theft alarm system has been set-off. There are a number of reasons why your alarm may have been triggered, one of which could be that your vehicle was stolen. If so, please see the details of the Stolen Vehicle Assistance service below. When you register, Theft Alarm Notification is automatically set to send you an E-mail at the mail address you provide should the alarm go off. You may also opt to have a text message sent to your mobile device.

Services to you, we may record and monitor

Care or Vehicle Care,

Services in your

ELECTRONICS

6. Stolen Vehicle Assistance - If your vehicle is stolen, contact local law enforcement

immediately to file a stolen vehicle report. Once this report has been filed, Uconnect for the stolen vehicle report number issued by local law enforcement. Then, using GPS technology and the built-in wireless connection within your vehicle, the Uconnect enforcement to help recover it. (Vehicle must be within the United States, have network coverage and must be registered with Uconnect subscription that includes the applicable feature).

7. WiFi Hotspot - WiFi Hotspot is on-demand WiFi 3G connectivity that's built-in and

ready to go whenever you are. Once your vehicle is registered for Uconnect Access, you can purchase a Wifi Hotspot subscription at the Uconnect®Store. After you've made your purchase, turn on your signal and connect your devices. It's never been easier to bring your home or office with you.

• Your vehicle must have a working electrical system in order for any of the in vehicle Uconnect

Uconnect® Access Remote Features

•

If you own a compatible iOS or Android®powered device, the Uconnect®Access App allows you to remotely lock or unlock your doors, start your engine or activate your horn and lights from virtually anywhere (Vehicle must be within the United States and have network coverage). You can download the App from Mopar Owner Connect or from the Apple App or Google Play store. Visit www.UconnectPhone.com to determine if your device is compatible. For Uconnect determine if your device is compatible:

• U.S. residents - visit www.UconnectPhone.com or call 1–877–855–8400

• Canadian residents - visit www.UconnectPhone.com or call 1–800–465–2001 (English) or 1–800–387–9983 (French).

1. Remote Start – This feature provides the ability to start the engine on your vehicle,

without the keys and from virtually any distance. You can send a request to your vehicle in one of three ways:

• Using the Uconnect

• From the Mopar Owner Connect website

• Contacting Uconnect

•

• After 15 minutes if you have not entered your vehicle with the key, the engine

care can help locate your vehicle. The Uconnect®Care agent will ask

Care agent will be able to locate the stolen vehicle and work with law

Access with an active

features to operate.

Phone customer support and to

Access App from a compatible smartphone

Care

You can also send a command to turn-off an engine that has been remote started.

will shut off automatically.

ELECTRONICS

• This remote function requires your vehicle to be equipped with a factoryinstalled Remote Start system. To use this feature after the Uconnect App is downloaded, login with your user name and Uconnect

Access

Security PIN.

• You can set-up notifications for your account to receive an E-mail or text (SMS) message every time a command is sent. See the “Managing Notifications” section under Using Mopar Owner Connect (www.MoparOwnerConnect.com) for further instructions.

2. Remote Door Lock/Unlock – This feature provides the ability to lock or unlock the

door on your vehicle, without the keys and from virtually any distance. You can send a request to your vehicle in one of three ways:

• Using the Uconnect

Access App from a compatible smartphone

• From the Mopar Owner Connect website

• By contacting the Uconnect

• To use this feature after the Uconnect

Care on the phone

Access App is downloaded, login using your user name and Uconnect Security PIN. Touch the App button on your smartphone with the closed lock icon to lock the door, and touch the open lock icon to unlock the driver’s door.

3. Remote Horn and Lights – It’s easy to locate a vehicle in a dark, crowded or noisy

parking area by activating the horn and lights. It may also help if you need to draw attention to your vehicle for any reason. You can send a request to your vehicle in one of three ways:

• Using the Uconnect

Access App from a compatible smartphone

• From the Mopar Owner Connect website

• By contacting the Uconnect

• To use this feature after the Uconnect your user name and Uconnect

Care on the phone

Access App is downloaded, login using

Security PIN. You can set-up notifications for your account to receive an E-mail or text (SMS) message every time a command is sent. See the “Managing Notifications” section under Using Mopar Owner Connect (www.MoparOwnerConnect.com) for further instructions.

ELECTRONICS

4. Voice Texting – Use the sound of your voice to create, listen to and send text

messages. Just tell Uconnect your voice to text and send the message at your command. Powerful, cloud-based voice recognition allows you to dictate free form text messages, and send them from your Bluetooth- enabled phone without taking your hands of the wheel or focus from the road.

what you want the message to say - it will convert

WARNING!

• ALWAYS drive safely with your hands on the steering wheel. You have full responsibility and assume all risks related to the use of the Uconnect and applications in this vehicle. Only use Uconnect Failure to do so may result in an accident involving serious injury or death.

• Ignoring the Rearview Mirror light could mean you may not have 9-1-1 Call service when you need it. If the Rearview Mirror light is illuminated, have an authorized dealer service the 9-1-1 Call system immediately.

• The Occupant Restraint Controller (ORC) turns on the Air Bag Warning Light on the instrument panel if a malfunction is detected in any part of the air bag system. If the Air Bag Warning Light is illuminated, the air bag system may not be working properly and the 9-1-1 system may not be able to send a signal to a 9-1-1 operator. If the Air Bag Warning Light is illuminated, have an authorized dealer service your vehicle immediately.

• If anyone in the vehicle could be in danger (e.g., fire or smoke is visible, dangerous road conditions or location), do not wait for voice contact from a 9-1-1 operator. All occupants should exit the vehicle immediately and move to a safe location.

• The 9-1-1 Call system is embedded into the vehicle’s electrical system. Do not add any aftermarket electrical equipment to the vehicle’s electrical system. This may prevent your vehicle from sending a signal to initiate an emergency call. To avoid interference that can cause the 9-1-1 Call system to fail, never add aftermarket equipment (e.g., two-way mobile radio, CB radio, data recorder, etc.) to your vehicle’s electrical system or modify the antennas on your vehicle. IF YOUR VEHICLE LOSES BATTERY POWER FOR ANY REASON (INCLUDING DURING OR AFTER AN ACCIDENT), THE UCONNECT FEATURES, APPS AND SERVICES, AMONG OTHERS, WILL NOT OPERATE.

when it is safe to do so.

features

ELECTRONICS

Uconnect® 3.0

Clock Setting

1. Press the Menu button at the bottom of the radio, next select the Time Format setting and then select Set Time.

2. Adjust the hours or minutes by turning the Tune/Scroll knob, then pressing the Enter/Browse button to move to the next entry. You can also select 12hr or 24hr format by turning the Tune/Scroll knob, then pressing the Enter/Browse button on the desired selection.

3. Once the time is set press the “Back” button to exit the time screen.

Audio

• Press the AUDIO button on the radio faceplate.

• The Audio Menu shows the following options for you to customize your audio

settings.

Mid, Bass, Fade, Balance

• Select the desired setting to adjust, then touch the Enter/Browse button. Turn the

Tune/Scroll knob to adjust the setting + or - 9. Press the back button when done.

ELECTRONICS

Radio Operation

Seek Up/Down Buttons

• Press to seek through radio stations in AM, FM or SXM bands.

• Hold either button to bypass stations without stopping.

Store Radio Presets

• The Presets are available for all Radio Modes, and are activated by touching any of the six Preset buttons.

• When you are receiving a station that you wish to commit into memory, press and hold the desired numbered button for more that 2 seconds or until you hear a confirmation beep.

• The Radio stores up to 18 presets in each of the Radio modes. Press the A-B-C hard-key to select the A, B or C preset list.

Disc Operation

• Your vehicle may have a remote CD player located in the lower center console storage bin, or in the lower center bench seat bin.

• CD/Disc Mode is entered by either inserting a CD/Disc or by touching the Media button located on the side of the display. Once in Media Mode, select Disc.

• Gently insert one CD into the CD player with the CD label facing as indicated on the illustration located on the Disc player.

Seek Up/Down Buttons

• Press to seek through CD tracks.

• Hold either button to bypass tracks without stopping.

USB/Audio Jack (AUX) Operation

USB/iPod®

• USB/iPod into the USB port or by touching the Media button located left of the display. Once in Media Mode, select USB/iPod for the source.

• Pressing the Media button, then select USB/iPod device if the device is connected, allowing the music from your portable device to play through the vehicle's speakers.

Audio Jack (AUX)

• The AUX allows a portable device, such as an MP3 player or an iPod plugged into the radio and utilize the vehicle’s audio system, using a 3.5 mm audio cable, to amplify the source and play through the vehicle speakers.

• Pressing the Media button, then touch the source soft-key and then select AUX to change the mode to auxiliary device if the audio jack is connected, allowing the music from your portable device to play through the vehicle's speakers.

The functions of the portable device are controlled using the device buttons, not the

• buttons on the radio. The volume may be controlled using the radio or portable device.

Mode is entered by either inserting a USB Jump Drive or iPod®cable

to change the mode to the USB

,tobe

Uconnect® 3.0 Available Media Hubs

Uconnect 3.0 Media Hub

(USB, AUX Ports)

S--OO

S = Standard Equipment

O = Optional Equipment

Media Hub (SD, USB, AUX Ports)

Uconnect® 5.0

Remote USB Port (Fully Functional)

ELECTRONICS

Remote USB Port (Charging Only)

Dual Charging Ports

Clock Setting

1. To start the clock setting procedure, perform either of the following:

• Press the More hard-key on the right side of the display, next press the Time soft-key and then press the Set soft-key.

• Press the Settings hard-key on the right side of the display, then press the Clock soft-key. The Time setting screen is displayed and the clock can be adjusted as described in the following procedure.

ELECTRONICS

NOTE:

In the Clock Setting Menu you can also select Display Clock. Display Clock turns the clock display in the status bar on or off.

Touch the Up or Down arrows to adjust the hours or minutes, next select the AM or PM soft-key. You can also select 12hr or 24hr format by touching the desired soft-key.

3. Once the time is set press the “Done” soft-key to exit the time screen.

Equalizer, Balance and Fade

1. Press the SETTINGS hard-key on the right side of the unit.

2. Then scroll down and press the Audio soft-key to get to the Audio menu.

3. The Audio Menu shows the following options for you to customize your audio settings.

Equalizer

• Touch the Equalizer soft-key to adjust the Bass, Mid and Treble. Use the + or -

soft-key to adjust the equalizer to your desired settings. Press the back arrow soft-key when done.

Balance/Fade

• Touch the Balance/Fade soft-key to adjust the sound from the speakers. Use the

arrow soft-key to adjust the sound level from the front and rear or right and left side speakers. Touch the Center “C” soft-key to reset the balance and fade to the factory setting. Press the back arrow soft-key when done.

Speed Adjustable

• Touch the Speed Adjusted Volume soft-key to select between OFF, 1, 2 or 3.

This will decrease the radio volume relative to a decrease in vehicle speed. Press the back arrow soft-key when done.

Loudness

• Touch the Loudness soft-key to select the Loudness feature. When this feature is

activated it improves sound quality at lower volumes.

Radio Operation

Seek Up/Down Buttons

• Press to seek through radio stations in AM, FM or SXM bands.

• Hold either button to bypass stations without stopping.

ELECTRONICS

Store Radio Presets

• When you are receiving a station that you wish to commit into memory, press and hold the desired numbered soft-key for more that 2 seconds or until you hear a confirmation beep.

• The Radio stores up to 12 presets in each of the Radio modes. 4 presets are visible at the top of the radio screen. Touching the “all” soft-key on the radio home screen will display all of the preset stations for that mode.

SiriusXM Premier Over 160 channels

• Get every channel available on your satellite radio, and enjoy all you want, all in one place. Hear commercial-free music plus sports, news, talk and entertainment. Get all the premium programming, including Howard Stern, every NFL game, Oprah Radio Stewart and more. And get 20+ Xtra channels, including SiriusXM Latino, a selection of channels dedicated to Spanish language programming.

• To access SiriusXM Satellite Radio, press the “RADIO” hard-key and then the SXM soft-key.

• SiriusXM services require subscriptions, sold separately after the 12-month trial included with the new vehicle purchase. If you decide to continue your service at the

end of your trial subscription, the plan you choose will automatically renew and bill at then-current rates until you call SiriusXM at 1-866-635-2349 for U.S. residents and 1-888-539-7474 for Canadian residents to cancel. See SiriusXM Customer Agree-

ment for complete terms at www.siriusxm.com. All fees and programming subject to change. Our satellite service is available only to those at least 18 and older in the 48 contiguous USA and D.C. Our Sirius satellite service is also available in PR (with coverage limitations). Our Internet radio service is available throughout our satellite service area and in AK and HI. Visit www.sirius.com/TravelLink for more information on SiriusXM Travel Link.© 2012 Sirius XM Radio Inc. Sirius, XM and all related marks and logos are trademarks of Sirius XM Radio Inc.

Disc Operation

• Your vehicle may have a remote CD player located in the lower center console storage bin, or in the lower center bench seat bin.

• CD/Disc Mode is entered by either inserting a CD/Disc or by touching the Media button located on the side of the display. Once in Media Mode, select Disc.

• Gently insert one CD into the CD player with the CD label facing as indicated on the illustration located on the Disc player.

Seek Up/Down Buttons

• Press to seek through Disc tracks.

• Hold either button to bypass tracks without stopping.

, every MLB®and NHL®game, every NASCAR®race, Martha

ELECTRONICS

Browse

• Touch the browse soft-key to scroll through and select a desired track on the Disc. Touch the exit soft-key if you wish to cancel the browse function.

USB/Audio Jack (AUX)/Bluetooth® Operation

USB/iPod®

• USB/iPod into the USB port or by touching the Media hard-key located left of the display. Once in Media Mode, touch the source soft-key and select USB/iPod

• Pressing the Media hard-key, then touch the source soft-key and then select USB/iPod allowing the music from your portable device to play through the vehicle's speakers.

Audio Jack (AUX)

• Pressing the Media hard-key, then touch the source soft-key and then select AUX to change the mode to auxiliary device if the audio jack is connected, allowing the music from your portable device to play through the vehicle's speakers.

The functions of the portable device are controlled using the device buttons, not the

• buttons on the radio. The volume may be controlled using the radio or portable device.

Bluetooth®

• Bluetooth Bluetooth

• Pressing the Media hard-key, then touch the source soft-key and then select Bluetooth music from your portable device to play through the vehicle's speakers.

Uconnect® 5.0 Available Media Hubs

Uconnect

5.0

Mode is entered by either inserting a USB Jump Drive or iPod®cable

to change the mode to the USB device if the device is connected,

Streaming Audio (BTSA) or Bluetooth®Mode is entered by pairing a

device, containing music, to the Uconnect®system.

to change the mode to Bluetooth®if the device is paired, allowing the

Media Hub (USB, AUX Ports)

S--SO

Media Hub (SD, USB, AUX Ports)

Remote USB Port (Fully Functional)

Remote USB Port (Charging Only)

Dual Charging Ports

,tobe

S = Standard Equipment

O = Optional Equipment

ELECTRONICS

VOICE COMMAND QUICK REFERENCE

Uconnect® 5.0 Voice Command Quick Reference

•

If the Uconnect Voice Command button exists on your steering wheel, you have the Voice Command feature, which is optimized for the driver. The Voice Command feature lets you keep your hands on the wheel, and your eyes on the road.

• When you press the Voice Command button located on the steering wheel, you will hear a beep. After the beep, give your command. If you do not know what commands to say, you can say “help” and the system will provide options to you. If you ever wish to interrupt the system while it lists options, press the Voice Command

NOTE:

All phone oriented voice commands are accessible by first pressing the Phone Pick Up Phone Hang Up the dual purpose of ending calls as well.

Voice Command (VR) User TIPs

• To hear available commands, press the Uconnect

• At any time, you can say the words “Cancel” or “Help”. These commands are

• You can interrupt the system prompts at any time by pressing the Uconnect

• You can ‘chain’ commands together for faster results. Say “Call Joe Doe mobile”,

• For best performance, adjust the rearview mirror to provide at least 1⁄2 in (1 cm)

• Always wait for the beep before speaking.

• Speak normally, without pausing, just as you would speak to a person sitting a few

• Make sure that no one other than you is speaking during a Voice Command period.

Steering Wheel Buttons

• You can control many of your radio features using your voice. Press either the

button, not the Voice Command button. To end a call, simply press the

say “Help”. You will hear available commands for the menu displayed.

universal and can be used from virtually any menu. All other specific commands can be used depending upon the active application.

Command button while the system is speaking. After the beep, you can say a command.

for example.

gap between the overhead console (if equipped) and the mirror.

feet/meters away from you.

button, after the beep, say your command.

button. In some vehicles, the Phone Pickup button serves

Voice Command button and

or Phone Pick Up button on your steering wheel.

Voice

ELECTRONICS

Available Radio Button Voice Commands

Steering Wheel Buttons to Press:

Uconnect

Voice

TypesofVoice Commands Available

Command (VR)

Button

Uconnect

Phone Pick Up

Button

Voice Command Examples – Uconnect® 5.0

Anytime

AM/FM

Satellite Band Control

Media Devices Control

(Functionality is dependent

on compatibility between

devises and radio)

Radio Mode Media Mode Phone Mode

“Go to Radio” (Media, Phone) – Compass, Settings, and

AM/FM &

Satellite Brand

Control

GENERAL

More functions are not Voice Command accessible

“Help” (to listen to suggested commands specific to

RADIO

“Tune to AM950”, “Tune to 95.5FM (preset 5)

“Tune to Satellite Channel 80's on 8”, Tune to Satellite

MEDIA

“Browse” (show) “artist” (albums, music)

“Play song – Maple Leaf Rag” (artist - Scott Joplin,

genre - rock, album - Ragtime Favorites)

Media Devices

Control

GENERAL

Call Initiation,

Call Manage-

“Cancel”

current need

“Repeat”

Channel 32 (preset 4)

“Show paired phones” (devices)

Pre-formatted

Voice Text

ment,

Call Initiation (Requires

that phone has been

Bluetooth

Voice Text Reply (Radio

audibly recognizes these

18 pre-formatted SMS

messages as you speak)

paired with

radio

Call Management

ELECTRONICS

PHONE

“Dial 123-456-7890” (phone number)

“Call John Smith mobile” (home, office, other)

“Redial”

“Show outgoing” (recent) “calls”

“Search for John Smith” (any contact name in

address book)

“Show (display list) contacts”

Forward one of 18 pre-formatted SMS messages to

incoming calls/text messages:

“Yes.”

“No.”

“Okay.”

“I can’t talk right now.”

“Call me.”

“I’ll call you later.”

“I’m on my way.”

“Thanks.”

“I’ll be late.”

“I will be <number> minutes late.”

“See you in <number> minutes”

“Stuck in traffic.”

“Start without me.”

“Where are you?”

“Are you there yet?”

“I need directions.”

“I’m lost.”

“See you later.”

ELECTRONICS

Uconnect® 8.4A

Uconnect® 8.4A AT A GLANCE

Displaying the Time

• If the time is not currently displayed on the radio or player main page, touch the Settings soft-key or the Apps soft-key and then the Settings soft-key. In the Settings list, touch the Clock soft-key then touch the check box next to Show Time in Status Bar.

Setting the Time

• Model 8.4AN synchronizes time automatically via GPS, so should not require any time adjustment. If you do need to set the time manually, follow the instructions below for Model 8.4A.

• For Model 8.4A, turn the unit on, then touch the time display at the top of the screen. Touch Yes.

ELECTRONICS

• If the time is not displayed at the top of the screen, touch the Settings soft-key or the Apps soft-key and then the Settings soft-key. In the Settings screen, touch the Clock soft-key, then check or uncheck this option.

• Touch + or – next to Set Time Hours and Set Time Minutes to adjust the time.

• If these features are not available, uncheck the Sync with GPS box.

• Touch X to save your settings and exit out of the Clock Setting screen.

Audio Settings

• Touch of the Audio soft-key to activate the Audio settings screen to adjust Balance\Fade, Equalizer, and Speed Adjusted Volume.

• You can return to the Radio screen by touching the X located at the top right.

Balance/Fade

• Touch the Balance/Fade soft-key to Balance audio between the front speakers or fade the audio between the rear and front speakers.

• Touching the Front, Rear, Left, or Right soft-keys or touch and drag the blue Speaker Icon to adjust the Balance/Fade.

Equalizer

• Touch the Equalizer soft-key to activate the Equalizer screen.

• Touch the + or - soft-keys, or by touching and dragging over the level bar for each of the equalizer bands. The level value, which spans between plus or minus 9, is displayed at the bottom of each of the Bands.

Speed Adjusted Volume

• Touch the Speed Adjusted Volume soft-key to activate the Speed Adjusted Volume screen. The Speed Adjusted Volume is adjusted by touching the + and - buttons or by touching and dragging over the level bar. This alters the automatic adjustment of the audio volume with variation to vehicle speed.

ELECTRONICS

RADIO

• To access the Radio mode, touch the Radio soft-key at the lower left of the screen.

Selecting Radio Stations

• Touch the desired radio band (AM, FM or SXM) soft-key.

Seek Up/Seek Down

• Touch the Seek arrow soft-keys for less than two seconds to seek through radio stations.

• Touch and hold either arrow soft-key for more than two seconds to bypass stations without stopping. The radio will stop at the next listenable station once the arrow soft-key is released.

Direct Tune

• Tune directly to a radio station by pressing the Tune soft-key on the screen, and entering the desired station number.

Store Radio Presets

• Your radio can store 12 total preset stations. They are shown at the top of your screen. To see all 12 stations, press the arrow soft-key at the top right of the screen to toggle between the six presets.

• To set a station into memory press and hold the desired numbered soft-key for more than two seconds or until you hear a confirmation beep.

ELECTRONICS

SiriusXM PREMIER OVER 160 CHANNELS

To access SiriusXM Satellite Radio, touch the SXM soft-key on the main Radio

• screen.

• The following describes features that are available when in SiriusXM Satellite Radio mode.

Seek Up/Seek Down

• Touch the Seek arrow soft-keys for less than two seconds to seek through channels in SXM mode.

• Touch and hold either arrow soft-key for more than two seconds to bypass channels without stopping. The radio will stop at the next listenable channel once the arrow soft-key is released.

Direct Tune

• Tune directly to a SXM channel by pressing the Tune soft-key on the screen, and entering the desired station number.

Jump

• Automatically tells you when Traffic & Weather for a favorite city is available, and gives you the option to switch to that channel. Touch Jump to activate the feature. After listening to Traffic and Weather, touch Jump again to return to the previous channel.

Fav

• Activates the favorites menu. You can add up to 50 favorite artists or songs. Just touch Add Fav Artist or Add Fav Song while the song is playing. You will then be alerted any time one of these songs, or works by these artists, is playing on other SiriusXM channels.

SiriusXM Parental Controls

• You can skip or hide certain channels from view if you do not want access to them. Touch the More soft-key, then the Settings soft-key, next touch the Sirius Setup soft-key, then select Channel Skip. Touch the box, check-mark, next to the channel you want skipped. They will not show up in normal usage.

SiriusXM also offers the option to permanently block selected channels. Call

• (1-888-601-6297 for U.S. customers, 1-888-539-7474 for Canadian customers) and request the Family Package.

, every MLB®and NHL®game, every NASCAR®race, Martha

ELECTRONICS

Browse

Lets you browse the SiriusXM channel listing or Genre listing. Favorites, Game Zone,

• Weather and Jump settings also provide a way to browse the SiriusXM channel list.

Browse Sub-Menu

All Shows the channel listing. Genre Provides a list of all genres, and lets you jump to a channel within the

Presets Lets you scroll the list of Preset satellite channels. Touch the channel, or

Favorites Lets you manage artists and songs in the Favorites list and configure Alert

Game Zone Provides alerts when your favorite sports teams are starting a game which

Jump Lets you select your favorite cities for Traffic & Weather information,

Replay

• Lets you replay up to 44 minutes of the content of the current SiriusXM channel.

Replay Option

Play/Pause Touch to Pause content playback. Touch Pause/Play again to resume

Rewind/RW Rewinds the channel content in steps of 5 seconds. Touch and hold to

Fast Forward/FW

Replay Time Displays the amount of time in the upper center of the screen by which

Live Resumes playback of Live content at any time while replaying rewound

Sub-Menu Description

selected genre.

press Enter on the Tune knob, to go to that channel. Touch the trash can icon to delete a preset. Your presets are also shown at the top of the main Satellite Radio screen.

Settings to let you know when favorite songs or artists are playing on other channels. Also, view a list of channels airing any of your Favorites.

is being aired on other SiriusXM channels, or when their game score is announced. You can select and manage your Teams list here, and configure alerts.

which is used by the Jump feature on the main satellite radio screen.

Option Description

playback.

rewind continuously, then release to begin playing content at that point. Forwards the content, and works similarly to Rewind/RW. However, Fast

Forward/FW can only be used when content has been previously rewound.

your content lags the Live channel.

content.

ELECTRONICS

• SiriusXM services require subscriptions, sold separately after the 12-month trial

included with the new vehicle purchase. If you decide to continue your service at the

ment for complete terms at www.siriusxm.com. All fees and programming subject to change. Our satellite service is available only to those at least 18 and older in the 48 contiguous USA and D.C. Our Sirius satellite service is also available in Puerto Rico (with coverage limitations). Our Internet radio service is available throughout our satellite service area and in AK and HI. Visit www.sirius.com/ TravelLink for more information on SiriusXM Travel Link.© 2012 Sirius XM Radio Inc. Sirius, XM and all related marks and logos are trademarks of Sirius XM Radio Inc.

Disc Operation

• Your vehicle may have a remote CD player located in the lower center console storage bin, or in the lower center bench seat bin.

• CD/Disc Mode is entered by either inserting a CD/Disc or by touching the Media button located on the side of the display. Once in Media Mode, select Disc.

• Gently insert one CD into the CD player with the CD label facing as indicated on the illustration located on the Disc player.

Seek Up/Down Buttons

• Press to seek through Disc tracks.

• Hold either button to bypass tracks without stopping.

Browse

• Touch the browse soft-key to scroll through and select a desired track on the Disc. Touch the exit soft-key if you wish to cancel the browse function.

ELECTRONICS

MEDIA HUB – PLAYING iPod/USB/MP3 DEVICES

• There are many ways to play music from iPod

/MP3 players or USB devices

through your vehicle's sound system.

Audio Jack (AUX)

• The AUX allows a portable device, such as an MP3 player or an iPod

,tobe plugged into the radio and utilize the vehicle’s sound system, using a 3.5 mm audio cable, to amplify the source and play through the vehicle speakers.

• Touching the Media soft-key then choosing AUX source will change the mode to auxiliary device if the audio jack is connected, allowing the music from your portable device to be heard through the vehicle's speakers. In order to activate the AUX, plug in the audio jack.

• The functions of the portable device are controlled using the device buttons. The volume may be controlled using the radio or portable device.

• To route the audio cable out of the center console, use the access cut out in the front of the console.

USB Port

• Connect your iPod

or compatible device using a USB cable into the USB Port. USB Memory sticks with audio files can also be used. Then, audio from the device can be played on the vehicles sound system while providing metadata (artist, track title, album, etc.) information on the radio display.

• When connected, the iPod

/compatible USB device can be controlled using the radio or Steering Wheel Audio Controls to play, skip to the next or previous track, browse, and list the contents.

• The iPod

battery charges when plugged into the USB port (if supported by the

specific device).

• To route the USB/iPod

cable out of the center console, use the access cut out.

ELECTRONICS

NOTE:

When connecting your iPod

device for the first time, the system may take several minutes to read your music, depending on the number of files. For example, the system will take approximately 5 minutes for every 1000 songs loaded on the device. Also during the reading process, the Shuffle and Browse functions will be disabled. This process is needed to ensure the full use of your iPod

features and only happens the first time it is connected. After the first time, the reading process of your iPod will take considerably less time unless changes are made or new songs are added to the playlist.

• The USB port supports certain Mini, Classic, Nano, Touch, and iPhone

devices.

The USB port also supports playing music from compatible external USB Mass

Storage Class memory devices. Some iPod support the USB port features. Please visit Apple’s website for iPod

software versions may not fully

software

updates.

SD Card

• Play songs stored on an SD card inserted into the SD card slot.

• Song playback can be controlled using the radio or Steering Wheel Audio Controls

to play, skip to the next or previous track, browse, and list the contents.

Bluetooth® Streaming Audio

If equipped with Uconnect®Voice Command, your Bluetooth-equipped iPod

•

devices, cell phones or other media players, may also be able to stream music to your vehicle's sound system. Your connected device must be Bluetooth-compatible, and

paired with your system (see Uconnect access the music from your connected Bluetooth

Phone for pairing instructions). You can

device by touching the Bluetooth

soft-key while in Media mode.

Uconnect® 8.4A & 8.4AN Available Media Hubs

Uconnect

8.4A &

8.4AN

Media Hub (USB, AUX Ports)

- SSOO

Media Hub (SD, USB, AUX Ports)

Remote USB Port (Fully Functional)

Remote USB Port (Charging Only)

Dual Charging Ports

S = Standard Equipment

O = Optional Equipment

ELECTRONICS

iPod®/CD/AUX CONTROLS

• The iPod played on the side of the screen and choosing between Disc, AUX, iPod Bluetooth or SD Card.

NOTE:

Uconnect thing is first connected or inserted into the system.

NAVIGATION (DEALER-ACTIVATED OPTION)

• Your Uconnect tion at an extra cost. See your dealer for details.

• The information in this section is only applicable if the feature has been equipped. If so equipped, you will see a Nav soft-key at the bottom of the touch-screen.

/CD/AUX controls are accessed by touching the desired soft-key dis-

will usually automatically switch to the appropriate mode when some-

8.4A is “Navigation-Ready”, and can be equipped with Naviga-

ELECTRONICS

Changing the Navigation Voice Prompt Volume

1. Touch the View Map soft-key from the Nav Main Menu.

With the map displayed, touch the Settings soft-key in the lower right area of the

2. screen.

3. In the Settings menu, touch the Guidance soft-key.

4. In the Guidance menu, adjust the Nav Volume by touching the + or – soft-keys.

Finding Points of Interest

• From the main Navigation menu, touch the Where To? soft-key, then touch the

Points of Interest soft-key.

• Select a Category and then a subcategory, if necessary.

• Select your destination and touch the Yes soft-key.

ELECTRONICS

Finding a Place by Spelling the Name

• From the Main Navigation Menu touch the Where to? soft-key, touch the Points of Interest soft-key and then touch the Spell Name soft-key.

• Enter the name of your destination.

• Touch the Done soft-key.

• Select your destination and touch the Yes soft-key.

Entering a Destination Address

• From the main Navigation menu touch the Where To? soft-key, then touch the Address soft-key.

• Follow the on-screen prompts to enter the address and touch the Yes soft-key.

• Destination entry is not available while your vehicle is in motion. However, you can also use Voice Command to enter an address while moving. See Voice Command Tips for more information.

Setting Your Home Location

• Touch the NAV soft-key in the menu bar to access the Navigation system and the Main Navigation menu.

• Touch the Where To? soft-key, then touch the Go Home soft-key.

• You may enter your address directly, use your current location as your home address, or choose from recently found locations.

• To delete your Home location (or other saved locations) so you can save a new Home location, touch the Where To? soft-key from the Main Navigation menu, then touch the Go Home soft-key, and in the Yes screen touch the Options soft-key. In the Options menu touch Clear Home. Set a new Home location by following the previous instructions.

ELECTRONICS

Go Home

• A Home location must be saved in the system. From the Main Navigation menu, touch the Where To? soft-key, then touch the Go Home soft-key.

• Your route is marked with a blue line on the map. If you depart from the original route, your route is recalculated. A speed limit icon could appear as you travel on major roadways.

Adding a Stop

• To add a stop you must be navigating a route.

• Touch the Menu soft-key to return to the Main Navigation menu.

• Touch the Where To? soft-key, then search for the extra stop. When another location has been selected, you can choose to cancel your previous route, add as the first destination or add as the last destination.

• Touch the desired selection and touch the Yes soft-key.

ELECTRONICS

Taking a Detour

• To take a detour you must be navigating a route.

• Touch the Detour soft-key.

NOTE:

If the route you are currently taking is the only reasonable option, the device might not calculate a detour.

• For more information, see your Uconnect

Uconnect® Phone (Bluetooth® HANDS FREE CALLING)

• If the Uconnect the Uconnect

• The Uconnect

Phone Button exists on your steering wheel, then you have

Phone features.

Phone is a voice-activated, hands-free, in-vehicle communica-

tions system with Voice Command Capability (see Voice Command section).

• The Uconnect

Phone allows you to dial a phone number with your mobile phone

using simple voice commands or using screen soft-keys.

• Refer to the Understand The Features Of Your Vehicle section of your vehicle's Owner's Manual on the DVD for further details.

NOTE:

The Uconnect®Phone requires a mobile phone equipped with the Bluetooth®HandsFree Profile, Version 1.0 or higher. For Uconnect visit www.UconnectPhone.com or call 1–877–855–8400. Canadian Residents call, 1-800-465–2001 (English) or 1-800-387-9983 (French).

Pairing a Phone

• To use the Uconnect with the Uconnect

Phone feature, you must first pair your Bluetooth®phone

system.

Start pairing procedure on the radio

• Touch the Phone soft-key and then the Settings soft-key. Next, touch Add Device.

Uconnect®Phone will display an “In progress” screen while the system is connecting.

•

Start pairing procedure on mobile phone

• Search for available devices on your Bluetooth usually within Settings or Options under “Bluetooth”. See your mobile phone’s manual for details.

• When your phone finds the system, select “Uconnect” as the paired device. You may be prompted by your phone to download the phonebook. This is so you can make calls by saying the name of your contact (PBAP-Phone Book Access Profile).

User's Manual.

Customer Support: U.S. residents

enabled mobile phone. This is

ELECTRONICS

Complete the pairing procedure

• When prompted on the phone, enter the 4-digit PIN number shown on the Uconnect

• If your phone asks you to accept a connection request from Uconnect, select “Yes”. If available, check the box telling it not to ask again – that way your phone will automatically connect each time you start the vehicle.

Select the mobile phone's priority level

• When the pairing process has successfully completed, the system will prompt you to choose whether or not this is your favorite phone. Selecting Yes will make this phone the highest priority. This phone will take precedence over other paired phones within range. Only one phone can be paired at a time.

• You are now ready to make hands-free calls. Press the Uconnect your steering wheel to begin.

Making A Phone Call

• Press the Uconnect

• After the BEEP, say “dial” then the number (or “call” then the name as listed in your phone; see Phonebook).

NOTE:

You can also initiate a call by using the touch-screen on the Phone main screen.

Receiving A Call – Accept (And End)

• When an incoming call rings/is announced on Uconnect button

• To end a call, press the Phone button

Screen.

Phone button .

Phone button on

, press the Phone

Mute (Or Unmute) Microphone During Call

• During a call, touch the mute soft-key on the Phone main screen to mute and unmute the call.

Transfer Ongoing Call Between Handset And Vehicle

• During an on-going call, touch the Transfer soft-key on the Phone main screen to transfer an on-going call between handset and vehicle.

Common Phone Commands (Examples)

• “Call John Smith”

• “Call John Smith mobile”

• “Dial 1 248 555 1212

• “Call Emergency”

• “Call Towing Assistance”

• “Redial”

ELECTRONICS

Phonebook

• Uconnect phone, if this feature is supported by your phone. Entries are updated each time that the phone is connected. If your phone book entries do not appear, check the settings on your phone. Some phones require you to enable this feature manually.

• Your phonebook can be browsed on your radio screen, but editing can only be done on your phone. To browse, touch the Phone soft-key, then the Phonebook soft-key.

• Favorite phonebook entries can be saved as Favorites for quicker access. Favorites are shown at the top of your main phone screen.

Voice Command Tips

• Using complete names (i.e; Call John Doe vs. Call John) will result in greater system accuracy.

• You can “chain” commands together for faster results. Say “Call John Doe, mobile”, for example.

• If you are listening to available voice command options, you do not have to listen to the entire list. When you hear the command that you need, press the button on the steering wheel, wait for the beep and say your command.

Changing The Volume

• Start a dialogue by pressing the Phone button example - "Help".

• Use the radio ON/OFF VOLUME rotary knob to adjust the volume to a comfortable level while the Uconnect Uconnect

NOTE:

To access help, press the Uconnect say "help." Touch the display or push either to cancel the help session.

radios will automatically download your phonebook from your paired

, then say a command for

is different than the audio system.

system is speaking. Please note the volume setting for

Phone button on the steering wheel and

or button and say "cancel"

ELECTRONICS

Voice Texting

• Voice texting enhances the voice text reply feature built into your Uconnect 8.4A and Uconnect 8.4AN radio, and helps reduce driver distraction while keeping you connected. While voice text reply provides 18 pre-formatted messages you can send, voice texting lets you create and send nearly any message you want. Just speak your message as if you were talking to the recipient, and the Uconnect voice-to-text technology will convert your voice into a text message. Voice texting and voice text reply features are compatible with many newer Android and Blackberry phones. Before using, determine if your phone has been tested to support Bluetooth “Message Access Protocol” (MAP) or AT Messaging Protocol at www.UconnectPhone.com, and ensure MAP is on and incoming message notification is enabled.

• Uconnect

• Your mobile phone must support SMS over Bluetooth If the Uconnect messaging over Bluetooth feature will not be available for use.

NOTE:

For mobile phone compatibility and pairing instructions, please visit www.UconnectPhone.com

• Uconnect not moving.

Phone can read or send new text messages on your mobile phone.

Phone determines your phone is not compatible with SMS

the “Messaging” button will be greyed out and the

Phone SMS touch-screen input is only available when the vehicle is

in order to use this feature.

WARNING!

• Any voice commanded system should be used only in safe driving conditions following applicable laws regarding phone use. Your attention should be focused on safely operating the vehicle. Failure to do so may result in a collision causing you and others to be severely injured or killed.

• In an emergency, to use Uconnect

• turned on,

• paired to Uconnect

Phone,

• and have network coverage.

Phone, your mobile phone must be:

ELECTRONICS

VOICE COMMAND QUICK REFERENCE

Uconnect® 8.4A Voice Command Quick Reference

• If the Uconnect®Voice Command button exists on your steering wheel, you have the Voice Command feature, which is optimized for the driver. The Voice Command feature lets you keep your hands on the wheel, your eyes on the road, and control navigation and media sources.

• When you press the Voice Command you will hear a beep. After the beep, give your command. If you do not know what commands to say, you can say “help” and the system will provide options to you. If you ever wish to interrupt the system while it lists options, press the Voice Command

NOTE:

All phone oriented voice commands are accessible by first pressing the Phone Pick Up Phone Hang Up serves the dual purpose of ending calls as well.

Voice Command (VR) User TIPs

• To hear available commands, press the Uconnect

• At any time, you can say the words “Cancel” or “Help”. These commands are

• You can interrupt the system prompts at any time by pressing the Uconnect

• You can ‘chain’ commands together for faster results. Say “Navigate to 1234 Main

• For best performance, adjust the rearview mirror to provide at least 1⁄2 in (1 cm)

• Always wait for the beep before speaking.

• Speak normally, without pausing, just as you would speak to a person sitting a few

• Make sure that no one other than you is speaking during a Voice Command period.

Steering Wheel Buttons

• You can control many of your radio features using your voice. Press either the

button, not the Voice Command button. To end a call, simply press the

say “Help”. You will hear available commands for the menu displayed.

universal and can be used from virtually any menu. All other specific commands can be used depending upon the active application.

Command button while the system is speaking. After the beep, you can say a command.

Street Hometown, California”, for example.

gap between the overhead console (if equipped) and the mirror.

feet/meters away from you.

button, after the beep, say your command.

button. In some vehicles, the Phone Pickup button

or Phone Pick Up button on your steering wheel.

button located on the steering wheel,

Voice Command button and

Voice

Available Radio Soft–Key Voice Commands

Steering

Types of Voice Commands Available

Wheel Buttons to Press:

Uconnect Voice Command (VR) Button

Uconnect Phone Pick

Up Button

(1) Radio Mode

AM/FM & Satellite Brand Control

(2) Media Mode

Media Devices Control

----

(3) Climate Controls

Temperature Control

GENERAL

ELECTRONICS

(4) Navigation

Destination Selection and View

(5) Phone Mode

- BING™

Call Initia-

tion, Call

Manage-

ment, Pre-

formatted Voice Text

(6) APPS

ELECTRONICS

Voice Command Examples – Uconnect® 8.4A

GENERAL

Anytime

AM/FM

Satellite Band Control

Media Devices Control

(Functionality is dependent

on compatibility between

devises and radio)

Temperature Control

Destination Selection & View

“Go to Radio” (Media, Climate, Navigation, Phone,

Apps) – Settings, and Controls are not Voice Command

“Help” (to listen to suggested commands specific to

“Launch BING” – Required 1st voice command to

“BING Search” – Required 2nd voice command to

activate app functionality using Steering Wheel Voice

RADIO

“Tune to AM950”, “Tune to 95.5FM (preset 5)

“Tune to Satellite Channel 80's on 8”, Tune to Satellite

MEDIA

“Browse” (show) “artist” (albums, music)

“Show paired phones” (devices)

“Play song – Maple Leaf Rag” (artist - Scott Joplin,

genre - rock, album - Ragtime Favorites)

“Shuffle” – available with iPod

CLIMATE

“Set temperature to 70 degrees” – single climate zone

“Set driver” (passenger) “temperature to 75 degrees” –

NAVIGATION

“Enter address” (provide location inputs sequentially,

“Go Home” – destination previously defined by driver

“Repeat guidance” – hear the last navigation prompt

accessible

“Cancel”

current need

“Repeat”

launch BING™ app

Control Button

Channel 32 (preset 4)

, USB and SD Card

vehicles

dual climate zone vehicles

via audible radio prompts)

“Cancel Route”

“View Map”

Call Initiation (Requires that

phone has been Bluetooth

paired with radio

Call Management

Voice Texting (Available

during trial period or if

subscribed to Uconnect

Access Advantage)

Voice Text Reply (Radio

audibly recognizes these

18 pre-formatted SMS

messages as you speak)

BING™ (BING™ adds it's

own audible prompts,

and response time varies

depending on carrier

coverage speed)

ELECTRONICS

PHONE

“Italian restaurants” – for nearest specified POI category

“Dial 123-456-7890” (phone number)

“Call John Smith mobile” (home, office, other)

“Redial”

“Show outgoing” (recent) “calls”

“Search for John Smith” (any contact name in address

book)

“Show (display list) contacts”

Create a text message using Voice Command Capability

“Send a message to John Smith (123-456-7890)”

“Show Messages”

“Listen to” (view) “number 4”

“Forward text” (message) “to John Smith”

(phone type, number)

Forward one of 18 pre-formatted SMS messages to

incoming calls/text messages:

“Yes.”

“No.”

“Okay.”

“I can’t talk right now.”

“Call me.”

“I’ll call you later.”

“I’m on my way.”

“Thanks.”

“I’ll be late.”

“I will be <number> minutes late.”

“See you in <number> minutes”

“Stuck in traffic.”

“Start without me.”

“Where are you?”

“Are you there yet?”

“I need directions.”

“I’m lost.”

“See you later.”

APPS

“Launch BING” – Required 1st voice command to

launch BING™ app

“BING Search” – Required 2nd voice command to

activate app functionality using Steering Wheel Voice

Control Button

“Hotel” (restaurant, gas station, mail, hospital) – for

nearest desired general POI

“Hotels” (restaurants, hospitals, Starbucks) “in Miami”

(location) – specified distance POI

ELECTRONICS

Uconnect® 8.4AN

Uconnect® 8.4AN AT A GLANCE

Displaying the Time

Setting the Time

• Model 8.4AN synchronizes time automatically via GPS, so should not require any time adjustment. If you do need to set the time manually, follow the instructions below for Model 8.4A.

• For Model 8.4A, turn the unit on, then touch the time display at the top of the screen. Touch Yes.

ELECTRONICS

• If the time is not displayed at the top of the screen, touch Settings soft-key or the Apps soft-key and then the Settings soft-key. In the Settings screen, touch the Clock soft-key, then check or uncheck this option.

• Touch + or – next to Set Time Hours and Set Time Minutes to adjust the time.

• If these features are not available, uncheck the Sync with GPS box.

• Touch X to save your settings and exit out of the Clock Setting screen.

Audio Settings

• Touch of the Audio soft-key to activate the Audio settings screen to adjust Balance\Fade, Equalizer, and Speed Adjusted Volume.

• You can return to the Radio screen by touching the X located at the top right.

Balance/Fade

• Touch the Balance/Fade soft-key to Balance audio between the front speakers or fade the audio between the rear and front speakers.

• Touching the Front, Rear, Left, or Right soft-keys or touch and drag the blue Speaker Icon to adjust the Balance/Fade.

Equalizer

• Touch the Equalizer soft-key to activate the Equalizer screen.

Speed Adjusted Volume

ELECTRONICS

RADIO

• To access the Radio mode, touch the Radio soft-key at the lower left of the screen.

Selecting Radio Stations

• Touch the desired radio band (AM, FM or SXM) soft-key.

Seek Up/Seek Down

• Touch the Seek arrow soft-keys for less than two seconds to seek through radio stations.

• Touch and hold either arrow soft-key for more than two seconds to bypass stations without stopping. The radio will stop at the next listenable station once the arrow soft-key is released.

Direct Tune

• Tune directly to a radio station by pressing the “Tune” button on the screen, and entering the desired station number.

Store Radio Presets

• To set a station into memory press and hold the desired numbered soft-key for more than two seconds or until you hear a confirmation beep.

ELECTRONICS

HD Radio

• HD Radio technology (available on Uconnect 8.4AN) operates similar to conventional radio except it allows broadcasters to transmit a high-quality digital signal.

• With an HD radio receiver, the listener is provided with a clear sound that enhances the listening experience. HD radio can also transmit data such as song title or artist.

SiriusXM PREMIER OVER 160 CHANNELS

Get every channel available on your satellite radio, and enjoy all you want, all in one

• place. Hear commercial-free music plus sports, news, talk and entertainment. Get all the premium programming, including Howard Stern, every NFL game, Oprah Radio every MLB get 20+ Xtra channels, including SiriusXM Latino, a selection of channels dedicated to Spanish language programming.

• To access SiriusXM Satellite Radio, touch the SXM soft-key on the main Radio screen.

• The following describes features that are available when in SiriusXM Satellite Radio mode.

Seek Up/Seek Down

• Touch the Seek arrow soft-keys for less than two seconds to seek through channels in SXM mode.

• Touch and hold either arrow soft-key for more than two seconds to bypass channels without stopping. The radio will stop at the next listenable channel once the arrow soft-key is released.

Direct Tune

• Tune directly to a SXM channel by pressing the Tune soft-key on the screen, and entering the desired station number.

Jump

Fav

and NHL®game, every NASCAR®race, Martha Stewart and more. And

ELECTRONICS

SiriusXM Parental Controls

SiriusXM also offers the option to permanently block selected channels. Call

• (1-888-601-6297 for U.S. customers, 1-888-539-7474 for Canadian customers) and request the Family Package.

Browse

• Lets you browse the SiriusXM channel listing or Genre listing. Favorites, Game Zone, Weather and Jump settings also provide a way to browse the SiriusXM channel list.

Browse Sub-Menu

All Shows the channel listing. Genre Provides a list of all genres, and lets you jump to a channel within the

Presets Lets you scroll the list of Preset satellite channels. Touch the channel, or

Favorites Lets you manage artists and songs in the Favorites list and configure Alert

Game Zone Provides alerts when your favorite sports teams are starting a game which

Jump Lets you select your favorite cities for Traffic & Weather information,

Sub-Menu Description

selected genre.

press Enter on the Tune knob, to go to that channel. Touch the trash can icon to delete a preset. Your presets are also shown at the top of the main Satellite Radio screen.

Settings to let you know when favorite songs or artists are playing on other channels. Also, view a list of channels airing any of your Favorites.

is being aired on other SiriusXM channels, or when their game score is announced. You can select and manage your Teams list here, and configure alerts.

which is used by the Jump feature on the main satellite radio screen.

ELECTRONICS

Replay

• Lets you replay up to 44 minutes of the content of the current SiriusXM channel.

Replay Option

Play/Pause Touch to Pause content playback. Touch Pause/Play again to resume

Rewind/RW Rewinds the channel content in steps of 5 seconds. Touch and hold to

Fast Forward/FW

Replay Time Displays the amount of time in the upper center of the screen by which

Live Resumes playback of Live content at any time while replaying rewound

• SiriusXM services require subscriptions, sold separately after the 12-month trial

included with the new vehicle purchase. If you decide to continue your service at the

ment for complete terms at www.siriusxm.com. All fees and programming subject to change. Our satellite service is available only to those at least 18 and older in the 48 contiguous USA and D.C. Our Sirius satellite service is also available in Puerto Rico (with coverage limitations). Our Internet radio service is available throughout our satellite service area and in AK and HI. Visit www.sirius.com/ TravelLink for more information on SiriusXM Travel Link.© 2012 Sirius XM Radio Inc. Sirius, XM and all related marks and logos are trademarks of Sirius XM Radio Inc.

Option Description

playback.

rewind continuously, then release to begin playing content at that point. Forwards the content, and works similarly to Rewind/RW. However, Fast

Forward/FW can only be used when content has been previously rewound.

your content lags the Live channel.

content.

Disc Operation

• Your vehicle may have a remote CD player located in the lower center console storage bin, or in the lower center bench seat bin.

• CD/Disc Mode is entered by either inserting a CD/Disc or by touching the Media button located on the side of the display. Once in Media Mode, select Disc.

• Gently insert one CD into the CD player with the CD label facing as indicated on the illustration located on the Disc player.

Seek Up/Down Buttons

• Press to seek through Disc tracks.

• Hold either button to bypass tracks without stopping.

Browse

• Touch the browse soft-key to scroll through and select a desired track on the Disc. Touch the exit soft-key if you wish to cancel the browse function.

ELECTRONICS

MEDIA HUB – PLAYING iPod/USB/MP3 DEVICES

• There are many ways to play music from iPod

/MP3 players or USB devices

through your vehicle's sound system.

Audio Jack (AUX)

• The AUX allows a portable device, such as an MP3 player or an iPod

,tobe plugged into the radio and utilize the vehicle’s sound system, using a 3.5 mm audio cable, to amplify the source and play through the vehicle speakers.

• The functions of the portable device are controlled using the device buttons. The volume may be controlled using the radio or portable device.

• To route the audio cable out of the center console, use the access cut out in the front of the console.

USB Port

• Connect your iPod

• When connected, the iPod

/compatible USB device can be controlled using the radio or Steering Wheel Audio Controls to play, skip to the next or previous track, browse, and list the contents.

• The iPod

battery charges when plugged into the USB port (if supported by the

specific device).

• To route the USB/iPod

cable out of the center console, use the access cut out.

ELECTRONICS

NOTE:

When connecting your iPod

device for the first time, the system may take several minutes to read your music, depending on the number of files. For example, the system will take approximately five minutes for every 1000 songs loaded on the device. Also during the reading process, the Shuffle and Browse functions will be disabled. This process is needed to ensure the full use of your iPod

features and only happens the first time it is connected. After the first time, the reading process of your iPod

will take considerably less time unless changes are made or new songs

are added to the playlist.

• The USB port supports certain Mini, Classic, Nano, Touch, and iPhone

devices.

The USB port also supports playing music from compatible external USB Mass

Storage Class memory devices. Some iPod support the USB port features. Please visit Apple’s website for iPod

software versions may not fully

software

updates.

SD Card

• Play songs stored on an SD card inserted into the SD card slot.

• Song playback can be controlled using the radio or Steering Wheel Audio Controls

to play, skip to the next or previous track, browse, and list the contents.

Bluetooth® Streaming Audio

If equipped with Uconnect®Voice Command, your Bluetooth-equipped iPod

•

devices, cell phones or other media players, may also be able to stream music to your vehicle's sound system. Your connected device must be Bluetooth-compatible, and

paired with your system (see Uconnect access the music from your connected Bluetooth

Phone for pairing instructions). You can

device by touching the Bluetooth

soft-key while in Media mode.

Uconnect® 8.4A & 8.4AN Available Media Hubs

Uconnect

8.4A &

8.4AN

Media Hub (USB, AUX Ports)

- SSOO

Media Hub (SD, USB, AUX Ports)

Remote USB Port (Fully Functional)

Remote USB Port (Charging Only)

Dual Charging Ports

S = Standard Equipment

O = Optional Equipment

ELECTRONICS

iPod®/CD/AUX CONTROLS

•

The iPod®/CD/AUX controls are accessed by touching the desired soft-key displayed on the side of the screen and choosing between Disc, AUX, iPod Card.

NOTE:

Uconnect thing is first connected or inserted into the system.

NAVIGATION

• Touch the Nav soft-key in the menu bar to access the Navigation system.

will usually automatically switch to the appropriate mode when some-

, Bluetooth or SD

ELECTRONICS

Changing the Navigation Voice Prompt Volume

1. Touch the View Map soft-key from the Nav Main Menu.

With the map displayed, touch the Settings soft-key in the lower right area of the

2. screen.

3. In the Settings menu, touch the Guidance soft-key.

4. In the Guidance menu, adjust the Nav Volume by touching the + or – soft-keys.

Finding Points of Interest

• From the main Navigation menu, touch the Where To? soft-key, then touch the

Points of Interest soft-key.

• Select a Category and then a subcategory, if necessary.

• Select your destination and touch the Yes soft-key.

Finding a Place by Spelling the Name

• From the Main Navigation Menu touch the Where to? soft-key, touch the Points of

Interest soft-key, then touch the Spell Name soft-key.

• Enter the name of your destination.

• Touch the Done soft-key.

• Select your destination and touch the Yes soft-key.

Entering a Destination Address

• From the main Navigation menu touch the Where To? soft-key, then touch the

Address soft-key.

• Follow the on-screen prompts to enter the address and touch the Yes soft-key.

ELECTRONICS

NOTE:

Destination entry is not available while your vehicle is in motion. However, you can also use Voice Commands to enter an address while moving. Refer to Common Navigation Voice Commands in the Uconnect

Setting Your Home Location

• Touch the NAV soft-key in the menu bar to access the Navigation system and the Main Navigation menu.

• Touch the Where To? soft-key, then touch the Go Home soft-key.

• You may enter your address directly, use your current location as your home address, or choose from recently found locations.

• To delete your Home location (or other saved locations) so you can save a new Home location, touch the Where To? soft-key from the Main Navigation menu, then touch the Go Home soft-key, and in the Yes screen touch the Options soft-key. In the Options menu touch the Clear Home soft-key. Set a new Home location by following the previous instructions.

Go Home

• A Home location must be saved in the system. From the Main Navigation menu, touch the Where To? soft-key, then touch the Go Home soft-key.

Voice Command section.

• Your route is marked with a blue line on the map. If you depart from the original route, your route is recalculated. A speed limit icon could appear as you travel on major roadways.

ELECTRONICS

Adding a Stop

• To add a stop you must be navigating a route.

• Touch the Menu soft-key to return to the Main Navigation menu.

• Touch the desired selection and touch the Yes soft-key.

Taking a Detour

• To take a detour you must be navigating a route.

• Touch the Detour soft-key.

NOTE:

If the route you are currently taking is the only reasonable option, the device may not calculate a detour. For more information, see your Uconnect

SiriusXM TRAFFIC (US Market Only)

Don't drive through traffic. Drive around it.

• Avoid congestion before you reach it. By enhancing your vehicle's navigation system with the ability to see detailed traffic information, you can pinpoint traffic incidents, determine average traffic speed and estimate travel time along your route. Since the service is integrated with a vehicle's navigation system, SiriusXM Traffic can help drivers pick the fastest route based on traffic conditions.

1. Detailed information on traffic speed, accidents, construction, and road closings.

2. Traffic information from multiple sources, including police and emergency

services, cameras and road sensors.

3. Coast-to-coast delivery of traffic information.

4. View conditions for points along your route and beyond. Available in over

130 markets.

SiriusXM TRAVEL LINK (US Market Only)

• In addition to delivering over 130 channels of the best sports, entertainment, talk, and commercial-free music, SiriusXM offers premium data services that work in conjunction with compatible navigation systems. SiriusXM Travel Link brings a wealth of useful information into your vehicle and right to your fingertips.

• Weather -- Check variety of local and national weather information from radar maps to current and 5-day forecast.

• Fuel Prices -- Check local gas and diesel prices in your area and route to the station of your choice.

• Sports Scores -- In-game and final scores as well as weekly schedules.

• Movie Listings -- Check local movie theatres and listings in your area and route to the theater of your choice.

User's Manual.

ELECTRONICS

•

SiriusXM Travel Link feature is completely integrated into your vehicle. A few minutes after you start your vehicle, Travel Link information arrives and updates in the background. You can access the information whenever you like, with no waiting.

• To access SiriusXM Travel Link, touch Apps soft-key, then the SiriusXM Travel Link soft-key.

NOTE:

SiriusXM Travel Link requires a subscription, sold separately after the 1 year trial subscription included with your vehicle purchase.

• SiriusXM Travel Link is only available in the United States.

Fuel Prices

Movie Listings Sports Scores

Weather

Uconnect® Phone (Bluetooth® HANDS FREE CALLING)

• If the Uconnect the Uconnect

• The Uconnect tions system with Voice Command Capability (see Voice Command section).

• The Uconnect using simple voice commands or using screen soft-keys.

• Refer to the Understand The Features Of Your Vehicle section of your vehicle's Owner's Manual on the DVD for further details.

NOTE:

The Uconnect Hands-Free Profile, Version 1.0 or higher. For Uconnect®Customer Support: U.S. residents visit www.UconnectPhone.com or call 1–877–855–8400. Canadian Residents call, 1-800-465–2001 (English) or 1-800-387-9983 (French).

Pairing a Phone

• To use the Uconnect with the Uconnect

Start pairing procedure on the radio

• Touch the Phone soft-key and then the Settings soft-key. Next, touch Add Device.

• Uconnect connecting.

Check local gas and diesel prices in your area and route to the station of your choice.

Check local movie theatres and listings in your area and route to the theater of your choice.

In-game and final scores as well as weekly schedules.

Check variety of local and national weather information from radar maps to current and 5-day forecast.

Phone Button exists on your steering wheel, then you have

Phone features.

Phone is a voice-activated, hands-free, in-vehicle communica-

Phone allows you to dial a phone number with your mobile phone

Phone requires a mobile phone equipped with the Bluetooth

Phone feature, you must first pair your Bluetooth®phone

system.

Phone will display an “In progress” screen while the system is

ELECTRONICS

Start pairing procedure on mobile phone

• Search for available devices on your Bluetooth usually within Settings or Options under “Bluetooth”. See your mobile phone’s manual for details.

Complete the pairing procedure

• When prompted on the phone, enter the 4-digit PIN number shown on the Uconnect

Select the mobile phone's priority level

• You are now ready to make hands-free calls. Press the Uconnect your steering wheel to begin.

Making A Phone Call

• Press the Uconnect

• After the BEEP, say “dial” then the number (or “call” then the name as listed in your phone; see Phonebook).

NOTE:

You can also initiate a call by using the touch-screen on the Phone main screen.

Receiving A Call – Accept (And End)

• When an incoming call rings/is announced on Uconnect button

• To end a call, press the Phone button

Mute (Or Unmute) Microphone During Call

• During a call, touch the mute soft-key on the Phone main screen to mute and unmute the call.

Screen.

Phone button .

enabled mobile phone. This is

Phone button on

, press the Phone

ELECTRONICS

Transfer Ongoing Call Between Handset And Vehicle

• During an on-going call, touch the Transfer soft-key on the Phone main screen to transfer an on-going call between handset and vehicle.

Common Phone Commands (Examples)

• “Call John Smith”

• “Call John Smith mobile”

• “Dial 1 248 555 1212

• “Call Emergency”

• “Call Towing Assistance”

• “Redial”

Phonebook

• Your phonebook can be browsed on your radio screen, but editing can only be done on your phone. To browse, touch the Phone soft-key, then the Phonebook soft-key.

• Favorite phonebook entries can be saved as Favorites for quicker access. Favorites are shown at the top of your main phone screen.

radios will automatically download your phonebook from your paired

Voice Command Tips

• Using complete names (i.e; Call John Doe vs. Call John) will result in greater system accuracy.

You can “chain” commands together for faster results. Say “Call John Doe, mobile”,

• for example.

Changing The Volume

• Start a dialogue by pressing the Phone button example - "Help".

• Use the radio ON/OFF VOLUME rotary knob to adjust the volume to a comfortable level while the Uconnect Uconnect

is different than the audio system.

system is speaking. Please note the volume setting for

, then say a command for

ELECTRONICS

NOTE:

To access help, press the Uconnect say "help." Touch the display or push either

Phone button on the steering wheel and

or button and say "cancel"

to cancel the help session.

Voice Texting

• Uconnect

• Your mobile phone must support SMS over Bluetooth If the Uconnect messaging over Bluetooth

Phone can read or send new text messages on your mobile phone.

Phone determines your phone is not compatible with SMS

the “Messaging” button will be greyed out and the

in order to use this feature.

feature will not be available for use.

NOTE:

For mobile phone compatibility and pairing instructions, please visit www.UconnectPhone.com

• Uconnect

Phone SMS touch-screen input is only available when the vehicle is

not moving.

WARNING!

• In an emergency, to use Uconnect

• turned on,

• paired to Uconnect

Phone,

• and have network coverage.

Phone, your mobile phone must be:

ELECTRONICS

VOICE COMMAND QUICK REFERENCE

Uconnect® 8.4AN Voice Command Quick Reference

•

If the Uconnect®Voice Command button exists on your steering wheel, you have the Voice Command feature, which is optimized for the driver. The Voice Command feature lets you keep your hands on the wheel, and your eyes on the road.

NOTE:

All phone oriented voice commands are accessible by first pressing the Phone Pick Up Phone Hang Up serves the dual purpose of ending calls as well.

Voice Command (VR) User TIPs

• To hear available commands, press the Uconnect

• At any time, you can say the words “Cancel” or “Help”. These commands are

• You can interrupt the system prompts at any time by pressing the Uconnect

• You can ‘chain’ commands together for faster results. Say “Call Joe Doe mobile”,

• For best performance, adjust the rearview mirror to provide at least 1⁄2 in (1 cm)

• Always wait for the beep before speaking.

• Speak normally, without pausing, just as you would speak to a person sitting a few

• Make sure that no one other than you is speaking during a Voice Command period.

Steering Wheel Buttons

• You can control many of your radio features using your voice. Press either the VR

button, not the Voice Command button. To end a call, simply press the

say “Help”. You will hear available commands for the menu displayed.

universal and can be used from virtually any menu. All other specific commands can be used depending upon the active application.

Command button while the system is speaking. After the beep, you can say a command.

for example.

gap between the overhead console (if equipped) and the mirror.

feet/meters away from you.

or Phone Pick Up button on your steering wheel.

button, after the beep, say your command.

button. In some vehicles, the Phone Pickup button

Voice Command button and

Voice

Available Radio Soft–Key Voice Commands

Steering

Types of Voice Commands Available

Wheel Buttons to Press:

Uconnect Voice Command (VR) Button

Uconnect Phone Pick

Up Button

(1) Radio Mode

AM/FM & Satellite Brand Control

(2) Media Mode

Media Devices Control

----

(3) Climate Controls

Temperature Control

GENERAL

ELECTRONICS

(4) Navigation

Destination Selection and View

(5) Phone Mode

- BING™

Call Initia-

tion, Call

Manage-

ment, Pre-

formatted Voice Text

(6) APPS

ELECTRONICS

Voice Command Examples – Uconnect® 8.4AN

GENERAL

Anytime

AM/FM

Satellite Band Control

Media Devices Control

(Functionality is dependent

on compatibility between

devises and radio)

Temperature Control

Destination Selection & View

Call Initiation (Requires

that phone has been

Bluetooth

Call Management

with radio

paired

“Go to Radio” (Media, Climate, Navigation, Phone,

Apps) – Settings, and Controls are not Voice Command

“Help” (to listen to suggested commands specific to

“Launch BING™” – Required 1st voice command to

“BING™ Search” – Required 2nd voice command to

activate app functionality using Steering Wheel Voice

RADIO

“Tune to AM950”, “Tune to 95.5FM (preset 5)

“Tune to Satellite Channel 80's on 8”, Tune to Satellite

MEDIA

“Browse” (show) “artist” (albums, music)

“Show paired phones” (devices)

“Play song – Maple Leaf Rag” (artist - Scott Joplin,

genre - rock, album - Ragtime Favorites)

“Shuffle” – available with iPod, USB and SD Card

CLIMATE

“Set temperature to 70 degrees” – single climate zone

“Set driver” (passenger) “temperature to 75 degrees” –

NAVIGATION

“Enter address” (provide location inputs sequentially,

“Go Home” – destination previously defined by driver

“Repeat guidance” – hear the last navigation prompt

PHONE

“Dial 123-456-7890” (phone number)

“Call John Smith mobile” (home, office, other)

“Show outgoing” (recent) “calls”

“Search for John Smith” (any contact name in address

“Show (display list) contacts”

accessible

“Cancel”

current need

“Repeat”

launch BING™ app

Control Button

Channel 32 (preset 4)

vehicles

dual climate zone vehicles

via audible radio prompts)

“Cancel Route”

“View Map”

“Redial”

book)

Voice Texting (Available

during trial period or if

subscribed to Uconnect

Access Advantage)

Voice Text Reply (Radio

audibly recognizes these

18 pre-formatted SMS

messages as you speak)

SiriusXM Travel Link (Traffic

function is not voice com-

mand accessible within

SiriusXM Travel Link

BING™ (BING™ adds it's

own audible prompts,

and response time varies

depending on carrier

coverage speed)

ELECTRONICS

PHONE

Create a text message using Voice Command Capability

“Send a message to John Smith (123-456-7890)”

“Show Messages”

“Listen to” (view) “number 4”

“Forward text” (message) “to John Smith”

(phone type, number)

Forward one of 18 pre-formatted SMS messages to

incoming calls/text messages:

“Yes.”

“No.”

“Okay.”

“I can’t talk right now.”

“Call me.”

“I’ll call you later.”

“I’m on my way.”

“Thanks.”

“I’ll be late.”

“I will be <number> minutes late.”

“See you in <number> minutes”

“Stuck in traffic.”

“Start without me.”

“Where are you?”

“Are you there yet?”

“I need directions.”

“I’m lost.”

“See you later.”

APPS

“Show Fuel prices”

“Show Current Weather” – provides access to Forecast

as well

“Show Weather map” – multiple map formats available

“Show Sports”

“Show Movie listings”

“Show My favorites”

“Launch BING™” – Required 1st voice command to

launch BING™ app “BING™ Search” – Required 2nd voice command to activate app functionality using Steering Wheel Voice

Control Button

“Hotel” (restaurant, gas station, mail, hospital) – for

nearest desired general POI

“Italian restaurants” – for nearest specified POI category

“Hotels” (restaurants, hospitals, Starbucks) “in Miami”

(location) – specified distance POI

ELECTRONICS

STEERING WHEEL AUDIO CONTROLS

•

The steering wheel audio controls are located on the rear surface of the steering wheel.

Right Switch

•

Press the switch up or down to increase or decrease the volume.

•

Press the button in the center to change modes AM/FM/CD/SXM.

Left Switch

• Press the switch up or down to search for the next listenable station or select the next or previous CD track.

• Press the button in the center to select the next preset station (radio) or to change CDs if equipped with a CD Changer.

ELECTRONIC VEHICLE INFORMATION CENTER (EVIC)

•

The EVIC features a driver interactive display that is located in the instrument cluster. Pressing the controls on the left side of the steering wheel allows the driver to select vehicle information and Personal Settings. For additional information, refer to Programmable Features in this guide.

• Press and release the UP button to scroll upward through the main menus (Fuel Economy, Vehicle Info, Tire PSI, Cruise, Messages, Trip Info, Vehicle Speed and Turn Menu Off) and sub menus.

• Press and release the DOWN menus and sub menus.

Press and release the RIGHT button for access to main menus, sub menus or to

• select a personal setting in the setup menu. Press and hold the RIGHT two seconds to reset features.

• Press the BACK/LEFT button to scroll back to a previous menu or sub menu.

button to scroll downward through the main

button for

RAM Chassis Cab 3500 2013, Chassis Cab 4500 2013, Chassis Cab 5500 2013 User's Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

TABLE OF CONTENTS

INTRODUCTION/WELCOME

WELCOME FROM CHRYSLER GROUP LLC

VEHICLES SOLD IN CANADA

USE OF AFTERMARKET PRODUCTS (ELECTRONICS)

CONTROLS AT A GLANCE

DRIVER COCKPIT

INSTRUMENT CLUSTER

Warning Lights

GETTING STARTED

KEY FOB

Locking And Unlocking The Doors

Panic Alarm

Emergency Key

KEYLESS ENTER-N-GO™

To Unlock From The Driver or Passenger Side:

To Lock The Vehicle’s Doors

Engine Starting/Stopping

REMOTE START

THEFT ALARM

To Arm:

To Disarm:

SEAT BELT

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) — AIR BAGS

CHILD RESTRAINTS

Installing The LATCH - Compatible Child Restraint System

Installing The Child Restraint Using The Vehicle Seat Belts

FRONT SEATS

Power Seats

Power Lumbar

Memory Seat

Manual Seats

HEATED/VENTILATED SEATS

Front Heated Seats

Front Ventilated Seats

REAR HEATED SEATS

HEATED STEERING WHEEL

TILT STEERING COLUMN

ADJUSTABLE PEDALS

OPERATING YOUR VEHICLE

ENGINE BREAK-IN RECOMMENDATIONS

DIESEL ENGINE BREAK-IN RECOMMENDATIONS

TURN SIGNALS/WIPER/WASHER/HIGH BEAMS LEVER

Turn Signals/Lane Change Assist

Wipers

High Beams

HEADLIGHT SWITCH

Automatic Headlights/Parking Lights/Headlights

SmartBeams™

Instrument Panel Dimmer

Cargo Light

SPEED CONTROL

Cruise ON/OFF

Accel/Decel

Resume

Cancel

ELECTRONIC RANGE SELECT (ERS) OPERATION

MANUAL CLIMATE CONTROLS WITHOUT TOUCH-SCREEN

Air Recirculation /Max A/C

Heated Mirrors

MANUAL CLIMATE CONTROLS WITH TOUCH-SCREEN

Air Recirculation

Heated Mirrors

AUTOMATIC CLIMATE CONTROLS WITH TOUCH-SCREEN

Air Conditioning (A/C)

SYNC Temperature Soft-Key

Air Recirculation

Heated Mirrors

POWER SLIDING REAR WINDOW

WIND BUFFETING

ELECTRONICS

YOUR VEHICLE'S SOUND SYSTEM

IDENTIFYING YOUR RADIO

Uconnect® Access (AVAILABLE ON Uconnect® 8.4A AND Uconnect® 8.4AN) (IF EQUIPPED)

Uconnect® Access Registration

Download the Uconnect® Access App
